Fudakang 481109 User manual

1
Instructions for Use
Talking Infrared Thermometer (Non contact)
Model 481109
DESCRIPTION
1. Table of Contents
2. Product Overview
3. Outline Drawing
4. The Definition of Symbols
5. Measuring
6. Battery Voltage Display & Replacement
7. Operation Precautions
8. Precaution for Measuring Temperature
9. Product Specification
10. Common question concerning forehead temperature

2
2. Product Overview
This infrared thermometer can get quick and accurate temperature reading data, with the
following advantages:
1). Easy to clean sensor
2). Fast & accurate
3). Convenient
4). 32 memories
5). Last memorized temperature display when you turn on the power.
3. Outline Drawing
4. The Definition of Symbols
(Blue squeeze trigger on front;
Turns unit on.)
(Blue slide cover on bottom)

3
5. MODE SETTINGS
BODY/AMBIENT setting
This IR thermometer has 2 measuring modes: Surface Temperature and Body
Temperature. It may arrive in the Surface mode. In order to use it for body temperature,
switch to Body mode.
Turn the unit on. Press button (the bottom center button with the icons of a head
andahouse)to switchbetweenBODYandSURFACETEMP(ambient)measuringmodes.
Fahrenheit or Celsius temperature setting
Turn the unit on. To switch between Fahrenheit and Celsius, press (Set) button
once. The unit does not speak or beep during this change. The temperature setting (C
or F) is displayed in the upper right hand corner of the display screen.
Voice Toggle On or Off
Turn the unit on. To turn the voice on and off, press and hold (Set) button for 5
seconds till “ON” displays. Press SET button again to toggle between ON and OFF.
This will turn the voice on and off. The voice status is shown by the alarm icon in the
bottom right corner of the display screen.
Change Between English or Spanish
Turn the unit on. Press and hold (Set) button for 8 seconds. The unit will display
ON (or OFF) for the Voice setting, but continue to hold Set. After 8 seconds, unit will
display 01 or 02. Press (Set) again to toggle between 01 for English and 02 for
Spanish. (Voices 03 through 06 are not active.)
Back light, laser selection
Press (light bulb/sunshine) button to toggle between the following functions in this
order: back light on, laser on, back light off, laser off. When you see (triangle) on
the LCD, it means the laser will be on once you use the device . When the backlight or
laser setting is enabled, it will come on every time the unit is turned on.
Memory recall
With the unit on, press (Memory) button to viewrecent measurements. Each push
of M will scroll through recent measurements. Memory results are only visual and are
not spoken. The memory capacity is 32 results。
6. Measuring
Install 2 AA batteries (not included.)
Push and slide the blue battery cover forward to open the battery compartment.
Insert 2 batteries. The positive end is closest to the cover hinge; the negative end is
furthest away from the hinge.
After inserting new batteries, wait 10 minutes for the unit to warm up.
Turn on the unit by squeezing the blue scan button on the front of the handle. The unit
will take a measurement as soon as it is turned on
If the mode is “BODY” last time you used, the LCD will display “Lo”; if the mode is
“SURFACE TEMP” last time you used, the LCD will show the ambient room temperature
Make sure the temperature mode is set to BODY when taking a body temperature
If the device is not used for a long time, when you turn on it again the device will check
the room temperature first and delay tuning on for 1~2 seconds.

4
Point the sensor 2” - 4” away from the forehead and pull the blue scan button. The
results will be spoken after 3 beeps. Make sure there is no perspiration, cosmetics or
hat on the forehead. When there is sweat on forehead, you can measure behind the ear
lobe, making sure no hair, clothing or other things cover the ear.
Memory recall: Press “M” button to visually recall recent
results.
Battery replacement: When the LCD shows the low battery symbol it means
you must install new batteries.
Remove the battery compartment cover and put 2AA (1.5 volt) batteries, paying
attention to the polarity
7. Operation Precautions
1) 2 AA batteries must be inserted when using the device for the first time
2) Please keep the probe clean after you used the IR Thermometer.
3) Please keep the IR Thermometer dry and never immerse it in water or any liquid.
4) Do not keep the IR Thermometer in a high temperature environment for a long time
and keep away from sunlight, dust and dirt.
5) Keep the IR Thermometer away from sharp objects
6) Do not touch the tip of probe with your finger.
7) Do not disassemble the IR Thermometer.
8) Do not use the IR Thermometer if you suffer from skin problems
9) Please take your temperature when you are relaxed and never take your temperature
after exercise or a bath. Rest at least 30 minutes afterward.
10) Under the following conditions, we recommend you take your temperature
at least three times and use the highest reading.
* Infants under three months old.
* Children under three years old who have a compromised immune system.
* This is your first time using the IR thermometer. Practice until you get accurate
and consistent reading.
11) Use a clean cloth with 70-90% Isopropyl alcohol to clean up before or after use.

