FTP-628MCL401/451
nOverview
The FTP-628 MCL Series are battery driven high-speed
printers with a 2-inch paper width equivalent.
The FTP-628 MCL Series can be used for a variety of
applications, such as portable terminals, POS, banking
terminals, and measurement and medical equipment.
nhighLighTs
• Ultralowprole
Height 21.8 mm, width 81.2 mm, depth 42.2 mm
• Highspeedprinting
It can print at 60 mm/s (480 dotlines/s) maximum by using
Fujitsu's unique head drive control.
• AutoCutter
Full cut type and partial cut type printers are available by
user selection.
• Easypapersetting
Our unique platen release mechanism allows a
wide paper route even if the printer is ultra-compact, so
paper can be easily inserted. Conventional auto loading is
also available.
• Multifunctionaldie-castform
Wide operating temperature range, long continuous
printing, high ESD absorbtion and discharge of static
electricity vibration and shock resistant.
• RoHScompliant
baTTery driveN, FTP-608 series
2” high sPeed TherMaL PriNTer
FTP-628MCL401
FTP-628DSL491R

2
FTP-628MCL401/451
nParT NuMbers
Part number FTP-628MCL401
Printing method Thermal-line dot method
Dot structure 384 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 48 mm
Number of columns ANK 32 columns/line (maximum 12 x 24 dot font)
Paper width 58 mm
Paper thickness 60 to 100 µ m (some paper in this range may not be used because
of paper characteristics)
Printing Speed Maximum 60mm/sec. (480 dot line/sec.) at 8.5V
Alphanumeric, kana: 159 types
International characters: 195 types
JIS Kanji (Kanji CG loaded board): about 6800 types
12 × 24 dots, (1.5 × 3.0 mm), 32 columns: ANK
24 × 24 dots, (3.0 × 3.0 mm), 16 columns: ANK
8 × 16 dots, (1.0 × 2.0 mm), 48 columns: ANK
16 × 16 dots, (2.0 × 2.0 mm), 24 columns: ANK
nsPeCiFiCaTiONs
SpecicationsItem
Character types
Character, dimensions (W×H), number
of columns
Name Part Number
Printer mechanism with cutter FTP-628MCL401 (Easy Load Model)
Printer mechanism without cutter FTP-628MCL451 (Easy Load Model with platen bracket + lock
lever)
LSI for driving FTP-629CU451R
Interface board for
Mechanism/Cutter
Cutter supported FTP-628DSL491R Parallel (Centronics) / Serial (RS-232C)
Interface cable Parallel (Centronics) FTP-628Y202
Serial (RS-232C) FTP-628Y302
Power cables Head, motor, logic FTP-628Y402

3
FTP-628MCL401/451
nsPeCiFiCaTiONs
*+5˚C to +40˚C printing density assurance rance (-25 to 70˚C capability)
metI noitacificepS
ecafretnI scinortneC/C232SRotsmrofnoC
rewoP
ylppus
daehtnirproF V2.7taA)4.2(8.1,tnerrucegarevaCDV5.8-2.4
).ces/mm06:deepstnirp,%5.21:oitartnirp(
rotomroF mumixamA1,CDV5.8-2.4
rotomrettucroF mumixamA1,CDV5.8-57.4
cigolroF mumixamA1.0,%5±CDV5
snoisnemiD
rettuchtiwmsinahceM )HxDxW(mm8.12x2.24x2.18
draobecafretnI mm21x06x07
thgieW
rettuchtiwmsinahceM g79yletamixorppA
draobecafretnI g52yletamixorppA
efiL
daeH
dradnatsruorednu(tod/seslupnoillim001:ecnatsiseresluP
mk05ecnatsidgnilevartrepap:ecnatsisernoisarbA;)snoitidnoc
)sselro%5.21:oitartnirp(
rettuC stuc000,005
gnitarepO
tnemnorivne
*erutarepmetgnitarepO C˚05otC˚
0
ytidimuhgnitarepO )noitasnednocon(HR%58ot02
erutarepmetegarotS )dedulcnitonrepap(C˚06+otC˚02-
ytidimuhegarotS )noitasnednocon(HR%59ot5
noitceteD
noitcnuf
erutarepmetdaeH
noitceted rotsimrehtybdetceteD
noitcetedkram/tuorepaP retpurretni-otohpybdetceteD
esaelernetalP hctiwsgnidilsybdetceteD
edalbelbavoM retpurretni-otohpybdetceteD
repapevitisneslamrehtdednemmoceR
repaPevitisneShgiH )repaPnoppiN(4E-SK05FT
:repapdradnatS -PTF,)repaPnoppiN(E-SK06FT
,)repaPijO(R501DP,)mm85(100UP020
)mm85(1070P020-PTF
repaPefiLmuideM ,)mm85(2010P020-PTF,1F-SK06FT
1-BBV022P,)repaPijO(R071DP
)repaPihsibustiM
repaPefiLgnoL 532-PFA,)repaPijO(N-R061DP
noppiN(R-JK05PT,)repaPihsibustiM(
)repaPnoppiN(AA022AH,)repaP
Platen 5,000 times (open/close)

