System
Operating Manual
FUJITSU Workstation
CELSIUS R940
CELSIUS R940power

Thank you for buying an innovative product from Fujitsu.
Latest information about our products, useful tips, updates etc. is available
on our website: "http://www.fujitsu.com/fts/"
You can find driver updates at: "http://support.ts.fujitsu.com/download"
Should you have any technical questions, please contact:
• our Hotline/Service Desk (see Service Desk list or from the Internet at:
"http://support.ts.fujitsu.com/contact/servicedesk")
• Your sales partner
• Your sales office
We hope you enjoy using your new Fujitsu system!

Published by / Contact address in the EU
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 Munich, Germany
"http://www.fujitsu.com/fts/"
Copyright
©Fujits
u Technology Solutions GmbH 2014. All rights reserved.
Publication Date
22/2014
Order No.: A26361-K1449-Z320-1-7619, edition 2

FUJITSU Workstation
CELSIUS R940
CELSIUS R940power
Operating Manual
Your CELSIUS... 5
Ports and operating elements 7
Important notes 9
Getting started 14
Operation 21
Troubleshooting and tips 28
System expansions 31
Technical data 79
Index 80

Remarks
Information on the product description meets the design specifications of Fujitsu and
is provided for comparison purposes. Several factors may cause the actual results to
differ. Technical data is subject to change without prior notification. Fujitsu rejects any
responsibility with regard to technical or editorial mistakes or omissions.
Trademarks
Fujitsu, the Fujitsu logo and CELSIUS are registered trademarks of Fujitsu Limited or its
subsidiaries in the United States of America and other countries.
PS/2 is a registered trademark of International Business Machines, Inc.
Pentium is a registered trademark of Intel Corporation, USA.
Kensington and MicroSaver are registered trademarks of ACCO Brands.
Microsoft and Windows are trademarks or registered trademarks of the Microsoft
Corporation in the United States and/or other countries.
All other trademarks specified here are the property of their respective owners.
Copyright
No part of this publication may be copied, reproduced or translated without
the prior written consent of Fujitsu.
No part of this publication may be saved or transferred by any electronic means
without the written approval of Fujitsu.

Contents
Contents
YourCELSIUS... ....................................................................... 5
Validityof the Reference Manual ......................................................... 5
Notational conventions .................................................................. 6
Ports and operating elements ......................................................... 7
Front ................................................................................... 7
Rear ................................................................................... 8
Important notes ........................................................................ 9
Safetyinformation ....................................................................... 9
Transportingthedevice .................................................................. 9
Cleaning thedevice ..................................................................... 10
Energy saving,disposaland recycling .................................................... 10
CEmarking ............................................................................ 11
EMC standard EN 55022:2010 (Information technology equipment - Radio disturbance
characteristics - Limits and methods of measurement) . .................................... 11
FCCComplianceStatement ............................................................. 12
FCCClass AComplianceStatement .................................................. 12
FCCClass BComplianceStatement .................................................. 13
FCCRadiationExposureStatement ...................................................... 13
Getting started ......................................................................... 14
Unpacking and checking thedelivery ..................................................... 14
Steps for initialsetup .................................................................... 14
Setting up the device .................................................................... 15
Connecting themachineto themains ..................................................... 15
Connecting externaldevices ............................................................. 16
Ports on the device .................................................................. 16
Connecting a monitor ................................................................ 17
Connecting aUSB mouse ............................................................ 18
Connecting a USB keyboard . . ....................................................... 18
Connectingexternal devicesto theUSBports ......................................... 18
Switching on for the firsttime: installingthe software ....................................... 19
Switch on themonitor andthemachine ............................................... 19
Installingthe software ............................................................... 20
Operation .............................................................................. 21
Switchthe deviceon .................................................................... 21
Switching offthedevice ................................................................. 21
Indicatorsonthedevice ................................................................. 22
Keyboard ............................................................................... 23
Important keys and keyboard shortcuts . . . . ............................................ 23
Settingsin BIOSSetup .................................................................. 24
Property and data protection . . ........................................................... 25
Anti-theft protection and lead-sealing . . . . . . ............................................ 25
Mechanical casing lock (optional) . . ................................................... 26
BIOSsetup securityfunctions ........................................................ 27
Accessauthorisationvia SmartCard .................................................. 27
Operating the SmartCard reader (optional) ............................................ 27
Troubleshooting andtips .............................................................. 28
Helpifproblems occur ................................................................... 28
Fujitsu 3

