Fuji Electric ecoWAVE Econ-Line PHF Series Instruction Manual

Fuji Electric Asia Pacific Pte. Ltd.
Fuji Electric Harmonic Mitigation
Econ-line Passive Harmonic Filters
EL1M-PHF-MNL/V1.1
Installation & User Manual

© All rights reserved.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or
by any means without the prior written permission of Fuji Electric Co., Ltd. The information in this manual
is subject to change without notice. Every precaution has been taken in the preparation of this manual.
Fuji Electric assumes no responsibility for errors or omissions. Neither is any liability assumed for damages
resulting from the use of the information contained in this publication.
Document name:
ecoWAVE Econ-Line PHF Installation and User Manual .pdf
Version history
Revision Date Description
EL1M-PHF-MNL/V1.1 Apr 2021 Initial version
EL1M=PHF-MNL/2 Jan 2023 Version 2
These instructions (PDF format) can be obtained from www.fujielectric.com or from your local
Fuji Electric sales representative.
Other technical documentation of our products is also available in the download area of
www.fujielectric.com
Passive Harmonic Filters
2

3
Table of Contents
Product Versions..............................................................
Introduction
Safety information...............................................................
About this manual...............................................................
Model Selection
Explanation of product code...............................................
Specifications
Additional electrical specifications......................................
General electrical specifications (50 Hz filters)...................
50 Hz Type technical data..................................................
50 Hz Type mechanical frame size.....................................
General electrical specifications (60 Hz filters)...................
60 Hz Type techincal data...................................................
60 Hz Type mechanical frame size.....................................
50 Hz / 60 Hz Outline drawing............................................
50 Hz Dimensions data.......................................................
60 Hz Dimensions data.......................................................
Terminals............................................................................
Performance data...............................................................
Wiring diagram...................................................................
Structure design.................................................................
Application..........................................................................
Installation
Step 1: Visual inspection.....................................................
Step 2: Mounting.................................................................
Step 3: Wiring.....................................................................
Fuse....................................................................................
Maintenance
1. Maintenance schedule....................................................
2. Fan..................................................................................
3. Power capacitors............................................................
4. Electrical connections.....................................................
Additional Information
Trap circuit disconnect........................................................
50 Hz Trap circuit recommended contactor........................
60 Hz Trap circuit recommended contactor........................
Troubleshooting..................................................................
Publications disclaimer.......................................................
ecoWAVE Econ-Line Passive Harmonic Filter
2
4 - 6
7
8
9
10
11
11
12
13
13
14
15
16
17 - 18
19 - 20
21 - 22
23 - 24
25
26
26 - 27
28 - 30
31
32
32
33
33
34
35
36
37
38

4
Safety Information
Important Information
NOTICE
Read these instructions carefully, and look at the equipment to become familiar with the device before
trying to install, operate, or maintain it. The following special messages may appear throughout this
documentation or on the equipment to warn of potential hazards or to call attention to information that
clarifies or simplifies a procedure.
PLEASE NOTE
Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel.
No responsibility is assumed by Fuji Electric for any consequences arising out of the use of this material.
A qualified person is one who has skills and knowledge related to the construction and operation of
electrical equipment and its installation, and has received safety training to recognize and avoid the
hazards involved.
Qualification Of Personnel
Only appropriately trained persons who are familiar with and understand the contents of this manual and
all other pertinent product documentation are authorized to work on and with this product. In addition,
these persons must have received safety training to recognize and avoid hazards involved. These
persons must have sufficient technical training, knowledge and experience and be able to foresee and
detect potential hazards that may be caused by using the product, by changing the settings and by the
mechanical, electrical and electronic equipment of the entire system in which the product is used. All
persons working on and with the product must be fully familiar with all applicable standards, directives,
and accident prevention regulations when performing such work.
High voltage potentials are involved in the operation of power quality equioment.
Always remove power before handling energized parts of the filter, and let ample time
elaspse for the capacitors to dischange to safe levels (<42V). Residual voltage are to be
measured both line to line and line to earth.
Equipment installation, start-up. operation and maintenance (if any) have to be carried out
by a trained and certified electrician or technician, who is familiar with safety procedures in
electrical system. Non-qualified person are not allowed to use, install, operate or maintain the
PQ filters!
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, will result in minor or
moderate injury.
NOTICE
NOTICE is used to address practices not related to physical imjury

