FSP Technology Proline 3/1 Series User manual

FSP Proline 3/1
3/1 10K~30K Online UPS
Uninterruptible Power Supply System
Version: 1.6
User M nu l

4
2. Inst ll tion nd Oper tion
There are two different types of online UPS: standard and long-run models. Please refer to the following
model table.
Model Type Model Type
10K
Standard
model
10KL
Long-run
model
15K 15KL
20K 20KL
30K 30KL
We also offer optional parallel function for these two types by request. The UPS with parallel function is
called as “Parallel model”. We have described detailed installation and operation of Parallel Model in the
following chapter.
2-1. Unp cking nd Inspection
Unpack the package and check the package contents. The shipping package contains:
● One UPS
● One user manual
● One monitoring software CD
● One RS-232 cable (option)
● One USB cable
● One parallel cable (only available for parallel model)
● One share current cable (only available for parallel model)
● One battery cable (only available for 10KL)
NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged
during transportation. Do not turn on the unit and notify the carrier and dealer immediately if there is any
damage or lacking of some parts. Please keep the original package in a safe place for future use.
2-2. Re r P nel View
Di gr m1: 10K/10KL Re r P nel Di gr m 2: 15KL/20KL Re r P nel

5
Di gr m 3: 15K/20K Re r P nel Di gr m 5 :15KL/20KL Input/Output
Termin l
Di gr m 6: 15K/20K Input/Output Termin l Di gr m 7: 15K/20K Grounding
Termin l
Di gr m 4: 10K/10KL Input/Output
Termin l

6
Di gr m 8: 30KL re r p nel Di gr m 9: 30K re r p nel
Di gr m 10: 30K(L) input/output termin l

7
Di gr m 11: 10KR(L) Re r P nel Di gr m 12:10KR(L) Input/
Output Termin l
Di gr m 13: 15KR(L)/20KR(L) Re r P nel Di gr m 14: 15KR(L)/20K(L)
Input/Output Termin l
Di gr m 15: B ttery p ck re r p nel
1. RS-232 communication port
2. USB communication port
3. Emergency power off function connector (EPO connector)
4. Share current port (only available for parallel model)
5. Parallel port (only available for parallel model)
. Intelligent slot
7. Maintenance bypass switch
8. External maintenance bypass switch port
9. Line input circuit breaker
10. Output circuit breaker for receptacles
11. Output receptacles: connect to mission-critical loads
12. Input/Output terminal (Refer to Diagram 4, 5, , 7,10, 12 and 14 for the details)
13. Output terminal: connect to mission-critical loads
14. Programmable output terminal: connect to non-critical loads

8
15. External battery connector/terminal (only available for Long-run model)
1 . Utility input terminal
17. Grounding terminal
18. Battery pack output circuit breaker
19. Bypass input circuit breaker
2-3. Single UPS Inst ll tion
Installation and wiring must be performed in accordance with the local electric laws/regulations and execute
the following instructions by professional personnel.
1) Make sure the mains wire and breakers in the building are enough for the rated capacity of UPS to
avoid the hazards of electric shock or fire.
NOTE: Do not use the wall receptacle as the input power source for the UPS, as its rated current is less than
the UPS’s maximum input current. Otherwise the receptacle may be burned and destroyed.
2) Switch off the mains switch in the building before installation.
3) Turn off all the connected devices before connecting to the UPS.
4) Prepare wires based on the following table:
Model Wiring spec (AWG)
Input Output Battery Ground
10K 8 8 8
10KL 8 8 8 8
15K
15KL
20K
20KL
30K 4 4 4
30KL 4 4 4 4
NOTE 1: The cable for 10K/10KL should be able to withstand over 3A current. It is recommended to
use 8AWG or thicker wire for safety and efficiency.
NOTE 2: The cable for 15K/15KL should be able to withstand over 75A current. It is recommended to
use AWG or thicker wire for safety and efficiency.
NOTE 3: The cable for 20K/20KL should be able to withstand over 100A current. It is recommended to
use AWG or thicker wire for safety and efficiency.
NOTE 4: The cable for 30K/30KL should be able to withstand over 140A current. It is recommended to
use 4AWG or thicker wire for safety and efficiency.
NOTE 5: The selections for color of wires should be followed by the local electrical laws and
regulations.
5) Remove the terminal block cover on the rear panel of UPS. Then connect the wires according to the
following terminal block diagrams: (Connect the earth wire first when making wire connection. Disconnect
the earth wire last when making wire disconnection!)

9
Terminal Block wiring diagram of 10K/10KL
Terminal Block wiring diagram of 15KL/20KL
Terminal Block wiring diagram of 15K/20K

10
Terminal Block wiring diagram of 30K(L)
Terminal Block wiring diagram of 10KR/10KRL
Terminal Block wiring diagram of 15KR(L)/20KR(L)
NOTE 1: Make sure that the wires are connected tightly with the terminals.
NOTE 2: There are two kinds of outputs: output terminal/outlets and programmable terminal. Please
connect non-critical devices to the programmable terminal and critical devices to the output terminal/outlets.
During power failure, you may extend the backup time to critical devices by setting shorter backup time for
non-critical devices.
NOTE 3: Please install the output breaker between the output terminal and the load, and the breaker
should be qualified with leakage current protective function if necessary.
) Put the terminal block cover back to the rear panel of the UPS.

