FujiFilm FinePix S3Pro User manual

THE COMPONENTS IDENTIFIED BY THE MARK “” ON THE SCHEMATIC
DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR SAFETY.
PLEASE REPLACE ONLY BY THE COMPONENTS SPECIFIED ON THE SCHEMATIC
DIAGRAM AND IN THE PARTS LIST.
IF YOU USE PARTS NOT SPECIFIED, IT MAY RESULT IN A FIRE AND AN
ELECTRICAL SHOCK.
FUJI PHOTO FILM CO., LTD. Ref.No.: ZM00576-102
Printed in Japan 2004.12
DIGITAL CAMERA
FinePix S3Pro
US/CA/EU/EG/GE/AS/JP-Model
SERVICE MANUAL
WARNING

2
FinePix S3Pro Service Manual
7. CAUTION: FOR CONTINUED
PROTECTION AGAINST FIRE
HAZARD, REPLACE ONLY WITH
SAME TYPE 2.5 AMPERES 125V
FUSE.
ATTENTION: AFIN D'ASSURER
UNE PROTECTION
PERMANENTE CONTRE LES
RISQUES D'INCENDIE,
REMPLACER UNIQUEMENT
PAR UN FUSIBLE DE MEME,
TYPE 2.5 AMPERES, 125 VOLTS.
8. WARNING:
TO REDUCE THE ELECTRIC
SHOCK, BE CAREFUL TO
TOUCH THE PARTS.
WARNING!
HIGH VOLTAGE
SAFETY CHECK-OUT
After correcting the original problem, perform the following
safety check before return the product to the customer.
1. Check the area of your repair for unsoldered or poorly
soldered connections. Check the entire board surface
for solder splasher and bridges.
2. Check the interboard wiring to ensure that no wires are
“pinched” or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair.
Point them out to the customer and recommend their
replacement.
4. Look for parts which, though functioning, show obvious
signs of deterioration. Point them out to the customer
and recommend their replacement.
5. Check the B + voltage to see it is at the values
specified.
6. Make leakage - current measurements to determine
that exposed parts are acceptably insulated from the
supply circuit before returning the product to the
customer.
2.5A 125V
2.5A 125V
RISK OF FIRE-
REPLACE FUSE
AS MARKED