5
Product Application type
This product is a Passive Harmonic Filter for 3-phase 400V class inverter, UPS, DC fast chargers ect.
Or any 3-phase power conversion equipment with front-end six-pulse rectifier AC and DC motor drives in
low dynamic applications intended for industrial use according to this manual. The product may only be
used in compliance with all applicable safety regulations and directives, the specified requirements and
the technical data. Prior to using the product, you must perform a risk assessment in view of the planned
application. Based on the results, the appropriate safety measures must be implemented. Since the
product is used as a component in an entire system, you must ensure the safety of persons by means of
the design of this entire system (for example, machine design). Any use other than the use explicitly
permitted is prohibited and can result in hazards. Electrical equipment should be installed, operated,
serviced, and maintained only by qualified personnel.
Product Related Information
Read and understand these instructions before performing any procedure with this product.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
Only appropriately trained persons who are familiar with and understand the contents of this manual
and all other pertinent product documentation and who have received safety training to recognize
and avoid hazards involved are authorized to work on and with this filter system. Installation,
adjustment, repair and maintenance must be performed by qualified personnel.
The system integrator is responsible for compliance with all local and national electrical code
requirements as well as all other applicable regulations with respect to grounding of all equipment.
Many components of the product, including the printed circuit boards, operate with mains voltage. Do
not touch. Use only electrically insulated tools.
Do not touch unshielded components or terminals with voltage present.
Prior to performing any type of work on the filter system, isolate power supply to prevent electric
shock circuit.
AC voltage can couple voltage to unused conductors in the power cable. Insulate both ends of unused
conductors of the motor cable.
Do not short across the filter’s bus terminals or control bus terminals.
Before performing work on the passive harmonic filter system:
Disconnect all power, including external control power that may be present.
Place a Do Not Turn On label on all power switches.
Lock all power switches in the open position.
Wait 15 minutes to allow the DC bus capacitors to discharge.
If the AC bus capacitors do not discharge properly, contact your local Fuji Electric representative.
Do not repair or operate the product.
Install and close all covers before applying voltage.
Failure to follow these instructions will result in death or serious injury.
WARNING
UNEXPECTED SHOCK CIRCUIT
Harmonic Filter systems may result unexpected shock circuit because of incorrect power wiring,
incorrect control wiring or other errors.
Carefully install the wiring in accordance with this manual’s informatiuon.
Do not operate the product with unknown or unsuitable applications or connection.
Perform a comprehensive commissioning test.
Failure to follow these instructions can result in death, serious injury, or equipment damage.

6
Damaged products or accessories may cause electric shock or unanticipated equipment operation.
Contact your local Fuji Electric sales office if you detect any damage whatsoever.
The metal surfaces of the product may exceed 100 °C (212 °F) during operation.
ELECTRIC SHOCK OR UNANTICIPATED EQUIPMENT OPERATION
Do not use damaged products or accessories.
Failure to follow these instructions will result in death or serious injury.
NOTICE
DESTRUCTION DUE TO INCORRECT MAINS VOLTAGE
Before switching on and configuring the product, verify that it is approved for the mains voltage
Failure to follow these instructions can result in equipment damage.
WARNING
HOT SURFACES
Ensure that any contact with hot surfaces is avoided.
Do not allow flammable or heat-sensitive parts in the immediate vicinity of hot surfaces.
Verify that the heat dissipation is sufficient by performing a test run under maximum load conditions.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
DANGER

7
About this manual
At a Glance
Document Scope
The purpose of this document is:
to give you mechanical and electrical information related to the ecoWAVE Passive Harmoinc Filter,
to show you how to install and wire this filter.
Validity Note
NOTE: The products listed in the document are not all available at the timeof publication of this document
online. The data, illustrations and product specifications listed in the guide will be completed and updated
as the product availabilities evolve. Updates to the guide will be available for download once products are
released on the market.
This documentation is valid for the ecoWAVE Econ-Line IP20 Passive Harmonic Filter series.
The technical characteristics of the devices described in this document also appear online. To access this
information online:
The characteristics that are presented in this manual should be the same as those characteristics that
appear online. In line with our policy of constant improvement, we may revise contentover time to improve
clarity and accuracy. If you see a difference between the manual and online information, use the online
information as your reference.
Step Action
1 Go to the Fuji Electric home page www.fujielectric.com .
2 In the Search box type the reference of a product or the name of a product range or look under Inverter
product category for ecoWAVE Passive Harmonic Filter series.