11
W rning: (Only for standard model)
● Make sure the UPS is not turned on before installation. The UPS should not be turned on during wiring
connection.
● Do not try to modify the standard model to the long-run model. Particularly, do not try to connect the
standard internal battery to the external battery. The battery type and voltage may be different. If you
connect them together, it maybe causes the hazard of electric shock or fire!
W rning: (Only for long-run model)
● Make sure a DC breaker or other protection device between UPS and external battery pack is installed. If
not, please install it carefully. Switch off the battery breaker before installation.
NOTE: Set the battery pack breaker in “OFF” position and then install the battery pack.
● Pay highly attention to the rated battery voltage marked on the rear panel. If you want to change the
numbers of the battery pack, please make sure you modify the setting simultaneously. The connection
with wrong battery voltage may cause permanent damage of the UPS. Make sure the voltage of the
battery pack is correct.
● Pay highly attention to the polarity marking on external battery terminal block, and make sure the
correct battery polarity is connected. Wrong connection may cause permanent damage of the UPS.
● Make sure the protective earth ground wiring is correct. The wire current spec, color, position,
connection and conductance reliability should be checked carefully.
● Make sure the utility input & output wiring is correct. The wire current spec, color, position, connection
and conductance reliability should be checked carefully. Make sure the L/N site is correct, not reverse
and short-circuited.
● Before turning on the UPS, be sure the breaker of the battery pack is on.
● UPS will alert while the external battery breaker is not on. If so, turn on the external battery breaker and
press “test” button on the UPS to release the audible alert.
2-4. UPS Inst ll tion for P r llel System
If the UPS is only available for single operation, you may skip this section to the next.
1) Install and wires the UPSs according to the section 2-3.
2) Connect the output wires of each UPS to an output breaker.
3) Connect all output breakers to a major output breaker. Then this major output breaker will directly
connect to the loads.
4) Each UPS is connected to an independent battery pack.
NOTE: The parallel system can not use one battery pack. Otherwise, it will cause system permanent failure.
5) Refer to the following wiring diagram:

12
Wiring diagram of parallel system for 10K/10KL

13
Wiring diagram of parallel system for 15K(L)/20K(L)

14
Wiring diagram of parallel system for 30K

15
Wiring diagram of parallel system for 10KR/10KRL
Wiring diagram of parallel system for 15KR(L)/20KR(L)
Share current
cable con
nection
Parallel
communica
tion
portconnection
Share current cable connection
Parallel communication port
connection

44
6. Specific tions
MODEL 10K 10KL 15K 15KL 20K 20KL 30K 30KL
CAPACITY* 10000VA / 8000W 15000VA / 12000W 20000VA / 1 000W 30000VA / 24000W
INPUT
Voltage
Range
Low Line Loss 110 VAC(L-N) ± 3 % at 50% Load
17 VAC(L-N) ± 3 % at 100% Load
Low Line Comeback Low Line Loss Voltage + 10V
High Line Loss 300 VAC(L-N) ± 3 % at 50% Load
27 VAC(L-N) ± 3 % at 100% Load
High Line Comeback High Line Loss Voltage - 10V
Frequency Range 4 Hz ~ 54 Hz @ 50Hz system
5 Hz ~ 4 Hz @ 0Hz system
Phase Three phase with ground
Power Factor ≧
0.9
9 at 100% Load
OUTPUT
Output voltage 208/220/230/240VAC
AC Voltage Regulation ± 1%
Frequency Range
(Synchronized Range)
4 Hz ~ 54 Hz @ 50Hz system
5 Hz ~ 4 Hz @ 0Hz system
Frequency Range (Batt. Mode) 50 Hz ± 0.1 Hz or 0Hz ± 0.1 Hz
Overload
AC mode
100%~110%: 10min
110%~130%: 1min
>130% : 1sec
Battery mode
100%~110%: 30sec
110%~130%: 10sec
>130% : 1sec
Current Crest Ratio 3:1 max
Harmonic Distortion ≦
2
%
@ 100%
Linear Load;
≦
5
%
@ 100%
Non
-
linear Load
Transfer
Time
Line Battery 0 ms
Inverter Bypass 0 ms
Inverter ECO <10 ms
EFFICIENCY
AC mode > 89% >89% >89% >90%
Battery Mode > 8 % >88% >87% >88%
BATTERY
Standard
Model
Type 12 V / 9 Ah 12 V / 9 Ah 12 V / 9 Ah
Numbers 20
(18-20 adjustable)
2 x 20
(18-20 adjustable)
2 x 20
(18-20 adjustable)
3 x 20
(18-20 adjustable)
Recharge Time 9 hours recover to 90% capacity
Charging Current 1.0 A ± 10% (max.) 2.0 A ± 10% (max.) 2.0 A ± 10% (max.) 4.0 A ± 10% (max.)
Charging Voltage 273 V ± 1% (Based on 20pcs batteries)
Long-run
Model
Type Depending on applications
Numbers 18 - 20
Charging Current 4.0 A ± 10% (max.) 8.0 A ± 10% (max.) 8.0 A ± 10% (max.)
12.0 A ± 10%
(max.)
Charging Voltage 273 V ± 1% (Based on 20pcs batteries)
PHYSICAL
Dimension, D X W X H mm 592X250X57 815X250
X82
592X250
X57
815X250
X82
592X250
X57
815 X 300
X 1000
815X250
X 82
Net Weight (kgs) 83 28 1 4 40 1 4 40 234 4
ENVIRONMENT
Operation Temperature 0 ~ 40°C (the battery life will down when > 25°C)
Operation Humidity <95 % and non-condensing
Operation Altitude** <1000m
Acoustic Noise Level Less than 58
dB @ 1
Meter Less than 0dB @ 1 Meter Less than
5dB @ 1
Meter
MANAGEMENT
Smart RS-232 or USB Supports Windows® 2000/2003/XP/Vista/2008/7/8, Linux, Unix and MAC
Optional SNMP Power management from SNMP manager and web browser
* Derate capacity to 0% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
**If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be derated one percent per 100m.
***Product specifications are subject to change without further notice.