3
TABLE OF CONTENTS
FinePix S3Pro Service Manual
TABLE CONTENTS
1. General ........................................................... 4
1-1. Product specification .............................................. 4
1-2. Explanation of Terms .............................................. 7
1-3. Names of External Components ............................ 8
2. Disassembly ................................................. 11
2-1. Names of internal Components ............................ 11
2-2. Removing the BATT CART ASSY ........................ 12
2-3. Removing the R CABI ASSY ................................ 12
2-4. Removing the SW PWB ASSY ............................. 13
2-5. Removing the LCD ............................................... 15
2-6. Removing the 10-pin TERMINAL ASSY ............... 15
2-7. Removing the BATTERY HOLDER ...................... 15
2-8. Removing the MAIN PWB ASSY .......................... 16
2-9.
Removing the CCD PWB ASSY and CCD UNIT ...... 17
2-10. How to dismantle the parts around the outer
wrappings ............................................................. 19
2-10-1. Removing TOP COVER UNIT ................ 19
2-10-2. Removing SB LOWER CASE UNIT ....... 21
3. Schematic ..................................................... 23
3-1. Cautions ............................................................... 23
3-2. Basic block name and function explanation ......... 23
3-3. Description of the Main Block Functions .............. 23
3-3-1. Overview of the new technology ............. 23
3-3-2. Block function descriptions ..................... 24
3-3-3. Description of the Power Supply Block
Functions ................................................ 24
3-4. Block Diagram ...................................................... 25
3-5. Overall connection Diagram ................................. 26
3-6. Circuit Diagrams ................................................... 27
3-6-1. CCD BLOCK ........................................... 27
3-6-2. DCDC BLOCK ........................................ 28
3-6-3. IEEE1394 BLOCK .................................. 29
3-6-4. PROCESS BLOCK ................................. 30
3-6-5. CARD BLOCK ........................................ 31
3-6-6. DCDC BLOCK (CAMERA BODY) .......... 31
3-6-7. PARTNER-CHIP BLOCK ........................ 32
3-6-8. PWON BLOCK ....................................... 33
3-6-9. USB2.0 BLOCK ...................................... 34
3-6-10. LCD BLOCK ........................................... 35
3-6-11. SW BLOCK ............................................. 36
3-7. Mounted Parts Diagrams ...................................... 37
3-7-1. CCD PWB ASSY .................................... 37
3-7-2. MAIN PWB ASSY ................................... 38
3-7-3. SW PWB ASSY ...................................... 40
4. Adjustments .................................................. 41
4-1. Important point Adjustment when
Replacing Major Parts .......................................... 41
4-2. Measuring Instruments Used ............................... 41
4-3. Use Jig list ............................................................ 41
4-4. Calibration method of pattern box ........................ 43
4-5. Adjusting soft installation ...................................... 43
4-5-1. Various downloading software
decompressions, preservation methods,
and notes ................................................ 43
4-5-2. Installation of DSC jig driver ................... 44
4-5-3. Adjusting soft initiation method ............... 44
4-6. Initial Settings of the Adjustment Software ........... 45
4-7. Starting the Adjustment Software ......................... 48
4-8. [F4] : CCD Defect Correction ............................... 51
4-9. [F5] : CAMERA Adjustment .................................. 53
4-10. [F1] : Battery Voltage Adjustment ......................... 56
4-11. [F11] : Video Adjustment ...................................... 60
4-12. [F2] : Rear LCD Panel Adjustment ....................... 62
4-13. [F8] : Firmware Download .................................... 64
4-14. [F12] : End Setting ................................................ 66
5. Inspection ..................................................... 71
5-1. Measuring Instruments and Jigs Used for
Inspection ............................................................. 71
5-2. Connection of Measuring Instruments for
Inspection ............................................................. 71
5-3. Inspection and Settings at Shipment .................... 72
5-4. Resolution Checking ............................................ 76
5-5. CCD Cleaning and Inspection Procedures ........... 78
5-5-1. CCD Cleaning Using a
Visual Inspection for Dusting .................. 78
5-5-2. CCD Cleaning Using
Test Photography to Detect Dusting ....... 79
5-6. AF Checking ......................................................... 80
5-6-1. Measuring equipment and tools
used for AF checking .............................. 80
5-6-2.
Settings for the measuring equipment
and tools used for AF checking ..................
80
5-6-3. AF testing procedure .............................. 81
5-6-4. Cause identification procedure for
focus-related problems ........................... 82
6. Parts List....................................................... 83
6-1. Packing and Accessories ..................................... 83
6-1-1. US-model ................................................ 83
6-1-2. CA-model ................................................ 84
6-1-3. EU-model ................................................ 85
6-1-4. EG-model ................................................ 86
6-1-5. GE-model ................................................ 87
6-1-6. AS-model ................................................ 88
6-1-7. JP-model ................................................. 89
6-2. Transportable form and necessary parts for
camera body repair .............................................. 90
6-3. CAMERA BODY ................................................... 91
6-4. R CABI ................................................................. 92
6-5. Internal parts ........................................................ 93
6-5-1. US/CA-model .......................................... 93
6-5-2. EU/EG/GE/AS-model .............................. 94
6-5-3. JP-model ................................................. 95
6-6. List of parts related to exterior .............................. 96
6-6-1. TOP COVER 1 ........................................ 96
6-6-2. TOP COVER 2 ........................................ 97
6-6-3. TOP COVER 3 ........................................ 98
6-6-4. CAMERA BODY External ....................... 99
6-7. Electrical parts .................................................... 100
7. Appendix..................................................... 101
7-1. List of Related Technical Updates Issued .......... 101