5
Note:
1.Any solutions, dilution and cleaning method other than mentioned above might cause
reliability problems with the Infrared thermometer.
2.Contraindications for the following: placing the thermometer probe on scarred tissue
or tissue compromised by skin disorders; patients in trauma;
Patients treated with certain skin’s inflammatory drugs; and placing the thermometer
probe on skin exposed to direct sunlight, fireplace heat, cold compress therapies, air
conditioner flow, etc.
3. Do not service the unit while the device is in use.
4.The patient is an intended operator. The patient can measure, transmit data under normal
circumstances and maintain the device and its accessories according to the user manual.
5. Please remove the batteries if it is not in use for a long time (More than 3 months).
6. Not intended to be sterilized. Not for use in an OXYGEN RICH ENVIRONMENT
7. Before every use, check the device. Do not use the device if it is damaged in any way.
The continuous use of a damaged unit may cause injury, improper results, or serious
danger.
8. No modification of this device is allowed.
8. Precaution for Measuring Temperature
Abnormality Meaning
Measured result is over 105°F
(Body measuring mode)
Measured result is below 93.0°F
(Body measuring mode)
The ambient temperature is beyond the range for proper
working temperature of 40°F – 104°F
9. Specifications
Model No.
FT-F41
Measuring Range
Forehead 34.0℃-43.0℃( 93.2℉-109.4℉)
Surface 0.0℃-100.0℃( 32.0℉-212.0℉)
Measuring time
minimum measuring time is 2 seconds; and minimum time between
measurements for the same site is 2 seconds
Accuracy
±0.2℃/0.4℉34.0℃-34.9℃(93.2℉- 94.82℉)
±0.2
℃
/0.4
℉
35.0
℃
-42.0
℃
(95.0
℉
-107.6
℉
)
±0.2℃/0.4℉42.1℃-43.0℃(107.78℉-109.4℉)
Resolution
0.1℃/0.2℉
Operation Condition
10.0℃-40.0℃(50.0℉- 104.0℉)
Rh≤80%
Pressure: 86~106 kPa
Storage Condition
-25.0℃-55.0℃(-13.0℉- 131.0℉)
Rh≤95%
Pressure: 86~106 kPa
Battery type and battery life
AA 2pcs
The typical service life of new and unused batteries is 300 measurements
Protection against electric
shock Internally powered ME equipment

6
Protection against electric
shock Type BF
IP classification
IP22 (IP22: The first number 2: Protected against access to hazardous
parts with a finger, and the jointed test finger of 12 mm Ф, 80 mm length,
shall have adequate clearance from hazardous parts .And protected
against solid foreign objects of 12,5 mm Ф and greater. The second
number: Protected against vertically falling water drops when enclosure
titled up to 15º. Vertically falling drops shall have no harmful effects when
the enclosure is titled at any angle up to 15’’on either side of the vertical.
Mode of operation Continuous operation
Size (body)
L145*W37*H98mm
Weight（including battery）6.5 ounces (180g)
Measuring Distance
2” – 4” (5-10CM)
Contents
-infrared thermometer
-Instruction Manual
10. Common questions concerning forehead temperature:
1) What is the forehead temperature?
Forehead temperature is the same temperature as the arterial blood supply under the
skin. It is the best determinate of body temperature, and unaffected by the artificial errors
and time delays of oral and rectal methods.
2) How to take forehead temperature properly?
Gently touch the probe to center of forehead or no contact about 5-10 cm distance the
probe to center of forehead. Make sure remove anything covering the area to be
measured (hair, hat, wig, and bandages). Failure to do so may insulate the area,
resulting in false readings. Press the “SCAN” button on the thermometer for the reading.
3) Why is a forehead temperature more accurate than ear temperature?
Ear thermometers are considered inaccurate because the positioning of the probe in the
ear canal might affect the accuracy. The forehead thermometer scans the forehead area
for temperature given off by the arterial blood supply under the skin without worrying
about correct positioning. The gentle scan is comfortable and not invasive.
Measurement method Normal temperature range Fever temperature range
Forehead
35.0~38.0℃(95.0~100.4℉)
NOTED: Measurements for
some adults may be lower
than 35.0℃(95.0℉)
A temperature that is 0.6~0.8℃
(1.0~1.5
℉
)higher than usual. It is
highly recommended that you use
our IR Forehead Thermometer to
establish the normal temperature
range for each person.
Temperature measurements are impacted by the type of measurement method used.

7
STATEMENTS AND DECLARATIONS:
1) This product needs special precautions regarding EMC and needs to be installed and
put intoserviceaccording tothe EMC information provided, and thisunit can be affected
by portable and mobile RF communications equipment.
2) Do not use a mobile phone or other devices that emit electromagnetic fields, near the
unit. This may result in incorrect operation of the unit.
3) This unit has been thoroughly tested and inspected to assure proper performance and
operation
4) This device should not be used adjacent to or stacked with other equipment. If
adjacent or stacked use is necessary, this machine should be observed to verify
normal operation in the configuration in which it will be used
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
Explanation of Symbols:
Symbol for batch code
Symbol for manufacturer
Symbol for ‘CE”
Symbol for “ENVIRONMENT PROTECTION – Waste electrical products should not
be disposed of with household waste. Please recycle where facilities exist. Check
with your local Authority or retailer for recycling advice”
Symbol for “TYPE BF APPLIED PART”
Symbol for “Follow operating instructions”
IP22 Symbol for “the IP classification”
Symbol for “RF transmitters”
LOT