45
MODEL 10KR(L) 15KR(L) 20KR(L)
CAPACITY* 10000VA / 8000W 15000VA / 12000W 20000VA / 1 000W
INPUT
Voltage
Range
Low Line Loss 110 VAC(L-N) ± 3 % at 50% Load
17 VAC(L-N) ± 3 % at 100% Load
Low Line Comeback Low Line Loss Voltage + 10V
High Line Loss 300 VAC(L-N) ± 3 % at 50% Load
27 VAC(L-N) ± 3 % at 100% Load
High Line Comeback High Line Loss Voltage - 10V
Frequency Range 4 Hz ~ 54 Hz @ 50Hz system
5 Hz ~ 4 Hz @ 0Hz system
Phase Three phase with ground
Power Factor ≧ 0.99 at 100% Load
OUTPUT
Output voltage 208/220/230/240VAC
AC Voltage Regulation ± 1%
Frequency Range
(Synchronized Range)
4 Hz ~ 54 Hz @ 50Hz system
5 Hz ~ 4 Hz @ 0Hz system
Frequency Range (Batt. Mode) 50 Hz ± 0.1 Hz or 0Hz ± 0.1 Hz
Overload
AC mode
100%~110%: 10min
110%~130%: 1min
>130% : 1sec
Battery mode
100%~110%: 30sec
110%~130%: 10sec
>130% : 1sec
Current Crest Ratio 3:1 max
Harmonic Distortion ≦ 2 % @ 100% Linear Load; ≦ 5 % @ 100% Non-linear Load
Transfer
Time
Line Battery 0 ms
Inverter Bypass 0 ms
Inverter ECO <10 ms
EFFICIENCY
AC mode > 89% >89% >89%
Battery Mode > 8 % >88% >87%
BATTERY
Standard
Model
Type 12 V /9 Ah 12 V / 9 Ah 12 V / 9 Ah
Numbers 20
(18-20 adjustable)
2 x 20
(18-20 adjustable)
2 x 20
(18-20 adjustable)
Recharge Time 9 hours recover to 90% capacity
Charging Current 1.0 A ± 10% (max.) 2.0 A ± 10% (max.) 2.0 A ± 10% (max.)
Charging Voltage 273 V ± 1% (Based on 20pcs batteries)
Long-run
Model
Type Depending on applications
Numbers 18 - 20
Charging Current 4.0 A ± 10% (max.) 4.0 A ± 10% (max.) 4.0 A ± 10% (max.)
Charging Voltage 273 V ± 1% (Based on 20pcs batteries)
PHYSICAL
Standard
Model
Dimension,
D X W X H
UPS: 8 x 438 x 133[3U]
Battery pack: 580 x 438 x
133[3U]
UPS: 8 x 438 x 2 [ U]
Battery pack : 580 x 438 x 133[3U] x 2 pcs
Net Weight (kgs) UPS: 22
Battery pack: 3
UPS: 45
Battery pack: 3 x 2 pcs
Long-run
Model
Dimension, D X W X H
8 x 438 x 133[3U] 8 x 438 x 2 [ U]
Net Weight (kgs) 22 45
ENVIRONMENT
Operation Temperature 0 ~ 40°C (the battery life will down when > 25°C)
Operation Humidity <95 % and non-condensing
Operation Altitude** <1000m
Acoustic Noise Level Less than 58dB @ 1 Meter Less than 0dB @ 1 Meter
MANAGEMENT
Smart RS-232 or USB Supports Windows® 2000/2003/XP/Vista/2008/7/8, Linux, Unix and MAC
Optional SNMP Power management from SNMP manager and web browser
* Derate capacity to 90% when the output voltage is adjusted to 208VAC.
**If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be derated one percent per 100m.
***Product specifications are subject to change without further notice.