4
1. General FinePix S3Pro Service Manual
1. General
1-1. Product specification
System
Model Digital camera FinePix S3 Pro
Effective pixels 12.34 million (S-pixel: 6.17 million, R-pixel: 6.17 million) pixels
CCD Large-format (23.0
× 15.5 mm) Super CCD SR II with primary color filter
Total 12.9 megapixels (S-pixels: 6.45 million; R-pixels: 6.45 million)
Storage media xD-Picture Card (16/32/64/128/256/512 MB)
CF card and Microdrive TM (FAT32-compatible) (Compatibility is listed on Fujifilm website:
http://home.fujifilm.com/products/digital/)
File format DCF-compliant
Compressed: Exif Ver.2.21 JPEG, DPOF-compatible
Uncompressed: CCD-RAW (RAF)*1
Max. recording resolution 4256
× 2848 (12.1 million)
Number of recorded pixels 4256
× 2848 pixels/3024 × 2016 pixels/2304 × 1536 pixels/1440 × 960 pixels
Lens mount Nikon F mount (with AF coupling and AF contacts)
Focal length Approx. 1.5
× the nominal focal length of the lens (35mm camera equivalent)
Sensitivity ISO 100/160/200/400/800/1600 *2
Metering modes TTL open metering/3D 10-zone Matrix, Center-weighted, Spot
Exposure control Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure
Exposure compensation -3.0 EV to +3.0 EV 1/2 EV step
Shutter Electronically controlled vertical-travel focal-plane shutter
Shutter speeds 30 to 1/4000 sec, Bulb X contact: Max. 1/180 sec. *3
Continuous shooting Max. 2.5 frames/sec.:
Up to max. 12 frames. (D-range: Standard; JPEG mode)
Up to max. 7 frames. (D-range: Standard; RAW mode)
Max. 1 frame/sec.:
Up to max. 6 frames. (D-range: Wide; JPEG mode)
Max. 1.4 frames/sec.: Up to max. 3 frames. (D-range: Wide; RAW mode)
Auto bracketing ±0.5 EV, ±1.0 EV, ±1.5 EV, ±2.0 EV,
Focus Mode: Single-AF servo, Continuous AF servo, Manual
AF system: TTL phase difference detection with auxiliary AF flash
AF frame selection: Single-area AF, Dynamic AF (Dynamic AF Mode with Closest Subject
Priority is available)
White balance Automatic scene recognition/Preset (Fine, Shade, Fluorescent (Daylight), Fluorescent
(Warm White), Fluorescent (Cool White), Incandescent, Custom (2 settings)
Self-timer 20 sec./10 sec./5 sec./2 sec.
Flash Manual pop-up, D-3D Multi-BL flash control, D Multi-BL flash control, Standard D-TTL
flash control
Guide No.: 12 (ISO 100-m); Sync. shutter speed: 1/180 sec. or slower
Flash modes Front Synchro, Slow Synchro, Rear synchro, Red-eye Reduction and Red-eye Reduction
Slow Synchro, suppressed flash
Accessory shoe Standard ISO-type with hot-shoe contact (Safty lock provided)
Synchro contacts X contacts only, synchronizing speed: 1/180 sec. or slower
Synchro terminal Equipped with ISO 519 synchro terminal as standard, lock screw provided
Viewfinder Eye-level pentaprism (coverage: Approx. 93% vertical, approx. 95% horizontal), dioptric
adjustment mechanism, viewfinder magnification approx. 0.8
× )
LCD monitor 2.0-inch 235,000-pixels low-temperature polysilicon TFT color LCD panel (approx. 100%
coverage for playback)
Remote release Release socket built into the shutter release button
10-pin remote release terminal provided on camera body front
Photography functions Color space selection, dynamic range selection, film simulation mode selection, framing
guideline, frame no. memory, multiple-exposure shooting, shutter button for vertical
shooting, live image
Playback functions Trimming, Auto Play, multi-frame playback, histogram display, brightness warning display
Other functions PictBridge compatibility, Exif Print compatibility, PRINT Image Matching II compatibility,
language selection (Japanese, English, French, German, Spanish, Italian, Chinese),
discharging function