8
How to read the model code
Model selection
F N 0.75 E L 1 M - 4 G 5
CODE Product Type
Passive Harmonic Filter
FN
CODE kW Rating
0.75kW
0.75
~
~
160kW
160
CODE Series
Advance-Line Series 1AL1
Econ-Line Series 1
EL1
CODE Protection
IP20 Enclosure Type
M
IP00 Skid Type
S
CODE Hz
50Hz
5
60Hz
6
CODE Destination
Global Model
G
CODE Input power source
400 Voltage Class *
4
* Exact input power source please refer to technical specifications
Select the most suitable filter rating for your application.
In case of inverter application, the inverter must incorporate with a 5% impedance DC-Link choke to achieve THID
10% @ rated power result with the ecoWAVE Econ-Line PHF series or apply ecoWAVE Advance-Line series if these
5% impedance DC-Link choke is absent.
In other words, there are two chokes (line choke and trap choke ) included in this filter series.
For ecoWAVE Econ-Line series.
Examples of 22kW 50Hz filter select to meet 10% THDi;
ecoWAVE Econ-Line PHF
FN22EL1M-4G5 : Filter for 50 Hz, 380...415 V AC grid, motor inverter power rating 22kW, IP20
Examples of 22kW 60Hz filter select to meet 10% THDi;
ecoWAVE Econ-Line PHF
FN22EL1M-4G6 : Filter for 60 Hz, 380...480 V AC grid, motor inverter power rating 22kW, IP20
In case you have difficulties to decide for the right filter, please contact your local Fuji Electric or representative for
support.
TYPE FN0.75EL1M-4G5
OUTPUT
SER No.
3Ø 380-415V ±10% / 50Hz / 2.5A
IP20 / UL Type 1 / NEMA 1
T8XA418A0008NJ
SOURCE 3Ø 380-415V ±10% / 50Hz±1 / 2.5A
Made in China
Passive Harmonic Filter
Risk of Electric Shock.
Discharge time - 5 min.
Use Overload monitor signal
for external load disconnection.
Use only for 6-pulse-type rectifier loads.
Refer to user manual.
www.fujielectric.com
!
WARNING
SAFETY
SCCR 100kA
MASS
18kg
Nameplate example
Model Code
Power part supply
Degree of protection
Serial Number
Product weight
Certifications
Safety Warning
The product nameplate contains the following data:

9
Additional Electrical Specifications
ecoWAVE Econ-Line PHF general electrical specifications refer to operating altitudes up to 2000m a.s.l. (6600ft).
Operation between 1000m and 4000m (3300ft and 13123ft) requires a derating according to the table 1 below:
Note: Do not use ecoWAVE Econ-Line PHF in altitudes above 4000m without consulting Fuji Electric first.
ecoWAVE Econ-Line PHF have been designed and certified acc. UL508, resp. UL508C, so there is no
limitation in terms of altitude up to 4000m for clerance and creepage.
Table 1 - Altitude correction factors
Altitude correction

10
Specifications
50Hz model
ecoWAVE Econ-Line filters reduce RMS input and peak current by reducing harmonic currents and improving
true power factor.
System requirements: THVD <2%, line voltage unbalance <1% Performance specification for six-pulse diode
rectifiers. SCR rectifier front-ends produce different results, depending upon the firing angle of the thyristors.
Conditions: line impedance <3%
Repetitive tests to be performed at max. 80% of above levels, for 2 seconds.
External UL-rated fuses required.
Iderated = Inominal×√ ((70°C-Tamb)/25°C)
50 Hz, 3.7 to 160kW
Equipment with front-end six-pulse rectifier /
Motor drives / Factory automation equipment/
Water/wastewater treatment facilities /
Fan and pump applications / HVAC applications
Mission-critical processes / DC fast chargers
50 Hz System
IP20
3x 380 to 415 VAC ± 10%
50 Hz ± 1 Hz
≤ 10% at rated power
>98% for rated voltage and power
P --> E 2500VAC (1min)
Natural convection cooling (0.75 to 7.5kW)
Internal forced cooling (11kW and above)
1.6x rated current for 1 minute, once per hour
2x rated current for 10 seconds, once per hour
5x rated current for 1 second, once per hour
- 25 °C to +45°C fully operational
+45°C to +70°C derated operation
- 25°C to +85°C transport and storage
UL 94V-2 or better
UL 508, EN 61558-2-20, CE (LVD 2006/95/EC)
TN, TT, IT
>200,000 hours
100 kA
Nominal operating voltage
Operating frequency
Nominal motor drive input power rating
Total harmonic current distortion THiD
Efficiency
High potential test voltage
Protection category
Cooling
Overload capability
Ambient temperature rage
Flammability corresponding to
Design corresponding to
Earth system
SCCR
Typical applications
Drive dc-link voltage No load: +10%, Full load: -5%
Pollution degree 1, 2 (according to EN 61800-5-1, EN 50178)
Total harmonic current distortion THID According to IEEE 519
<10% @ rated power (with Ldc)
<15% @ rated power (without Ldc)
Insulation class of magnetic components H (180°C)
MTBF @ 45°C) / 415V (Mil-HB-217F)
MTTR <15 minutes (capacitor modules and fan modules)
Lifetime (calculated) ≥10 years
Safety monitoring functions Over-temperature of magnetic components
Item
Total demand distortion TDD According to IEEE 519
Partially weighted harmonic distortion PWHID <22% @ rated power
Capacitive current @ no load: <30% of rated input current, at 400VAC
<37% of rated input current, at 500VAC

