Fujioh FR-HT2170V Manual

Cooker Hood
Operating / Installation Manual
FR-HT2190V
FR-HT2170V
Please read this manual carefully
before using this appliance.

Content
SAFETY INSTRCUTION...................................................................................... 1
INSTALLATION......................................................................................................4
START USING YOUR COOKER HOOD...........................................................9
TROUBLESHOOTING........................................................................................10
MAINTENANCE AND CLEANING....................................................................11
ENVIRONMENTAL PROTECTION.................................................................. 13
LIST OF INCLUDED ITEMS..............................................................................14
CIRCUIT DIAGRAM............................................................................................ 15
INFORMATION FOR LAMP.............................................................................. 15
SPECIFICATION..................................................................................................15
目录
安全指引................................................................................................................ 16
安装........................................................................................................................ 18
开始使用吸油烟机................................................................................................ 23
故障排除................................................................................................................ 24
维修及清洁............................................................................................................ 24
环境保护................................................................................................................ 26
包含物品清单........................................................................................................ 28
电路图.................................................................................................................... 29
灯具信息................................................................................................................ 29
规格........................................................................................................................ 29
目錄
安全指引................................................................................................................ 30
安裝........................................................................................................................ 32
開始使用吸油煙機................................................................................................ 37
故障排除................................................................................................................ 38
保養及清潔............................................................................................................ 38
環境保護................................................................................................................ 40
包含物品清單........................................................................................................ 42
電路圖.................................................................................................................... 43
燈具資料................................................................................................................ 43
規格........................................................................................................................ 43

1
SAFETY INSTRCUTION
This manual explains the proper installation and use of your cooker
hood, please read it carefully before using even if you are familiar with
the product.
The manual should be kept in a safe place for future reference.
Never to do:

Do not try to use the cooker hood without the grease filters or if the
filters are excessively greasy!
Do not install above a gas hob with a high level
grill.
Do not leave frying pans unattended during use
because overheated fats or oils might catch fire.
Never leave naked flames under the cooker
hood.
If the cooker hood is damaged, do not attempt to use.
Do not flambé under the cooker hood.
CAUTION: Accessible parts may become hot when used with
cooking appliances.
The minimum distance between the supporting surface for the
cooking vessels on the hob and the lowest part of the cooker hood.







(When the cooker hood is located above a gas appliance, this
distance shall be at least5 cm)
The air must not be discharged into a flue that is used for
exhausting fumes from appliances burning gas or other fuels.
Cooker hoods and other cooking fume
extractors may adversely affect the safe
operation of appliances burning gas or other
fuels (including those in other rooms) due to
back flow of combustion gases. These
gases can potentially result in carbon

2
monoxide poisoning. After installation of a cooker hood or other
cooking fume extractor, the operation of open flued gas appliances
should be tested by a competent person to ensure that back flow of
combustion gases does not occur.
Always to do:
Important! Always switch off the electricity supply at the mains
during installation.
The cooker hood must be installed in accordance with the
installation instructions and all measurements followed.
All installation work must be carried out by a competent person or
qualified electrician.
Please dispose the packing material carefully. Children are
vulnerable to it.
Pay attention to the sharp edges inside the cooker hood especially
during installation and cleaning.
Make sure the ducting has no bends sharper than 90 degrees as
this will reduce the efficiency of the cooker hood.
WARNING: Failure to install the screws or fixing device in
accordance with these instructions may result in electrical hazards.
WARNING: Before obtaining access to terminals, all supply circuits
must be disconnected.
Always put lids on pots and pans when cooking on a gas cooker.
When in extraction mode, air in the room is being removed by the
cooker hood.
Please make sure that proper ventilation measures are being
observed. The cooker hood removes odours from room but not
steam.
This cooker hood is for domestic use only.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.

3
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
CAUTION: The appliance and its accessible parts can become hot
during operation. Be careful to avoid touching the heating elements.
Children younger than 8 years old should stay away unless they are
under permanent supervision.
There shall be adequate ventilation of the room when the cooker
hood is used at the same time as appliances burning gas or other
fuels.
There is a fire risk if cleaning is not carried out in accordance with
the instructions.
Regulations concerning the discharge of air have to be fulfilled.
Clean your appliance periodically by following the method given in
the chapter MAINTENANCE.
For safety reason, please use only the same size of fixing or
mounting screw which are recommended in this
operating/installation manual.
Regarding the details about the method and frequency of cleaning,
please refer to maintenance and cleaning section in the
operating/installation manual.
Cleaning and user maintenance shall not be made by children
without supervision.
When the cooker hood and appliances supplied with energy other
than electricity are simultaneously in operation, the negative
pressure in the room must not exceed 4 Pa (4 x 10-5 bar).
WARNING: Danger of fire: do not store items on the cooking
surfaces.
A steam cleaner is not to be used.

