DESKPOWER 2000 Series User’s Manual
Fujitsu endeavours to ensure that the information in this document is correct,
but accepts no liability for any error or omission in the same. Any procedures described in
this document for operating Fujitsu products should be read and understood by the
operator before such products are used. To ensure that Fujitsu products function without
risk to safety and health, such procedures should be strictly observed by the operator.
The development of Fujitsu products and services is continuous and published
information may not be up to date. Any particular issue of a product may contain facilities
not described herein. It is important to check the current position with Fujitsu.
Specifications and statements as to performance in this document are Fujitsu estimates
intended for general guidance. They may require adjustment in par ticular circumstances
and should therefore not be taken as formal offers or commitments.
DESKPOWER is a trademark of Fujitsu Limited. The following are registered trademarks of
Microsoft Corporation: MS, MS-DOS, Windows®NT, Windows®for Workgroups, Windows®
98, Window®2000. Pentium®, Celeron and MMX™ technology are trademarks of Intel
Corporation. Award is the registered trademark of Award Software International Inc.
All other products are trademarks or registered trademarks of their respective companies.
© Copyright 2000 Fujitsu Limited. All rights reserved. No par t of this publication may be
copied, reproduced, or translated without the prior written consent of Fujitsu Limited. No
part of this publication may be stored or transmitted in any electronic form without the
written consent of Fujitsu Limited.
© Copyright Fujitsu PC (Asia) Pte Ltd
Fujitsu PC (Asia) Pte Ltd
200 Pandan Loop
#05-03 Pantech 21
The Computer Centre
Singapore 128388
Tel: [phone]
Fax: [phone]
01Carrol_intro i-ix 17/06/2000, 13:491

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions carefully. Save these instructions for future reference.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water.
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing
serious damage to the product.
6. Slotsandopeningsinthecabinetandthebackorbottomareprovidedforventilation;toensure
reliableoperationoftheproductandtoprotectitfromoverheating,theseopeningsmustnotbe
blocked or covered. The openings should never be blocked by placing the product on a bed,
sofa,rug,or othersimilarsurface. Thisproductshould neverbeplaced nearorover aradiator
or heat register, or in a built-in installation unless proper ventilation is provided.
7. This product should be operated from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your dealer or local power company.
8. This product is equipped with a 3-wire grounding-type plug, a plug having a third (grounding)
pin. This will only plug into a grounding-type power outlet. This is a safety feature. If you are
unabletoinserttheplugintotheoutlet,contactyourelectriciantoreplaceyourobsoleteoutlet.
Do not defeat the purpose of the grounding-type plug.
9. Do not allow anything to rest on the power cord. Do not locate this product where persons will
walk on the cord.
10. If an extension cord is used with this product, make sure that the total ampere rating of the
equipmentpluggedintotheextensioncorddoesnotexceedtheextensioncordampererating.
Also,makesurethatthetotalratingofallproductspluggedintothewalloutletdoesnotexceed
15 amperes.
11. Never push objects of any kind into this product through cabinet slots as they may touch
dangerous voltage points that could result in a fire or electric shock. Never spill liquid of any
kind on the product.
12.Donotattempttoservicethisproductyourself,asopeningorremovingcoversmayexposeyou
to dangerous voltage points or other risks. Refer all servicing to qualified service personnel.
01Carrol_intro i-ix 17/06/2000, 13:492

13.Unplugthisproductfromthewalloutletandreferservicingtoqualifiedservicepersonnelunder
the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. Iftheproductdoesnotoperatenormallywhentheoperatinginstructionsarefollowed.Adjust
onlythosecontrolsthatarecoveredbytheoperatinginstructionssinceimproperadjustment
ofothercontrolsmay resultindamageandwill oftenrequireextensivework bya qualified
technician to restore the product to normal condition.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
14. CAUTION.Whenreplacingthebattery,besuretoinstallitwiththepolaritiesinthecorrect
position. There is a danger of explosion if the battery is replaced with an incorrect type
or is mistreated. Do not recharge, disassemble or dispose of in fire. Replace only with
the same or equivalent type recommeded by the manufacturer. Dispose of the used
battery according to the manufacturer’s instructions.
15. Use only the proper type of power supply cord set (provided in your accessories box) for this
unit. It should be a detachable type: UL listed/CSA certified, BS1363,ASTA,SS145 certified,
rated 10A 250V minimum, VDE approved or its equivalent. Maximum length is 15 feet (4.6
meters).
01Carrol_intro i-ix 17/06/2000, 13:493