11
Specifications 50 Hz Type
Technical data
Mechanical frame sizes
ecoWAVE Econ-Line PHF are implemented on a base plate or base frame featuring 6 different frame sizes, Frame A
to Frame F, from the lowest to the highest rating. Dimensions and footprint are provided in diagram 1 below.
In particular, frame sizes A do not require air flow, while frame sizes B to F with embedded fan.
Diagram 1.
50 Hz IP20 Frame Size Layout
3-Phase, 380...415VAC, 50 Hz
Air flow cooling (embedded ventilation fan)
3.7kW
5.5kW
7.5kW
11kW
15kW
18.5kW
22kW
30kW
37kW
45kW
55kW
75kW
90kW
110kW
132kW
160kW
A B C D E F
No Ventilation
Fan
*** Filter rating which does not require forced cooling or fan module.
***Filter to be selected by system voltage and load (motor drive) power. Note: the harmonic filter will reduce RMS input
current. Therefore, filter selection by current rating, as it is common for EMC/EMI filters, is not recommended.
*** Calculated power loss at rated load power.
Rated
Voltage
Nominal
applied motor
[kW]
Filter
Motor drive
input current
[Arms]**
Typical
Losses
[W]***
Frame
50Hz
3-Phase
380-415V
Class
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
-
-
FN3.7EL1M-4G5 *
FN5.5EL1M-4G5 *
FN7.5EL1M-4G5 *
FN11EL1M-4G5
FN15EL1M-4G5
FN18.5EL1M-4G5
FN22EL1M-4G5
FN30EL1M-4G5
FN37EL1M-4G5
FN45EL1M-4G5
FN55EL1M-4G5
FN75EL1M-4G5
FN90EL1M-4G5
FN110EL1M-4G5
FN132EL1M-4G5
FN160EL1M-4G5
-
-
10
13
16
24
32
38
45
60
75
90
110
150
180
210
260
320
-
-
-
-
135
183
256
287
359
343
460
570
581
783
858
1036
1166
1365
1392
1462
-
-
A
B
D
E
F
- - - - -
-44
-44
-44
-33
-33
-33
-33
-34
-34
-35
-35
-40
-40
-40
-99
-99
C
Terminal

