The Fujitsu SPF200-USB is an all-in-one USB device. Simply
connect it to your USB cable and you have a working fingerprint
sensor! The SPF200-USB is ideal for integrating into devices
where USB is the communication interface such as computer
peripherals and embedded applications. Mount the SPF200-
USB into your device and you have a completed product
without going through the expense of board layout and debug.
Features
▲
Description
▲
• All-in-one Fingerprint module with USB connector.
• Easy to integrate with other devices
• Uses Fujitsu MBF200 Fingerprint Sensor
• Low Power
– 18 milliamps: Operating
– 500 microamps: Standby
• USB 1.1 compatible (to 13 FPS)
• 256 x 300 Pixel Array (50 µm pixel pitch)
SPF200-USB Fingerprint Sensor
• 500 DPI resolution
• 8-bit grayscale (256 gray levels)
• On board A/D Converter
• Programmable gain control for image optimization
• 12.8mm x 15mm image area
• Lead-Free and ROHS compliant parts available
• Windows XP USB signed drivers
Users will no longer be required to remember and enter
cumbersome passwords or PIN codes. Fingerprint authentication
provides a reliable, quick and user friendly alternative to
passwords. The SPF200-USB fingerprint sensor has the USB 1.1
controller logic built right into the sensor, no external hardware is
required. Merely plug the sensor into the USB cable, the power
and data communications is managed by the USB protocol.
(Front view) (Back view)
“Lead Free”
Available

• Computer peripherals – improves security and convenience
• Physical access systems – approval for entry
• Transportation systems – validation of operators, drivers
and inspectors
• Medical equipment – authorization of operator or technician
SPF200-USB Fingerprint Sensor
Applications
▲
Description (continued)
▲
The Fujitsu SPF200-USB fingerprint sensor quickly captures the
image of the fingerprint, analyzes it and compares it to a
previously registered fingerprint template. The Fujitsu SPF200-
USB fingerprint sensor consists of a 256 column x 300 row
array of tiny metal electrodes. Each electrode acts as one plate in
a capacitor and the finger acts as the second plate in a capacitor.
• Kiosks and vending machines – confirmation of person
receiving the selection
• Point of Sale terminals – authentication of tellers and
cashiers
A passivation layer on the surface of the device forms a tough
outer shell, protecting the device from abrasion, chemicals,
moisture and other forms of damage. The SPF200-USB is
manufactured in standard CMOS technology, a mature and
cost effective manufacturing method.
Specifications
▲
FUJITSU MICROELECTRONICS AMERICA, INC.
Corporate Headquarters
1250 E. Arques Avenue, M/S 333, Sunnyvale, CA 94085-5401
Tel: [phone] Fax: [phone]
E-mail: [email protected] Web Site: http://us.fujitsu.com/micro
© 2006 Fujitsu Microelectronics America, Inc.
All company and product names are trademarks or
registered trademarks of their respective owners.
Printed in the U.S.A. BMS-FS-21165-3/2006
Part Number Description Interface
SPF200-USB Standard Part 5-pin Hirose
connector
SPF200-USB-E1 Lead-Free 5-pin Hirose
product connector
• Power: 5 volts DC (from USB)
• Operating Current: 18 milliamps
• Standby Current: 500 microamps
• Fingerprint Sensor: MBF200
• Operating Temperature: 0 to 60°C
• Storage Temperature: -65 to 150°C
• Resolution: 500 DPI, 8-bit grayscale