Contents
Troubleshooting . . ....................................................................... 28
Power-on indicatorremains unlitafteryouhave switchedon yourdevice ................. 28
The device cannot be switched off with the ON/OFF switch. . . .......................... 29
Monitorremainsblank ............................................................... 29
Time and/or date is not correct . . . . . . ................................................. 30
Errormessageson thescreen ........................................................ 30
Installingnewsoftware .................................................................. 30
Restoring thehard diskcontents ......................................................... 30
Tips .................................................................................... 30
Systemexpansions .................................................................... 31
Information about boards ................................................................ 32
Opening the casing . . ................................................................... 33
Closingthe casing ...................................................................... 34
Overview ofdrivebays anddrives inyourdevice .......................................... 34
Installing and removing the accessible 51/4inchdrive (UltraSlim,top drivebay) .............. 35
Installingan accessibledrive ......................................................... 35
Removing anaccessible drive ........................................................ 37
Installing and removing the accessible 51/4inch drive (standard size, bottom drive bay) . . . .... 39
Fitting the drive cover for the 5 1/4inchdrive ........................................... 39
Installingan accessibledrive ......................................................... 40
Removing anaccessible drive ........................................................ 41
Installing/removing a 3½" reader in a 3½" bay (optional, SmartCard or MultiCard) . ........... 42
Screwing thereaderontothemoduleholder ........................................... 43
Installing a module holder with reader ................................................. 43
Removing a module holder with reader . . . ............................................. 44
Removing thereader fromthe moduleholder .......................................... 45
Installingthe harddiskdrive ............................................................. 45
Mounting or replugging the cold plug master cable . . . .................................. 47
Installinga newassemblykit(for expansionfrom 4tomax.8drives) .................... 50
Installingharddisks ................................................................. 56
Removing aharddisk ............................................................... 59
Remove and install type 1 boards ........................................................ 62
Performboardinstallation ............................................................ 62
Performboardremoval .............................................................. 68
Connecting display adapters with additional power supply .................................. 72
Remove and install type 2 boards ........................................................ 73
Installing a board . . . . ................................................................ 73
Removing a board . . . ................................................................ 75
Removing the heat sink . ................................................................ 76
Replacing theprocessor ................................................................. 76
Installing the heat sink ................................................................... 76
Upgrading mainmemory ................................................................ 77
Replacing thelithiumbattery ............................................................. 78
Technicaldata ......................................................................... 79
Index .................................................................................. 80
4Fujitsu

Your CELSIUS...
Your CELSIUS...
Overview
... is available with various configuration levels which differ in terms of hardware and software
equipment. You can install accessible drives (e.g. DVD drives) and other modules.
This manual tells you how to start using your device and how to operate it in daily use.
This manual applies for all configuration levels. Depending on the chosen configuration
level, some of the hardware components described may not be available on your PC.
Please also read the notes about your operating system.
Depending on the configuration selected, the operating system is preinstalled
on your hard disk (e.g. Windows 8).
Further information on this device is also provided:
• in the "Quick Start Guide" poster
• in the "Safety/regulations" manual
• in the "Warranty" manual
• in the operating manual for the monitor
• in the manual for the mainboard
• in the documentation for your operating system
• in the information files (e.g. *.PDF,*.HTML,*.DOC,*.CHM,*.TXT,*.HLP)
Some of the manuals listed can be found in electronic form on the "Drivers & Utilities" DVD.
You can access and view the required information using the Acrobat Reader program,
which is also included on the DVD. If necessary, you can also print out the manuals.
ValidityoftheReferenceManual
This Reference Manual is valid for the following system:
• FUJITSU Workstation CELSIUS R940
• FUJITSU Workstation CELSIUS R940power
Fujitsu 5

Your CELSIUS...
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://www.fujitsu.com/fts"
• Names of CDs, DVDs and titles or designations for other materials,
e.g.: "CD/DVD Drivers & Utilities" or "Safety/Regulations" manual
Key indicates a key on the keyboard, e.g: F10
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
6Fujitsu

Ports and operating elements
Ports and operating elements
Ports
This chapter presents the individual hardware components of your device. This will provide
you with an overview of the ports and operating elements on the device. Please familiarise
yourself with these components before starting to work with your device.
Front
8
1
2
3
4
5
6
7
1 = Module bays for5
1/4" drives
2 = Module bays for 3 1/2inch slide-in modules
3 = ON/OFF switch
4 = Headphone port
5 = Microphone jack
6 = USB ports
7=Harddiskfro
nt panel (removable)
8 = Latch with optional casing lock
Fujitsu 7

Ports and operating elements
Rear
2
3
4
1
1 = Holes for padlock / lead seal and
device for Security Lock
2 = Alternating voltage socket (AC IN)
3 = Ports for external devices
4 = Slot covers
8Fujitsu