■Conventions used in this manual
●Warning icons
Various icons and icon/word combinations are used in this manual. They are used to encourage
you to use the equipment safely and correctly in order to prevent danger and damage that may
occurtoyouandpeoplearoundyou. Thefollowingparagraphsdescribewhateachiconlookslike
and what it means. Please ensure you understand the purpose and meaning of each icon before
reading the corresponding instructions.
Indicatesa danger of deathorserious injury if thePC is handled
incorrectlyby ignoring the correspondinginstruction.
Indicatesa danger of injuryorphysical damage if thePC is handled
incorrectlyby ignoring the correspondinginstruction.
In some cases, the following icons are also used along with the above icon/word combinations to
detail the related danger and damage.
Theicon indicates the corresponding instructionhasa nature of
warningor caution. The meaningof thewarning or caution is
symbolizedin the iconand outlinedabove it.
Theicon indicates the corresponding instructionisintended to tell
younot to do something. Themeaningof the instruction issymbolized
inthe icon and outlinedaboveit.
The icon ●indicatesthe corresponding instructionis intendedto tell you
todo something. The meaning oftheinstruction is symbolized inthe
iconand outlined aboveit.
●Representing keys and how to use them
Inthetextofthemanual,keyboardkeysarerepresentedusingonlynecessarycharactersasshown
below rather than describing all the indication on each key top.
Example: [Ctrl] key, [Enter] key, and [→] key
When more than one key is to be pressed simultaneously, they are represented as shown below:
Example: [Ctrl] + [F3] and [Shift] + [↑]
●Representing buttons
Buttons displayed on the screen are enclosed in square brackets, [ and ], as shown below:
Example: [OK]
●Command entries
In the text of the manual, a command is represented as shown below:
diskcopy a: a:
↑ ↑
Ablank(shownwith↑)betweencharactersmeansthatthe[Space]key(longbaronthefrontofthe
keyboard) is to be pressed once. Command names are represented in lower case, but they may
be entered using uppercase letters.
WARNING
CAUTION
01Carrol_intro i-ix 17/06/2000, 13:494

●Conventions used in the text of the manual
The symbols used in the text of the manual have meanings as explained below:
Information necessary to run hardware or software correctly.
Informationonhowtoundoanincorrectoperationorhowtocarryout
troubleshooting.
●Screen display examples
Screendisplaysgiveninthismanualareexamples.Theymaybedifferentfromthedisplays(including
file names) that actually appear on your display unit screen.
●Illustrations
Illustrations given in this manual are examples. They may be different from those which actually
appear on your PC screen, depending on installed options.
●Referencing products
In this manual, products are referred to using their respective abbreviations as explained below:
Windows 98 refers to Microsoft
®
Windows
®
98 operating system.
WindowsNT4.0andWindowsNTrefertoMicrosoft
®
WindowsNT
®
Servernetworkoperatingsystem
Windows 2000 refers to Microsoft
®
Windows
®
2000 operating system.
Version 4.0 and Microsoft
®
Windows NT
®
Workstation operating system Version 4.0.
MS-DOS refers to Microsoft
®
MS-DOS
®
operating system Version 6.2/V.
ICU refers to ISA Configuration Utility.
The terms "your PC," "the PC," "your PC main unit," and "the PC main unit" refer to the
DESKPOWER 2000.
???
Note the following
Help
01Carrol_intro i-ix 17/06/2000, 13:495

■Warning and caution labels
Your PC bears the warning and caution labels as shown below.
Never detach or soil the warning or caution labels.
● Rear surface of the equipment
Electric shock
WARNING
●Before starting to mount or dismount an optional unit for your PC, switch
off the PC and all units linked to it, and unplug them from their respective
outlets.
Otherwise, electric shock may occur.
When removing exterior parts
in order to mount option parts
or others inside the cabinet,
switch off the power supply for
PC unit and peripheral devices
linked with it, and disconnect
the power cable from outlet
before working to avoid risk of
electric shock.
Electric Shock
WARNING
FUJITSU LIMITED
MADE IN JAPAN
UL
FC
DESKPOWER
MODEL FPC-M05AAD
P/N CP019141-01
100-120/200-240V
3.5/1.7A 50/60Hz
K
LISTED
UL1850
7J61
01Carrol_intro i-ix 17/06/2000, 13:496