5
1. General
FinePix S3Pro Service Manual
Power Supply and Others
Power supply Use one of the following:
• 4×AA-size Ni-MH (Nickel-Metal Hydride) batteries
• AC Power Adapter AC-5VX (sold separately)
Dimensions and weight Camera body dimensions: 147.8 mm ×135.3 mm ×78.5 mm/5.8 in. ×5.3 in. × 3.1 in.
(W ×H ×D)
(excluding lens and attachments)
Camera body weight: 815 g/28.7 oz (excluding lens, batteries and recording media)
Weight when shooting: Dependent on the lens used
Operating conditions Temperature: 0oC to +40oC. (+32oF to +104oF)
*Note that the range for Microdrive is +5oC to +40oC (+41oF to +104oF).
Humidity: 80% or less (no condensation)
According to the CIPA (Camera & Imaging Products Association) standard procedure for
measuring digital still camera battery consumption (extract):
When using Ni-MH batteries, use the batteries supplied with the camera. The storage
media should be xD-Picture Card.
Shots taken at 23oC, one shot every 30 seconds using a 50mm AF1.4D lens with 1-time
AF operation, full flash for every other shot, the camera turned off/on every 10 shots and
auxiliary AF lighting turned off.
• Note: Because the number of available shots varies depending on the level of charge in
Ni-MH batteries, the figures shown here for the number of available shots using
batteries are not guaranteed.
The number of available shots will also decline at low temperatures.
Accessories zAA-size Ni-MH Batteries (HR-AA) (4)
zBattery charger BCH-NH2 (1)
* Plug-in and cord-attached types are provided depending on the intended country of use.
zStrap (1) zAccessory shoe cover (1) Fitted on the camera body
zEyepiece cap (1) zLCD cover (1) Fitted on the camera body
zCamera body cap (1) Fitted on the camera body
z
Video cable (1) (approx. 1.5 m (4.9ft.), mini-plug (3.5 mm-dia.) to pin-plug cable)
zIEEE 1394 4-pin to 6-pin cable (1) (approx. 1.5 m (4.9ft.))
zUSB cable (mini-B) (1) zCable holder (1) zClamp filter (1)
zSynchronizing terminal cap (1) Fitted on the camera body
zRemote release socket cap (1) Fitted on the camera body
zBattery holder (1) Fitted on the camera body
zCD-ROM: Software for FinePix AX (1)
zOwner’s Manua (1) zSoftware Quick Start Guide (1)
Optional accessories zxD-Picture Card
DPC-16 (16 MB)/DPC-32 (32 MB)/DPC-64 (64 MB)/DPC-128 (128 MB)/
DPC-256 (256 MB)/DPC-512 (512 MB)
zAC Power Adapter AC-5VX
zFujifilm Rechargeable Battery 2HR-3UF
zFujifilm Battery Charger with Battery BK-NH2 (With Euro type or UK type plug)
zImage Memory Card Reader DPC-R1
• Compatible with Windows 98/98 SE, Windows Me, Windows 2000 Professional,
Windows XP or iMac, Mac OS 8.6 to 9.2.2, Mac OS X (10.1.2 to 10.2.2) and
models that support USB as standard.
• Compatible with xD-Picture Card of 16 MB to 512 MB, and SmartMedia of 3.3 V,
4 MB to 128 MB.
zPC Card Adapter DPC-AD
• Compatible with xD-Picture Card of 16 MB to 512 MB, and SmartMedia of 3.3 V,
2 MB to 128 MB.
zCompactFlash Card Adapter DPC-CF
• Windows 95/98/98 SE/Me/2000 Professional/XP
• Mac OS 8.6 to 9.2/X (10.1.2 to 10.1.5)
zxD-Picture Card USB Drive DPC-UD1
• Compatible with xD-Picture Card of 16 MB to 512 MB
• Windows 98/98 SE/Me/2000 Professional/XP
• Mac OS 9.0 to 9.2/X (10.0.4 to 10.2.6)
zHyper-Utility Software HS-V2 Ver.3.0
Guide to the number
of available frames
for battery operation
Ni-MH batteries 2300 mAhApprox. 400 frames
Battery Type With LCD monitor ON