12
Specifications
60Hz model
ecoWAVE Econ-Line filters reduce RMS input and peak current by reducing harmonic currents and improving
true power factor.
System requirements: THVD <2%, line voltage unbalance <1% Performance specification for six-pulse diode
rectifiers. SCR rectifier front-ends produce different results, depending upon the firing angle of the thyristors.
Conditions: line impedance <3%
Repetitive tests to be performed at max. 80% of above levels, for 2 seconds.
External UL-rated fuses required.
Iderated = Inominal×√ ((70°C-Tamb)/25°C)
60 Hz, 3.7 to 160kW
Equipment with front-end six-pulse rectifier /
Motor drives / Factory automation equipment/
Water/wastewater treatment facilities /
Fan and pump applications / HVAC applications
Mission-critical processes / DC fast chargers
60 Hz System
IP20
3x 380 to 480 VAC ± 10%
60 Hz ± 1 Hz
≤ 10% at rated power
>98% for rated voltage and power
P --> E 2500VAC (1min)
Natural convection cooling (0.75 to 7.5kW)
Internal forced cooling (11kW and above)
1.6x rated current for 1 minute, once per hour
2x rated current for 10 seconds, once per hour
5x rated current for 1 second, once per hour
- 25 °C to +45°C fully operational
+45°C to +70°C derated operation
- 25°C to +85°C transport and storage
UL 94V-2 or better
UL 508, EN 61558-2-20, CE (LVD 2006/95/EC)
TN, TT, IT
>200,000 hours
100 kA
Nominal operating voltage
Operating frequency
Nominal motor drive input power rating
Total harmonic current distortion THiD
Efficiency
High potential test voltage
Protection category
Cooling
Overload capability
Ambient temperature rage
Flammability corresponding to
Design corresponding to
Earth system
SCCR
Typical applications
Drive dc-link voltage No load: +10%, Full load: -5%
Pollution degree 1, 2 (according to EN 61800-5-1, EN 50178)
Total harmonic current distortion THID According to IEEE 519
<10% @ rated power (with Ldc)
<15% @ rated power (without Ldc)
Insulation class of magnetic components H (180°C)
MTBF @ 45°C) / 415V (Mil-HB-217F)
MTTR <15 minutes (capacitor modules and fan modules)
Lifetime (calculated) ≥10 years
Safety monitoring functions Over-temperature of magnetic components
Item
Total demand distortion TDD According to IEEE 519
Partially weighted harmonic distortion PWHID <22% @ rated power
Capacitive current @ no load: <30% of rated input current, at 400VAC
<37% of rated input current, at 500VAC

13
Specifications 60 Hz Type
Technical data
Mechanical frame sizes
ecoWAVE Econ-Line PHF are implemented on a base plate or base frame featuring 6 different frame sizes, Frame A
to Frame F, from the lowest to the highest rating. Dimensions and footprint are provided in diagram 1 below.
In particular, frame sizes A do not require forced cooling fan air flow, while frame sizes B to F with embedded fan.
Diagram 1.
60 Hz IP20 Frame Size Layout
3-Phase, 380...480VAC, 60 Hz
Air flow cooling (embedded ventilation fan)
3.7kW
5.5kW
7.5kW
11kW
15kW
18.5kW
22kW
30kW
37kW
45kW
55kW
75kW
90kW
110kW
132kW
160kW
A B C D E F
No Ventilation
Fan
* Filter rating which does not require forced cooling or fan module.
** Filter to be selected by system voltage and load (motor drive) power. Note: the harmonic filter will reduce RMS input
current. Therefore, filter selection by current rating, as it is common for EMC/EMI filters, is not recommended.
*** Calculated power loss at rated load power.
**** In case of filter accurate rating, please refer to Horsepower (HP) rating.
Rated
Voltage
Nominal
applied motor
[kW]
Filter
Motor drive
input current
[Arms]***
Typical
Losses
[W]****
Frame
50Hz
3-Phase
380-480V
Class
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
-
-
FN3.7EL1M-4G6 *
FN5.5EL1M-4G6 *
FN7.5EL1M-4G6 *
FN11EL1M-4G6
FN15EL1M-4G6
FN18.5EL1M-4G6
FN22EL1M-4G6
FN30EL1M-4G6
FN37EL1M-4G6
FN45EL1M-4G6
FN55EL1M-4G6
FN75EL1M-4G6
FN90EL1M-4G6
FN110EL1M-4G6
FN132EL1M-4G6
FN160EL1M-4G6
-
-
10
13
16
24
32
38
45
60
75
90
110
150
180
210
260
320
-
-
-
-
135
183
256
287
359
343
460
570
581
783
858
1036
1166
1365
1392
1462
-
-
A
B
D
E
F
- - - - -
-44
-44
-44
-33
-33
-33
-33
-34
-34
-35
-35
-40
-40
-40
-99
-99
C
Terminal
[HP]
1
2
3
71/2
10
15
20
25
30
40
50
60
75
100
125
150
200
250
5

14
Filter Overview
Frame Sizes
Frame design for A, B, C & D Frame design for E
Frame design for F
FN3.7EL1M-4G5 ~ FN55EL1M-4G5
FN3.7AL1M-4G6 ~ FN55AL1M-4G6
The ecoWAVE Econ-Line PHF includes 6 frame sizes for IP20 products.
FN75EL1M-4G5 ~ FN110EL1M-4G5
FN75EL1M-4G6 ~ FN110EL1M-4G6
FN132EL1M-4G5 ~ FN160AL1M-4G5
W
H
D
W
DD
W
H
WD
W
H
D
W
D
FN132EL1M-4G6 ~ FN160AL1M-4G6