Important notes
Important notes
ImportantnotesNotes
In this chapter you will find information regarding safety which it is essential to
take note of when working with your device.
Safety information
SafetyinformationNote
Please note the information provided in the "Safety/regulations" manual
and in the following safety notes.
When installing and operating the device, please observe the notes on
environmental conditions in Chapter "Technical data", Page 79 as well as
the instructions in Chapter "Getting started", Page 14.
When setting up the device, make sure there is clearance all around it so that
thecasingreceivesenough ventilation. In order to avoid overheating, do not
cover the ventilation areas of the monitor or the device.
You must only operate the device if the rated voltage used by the
device is set to the local mains voltage.
You must remove the power plug from the power socket so that the
mains voltage is completely disconnected.
Operate the device only with the casing closed.
Replace the lithium battery on the mainboard in accordance with the instructions
in "Replacing the lithium battery", Page 78.
Caution, components in the system can get very hot.
The activities described in these instructions must always be
performed with the greatest care.
Repairs to the device must only be performed by qualified technicians.
Incorrect repairs could put the user at great risk or cause serious damage
to the equipment (electric shock, risk of fire).
Transporting the device
Device,Tr ansp ortati on Retransportation
Transport all parts separately in their original packaging or in a packaging which
protects them from knocks and jolts, to the new site.
Do not unpack them until all transportation manoeuvres are completed.
If the device is brought from a cold environment into the room where it will be
used, condensation may occur. To avoid damaging the device, wait until it has
reached room temperature and is absolutely dry before initial startup.
Fujitsu 9

Important notes
Cleaning the device
Device,Tran sporta tionRetransportationSystemunit, see Devi ce
Turn off all power and equipment switches and disconnect the power
plug from the mains outlet.
Do not clean any interior parts yourself, leave this job to a service technician.
Do not use any cleaning agents that contain abrasives or may corrode
plastic (alcohol, thinner or acetone).
Never clean the device with water! Water entering into the device could
present a serious risk to users (e.g. electric shock).
Ensure that no liquid enters the system.
The surface can be cleaned with a dry cloth. If particularly dirty, use a cloth that has been
moistened in mild domestic detergent and then carefully wrung out.
Use disinfectant wipes to clean the keyboard and the mouse.
Energy saving, disposal and recycling
DisposalEnergysavingRecyclingDrivers&UtilitiesDVDUserDocumentationDVD
You can find information on these subjects on the "Drivers & Utilities" DVD or on our
website ("http://www.fujitsu.com/fts/about/fts/environment-care/").
For China: The energy efficiency of this product has been tested in accordance with GB
28380. The corresponding energy efficiency label can be used.
10 Fujitsu

Important notes
CE marking
CEmarkingCEmarkingNotesElectromagneticcompatibilityLowvoltagedi rective
The shipped version of this device complies with the requirements of EU directives 2004/108/EC
"Electromagnetic compatibility", 2006/95/EC "Low voltage directive", 2011/65/EC "RoHS directive"
and 2009/125/EC "ecodesign directive".
CE marking for devices with radio component
This equipment complies with the requirements of Directive 1999/5/EC of the European Parliament
and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment
and mutual recognition of conformity.
CE nnnn (!) ; nnnn: For digits and exclamation mark (!), see label on the product.
You can find more information and declarations of conformity on the Internet at:
"http://globalsp.ts.fujitsu.com/sites/certificates".
This equipment can be used in the following countries:
Belgium Bulgaria Denmark Germany
Estonia Finland France Greece
UK Ireland Iceland Italy
Croatia Latvia Liechtenstein Lithuania
Luxembourg Malta Netherlands Norway
Austria Poland Portugal Rumania
Sweden Switzerland Slovakia Slovenia
Spain Turkey Czech Republic Hungary
Cyprus
Contact the corresponding government office in the respective country for current information on
possible operating restrictions. If your country is not included in the list, then please contact
the corresponding supervisory authority as to whether the use of this product is permitted in
your country.
EMC standard EN 55022:2010 (Information technology
equipment - Radio disturbance characteristics -
Limits and methods of measurement)
CELSIUS systems whose designation ends with "a" or "an", e.g. CELSIUS R940a,
comply with the standard EN 55022:2010 according to class A.
This equipment may cause radio interference in residential areas. In this case,
the operator can be requested to take appropriate measures.
Fujitsu 11

Important notes
FCC Compliance Statement
CELSIUS systems whose designation ends with "a" or "an", e.g. CELSIUS R940a,
comply with the standard FCC part 15 according to class A.
If the device complies with the FCC regulations, the FCC sign can be found on the type rating plate.
FCC Class A Compliance Statement
The following statement applies to the products covered in this manual, unless otherwise specified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules and meets all requirements of the Canadian
Interference- Causing Equipment Standard ICES-003 for digital apparatus. These limits
are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/T.V. technician for help.
Fujitsu Technology Solutions GmbH is not responsible for any radio television interference
caused by unauthorized modifications of this equipment or the substitution or attachment
of connecting cables and equipment other than those specified by Fujitsu Technology
Solutions GmbH. The correction of interference caused by such unauthorized modification,
substitution or attachment will be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all optional
peripheral or host devices. Failure to do so may violate FCC and ICES rules.
12 Fujitsu