6
1. General FinePix S3Pro Service Manual
Input/Output Terminals
Video output NTSC/PAL selectable
Digtal Interface USB 2.0 (High-speed), IEEE 1394
DC input Socket for specified AC Power adapter AC-5VX (sold separately)
*1: CCD-RAW is a format specific to the FinePix S3 Pro. The enclosed “FinePixViewer” software or the optional
Hyper-Utility software “HS-V2 Ver. 3.0” is required to interpret the images.
*2: Images shot in high-sensitivity photography (ISO 400 or higher) may appear coarse and may also be affected
by noise such as white dots.
*3: Images shot with long exposures (about 4 second or longer) may appear coarse and may also be affected by
noise such as white dots.
Standard Number of Available Shots per Media
The number of available shots varies slightly depending on the type of subject. Also, the discrepancy between the actual
number of available shots and the standard number grows as the capacity of the media increases.
For CCD-RAW files, “ ” is displayed as the resolution.
Quality Mode
Image File Size
DPC-16 (16 MB)
DPC-32(32MB)
DPC-64 (64 MB)
DPC-128 (128 MB)
FINE
Number of recorded
pixels
4256 2848 1440 9603024 20162304 1536
DPC-256 (256 MB)
DPC-512 (512 MB)
Approx.
4.7 MB
13
26
6
3
53
107
NORMAL
Approx.
2.4 MB
26
53
13
6
107
214
FINE
Approx.
3.0 MB
21
42
10
5
85
170
NORMAL
Approx.
1.5MB
42
84
20
10
169
339
FINE
Approx.
1.7 MB
36
72
17
8
146
292
NORMAL
Approx.
880 KB
72
144
35
17
290
580
FINE
Approx.
1MB
61
122
30
14
245
491
NORMAL
Approx.
520 KB
120
241
59
29
484
967
Microdrive (340 MB) 73 146 116232200 396 338 671
Microdrive (1GB) 220 437
D-RANGE
WIDE
HIGH
CCD-RAW
Approx.
25 MB
01
12
24
59
1019
2039
1327
4181
D-RANGE
STANDARD
Approx.
13 MB
349 698 597 1173 9951932

7
1. General
FinePix S3Pro Service Manual
1-2. Explanation of Terms
Adobe RGB (1998) A color space introduced as the working color space for Adobe Photoshop 5.0.
AdobeRGB encompasses almost all the colors reproduced by CMYK printers and is
intended primarily for printing applications. It was introduced as “SMPTE-240E” in the
RGB settings in Adobe Photoshop 5.0 and as “Adobe RGB (1998)” in the profile settings
from version 6.0 onwards.
CCD-RAW This is the image data prior to signal processing (the reconstruction of the data read in
from the CCD as an image). Because the signal processing is performed on the com-
puter, high levels of control are possible.
• To reconstruct images, FinePixViewer (on the enclosed CD-ROM) or the Hyper Utility
(optional) must be installed on your computer.
Color space Refers to the range of colors, expressed as two-dimensional or three-dimensional
numerical values, that can be reproduced by devices such as cameras, monitors and
printers. The sRGB and AdobeRGB color spaces are each shown as an xy color chart (a
coordinate color space in which colors are represented in two dimensions with no
brightness value). The range of colors that can be expressed by a particular color space
is indicated by a triangle imposed on the xy color chart. Colors become brighter as they
approach the outer edge of the xy color chart. This color representation method is
capable of showing all the actual colors.
Color Temperature Low-temperature light sources, such as a candle flame, are strongly red, while high-
temperature light sources, such as a gas burner flame, are strongly blue. The color of
the light for these temperatures is expressed as a color temperature (K = Kelvin). The
light of the sun at midday in a completely clear sky is taken to be 5500K.
EV: A number that denotes Exposure Value. The EV is determined by the brightness of the
subject and sensitivity (speed) of the film or CCD. The number is larger for bright
subjects and smaller for dark subjects. As the brightness of the subject changes, a
digital camera maintains the amount of light hitting the CCD at a constant level by
adjusting the aperture and shutter speed.
When the amount of light striking the CCD doubles, the EV increases by 1. Likewise,
when the light is halved, the EV decreases by 1.
JPEG: Joint Photographic Experts Group
A file format used for compressing and saving color images. The higher the compression
rate, the greater the loss of quality in the decompressed (restored) image.
White Balance: Whatever the kind of the light, the human eye adapts to it so that a white object still
looks white. On the other hand, devices such as digital cameras see a white subject as
white by first adjusting the color balance to suit the color of the ambient light around the
subject. This adjustment is called matching the white balance.
Exif Print: Exif Print Format is a newly revised digital camera file format that contains a variety of
shooting information for optimal printing.

