Fudakang Earmo User manual

In order to guarantee a safe and proper operation,
please read the instruction and safekeep it for future
reference.
Thank you for purchasing Earmo.

Menu
1 Product Introduction
3 Product Identification
5 Battery Installation
4 Inventory of Parts
6 Operating Instruction
7 Care and Maintenance
8 Troubleshooting
9 Technical Specification
10 Warranty
11 Disclaimer
12 Copyright Statement
13 Certificate
2 Notice
1
3
5
4
6
10
11
12
13
14
15
16
2

1. Product Introduction
1
Thank you for choosing Earmo.
Ergonomic design makes it easy to use. The reading of
Earmo is based on operation principle of medical digital
thermometer. It’s convenient and hygienic. Simply follow
the instruction to take temperature properly.
Earmo is designed to measure ear temperature.
Fast: It only takes 1-2 seconds to get an accurate
temperature reading.
Earmo itself can store 300 sets of temperature data and
display 5 sets, while all data can be securely stored in
the Cloud.
Temperature unit can be switched between °C and °F
No probe cover needed makes it convenient and
low-cost during usage.
When disinfecting, apply alcohol pad on the waterproof
probe to clean it. (Don’t dip the probe in water)
Earmo is energy saving. It automatically hibernates after
20 seconds.
1.
2.
3.
4.
5.
6.
7.
8.
Earmo has features as below:

Self-judgment can be dangerous. Please consult a
doctor for professional advice.
Any measuring outcomes of Earmo can only be used as
references. If you have any questions regarding the
outcomes, please consult a doctor for more information.
Please keep batteries and probe protector away from
babies. If caused accidents, please consult a doctor
immediately.
Please do not throw batteries into fire in case of
explosion.
1.
2.
3.
4.
People who have otitis externa, otitis media and other types
of ear diseases are prohibited to use this product.
Warning | Indicates it might cause danger if used in a
wrong way.
Prohibited | Indicates situations that are not allowed
to use.
2 Notice
Warnings:
Prohibited:
2

This infrared ear thermometer is constituted of thermopile
sensor, LED screen, circuit module, button, ABS plastic shell
and probe protector.
3 Product Identification
Button
LED screen
Touch Area
Thermopile sensor
Probe protector
ABS plastic shell
Circuit module
3

Please check the parts in package. Including: 1 Earmo, 1
probe protector, 2 AAA batteries and instruction.
If it comes short of any part, please contact customer
service.
4 Inventory of Parts
Probe protector Earmo Batteries
Instruction
4

1. Gently press the lid and push it down, and take the lid off.
2. Insert 2 AAA batteries in the battery cell as indicated.
3. Place the lid back.
Battery power warning: If battery icon flickers when turn on
Earmo, it means battery power is low and needs to be
replaced. Low battery power may cause inaccurate readings.
It is recommend to remove the batteries if Earmo will not
be used for any extended period of time.
Please follow local rules of battery disposal to dispose
used batteries properly.
1.
2.
Kindly reminder
5 Battery Installation
5

Note: Temperature unit can only be changed in Earmo
App after set.
!
6 Operation Instruction
Set temperature unit
1
Step 1. Press the button to turn on Earmo.
Step 2. Swipe left and right on the surface to choose temperature unit.
Step 3. Press the button again to set temperature unit.
6

Measure temperature
2
Step 1. Gently pull the ear back to make ear canal straight,
which helps to improve the accuracy of measurement.
7
Step 2. Insert Earmo into ear canal, and press the button to
measure.

Step 3. Measurement is done after a sound of beep, and
the result will be instantly shown on the LED screen.
Step 4. You can swipe up and down to see previous
temperature readings.
8

Connect with Earmo app
3
Step 1. Download Earmo app at Apple Store or Google Play.
Step 2. Turn on Bluetooth and keep Earmo closed to your
phone. Follow the instruction on the app to connect.
9

7 Care and Maintenance
Probe: In order to prevent infection, please apply alcohol
pad on the waterproof probe after single use. (Don’t dip
the probe in water)
If need to take another temperature after cleaning with
alcohol pad, please wait for 5 minutes.
Body of Earmo: Please use paper towel or dry cloth to
gently wipe it. Avoid washing it by water.
Kindly reminder
Why cleaning after single use is necessary?
Due to infrared measuring method aims to measure the
temperature of object, earwax and other filthy objects not
only affect the accuracy, but also cause infection. So it is
recommended to clean the probe after each use.
1.
2.
3.
10

11
8 Troubleshooting
LED screen shows LO if temperature reading is below 89.6°F.
LED screen shows HI if temperature reading is above 109.2°F.
It shows ERR if the operation condition is beyond 60.8°F-104°F.
Solutions of LO or HI reading:
Make sure Earmo is operated under proper instruction.
The reading LOW might due to probe is not firmly inserted
into ear canal. Please insert firmly during the next
measurement.
The reading LOW might due to probe covered by filthy
objects. Please use alcohol pad to wipe it.
Solutions of HIGH reading:
Please use Earmo when the surrounding temperature is
between 59°F to 95°F.

12
Name
Earmo - Infrared ear
thermometer
Transmission distance
Up to 33ft
Range
89.6°F - 109.2°F
Accuracy
±0.4°F (95.0°F - 107.6°F)
±0.6°F (other ranges)
Storage condition
-8°F - 131°F with ≤85%RH
Battery
2 AAA batteries
Battery life
2 years / 1000 times of
measurement
Model
FT-F21
Size
5.3*1.7*1.9 inch
Weight
0.13 lb (battery excluded)
Operation condition
60.8°F – 104°F
System requirements
iOS: iPhone 5 or above with
version at least iOS 8.0, iPhone
4/4s excluded.
Android: 4.3 or above and
supports Bluetooth 4.0/4.1
9 Technical Specification

Product model: Remark:
Purchase data: Point of sales:
Note
• 1-year warranty (from date of purchase) is included under
proper usage.
• Warranty doesn’t cover parts other than Earmo itself.
• Under these circumstances, repair will be charged.
• Warranty expired.
• Warranty card not shown to seller.
• Vague information on warranty card.
Warranty does not cover
• Product surface damage
• Battery
• Damages caused by improper using habit
• Improper inspection and maintenance
• Other irresistible reasons.
10 Warranty
13

This manual is written in accordance with available
information and contents are subject to change without
notice. Bongmi has made the best effort to garantee the
manual’s accuracy and relability. However, the company
does not assume liability for loss or damage caused by
omissions, inaccuracies or typographical errors in this
manual.
If there are discrepancies in this manual due to software
upgrades, instructions and function dictated by the
software.
11 Disclaimer
14

Fudakang Industrial Co,. LTD.
Infrared ear thermomerer
Model: FT-F21
Date of inspection:
Date of manufacture:
Distributor: BONGMI Inc.
13 Certificate
16

Distributor: Bongmi Inc.
Address: F12, 92 Yueda St., Binjiang District, Hangzhou,
Zhejiang, China
Website: www.bongmi.com
Phone: [phone]
Manufacturer Information

Infrared Ear Thermometer Instruction
Model : FT-F21
Earmo

BONGMI INC. reserves all rights, and retains the final right
to interpret and revise this handbook and the statements
contained therein. Copy right of this manual belongs to
BONGMI INC. Without prior written permission, no
company or individual is allowed to reproduce, copy or
translate this manual or any information contained therein.
BONGMI INC.
San Francisco, CA 94118
12 Copyright Statement
15
