Fugoo Element F6ELKS01 User manual

Bluetooth Speaker
Model: F6ELKS01
We create experiences
User Manual

i
Contents
In the Box ..................................................................................... i
Buttons, LEDs, ports, & mounts functions ................................... 2
Charging ...................................................................................... 2
Battery status .............................................................................. 2
Power, Bluetooth pairing and speaker controls
Power .................................................................................. 3
Bluetooth pairing ................................................................. 3
Audio controls ...................................................................... 3
Call controls ......................................................................... 3
TWS pairing ................................................................................. 4
AUX IN (3.5mm audio cable) ....................................................... 4
IPX7 (waterproof) ........................................................................ 4
Floats ........................................................................................... 4
Support ........................................................................................ 4
Specifications .............................................................................. 5
Legal notices (FCC & IC statements) .......................................... 5
•Fugoo Element Bluetooth speaker
•5V/1A 1m (3.2'/3.2ft) Micro-USB power cable
•3.5mm 0.6m (1.9'/1.9ft) AUX IN audio cable
•Quick Start Guide & User Manual
(Including Warranty Statement)
In the Box

Charging Battery status
2
Button & LED Lights (Top)
Buttons, LED, ports & mount functions
Bracket & Ports (Side) Mount (Bottom)
1211 13
135246789 10
1Power Button
2Power LED (RED)
3Play/Pause Button
4Decrease Volume Button
5Microphone
6Increase Volume Button
7Bluetooth®Button
8SYNC LED (Blue/Amber)
9SYNC Button
10 Carrying Strap Bracket
11 AUX IN 3.5 mm Port
- Wired Audio-in
12 Micro-USB Port (DC IN)
- Charging / Firmware Updating
13 ¼" Universal Mount
IMPORTANT: Charge for 6 hours before first use.
Connect a micro-USB cable into DC IN port of the speaker. Plug
the other end of the cable into an AC adapter and that adapter
into an AC power outlet.
•While the battery is being charged, the LED will slowly pulse RED;
When fully charged, the LED will glow solid RED.
•Full charge achieved in 6 hours while powered OFF or 12 hours
while powered ON.

3
Call controls
Answer / end call ..................................... Click button
Reject a call ............................................... Double-click button
Mute microphone in a call ..................... Click and buttons
The speaker must be off for the following functions to work:
Power Save On / O ............................... Hold and buttons
•If the speaker is not connected to a source device and is not
plugged into a power source, the speaker turns o after
15 minutes of inactivity.
•If the speaker is not connected to a source device and is
plugged into a power source, the speaker turns o after
30 minutes of inactivity.
•If the speaker is connected to a source device and is not
plugged into a power source, the speaker turns o after
1 hour of inactivity.
•If the speaker is connected to a source device and is plugged
into a power source, the speaker will not shut o automatically.
Line in mode
•If there is no signal input and is not plugged into a power
source, the speaker turns o after 60 minutes of inactivity.
•If the speaker is plugged into a power source, the speaker will
not shut o automatically.
•If Power Save mode is o, then the speaker will remain on until you
turn it o by pressing the button for 1 second.
Power, Bluetooth pairing, and speaker controls
Power
Power On / O ......................................... Hold button (1 second)
Bluetooth pairing
•DO NOT have a line connection in the AUX-IN port
•Pair devices within 3 feet (1 meter); Max signal range of
33 foot (10 meter); Signal disruption/loss may accoure
when devices are out of range from each other.
Pair device ................................................ Hold button (3 seconds)
•Turn your audio source’s Bluetooth On and select
“FUGOO ELEMENT”
Disconnect device .................................. Click button
Clear all paired devices ......................... Hold button (10 seconds)
Audo controls
Play / Pause .............................................. Click button
Volume up ................................................. Click button
Volume down ........................................... Click button
Next track ................................................... Click and
Previous track ............................................ Click and
Voice Control.............................................. Hold (2 seconds)
TWS pair/unpair.......................................... Hold (2 seconds)

4
TWS pairing
CAUTION:
•The protective rubber tab, covering the DC IN and AUX IN ports,
must be firmly in place before immersing the speaker in water or
permanent damage may occur.
•Do NOT immerse while charging.
•
Never connect a cable to any of these connectors if they are wet,
or are at risk of getting wet.
Floats
The speaker naturally floats on the surface of the water.
Support
•Visit Fugoo's Support page at support.fugoo.com for help with
connecting, to view our FAQs or to ask us a question.
•Visit Fugoo's downloads page at fugoo.com/product-support, for
firmware updates, alternative voice prompts, and mobile
wallpaper images.
•Send us a support request at [email protected].
IPX7 (waterproof)
AUX IN (3.5 mm audio cable)
This speaker has protection against water to a max depth of 3
feet (1 meter) for up to 30 minutes.
1Pair speaker to a Bluetooth audio device (transmitter).
2Power On a second SYNC capatible speaker (receiver)
Do NOT pair to Bluetooth device.
•If BT (receiver) device is connected, long press button
(3 seconds) to enter TWS pairing.
3Hold button of the bluetooth paired speaker for 2 seconds.
•While TWS pairing
The LED on the transmitting devices will flashes blue alternately,
searching for a TWS compatible device to connect to.
•TWS Successful
Transmitting LED: Blue
Receiving LED: Amber
Plugging in a 3.5 mm audio cable into the AUX IN input will
disable the Bluetooth function and will switch the audio signle to
the AUX IN audio mode.

5
Specifications
Power
Battery ........................................................ Lithium-Ion 4400mA
Audio
Speaker drivers ........................................ (x2) 1.75” Speaker
.................................................................. (x2) 2.5” Passive Radiators
Audio output ............................................. 20W
Frequency Range .................................... 50Hz - 20KHz
THD + Noise ............................................. ≤10%
Signal-to-Noise ........................................ >60dB
Microphone ............................................... Omnidirectional
.................................................................. Echo cancelling
.................................................................. Noise reducting
Conectivity
Bluetooth Version ................................... 4.2
Construction
Materials .................................................... Plastic and metal
Weight ........................................................ 1.8 lbs. / 0.82 kg
Dimensions (LxWxH) ............................... 9.35” x 3.3” x 3.25”
.................................................................. 238 x 84 x 82mm
Enviroment
Water resistants ....................................... IPX7
Operating Temp. Range ........................ 32F° to 104F° / 0C° to 40C°
Operating Humidity ................................ 40-90% RH
Storage Temp. Range ............................ -13F° to 158F° / -25C° to 70C°
Legal notices
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This device complies with Part 15 of the
FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.

6
Caution!
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
IC Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
RF exposure statement
This equipment complies with the FCC RF radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20cm between the
radiator and any part of your body.