8
1. General FinePix S3Pro Service Manual
1-3. Names of External Components
AF-assist illuminator
Self-timer lamp
Red-eye reduction lamp
Accessory shoe
Accessory shoe cover
Power switch
Sub-command dial
Depth of field check button
Shutter button for
vertical shooting
Strap mount
Flash exposure compensation
button
Exposure compensation button
Top display panel
LCD illuminator button
Shutter button
Release mode switch
unlock button
Exposure mode dial
Release mode switch
Synchronizing
terminal cap
Synchronizing terminal
Lock lever for vertical shooting

9
1. General
FinePix S3Pro Service Manual
Tripod mount
Slot cover
unlock button
Main-command dial
Access lamp
4-direction button
lock switch
MENU/OK button
BACK button
xD-Picture Card slot
CF / Microdrive
eject button
CF / Microdrive slot
Slot cover
4-direction button
AE-L/AF-L button
Metering system selector dial
PLAY button
FUNCbutton
F1 button
F2 button
F3 button
F4 button
LCD monitor
Rear display panel
Synchro mode button
A
uto Exposure Bracketing
button
Diopter adjustment knob
Rubber eyecup
Viewfinder

10
1. General FinePix S3Pro Service Manual
Flash pop-up button
Focus mode selector switch
Battery holde
r
release catch
Lens release button
Strap mount
Flash
USB socket (mini-B)
Battery holde
r
IEEE 1394 socket
VIDEOOUT (Video output)
socket
DC IN 5V (power input) socket
Terminal cover
Digital terminal cove
r
Remote release socket
(10-pinterminal)
Remote release socket cap

11
2. Disassembly
FinePix S3Pro Service Manual
2. Disassembly
2-1. Names of internal Components
SW PWB ASSY
LCD MONITOR
REAR FRAME
RELESE HOLDER CONST
10Pin TERMINAL ASSY
CCD UNIT
BOTTOM FRAME ASSY
CCD PWB ASSY
BATT HOLDER
BATT CART ASSY
CAMERA BODY ASSY
DOT MATRIX LCD
MAIN PWB ASSY
R CABI ASSY

12
2. Disassembly FinePix S3Pro Service Manual
1
3
3
3
1
2
4
3
5
2-2. Removing the BATT CART ASSY
(1) Unlock the battery holder by turning the lock lever and
pull out the BATT CART ASSY.
2-3. Removing the R CABI ASSY
(1) Open the CARD COVER.
(2) Open the DIGITAL TERMINAL COVER.
(3) Remove the 16 screws (N-MS2M 1.7 x 3.0 BA).
(4) Remove the R CABI ASSY in the direction of the arrow.
(5) Remove the MAIN-SW FPC from the connector (SW
PWB ASSY CN 102).
[Notes on assembling the R CABI ASSY]
1. Ensure that the FPC is not inserted on an angle and
that it is fully inserted before locking.
2. Confirm the IEEE1394 JACK is correctly matched to
the hole of R CABI ASSY.
3. Ensure that there are no gaps
between the CAMERA BODY
ASSY and R CABI ASSY after
assembly.

13
2. Disassembly
FinePix S3Pro Service Manual
2
1
3
4
2-4. Removing the SW PWB ASSY
(1) Remove the FPC at 3 points.
(2) Remove the wire harness at 1 point.
(3) Remove the EMI SHEET 10 FPC in the direction of the
arrow.
(4) Remove the EMI SHEET 10 CNN in the direction of the
arrow.

14
2. Disassembly FinePix S3Pro Service Manual
5
6
7
Hook
(5) Remove the 3 screws (BT2M 1.7 x 4.0 B).
(6) Remove the REAR FRAME in the direction of the
arrow.
(7) Remove the SW PWB ASSY in the direction of the
arrow.
[Notes on assembling the SW PWB ASSY]
1. Check that the top edge of the SW PWB ASSY is
engaged with the hook on the R CABI ASSY side.
2. Take care to avoid inserting the FPC on an angle and
ensure that it is fully inserted before locking.
3. Ensure that there are no gaps between the CABI
after assembly.