Important notes
FCCClassBComplianceStatement
DOC (INDUSTRY CANADA) NOTICES
Notice to Users of Radios and Television:
This class B digital apparatus complies with Canadian ICES-003.
The following statement applies to the products covered in this manual, unless otherwise specified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a "Class B" digital
device, pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian
Interference-Causing Equipment Standard ICES-003 for digital apparatus. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in strict accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Fujitsu is not responsible for any radio or television interference caused by unauthorized
modifications of this equipment or the substitution or attachment of connecting cables and
equipment other than those specified by Fujitsu. The correction of interferences caused by such
unauthorized modification, substitution or attachment will be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all optional
peripheral or host devices. Failure to do so may violate FCC and ICES rules.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
The transmitters in this device must not be co-located or operated in conjunction
with any other antenna or transmitter.
To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment (or
its transmit antenna) that is installed outdoors is subject to licensing.
Users are not authorized to modify this product. Any modifications invalidate the warranty.
This equipment may not be modified, altered, or changed in any way without signed
written permission from Fujitsu. Unauthorized modification will void the equipment
authorization from the FCC and Industry Canada and the warranty.
Fujitsu 13

Getting started
Getting started
Gettingstarted
Please observe the safety information in the "Important notes", Page 9 chapter.
Unpacking and checking the delivery
It is recommended not to throw away the original packaging material! It may be
required for reshipment at some later date.
PackagingContentsofd eliveryPackaging,
►Unpack all the individual parts.
►Check the contents of the package for any visible damage caused during transport.
►Check whether the delivery conforms to the details in the delivery note.
►Should you discover that the delivery does not correspond to the delivery
note, notify your local sales outlet immediately.
Steps for initial setup
Preparingforfirs tuse,ove rviewPreparingforuse,
Only a few steps are necessary to put your new device into operation for the first time:
• Select a location for device and set up device
• Connect external devices such as mouse, keyboard and monitor
• Check the voltage at the mains outlet and connect the device to an electrical outlet
• Switch the device on
You will learn more about the individual steps in the following sections.
External devices
If you have received other external devices in addition to your own device (e.g.
a printer), do not connect these until after the initial installation. The following
sections describe how to connect these external devices.
Drives and boards
If you have received drives or boards with your device, please do not install
them until after first-time setup. How to install drives and boards is described
in the "System expansions", Page 31 chapter.
14 Fujitsu

Getting started
Settingupthedevice
WorkstationErgonomicDevice
When installing your device, please read the recommendations and safety
notes in the "Safety/regulations" manual.
We recommend that you place your device on a surface which is not slippery. In
view of the many different finishes and varnishes used on furniture, it is possible
that the rubber feet will mark the surface they stand on.
Depending on the location of your device, bothersome vibrations and noises may
occur. To prevent this, a distance of at least 10 mm / 0.39" should be maintained
from other devices on casing sides without ventilation surfaces.
In order to avoid overheating, do not cover the ventilation areas
of the monitor or the device.
A minimum distance of 200 mm / 7.87" from the device must be
observed for ventilation areas.
Do not stack several devices on top of each other.
Do not expose the device to extreme ambient conditions (see "Technical data", Page 79,
section "Ambient conditions"). Protect the device against dust, humidity and heat.
Connecting the machine to the mains
Mainsadapter,
2
1
►Connect the mains cable to the machine (1).
►Plug the mains plug into a three-pin socket (2).
Fujitsu 15

Getting started
Connecting external devices
Read the documentation on the external device before connecting it.
With the exception of USB devices, always remove all power plugs
before connecting external devices!
Do not connect or disconnect cables during a thunderstorm.
Always take hold of the actual plug. Never unplug a cable by pulling the cable itself.
Ports on the device
PortsExternaldevicesDevice
The ports are located on the front and back of the device. The ports available on your
device depend on the configuration level you have selected. The standard ports are
marked with the symbols shown below (or similar). Detailed information on the location
of the ports is provided in the manual for the mainboard.
Headphones jack, light green
Headphones
Microphone jack, pink
Microphonejack
Audio output (Line out), light green
AudiooutputLineout
Audio input (Line in), light blue
AudioinputLinein
USB 2.0 - Universal Serial Bus, black
USB 3.0 - Universal Serial Bus, blue
UniversalSerialBus
eSATA eSATA port (optional)
eSATA
LAN
LAN port
LANport
Some of the connected devices require special software (e.g. drivers) (refer to the
documentation for the connected device and operating system).
16 Fujitsu