Chapter 1Installation and Connection
This chapter describes what precautions you should take when
installing your PC and explains how to connect cables.
Before starting to assemble the PC, read this chapter.
Chapter 2Basic Operations
This chapter explains basic operations required to use the PC, such
as how to switch on and off the power and handle storage media.
Be sure to read this chapter.
Chapter 3Troubleshooting
This chapter explains what to do if your PC does not operate as you
expect or if an error message appears.
Read this chapter as required.
Appendix
This appendix describes the name of each component of your PC,
informationrelatedtomaintenanceofthePC,thespecificationofthe
PC main unit, and notices.
Read through this appendix.
Manualconfiguration
01Carrol_intro i-ix 17/06/2000, 13:497

Content
CHAPTER 1
Installation and Connectioon
Where to install...................................................................2
Example of installing the PC...............................................2
Preventing electromagnetic interference with aTV and
radio....................................................................................3
Attaching CRT display unit, keyboard, mouse, and LAN
cables .................................................................................5
Connecting the power cord.................................................6
CHAPTER2
Basic Operation
1 Switching on ..........................................................................8
2 Switching off ..........................................................................9
Switching off the power via Windows 95/98
(onWindows 95/98 models) ...............................................9
Switching off the power via Windows NT
(onWindows NT models) .................................................10
Switching off the power via Windows 2000
(onWindows 2000 models) ..............................................11
3 Reset .....................................................................................12
Soft reset ..........................................................................12
4 Floppy Disk ..........................................................................14
Handling precautions........................................................14
Inserting and removing a floppy disk ................................14
5 CD-ROM................................................................................15
Handling precautions........................................................15
Inserting and taking out a CD-ROM disk..........................16
6 Hard Disk .............................................................................. 17
What is the hard disk? ......................................................17
Handling precautions........................................................17
02Carrol_Content 17/06/2000, 13:498

CHAPTER3
Installing Internal Options
Installation Precautions ....................................................20
ESD Precautions ..............................................................20
Pre-installation Instructions ..............................................20
Post-installation Instructions.............................................21
Installing an expansion card .............................................23
CHAPTER4
Troubleshooting
Trouble information related to the PC main body and
peripheral equipment........................................................26
Trouble information concerning Windows 98 ....................27
APPENDIX
1 Name and Function of Each Component ..........................30
Front of the system unit ....................................................30
Back of the system unit ....................................................32
2 Standard Specifications......................................................34
02Carrol_Content 17/06/2000, 13:499

CHAPTER 1
Installation and
Connection
03Carrol(1-6) 17/06/2000, 13:491

2
1 Installation
Thissection describes countermeasures thatshould be observedwhen installingand using your
PC.
■Where to install
Avoid:
- Any area exposed to moisture, dust, and greasy fumes
- Poorly ventilated areas
- Areas where an open flame is present
- Bathrooms, shower room, and any other area where water may splash on the PC
- Areas exposed to direct sunlight and areas subjected to extreme temperatures, such as near
a heating apparatus
- Areas where the temperature may fall to or go below ˚C
- Areas where you may trip over the power cord
- Areas where there is a strong magnetic field, like near a TV or speaker
- Areas subjected to strong vibration and unstable area like a tilted surface
■Example of installing the PC
You may install your PC as shown below:
Keyboard Mouse
CRT display
PC main unit
03Carrol(1-6) 17/06/2000, 13:492

3
■PreventingelectromagneticinterferencewithaTVandradio
YourPCcomplieswiththeFCCStandardrestrictingelectromagneticinterferencewithTVandradio.
However,itmaycauseinterferencewithaTVandradionearit,dependingonwheretheyareinstalled.
Even in this case, the PC is not defective.
To keep your PC from interfering with TV and radio reception, observe the following:
●Cautions on the PC side
- Do not use the PC with its cover removed.
- Use a specified cable to connect the PC with a peripheral. Do not use an unauthorized cable.
- Afterinstallingacable,makesurethattheconnectorisfixedfirmlyandscrews(ifany)aretight.
- Do not plug the PC in the same outlet as the TV or radio.
●Cautions on the TV and radio side
- Place the TV and radio away from the PC.
- DirectandlocatetheantennasoftheTVandradioinsuchawaythattheinterferenceisminimized.
- Route the antenna line for the TV and radio away from the PC.
- Use coaxial cables as antenna feeders.
Whether the PC and its peripherals interfere with TV and radio reception can be determined by
switchingoffallthePCandtheperipherals. IfitturnsoutthatthePCoraperipheralinterfereswith
TV and radio reception, check the items listed above again.
Ifinterferencestill lingers,contactyour localFujitsuService Centreorthe shopwhereyou bought
your PC or peripheral, and ask for information or help.
03Carrol(1-6) 17/06/2000, 13:493