15
2. Disassembly
FinePix S3Pro Service Manual
2
1
1
1
2
2-5. Removing the LCD
(1) Remove the DOT MATRIX LCD in the direction of the
arrow.
(2) Remove the LCD MONITOR in the direction of the
arrow.
2-6. Removing the 10-pin TERMINAL ASSY
(1) Remove the 10-pin TERMINAL ASSY in the direction of
the arrow.
2-7. Removing the BATTERY HOLDER
(1) Remove the wire harness from the connector (MAIN
PWB ASSY CN 600).
(2) Remove the BATTERY HOLDER in the direction of the
arrow.

16
2. Disassembly FinePix S3Pro Service Manual
1
3
2
5
6
7
8
4
8
8
9
Hook
2-8. Removing the MAIN PWB ASSY
(1) Remove the FPC from the connector (MAIN PWB
ASSY CN 101).
(2) Remove the 2 screws (BT2M 1.7 x 4.0 B).
(3) Remove the RELEASE HOLDER CONST in the
direction of the arrow.
(4) Remove the wire harness (CAMERA BODY) from the
connector (MAIN PWB ASSY CN 700).
(5) Remove the MAIN-CCD FPC from the connector
(MAIN PWB ASSY CN 100).
(6) Remove the wire harness (CAMERA BODY) from the
connector (MAIN PWB ASSY CN 104).
(7) Remove the FPC (CAMERA BODY) from the connector
(MAIN PWB ASSY CN 103).
(8) Remove the 6 screws (MS2M 1.7 x 3.0 N).
(9) Remove the MAIN PWB ASSY in the direction of the
arrow.
[Notes on assembling the MAIN PWB ASSY]
Check that the notch in the CARD SLOT side of the
MAIN PWB ASSY is engaged with the hook on the
CAMERA BODY.

17
2. Disassembly
FinePix S3Pro Service Manual
1
4
3
2
2-9. Removing the CCD PWB ASSY and CCD UNIT
(1) Remove the SHIELD SHEET.
(2) Remove the 3 screws (CCD PWB SCREW).
(3) Remove the EMI SHEET L in the direction of the arrow.
(4) Remove the EMI SHEET R in the direction of the arrow.

18
2. Disassembly FinePix S3Pro Service Manual
6
5
8
7
(5) Remove the solder on the CCD PWB ASSY (36
locations).
(6) Remove the CCD PWB ASSY in the direction of the
arrow.
(7) Remove the 4 screws (M 1.2 x 2.4 C).
(8) Remove the CCD UNIT in the direction of the arrow.

19
2. Disassembly
FinePix S3Pro Service Manual
2-10. How to dismantle the parts around the outer wrappings
2-10-1. Removing TOP COVER UNIT
Remove in the order indicated by circled numbers.
<Step 1>
(1) Remove the lens cap.
(2) Remove A/M COVER PLATE.
(3) Remove one screw.
(4) Remove A/M CHANGE LEVER.
(5) Remove two screws.
(6) Remove two screws.
(7) Remove four screws.
(8) Remove FRONT COVER BLACK in the direction of
the arrow.
(9) Remove FRONT CABINET UNIT in the direction of
the arrow.
(10) Remove four screws.
(11) Remove the MAIN FRAME.
1
2
3
8
11
7
9
6
4
5
10
10
7
13
13
13
13
15
Black:
12
14
<Step 2>
(12) Do the lens cap.
(13) Remove five screws.
(14) Float TOP COVER UNIT in the direction of the arrow.
(15) Remove one screw.
Revised: 1. Dec. 2004

20
2. Disassembly FinePix S3Pro Service Manual
16
A
17
Blue:
Red:
White:
Black:
Pink:
Light Blue:
17
18
18
18
18
18
18
Brown:
18
<Step 3>
(16) Remove FPC from the TOP COVER side, and
remove TOP COVER UNIT to the grip side.
* As for the grip side, the harness is stopped with solder.
<Step 4>
(17) Peel off the insulation tape then discharge the MAIN
CONDENSER before remove the wiring harnesses.
(18) Remove six harness, and remove TOP COVER
UNIT completely.
[ Notes of assembly of TOP COVER UNIT ]
Hang part A inner EYE PIECE BARREL UNIT.
And, build in TOP COVER UNIT.
Revised: 1. Dec. 2004