15
Specifications 50 Hz Type
Dimensions
Model Number Frame
Size
Nominal
Power
kW W H D W1 H1 T
Outside dimensions
(mm)
Mounting Drill
(mm)
185
*** Filter rating which does not require forced cooling or fan module.
***Filter rating which does not require RC damping module for rectifiers with EMI filter.
*** Motor drive input current without harmonic filter
450
250
280
3-phase, 380...415V, 50 Hz
FN3.7EL1M-4G5*
FN5.5EL1M-4G5*
FN7.5EL1M-4G5*
FN11EL1M-4G5
FN15EL1M-4G5
FN18.5EL1M-4G5
FN22EL1M-4G5
FN30EL1M-4G5
FN37EL1M-4G5
FN45EL1M-4G5
FN55EL1M-4G5
FN75EL1M-4G5
FN90EL1M-4G5
FN110EL1M-4G5
FN132EL1M-4G5
FN160EL1M-4G5
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
390 190 140 370 M6 A
455 230 200 435 M8 B
520
580
248 255 500
M8 C
D
700 385 350 665 M12 E
450 700 385 350 665 M12 F
NOTE: Frame E & Frame F are same in dimension but different terminal type.
M10

16
Specifications 60 Hz Type
Dimensions
3-phase, 380...480V, 60 Hz
*** Filter rating which does not require forced cooling or fan module.
***Filter rating which does not require RC damping module for rectifiers with EMI filter.
*** Motor drive input current without harmonic filter.
**** In case of filter accurate rating, please refer to Horsepower (HP) rating.
NOTE: Frame E & Frame F are same in dimension but different terminal type.
185
450
250
280
FN3.7EL1M-4G6*
FN5.5EL1M-4G6*
FN7.5EL1M-4G6*
FN11EL1M-4G6
FN15EL1M-4G6
FN18.5EL1M-4G6
FN22EL1M-4G6
FN30EL1M-4G6
FN37EL1M-4G6
FN45EL1M-4G6
FN55EL1M-4G6
FN75EL1M-4G6
FN90EL1M-4G6
FN110EL1M-4G6
FN132EL1M-4G6
FN160EL1M-4G6
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
390 190 140 370 M8 A
455 230 200 435 M10 B
520
580
248 255 500
C
D
700 385 350 665 M12 E
450 700 385 350 665 M12 F
M10
1
2
3
5
71/2
10
15
20
25
30
40
50
60
75
100
125
150
200
250
Model Number Frame
Size
Nominal****
Power
kW W H D W1 H1 T
Outside dimensions
(mm)
Mounting Drill
(mm)
HP

ecoWAVE Econ-Line PHF need to be carefully selected and configured in order to enjoy maximum benefits.
Step 1: Grid frequency
Determine, whether the system in consideration will be operated in a 50 Hz or 60 Hz electricity grid, and select the
corresponding filter series according to the following table:
50 Hz grid Europe, Middle East, parts of Asia, parts of South America (FNXXXEL1M-4G5)
60 Hz grid North and Central America, parts of Asia, parts of South America (FNXXXEL1M-4G6)
Note: a 50 Hz filter will not provide satisfying harmonics mitigation in a 60 Hz grid, and vice versa.
Step 2: Grid voltage
Verify that the grid configuration is suitable for standard ecoWAVE Econ-Line PHF according to the following table:
50 Hz grid Nominal voltage 380–415 V AC TN, TT, IT configuration
60 Hz grid Nominal voltage 380–480 V AC TN, TT, IT configuration
Step 3: Rectifier type, presence of DC-link choke in drive
ecoWAVE Econ-Line filter only for use in 6-pulse diode rectifier with a 5% impedance DC-link choke for
guarantee performance.
Step 4: Rectifier/Drive input power
The individual filter must be selected with respect to the rectifier/motor drive input power in kW respectively.
It is important to match rated filter power as close as possible with the effective input power of the rectifier/
drive.
Note that if the rectifier/drive is being operated very close to its rated power, then the filter can be selected
by the motor drive’s nominal power rating. However, if the drive will be operated e.g. at only 66% of its rated
power, then a smaller filter should be selected in order to get maximum harmonics mitigation performance
and the optimum in terms of cost, size, and weight. In that case the customer is responsible to ensure that
ecosine passive harmonic filter will be operated within specification. This is particular important in terms of
overload.
17
Terminals
Terminal Data
50 Hz / 60 Hz IP20 Power Terminals
A
B
C
D
E
F
M8 10 6 8 1.0 - 1.2
M10 16 10 6 1.4 - 1.6
M10 35 25 2 4.0 - 4.5
M10 50 50 1/0 7.0 - 8.0
M12 95 95 4/0 17 - 20
M12 150 150 6/0 25 - 30
Solid Wire
mm²
Screw
Thread
Frame Flex Wire
mm²
AWG
Type
Wire
Recommended
Torque
Nm
Power Terminal
M10
M12
M8
17
35
9
M3 0.5
Screw
Thread
Screw
Torque Value
[Nm]
Screw
Thread
Screw
Torque Value
[Nm]
Earth Terminal (PE) Signal Terminal

