Fujitsu ASYG07LMCE User manual

SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
Indoor unit Outdoor unit
CONTENTS
SPECIFICATIONS. . . . . . . . . . . . . . . . . . .1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . 2
REFRIGERANT SYSTEM DIAGRAM. . . . 4
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . 5
ERROR DETECTION . . . . . . . . . . . . . . . .
6
PCB CIRCUIT DIAGRAM . . . . . . . . . . . . .
8
PARTS (INDOOR UNIT) . . . . . . . . . . . . . 9
PARTS (OUTDOOR UNIT) . . . . . . . . . . .16
19
ACCESSORIES . . . . . . . . . . . . . . . . . . .
ASYG07LMCE
ASYG09LMCE
AOYG07LMCE
AOYG09LMCE

SPECIFICATIONS
INDOOR UNIT
OUTDOOR UNIT
CAPACITY
CAPACITY
POWER SOURCE
RUNNING CURRENT
RUNNING CURRENT
MAXIMUM CURRENT
MAXIMUM CURRENT
POWER CONSUMPTION
POWER CONSUMPTION
EER
COP
Heating Cooling
MOISTURE REMOVAL
ASYG09LMCE
AOYG09LMCE
ASYG07LMCE
AOYG07LMCE
2.50 kW
3.20 kW
2.00 kW
3.00 kW
230 V 50 Hz Single phase
3.2 A
3.5 A
6.0 A 6.0 A
7.5 A 7.5 A
0.65 kW
0.73 kW
3.85 kW/kW
4.38 kW/kW
1.3 L/h
2.5 A
3.3 A
0.465 kW
0.685 kW
4.30 kW/kW
4.38 kW/kW
1.0 L/h
750 m3/h
640 m3/h
480 m3/h
310 m3/h
750 m3/h
640 m3/h
520 m3/h
330 m3/h
1,670 m3/h
1,470 m3/h
FAN MOTOR AND FAN REVOLUTION
OUTDOOR UNIT’S Discrimination
MFE-22AVAL
INDOOR UNIT’S Discrimination MFD-12CYBL
High
INDOOR UNIT
Cooling
Medium
Low
Quiet
High
INDOOR UNIT
Heating
Medium
Low
Quiet
High
Medium
Low
Quiet
1,320 rpm
1,160 rpm
930 rpm
680 rpm
1,320 rpm
1,160 rpm
980 rpm
710 rpm
650 rpm
730 rpm
ELECTRICAL DATA
INDOOR UNIT
Cooling
INDOOR UNIT
Heating
OUTDOOR
UNIT Heating
AIRFLOW
High
Medium
Low
Quiet
Cooling
OUTDOOR
UNIT Heating
Cooling
High
Medium
Low
Quiet
INDOOR UNIT
Cooling
INDOOR UNIT
Heating
OUTDOOR
UNIT Heating
NOISE LEVEL
43 dB
40 dB
32 dB
High
Medium
Low
43 dB
38 dB
33 dB
22 dB
Quiet 21 dB
45 dB
Cooling 45 dB
2016.11.21 1
COMPRESSOR TYPE
Hermetic type,
4 pole, 3 phase,
DC inverter motor, Rotary
DISCRIMINATION 5SS072XHA01
PRECHARGED REFRIGERANT
REFRIGERANT TYPE R410A
700 g
700 g
WEIGHT (with oil) 6.0 kg
COMPRESSOR AND REFRIGERANT
Pipe length 15 m
FULL CHARGE 20 m 800 g
MAXIMUM PIPING HEIGHT 15 m
ADDITIONAL CHARGE 20 g/m
WEIGHT
INDOOR UNIT Net / Shipping
Net / Shipping
8.5 kg / 11 kg
OUTDOOR UNIT 21 kg / 25 kg
INDOOR UNIT H x W x D
H x W x D
270 x 870 x 204 mm
OUTDOOR UNIT 535 x 663 x 293 mm
DIMENSIONS

2016.11.21 2
DIMENSIONS
INDOOR UNIT
15.8 to 16.7
Drain hose
Diameter
Outside
Inside : 13.8 mm
600
270 mm
204 mm870 mm

2016.11.21 3
OUTDOOR UNIT
15
663 mm20
293 mm
68
454 mm
535 mm

REFRIGERANT
SYSTEM DIAGRAM
2-way valve
Strainer
Strainer
3-way valve
Muffler
4-way valve Expansion valve
Refrigerant direction
Heat exchanger
(indoor unit)
Heat exchanger
(outdoor unit)
Compressor
Cooling
Heating
Refrigerant pipe diameter
Liquid : 1/4" (6.35 mm)
Gas : 3/8" (9.52 mm)
2016.11.21 4