4
FTP-628MCL401/451
11
7.5
(54)
13.9
13.1
42.2
21.8
10.7
5.4
81.2
platen center
printer position standard
platen unit
paper exhaust position
lever
platen unit
paper
printer
cutting position
nFuNCTiON OF iNTerFaCe bOard
ndiMeNsiONs
1.Printermechanism
Unit: mm
Note: 1. Dimensions are nominal value (tolerance ±5 unless otherwise specied).
2. Platen unit (lever, platen, etc) moves by approximately 0.7mm toward paper insertion direction when platen is
open.
FTP-628MCL401
Item Item
1. Test print function 8. Cutter trouble detect
2. Paper out detection 9. Motor power saving function
3. Paper near end detection 10. Mark detection function
4. Platen open detection 11. MCU operation abnormality detection
5. Thermal head temperature abnormality detection 12. Power ON/OFF sequence protection
6. Blow-out fuse detection 13. Motor over-current protection
7. Head voltage abnormality detection 14. Hardware timer

5
FTP-628MCL401/451
1.Printermechanism
FTP-628MCL451

6
FTP-628MCL401/451
2.Interfaceboard
17.5
49.5
63.5
(70.0)
3.25
53.5
3.25
(60.0)
50.5
42.0
3.25
FGØ3.2 3-Ø3.2
CN7
CN2
CN1
CN8
CN3
11
68
1 2
29
30
12
CN4
18
25.5
13.5
3.25
3.25
1.25
1.0
1.2
7
3
1.6
30 1
45.5
Note:
1. The size with parentheses is a reference value.
2. Part mounting height is maximum. Unit:mm
Mounting height
Mounting height
1.45

7
FTP-628MCL401/451
FTP-628MCL401mechanism/cutterFPCPINAssignment
(1) For thermal head, motor and sensor
Connector on control circuit: 52610-3090 (Molex or equivalent)
oN langiS stnetnoC
1 KHP rotpurretniotohprofedohtaC
2 NESV rewoprosnesrepap
3 EHP rotpurretniotohprofrottimE
4 HV rewopevirddaeH
5 HV
6 ID niataD
7 KLC kcolC
8 DNG dnuorgdaeH
9 DNG
01 6BTS 6ebortS
11 5BTS 5ebortS
21 4BTS 4ebortS
31 ddV rewopcigoL
41 MT rotsimrehT
51 MT
61 3BTS 3ebortS
71 2BTS 2ebortS
81 1BTS 1ebortS
91 DNG dnuorgdaeH
02 DNG
12 TAL hctalataD
22 OD tuoataD
32 HV rewopevirddaeH
42 HV
52 WS hctiwsesaelernetalP
63 WS
72 A/TM AlangisnoitaticxE
82 A/TM AlangisnoitaticxE
92 B/TM BlangisnoitaticxE
03 B/TM BlangisnoitaticxE

8
FTP-628MCL401/451
FTP-628MCL451mechanism/platenbracketFPCPINAssignment
(1) For thermal head, motor and sensor
Connector on control circuit: 52610-3090 (Molex or equivalent)
oN langiS stnetnoC
1 KHP rotpurretniotohprofedohtaC
2 NESV rewoprosnesrepap
3 EHP rotpurretniotohprofrottimE
4 HV rewopevirddaeH
5 HV
6 ID niataD
7 KLC kcolC
8 DNG dnuorgdaeH
9 DNG
01 6BTS 6ebortS
11 5BTS 5ebortS
21 4BTS 4ebortS
31 ddV rewopcigoL
41 MT rotsimrehT
51 MT
61 3BTS 3ebortS
71 2BTS 2ebortS
81 1BTS 1ebortS
91 DNG dnuorgdaeH
02 DNG
12 TAL hctalataD
22 OD tuoataD
32 HV rewopevirddaeH
42 HV
52 WS hctiwsesaelernetalP
63 WS
72 A/TM AlangisnoitaticxE
82 A/TM AlangisnoitaticxE
92 B/TM BlangisnoitaticxE
03 B/TM BlangisnoitaticxE

9
FTP-628MCL401/451
Platen unit
Thermal head
Motor
Sensor (Photo-
interruptor)
30,29,
Connector No
(FPC pin
FPC
Connect terminal:
surface side
(2) For cutter
Connector on control circuit: 52610-0890 (Molex or equivalent)
oN langiS stnetnoC
1 NESV rewoprosnesnoitisopemoH
2 EHP rotpurretniotohprofrottimE
3 KHP rotpurretniotohprofedohtaC
4 A/TM AlangisnoitaticxE
5 A/TM AlangisnoitaticxE
6 B/TM BlangisnoitaticxE
7 B/TM BlangisnoitaticxE
8 CN detcennoctoN