4
Never try to extinguish a fire with water, but switch off the appliance
and then cover flame e.g. with a lid or a fire blanket.
INSTALLATION
MOUNTING OF THE V-FLAP
If the cooker hood does not have an assembled V-flap 1, you should
mount the half-parts to its body. The images only show an example of how
to mount the V-flap, because the outlet may vary according to different
models and configurations.
To mount the V-flap 1 you should:




Mount two half-parts 2 into the body 6;
The pin 3 should be top oriented;
The axis 4 should be inserted into the holes 5 on the body;
Repeat all the operations for the 2nd half-part.
INSTALLATION
If you have an outlet to the outside, your cooker hood can be connected
as below picture by means of an extraction duct (enamel, aluminum,
flexible pipe or non-flammable material with an interior diameter of 150mm).

5
1. Before installation, turn the unit off and unplug it from the outlet.
2. The cooker hood should be placed at a distance ofPRUHWKDQFP
DQGOHVVWKDQFPIURPWKHcooking surface for best effect. See Pic 1.
3. After determining the installation height, drill 7φ8 holes on a suitable
place and then insert the attached plastic expansion pipes into the hole.
Fix the hanging bracket on the wall with 3pcs ST4x40 screws and keep it
in line. Install the duct cover fixing bracket on the wall with 2pcs ST4x40
Pic 1

6
screws. The fixed position of the duct cover fixing bracket is the highest
place of slide duct cover. See Pic 2.
4. Fix the flexible tube duct on the cooker hood. See Pic 3.
5. Put the slide duct cover into the duct cover, and be sure that the slide
duct cover can be adjusted the height in it freely. See Pic 4. Note: The
flexible tube duct is not included in the product.
6. Put the cooker hood on the hanging bracket and fix it with 2pcs ST4x30
wood screws. See Pic 5.
Note: The 2woodscrews are positioned on the main unit back housing,
with a diameter of 6mm.
7. Adjust the height of the slide duct cover to the position of the duct cover
fixing bracket and fix it with 2pcs ST4x8 screws, then fix the duct cover
with 2pcs ST4x8 screws. See Pic 6.

7
8. Put on the magnetic ring rubber sleeve. See Pic 7.
9. Hang the oil guide plate on two U-shaped hooks. See Pic 8.
10. Install the oil tray. See Pic 9.

8
HINTS FOR EXHAUST DUCT INSTALLATION
The following rules must be strictly followed to obtain optimal air extraction:
Keep flexible tube duct short and straight.
Do not reduce the size or restrict the flexible tube duct.
When using the flexible tube duct always install the pipe pulled taut to
minimize pressure loss.
Failure to observe these basic instructions will reduce the
performance and increase noise level of the cooker hood.
Any installation work must be carried out by a qualified electrician or
competent person.
Do not connect the ducting system of the hood to any existing
ventilation system which is being used for any other appliance ,such
as warmer tube, gas tube , hot wind tube.
The angle of the bend of the flexible tube duct should not be less than
90 ° ; you must direct the pipe horizontally, or, alternatively, the pipe
should go up from the initial point and should be led to an outer wall.
After the installation, make sure that the cooker hood is installed
correctly to avoid grease collection at on end.
Ensure the flexible tube duct selected for installation complies with
relevant standards and is fire retardant.

9
Warning For safety reason, please use only the same size of
fixing or mounting screws which are recommended
in this instruction manual.
Failure to install the screws or fixing device in
accordance with these instructions may affect the
use of range hood.
START USING YOUR COOKER HOOD
Touch control with LED display
Timer Lamp Speed Power
1. Press the “Power” button, the button control the “on” & “off ” of the hood.
2. Press the button “Speed” time after time, the motor runs as low / mid /
high / low mid … , the speed runs circularly; and the LED display will
indicate as 1-2-3-1-2…circularly.
3. Press “Lamp” button, the light is on, press this button again, the light is
off. Please note the Lamp is not under control of the on/off button.
4. When the hood is working, if press the “Timer” button, the hood will go
into the status of acquiescent working (acquiescent time is 9mins), and
then, LED display will be shown 9.8.7.6 ...decreasing by 1,when time is up,
Led display

10
the hood will be off automatically and the lamp will extinguish. If pressing
“Timer” button, the hood will go in or go out “Timer” function.
TROUBLESHOOTING
Fault
Possible Cause
Solution
Light on, but motor
does not work.
Fan switch turned off.
Select a fan switch position.
Fan switch failed.
Contact service center.
Motor failed.
Contact service center.
Light does not work,
motor does not work.
House fuses blown.
Contact service center.
Mains power cable is
loose or disconnected.
Contact service center.
Oil leakage.
One way valve and
the outlet are not
tightly sealed.
Contact service center.
Leakage from the
connection of chimney
and cover.
Contact service center.
Lights does not work.
Broken or faulty bulbs.
Contact service center.
Insufficient suction.
The distance between
the cooker hood and
the gas top is too far.
Contact service center.
The Cooker hood
inclines.
The fixing screw is not
tight enough.
Contact service center.
NOTE:
Any electrical repairs to this appliance must conform to your
local, state and federal laws. Please contact the service centre
if in any doubt before undertaking any of the above actions.
Always disconnect the unit from the power source when
opening the unit.