18
Terminals
Please refer to the following examples:
Example 1:
Power line rating: 415 V, 50 Hz (FN15EL1M-4G5)
Drive rating: 380–500 V, 50–60 Hz, 15 kW, 22.5 A, B6-diode rectifier with DC-link choke
Planned rectifier/drive input real power: 15 kW (100% of drive rating)
Example 2:
Power line rating: 480 V, 60 Hz (FN15EL1M-4G6)
Drive rating: 380–500 V, 50–60 Hz, 15 kW, 22.5 A, diode rectifier
Planned rectifier/drive input real power: 15 kW (100% of drive rating)
NOTICE
Oversizing of passive harmonic filters is not recommended because of the inherent lower harmonic mitigation
performance at partial load as well as higher cost, size, and weight.
NOTICE
ecoWAVE Econ-Line Filter with embedded ventilation
The filters 11kW - 160kW IP20 enclosure type contain embedded ventilation, which means the filters contain
fan and aux. power supply. (refer to page 24 Figure 3 for sample view of filter with embedded ventilation)

19
Performance Data
NOTICE
All other ecoWAVE Econ-Line 50 Hz / 60 Hz filters are not subject to any such limitations.
ecoWAVE Econ-Line PHF achieve % THID with 6-pulse diode rectifiers under the following condition.
Filter is applied to rated voltage and power THVD <2%, line voltage unbalance <1%
The values of EMI-filter components present in the same non-linear load (e.g. motor drive) can influence the mitigation
performance of passive harmonic filters. For ecoWAVE Econ-Line PHF the following boundary conditions exist for the
smallest frame sizes: Typical expected EMI filter capacitance (phase to star point) are shown in Table 3.
Table 3
Typical expected EMI filter capacitance (phase to star point) for series 60Hz ecoWAVE Econ-Line PHF
* System requirements: THVD <2%, line voltage unbalance <1%
Power factor vs. load (diode rectifier front-ends)
Note: in SCR rectifier applications, filter characteristics greatly depend upon the firing angle of the thyristors.
Drive dc-link voltage vs. load (diode rectifier front-ends)
Note: in SCR rectifier applications, filter characteristics greatly depend upon the firing angle of the thyristors.
FN3.7EL1M-4G6
FN5.5EL1M-4G6
FN7.5EL1M-4G6
8.4mH
6.7mH
-
4.2mH
-
-
≤ 1.0μF
≤ 1.5μF
≤ 1.5μF
≤ 3.3μF
≤ 2.2μF
~10%
~10%
~13%
~10%
~15%
≤ 3.3μF ~15%
Model Typical drive
dc-linke choke
Max. recommended
EMI-filter X-capacitor
Expected
THID *

20
Performance Data
Note: in SCR rectifier applications, filter characteristics greatly depend upon the firing angle of the thyristors.
Performance characteristics ecoWAVE Econ-Line 50 Hz / 60 Hz
THID vs. load (diode rectifier front-ends)
Note:
shown above is the typical performance characteristic of ecoWAVE Econ-Line series in balanced diode rectifier
front-end. In SCR rectifier applications, filter performance greatly depends upon the firing angle of the thyristors.
Power factor vs. load (diode rectifier front-ends)
Drive dc-link voltage vs. load (diode rectifier front-ends)
Note: in SCR rectifier applications, filter characteristics greatly depend upon the firing angle of the thyristors.
