PRIMERGY TX200 S3
Dual Socket Intel® Xeon® Server - Cost-efficient
expansion options and failsafe operation Pages 2
PRIMERGY TX Tower Servers ensure carefree and continuous operation with proven data center technology. Their
design for maximum ease of use and ease of management has been honored with industry design awards. The latest
processor generation combined with innovative air flow cooling technology (“Cool-safe”) assure a long life and the
highest possible performance at work. And as your business grows, so do our PRIMERGY towers, providing plenty of
headroom for expansion so that you benefit longer from your investments in PRIMERGY tower servers. For corporate
workgroups and remote sites, PRIMERGY TX servers ensure less troubleshooting and lower costs with their complete
PRIMERGY ServerView Suite remote management functions – flexible management from anywhere at any time. Since
corporate infrastructure is subject to consolidation changes, our universal tower-to-rack conversion kit protects your
investment by prolonging the system’s lifecycle.
The flexible custom supply model and our build-to-order process mean that only fully built and pre-tested solutions are
shipped to customers, who can select from a broad family of tower models to meet their individual needs.
PRIMERGY TX200 S3
Flexible expansion options are the key to placing new or
larger workloads on your server. This applies not only to
physical capacity, such as the number of disk drives,
advanced data protection schemes, or I/O connectivity; in
particular consideration of the transition to 64-bit computing is
a must in today’s technology purchase decisions.
The PRIMERGY TX200 S3 is a perfect match for these
requirements, providing you with a cost-efficient standard.
TX200 is a failsafe operation platform for your application
stacks, with standards such as disk mirroring, hot-plug disks,
SDDC and hot-spare memory and the “Cool-safe™”
innovative air flow system design. Expandability is covering
for heavy workload: up to 16 GB FBD667 memory, up to 6
SCSI, SAS or SATA hard disk drives, and sufficient free PCI
slots for heavy I/O requirements. Your business can rely on
this solution!
In addition, further options – such as extended RAID
functions, clustering options and redundancy for power
supplies and fans – tailor these standards to your individual
safety needs.
Key Features Benefits
Intel Dual- or Quad-Core Xeon 5000 sequence and 2x 2 / 4
/ 2x 4 MB SLC offer outstanding Dual-/Quad-Core
performance and balanced architecture that incorporates
next generation memory and I/O technologies
Higher overall productivity through outstanding Dual-
/Quad-Core performance with faster FSB, larger L2 cache
etc and extended 64-bit address space and therefore
more direct useable memory and performance
Onboard 8-port SAS controller with low-cost ZCR RAID 0,
1, 10, 5, 50 option, or 2-channel U320 SCSI/RAID PCI
controller or 6-port SATA controller with RAID 0, 1 (RAID 5
iButton option) functionality
Hot spare memory
Enhanced data reliability, business continuity right from
the entry-class server, more value for money as well as
added data safety
Up to 6x hot-plug HDD (SAS, SCSI or SATA)
Hot-plug functionality is available as option for the most
important system components: hot-plug, redundant PSU
and system fans, integrated RSB Advanced Pack with e.g.
disable local monitor function (options)
PCIe and PCI-X slots, 1x Gbit LAN
Tailor made availability, offers the security level which is
recommended by your individual application demands
Fast communication link through onboard PCI-Express
interconnect

Datasheet ⏐Issue: April 27, 2007⏐PRIMERGY TX200 S3 Page 2 / 2
All rights, including rights created by patent grant or registration of a utility model or design as well
as rights of technical modifications are reserved. Delivery subject to availability. Designations may
be trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright ©Fujitsu Siemens Computers, 05/2007
Published by
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
Type Dual Socket Tower Server
System board D 2109
Chip set Intel® 5000V
Processors Dual- or Quad-Core Intel® Xeon® (1 - 2)
Frequencies (GHz) 5050 (3.00) / 5060 (3.20), or 5110 (1.60),
5120 (1.86) / 5130 (2.00), 5140 (2.33) Dual-
Core, or E5310 (1,60) E5320 (1.86) Quad-
Core
Front-Side-
Bus/Socket 667 / 1066 / 1333; 1066 MHz (E5310/20)
Second-Level-Cache 2x 2 / 4 (51xx) / 2x 4 MB (E53xx), ECC
Memory 1 GByte bis max. 16 GByte
2-way interleaved, registered ECC PC2-5300F FullyBuffered DIMM
RAM; 3 banks with 2 slots each for modules 512 MB, 1, 2 and 4 GB;
SDDC (Chipkill) and hot-spare memory opt.
Flash-EPROM
Local BIOS update with floppy disk; Remote BIOS-Update via LAN
with Global Flash and service partition
Interfaces
Serial 1 1x RS-232-C (9-pin) (usable for
iRMC or system)
Serial 2 1x RS-232-C (9-pol)
Parallel (option) Centronics, 25-pin, EPP/ECP comp.