11
MAINTENANCE AND CLEANING
Caution:
Before maintenance or cleaning is carried out, the
cooker hood should be disconnected from the
mains power supply. Ensure that the cooker hood
is switched off at the wall socket and the plug
removed.
External surfaces are susceptible to scratches and
abrasions, so follow the cleaning instructions to
ensure the best possible result without damage.
GENERAL
Cleaning and maintenance should be carried out only when the appliance
is cooled after use especially.
Avoid leaving alkaline or acids substances (lemon juice, vinegar etc.) on
the surfaces.
STAINLESS STEEL
The stainless steel must be cleaned regularly (e.g. weekly) to ensure a
long life expectancy. Dry with a clean soft cloth after cleaning. A
specialized stainless steel cleaning fluid may be used.
NOTE:
Ensure that wiping is done along with the grain of the stainless steel to
prevent any unsightly crisscross scratching patterns from appearing.
CONTROL PANEL SURFACE
The inlay control panel can be cleaned using warm soapy water. Ensure
the cloth is clean and well wrung before cleaning. Use a dry soft cloth to
remove any excess moisture left after cleaning.
THE OIL TRAY
Your cooker hood includes a unique oil tray which collects the oil that
Important
Use neutral detergents and avoid using harsh cleaning chemicals, strong
household detergents or products containing abrasives, as these will affect
the appearance of the appliance and potentially remove any printings on
the control panel and will void manufactures warranty.

12
is deposited on the grease filters.
When the oil tray is about 2/3 full the oil tray needs to be cleaned.
Take away the oil tray as the diagram below shows, by slightly pulling
the oil tray forwards to release it from the Cooker hood.
Discard the oil before cleaning/washing the oil.
Ensure the oil has been cleaned and dried before reattaching to the
Cooker hood.
GREASE FILTER
The filter can be cleaned by hand. Soak them for about 3 minute in water
with a mild detergent and then brush it gently with a soft brush. Do not
apply too much pressure so as to avoid any damage to it . (Leave to dry
naturally out of direct sun light)
Filter should be washed separately to crockery and kitchen utensils. It is
advisable not to use rinse aid.

13
REMOVING GREASE FILTER
1. Hold he oil tray with your hands and pull it back to remove the oil tray,
pour out the oil and clean the oil tray.
2. Open the rectifier panel (note that the oil tray must be removed before
opening the rectifier panel, otherwise it will cause oil stains in the in the oil
tray pour out), remove the screws that fix the filter and remove the filter.
3. Apply the reverse procedure to install the filter back.
ENVIRONMENTAL PROTECTION:
This product is marked with the symbol on the selective
sorting of waste electronic equipment. This means that this
product must not be disposed of with household waste but
must be supported by a system of selective collection in
accordance with Directive 2012/19/EU. It will then be
recycled or dismantled to minimize impacts on the
environment, electrical and electronic products are
potentially dangerous for the environment and human
health due to the presence of hazardous substances. For
more information, please contact your local or regional
authorities.
NOTE:
The following shows how to reduce total environmental impact (e.g.
energy use of the cooking process).
(1) Install the cooker hood in a proper place where there is efficient
ventilation.
(2) Clean the cooker hood regularly so as not to block the airway.
(3) Remember to switch off the cooker hood light after cooking.
(4) Remember to switch off the cooker hood after cooking.
INFORMATION FOR DISMANTLING
Do not dismantle the appliance in a way which is not shown in the user
manual. The appliance can not be dismantled by user. At the end of life,
the appliance should not be disposed of with household waste. Check with
your Local Authority or retainer for recycling advice.