4
2 Connection
WARNING
●If your device requires grounding, be sure to ground it correctly before
supplying power to the equipment.
Operatingthedevice whileitis improperlygroundedmay leadtoanelectric
shock.
Never connect the grounding wire to a gas pipe.
Failure to observe this precaution may result in fire.
●Before starting to attaching and detaching a CRT display unit, keyboard,
mouse, LAN cables, and power cords, switch off the power to the PC main
unitandanyequipmentconnectedtoitandunplugthemfromtheirrespective
outlets.
Otherwise, electric shock may occur.
●When installing a CRT display unit, keyboard, and mouse, make sure that
they are Fujitsu brand products.
Failure to observe this precaution may result in electric shock, fire and/or
device malfunction.
CAUTION
●Be careful not to connect cables incorrectly.
IfyourPCandperipheralsareconnectedincorrectlyamalfunctionmyoccur.
●IfyourdevicehasaACserviceoutlet,donotconnectanyunitotherthanthe
one specified in the applicable manual to the service outlet.
Failuretoobservethisprecautionmayresultinfireand/ordevicemalfunction.
●DonottouchanycomponentonaPCboardatalocationotherthanspecified.
Failure to observe this precaution may result in injury and/or device
malfunction.
Note the following
Use of a twisted pair cable, which must be purchased separately, is required for connection to a
LAN. No twisted pair cable is included with the package of your PC.
First connect the CRT display unit, keyboard, and power cord to your PC main unit.
Electric shock
Electric shock
Electric shock
Injury
Fire
Failure
03Carrol(1-6) 17/06/2000, 13:494

5
■AttachingCRTdisplayunit,keyboard,mouse,andLANcables
Note the following
The connection explained on this page supplies power to the CRT display unit from the PC main
unit. In this case, the power cord supplied along with the CRT display unit is not used.
Connect the CRT
cable to the PC
main unit.
Attach the CRT
cable connector to
the CRT connector
on the rear of the PC
main unit, and
tighten the
connection screws.
Connect the LAN cable.
Attach one end of a
twisted-pair cable
(purchased separately) to
the LAN connector on the
rear of the PC main unit.
Connect the power cord
to the service outlet.
Attach the plug of the
supplied CRT power cord
to the service outlet of the
PC main unit.
Connect the LAN cable.
Attach the other end of
the twisted-pair cable
(purchased separately) an
appropriate LAN
connector.
Connect the power cord
to the CRT display unit.
Attach the female connector
of the supplied CRT power
cord to the inlet on the rear
of the display unit.
Connect the mouse.
Attach the mouse cable
connector to the mouse
connector (make sure the colors
of the two connectors match)
located on the rear of the PC
main unit while keeping the
arrow imprinted in the mouse
cable connector housing facing
to the right.
Connect the
keyboard.
Attach the keyboard
cable connector to the
keyboard connector
(ensuring the colors of
both connectors
match) on the rear of
the PC main unit while
keeping the arrow
imprinted in the
keyboard cable
connector housing
facing to the right.
03Carrol(1-6) 17/06/2000, 13:495

6
■Connecting the power cord
AfterconnectingtheCRTdisplayunitandotherperipheralstothePCmainunit,connectthepower
cord of the PC main unit to a wall outlet while observing the following precautions.
- Do not plug or unplug the power cord while your hands are wet.
- Do not abuse or remodel the power cord.
- Do not put heavy objects on the power cord and/or stretch, bend excessively, twist, or heat it.
- Do not use your PC if its power cord or plug is damaged or if its receptacle is loose.
- Iftheelectrodesof thepower cordplugortheslots ofthe correspondingreceptaclearesoiled,
wipe them clean with a dry cloth.
- Connect the power cord to a household power source.
Note the following
DonotplugthepowercordofyourPCinamultipleplugbox. Keepthekeyboardandmousecables
from getting entangled with each other.
- Whenanelectricalstormapproaches,disconnectallpowercordsofyourPCfromwalloutlets.
- When disconnecting the power cord, hold its plug housing rather than pulling directly on the
cord.
- Insert the power cord into the outlet until it is seated completely.
- For safety, you should unplug your PC if you do not plan to use it for a long period of time.
Attachthepowercordfemale
connector to the inlet on the
rear of the PC.
Connect the power cord to a power source.
Insert the power cord plug into a wall outlet.
03Carrol(1-6) 17/06/2000, 13:496