Keyboard, Mouse 2x PS/2
USB 2.0 1x front, 2x back (UHCI, 480 Mbit/s)
2x internal for backup drive
Graphics 1x VGA (15-pin)
LAN 1x RJ45, 1x Service-LAN RJ45
Front Panel
On/off button; NMI-, reset button; front LEDs for hard disks access
(green), power (amber/green); front and back for system status
(amber), identification (blue),
Onboard controller **
IDE (ATA100) 1-channel Fast-IDE controller for 1 device
SAS variant (LSI1068) 8-Port SAS controller with RAID 0, 1, 1E (1E
requires 3 or more HDD´s) (also for SATA
HDD´s)
RAID option
(PCI card, ZCR) RAID level 0, 1, 10, 5, 50 extension for
onboard SAS controller
SATA version
(ESB2 onboard) 6-Port SATA Controller with RAID level 0,
1,10; RAID 5 iButton key optional
LAN (Intel® GilGal) 1x 10/100/1000 Mbit/s Ethernet
(PCE-Boot via LAN from PXE server)
Server management Integrated Remote Management Controller
(iRMC) incl. graphics controller, IPMI 2.0
PCI controller ** in SCSI base unit
LSI320/2 2-channel U320 SCSI/RAID 0, 1, 5 controller
with 128 MB SDRAM ECC Cache and TBBU
Hard disk drives 36, 73, 146, 300 Gbyte SAS (no mix with
SATA)
80, 160, 250, 500 Gbyte SATA
36, 73, 146, 300 Gbyte SCSI
1 Gbyte equals one billion bytes when referring to hard disk drive capacity; accessible
capacity may vary.
I/O Slots (Standard)
1x PCIe x8, long; 1x PCIe x8 (x4 wired), long; 2x PCI-X 64-bit/ 100
MHz, 1x long, 3,3V; (1 for ZCR in SAS variant, 1x occupied in SCSI
version) (1x with max. 133 MHz (IOOP™), if only 1 slot is occupied)
(with SAS only 66/100 MHz); 1x PCI 32-bit / 33 MHz, long, 5V
Drive bays
for hard disks 6x 3.5/1-inch, hot-plug, slide-in chassis
for optional SCSI
hard disks 3x 3.5/1-inch, hot-plug, requires
2 bays for accessible drives
for accessible drives 3x 5,25/1,6-inch free or;
2x 5,25/1,6-inch free
1x 5,25/0,5-inch for CD,DVD;
CD-/DVD-RW
1x 3,5/1-inch occupied with FD
System fans
Standard 2 fans
Hot-plug, redundant (option): (2 + 2) fans + 2 fans for CPU`s
Electrical values
1x standard or 2x optional redundant hot-plug power supplies
Output power 600 W / 1 + 1 x 600 W each
Rated voltage range 100 - 240 V
Rated frequency 50 - 60 Hz
Max. rated current 100 V - 240 V / 9.0 A – 5.0 A
Rated current in basic
configuration 100 V - 240 V / 4.4 A - 1.5 A
Active power 798 W
Apparent power 809 VA
Heat emission 2873 kJ/h (2723 btu/h)
Temperature/Noise/Dimension/Weight
Ambient temperature 10°C - 35°C (DIN IEC 721-3-3) class
3K2
Declared noise emission
according to ISO 9296 idle* operating* *(ISO 7779)
LWAd (1 B = 10 dB) : 5,7 B*** 5,8 B***
LpAm (bystander position): 39 dB*** 40 dB***
Floor-stand (HxWxD) 473 x 286 x 775 mm
Rack (HxWxD) 177 x 483 x 770 mm;
Rack mounting depth 735 mm; 4 U
Weight 25 - 40 kg (configuration dependent)
Compliance with Norm and Standards
Product safety
Global IEC 60950-1
Europe EN 60950-1
USA UL 60950-1
Canada CAN/CSA C22.2 No. 60950-1-03
Electro magnetic compatibility
This product and the released accessories, are in compliance with
emission class A. In certain cases measures have to be taken to
reduce the electro magnetic influence to other equipment.
Europe EN 55022 class A, EN 55024,
EN 61000-3-3, EN 61000-3-2
Taiwan / Japan CNS 13438 class A; VCCI class A
Australia / New Zealand AS / NZS CISPR 22 class A
USA / Canada FCC class A
Declaration of conformity
Europe (CE) 89/336/EEC(EMC);73/23 EEC(LVD)
North America FCC class A
Approvals
Product safety
Global CB
Europe CE
USA / Canada CSAUS / CSAC
There is general compliance with the safety requirements of all
European countries and North America. National approvals
required in order to satisfy statutory regulations or for other
reasons, can be applied for on request.
Supported operating systems
Actual release status operating systems: e.g. Windows 2003;
Linux SLES, Linux EL; VMware Infrastructure see PRIMERGY
released OS
http://extranet.fujitsu-
siemens.com/products/primergy/opsys/relcurrsys/osrel_a.html
** For supported controllers (onboard and PCI cards for SCSI,
RAID, LAN, WAN, etc.), please refer to the corresponding system
configurator.
*** only with standard fans and standard PSU
Server Management (see separate data sheets)
Standard: PRIMERGY ServerView Suite;
PDA, ASR&R
Optional: RemoteView, iRMC Advanced Pack