14
LIST OF INCLUDED ITMES
No.
Items name
Drawing
Qty.
1
Main unit
1
2
Rectifier panel
1
3
Oil tray
1
4
Duct cover
1
5
Slide duct cover
1
6
Duct cover fixing bracket
1
7
Hanging bracket
1
8
Plastic expansion pipe
7
9
Wood Screw(ST4x40mm)
5
10
Wood Screw(ST4x30mm)
2
11
Screw(ST4X8mm)
4
12
V-flap
2
13
Magnetic ring rubber sleeve
2

15
CIRCUIT DIAGRAM
INFORMATION FOR LAMP
ILCOS D code for this lamp is:
DSR-1.5/65-S-64
- LED modules - round lamp
- Max wattage: 2x1.5 W
- Voltage range: DC 12V
- Dimensions:
SPECIFICATION
Rated
voltage (V)
Speed
Frequency
(Hz)
Power
consumption (W)
Air flow
(m³/h)
Sound
(dB)
220
Hi
50
244
725
58
Med
194
560
52
Low
167
410
45
230
Hi
50
260
745
59
Med
208
585
53
Low
180
435
47
240
Hi
50
275
760
59
Med
223
615
54
Low
194
460
48
* With 2x1.5W=3W Watts for lamp

16
安全指引
本手册说明了吸油烟机的正确安装和使用方法，即使熟悉产品，也请在使用
前仔细阅读。
本手册应妥善保存，以备日后参考。
切勿进行以下操作：
请勿尝试在未安装过滤网或过滤网油渍过度积油的情况下使用吸油
烟机！
请勿安装在带有高位烤架的炉具上方。
在使用过程中不要远离煎锅，因为油脂过热会燃烧。
切勿将明火留在吸油烟机下。
若吸油烟机损坏，请暂停使用。
请勿在吸油烟机下烘烤食物。
注意：与炊具一起使用时，可触及的部件可能会变热。
灶具上烹饪容器的支撑面与吸油烟机最低部分之间保持最小距离
（当吸油烟机位于燃气器具上方时，此距离应至少为5厘米）。
正确的操作方法：
重要提示：在安装过程中请始终关闭主电源。
必须按照安装说明安装吸油烟机，并随后进行所有测量。
所有安装工作必须由合资格人员或合资格电工进行。
请妥善处理包装材料。远离儿童。
不得将空气排入用于排放燃气或其它燃料器具产生
的烟气的烟道中。由于燃烧气体的回流，吸油烟机
及其它厨房油烟抽取器可能会对使用燃气或其它燃
料的器具（包括其它房间的器具）的安全操作产生
不利影响。这些气体可能会导致一氧化碳中毒。安
装吸油烟机或其它厨房油烟抽取器之后，开放式烟
气器具的操作应由合资格人员进行测试，以确保燃
烧气体不会发生倒流。

17
注意吸油烟机内部的锋利边缘，尤其是在安装和清洁过程中。
确保管道不低于90度的弯曲，因为这会降低吸油烟机的效率。
警告：不按照这些说明安装螺钉或固定装置可能会导致电气危险。
警告：在接触端子之前，所有电源电路必须断开连接。
用燃气灶做饭时，一定要盖好锅盖。
在抽气模式下，房间内的空气也会被吸油烟机排出。请务必遵守适
当的通风措施。吸油烟机可以去除房间内的异味，但不能去除蒸
汽。
此吸油烟机仅供居家使用。
若电源线损坏，则必须由制造商、其服务代理或相关合资格人员更
换，以免发生危险。
本产品可供 8岁及以上儿童和身体、感官或精神上有缺陷或缺乏经
验和知识的人士使用，前提是获得有关安全使用本产品的监督或指
导，并理解其中所涉及的危险。儿童不得玩耍本电器。儿童不得在
无人看管的情况下进行清洁和用户维护工作。
注意：设备及其可触及部件在运行过程中会变热。小心避免接触发
热元件。8岁以下儿童应远离该设备，除非有家长陪同监护。
吸油烟机与使用燃气或其它燃料的器具同时使用时，房间应有足够
的通风。
如不按照说明进行清洁，则有火灾危险。
必须符合有关空气排放的规定。
按照「维护」一章中给出的方法定期清洁电器。
为安全起见，请仅使用本安装及操作手冊中推荐的相同尺寸的固定
或安装螺钉。
有关清洁方法和频率的详细信息，请参阅安裝及操作手册中的保养
及清洁章节。
儿童不得在无人看管的情况下进行清洁和用户维护。
当吸油烟机和非电力能源器具同时工作时，室内负压不得超过4帕
（4×10-5巴）。

18
警告：火灾危险：不要将物品存放在烹饪台面上。
请勿使用蒸汽清洁器。
切勿尝试用水灭火，正确的灭火方法为：关闭设备，然后用盖子或
防火毯等盖住火焰。
安装
V型挡气板的安装
若吸油烟机没有组装的V型挡气板1，则应将半片安装到机身上。图示仅
为安装V型挡气板的示例，由于型号和配置的差异，排放管可能有所不
同。
V形挡气板1的安装步骤如下：
将两个半片2装入机身6；
销钉3应朝上；
将轴4插入机身上的孔5；
第二个半片重复所有操作。
安装
若有一个室外插座，则吸油烟机可以通过排气管（内径为150mm的搪瓷