CHAPTER 2
Basic Operation
04Carrol(7-18) 17/06/2000, 13:497

8
This section explains how to switch on the power to your PC.
CAUTION
●Onceyouhaveswitchedonthepower,donotmoveanyequipmentfromone
place to another or subject it to shock and/or vibration.
Failure to heed this precaution may result in malfunction of the device.
1 Press the power switch of the CRT display.
At this point, nothing is displayed.
2 Press the power switch of the PC main unit.
The power LEDs of the PC main unit and CRT display
unit activates.
Whenthepowerisswitchedon,thelogo"Fujitsu"appears
on the CRT screen, and the system is activated after a
while. (Power On Self Test (POST) is carried out while
the logo is on the screen.)
Note the following
- IfnothingappearsontheCRTscreen,checkthattheCRTdisplayunitcablehasbeenconnected
securely.
Ifthedisplay areaisnotat thecenterof thescreen,makeadjustments ontheCRTdisplay unit
side.
- If POST detects any abnormal condition, it displays an error message.
- If the CRT display unit power cord is connected to the service outlet of the PC main unit, the
CRTdisplayunitisswitchedonsimultaneouslywiththemainunit. Inthiscase,thepowerswitch
of the CRT display unit can be left in the on position; there is no need to set it to on or off each
time you start or finish using the PC.
Press only the power switch of the PC main the unit next time you use the PC, as described in
step 2, and the CRT display unit will also be switched on.
- When you want to switch on the power immediately after you switched off, or vice versa, just
wait for about 10 seconds.
1 Switchingon
04Carrol(7-18) 17/06/2000, 13:498

9
This section explains how to switch off the power for your PC.
Note the following
- Before switching off the power, exit all applications and save all necessary data.
- Beforeswitchingoffthepower,makesurethattheaccessindicatorLEDsofthefloppyandhard
diskdrivesareoff. IfthepowerisswitchedoffwhentheaccessindicatorLEDsareon,newdata
may be lost and previously saved disk data may be damaged.
- If the power cord is disconnected from the outlet or a power failure occurs while the PC is on,
justre-connect the powercord or waituntil AC powerrecovers. You neednot press thepower
switch. When the power becomes on, the PC starts automatically.
- IfthePChangs, or"PowerButtonBehavior"in "Power"BIOSsettingis setto Sleep/Wake,the
power can be switched off by holding down the power switch for at least four seconds. In this
case, it becomes impossible for other means (such as by LAN) to switch on the power.
■Switching off the power via Windows 95/98
(on Windows 95/98 models)
This section explains how to switch off the power for the PC via Windows 98.
1 Click [Start].
The "Start" menu appears.
2Click [Shut Down].
The following dialog box appears.
3 Select "Shut down the computer?" and click [Yes].
The power is switched off automatically.
2 Switchingoff
04Carrol(7-18) 17/06/2000, 13:499

10
■Switching off the power via Windows NT
(on Windows NT models)
This section explains how to switch off the power for the PC via Windows NT.
1 Click [Start].
The "Start" menu appears.
2 Click [Shut Down].
The following dialog box appears.
3 Select "Shut down the computer?" and click [Yes].
Turn off the power switch.
Note the following
The following procedure can also be used to switch off the power:
1 Press [Ctrl]+[Alt]+[Delete].
The "Windows NT Security" dialog box appears.
2 Click [Shut Down].
The "Shut Down Computer" dialog box appears.
3 Select "Switch off power after shut down?" and click [Yes].
04Carrol(7-18) 17/06/2000, 13:4910

11
■Switching off the power via Windows 2000
(on Windows 2000 models)
This section explains how to switch off the power for the PC via Windows 2000.
1 Click [Start].
The "Start" menu appears.
2 Click [Shut Down].
The following dialog box appears.
3 Select "Shut down" and click [OK].
Note the following
The following procedure can also be used to switch off the power:
1 Press [Ctrl]+[Alt]+[Delete].
The "Windows Security" dialog box appears.
2 Click [Shut Down].
The "Shut Down Windows" dialog box appears.
3 Select "Shut Down" and click [OK].
04Carrol(7-18) 17/06/2000, 13:4911
