Fujitsu FTP-641MCL351 User manual

FTP-641MCL351/352
■OVERVIEW
This thermal printer (driven by 24 VDC) and cutter provide high
speed printing for 4-inch wide paper (114 mm). This printer is small
in size, light weight, and has low power consumption. The print
head features open construction for easy maintenance.
This printer is suitable for a variety of applications, such as POS
terminals, ticket machines, label printers, measuring devices and
medical equipment.
In addition to the interface board, a driving LSI (MCU + Gate Array)
is also available.
■HIGHLIGHTS
• Ultra high speed printing
It can print at 100 mm/s (800 dotlines/s) by using Fujitsu
Components' unique head drive control system.
• Auto cutter
Full or partial cutting are available by normal or reverse rotation
of the motor (command set).
• Low power consumption
The peak current for head driving is approximately 3.3 A (at 50
mm/s printing speed, 50% printing ratio).
• Easy head access
Head-open construction makes head maintenance easy,
especially for head cleaning.
• Paper auto loading function
The thermal paper can be loaded without head-up lever
operation.
• High resolution
8 dots/mm head provides clear print output.
• Selectable paper paths
Front or rear insertion types are available.
24V DRIVE, ULTRA HIGH SPEED LINE THERMAL PRINTER
4” MECHANISM, WITH AVAILABLE CUTTER
FTP-641MCL351/352 shown after
assembly with FTP-641CT001cutter
FTP-621DCL013
FTP-621CU102, FTP-633GA101
1

2
FTP-641MCL351/352
■DESIGNATION
Part number
Front paper insertion type
Rear paper insertion type
FTP-641MCL351
FTP-641MCL352
FTP-641CT001
FTP-621DCL013
FTP-621CU102
FTP-633GA101
Item
Printer mechanism
Micro Controller Unit
Gate Array
LSI
Interface board
Cutter
Printing method Thermal-sensitive line dot method
Dot structure 864 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 108 mm
Number of columns 72 columns/line (maximum)—Alphanumeric KANA
Maximum printing speed 800 dotlines/s (100 mm/s) maximum
JIS ANK : 128 International characters : 130
Character types Semi-graphic : 63 ASCII small characters : 31
Download : 384
24 ×12 dots, (3.0 ×1.5 mm), 72 columns
32 ×16 dots, (4.0 ×2.0 mm), 54 columns
24 ×24 dots, (3.0 ×3.0 mm), 36 columns
32 ×32 dots, (4.0 ×4.0 mm), 27 columns
Interface 1) Centronics standard 2) Bus interface*1
Cutting method Guillotine method
Cutting type Full-cut or partial cut (command set)
Cutter Minimum cut length 20 mm
Paper thickness 65 to 150 µm
■GENERAL SPECIFICATIONS
SpecificationsItem
Character composition, dimensions (H×W),
Number of columns (standard)
(Continued)

3
FTP-641MCL351/352
24 VDC ±5%, average:*2
0.82 (1.11) A (at 25 mm/s printing speed, 25% printing ratio)
For head 1.25 (1.66) A (at 50 mm/s printing speed, 25% printing ratio)
4.75 (6.30) A (at 50 mm/s printing speed, 100% printing ratio)
( ): Peak
For motor 24 VDC ±5%, 1.0 A maximum
For logic 5 VDC ±5%, 0.5 A maximum
Weight Mechanism with cutter: approximately 610 g
Interface board: approximately 100 g
Mechanism + cutter 159 (W) ×60 (D) ×71.0 (H) mm (excluding connector)
Interface board 140 (W) ×89 (D) ×24.0 (H) mm
Pulse durability : 5 ×107pulse/dot (using Fujitsu & Takamisawa's
standard driving method)
Wear resistance: 50 km (at 12.5% printing ratio)
Cutter Cutting life: 3 ×105times
Operating temperature +5 to +40°C*3
Operating humidity 20 to 85% RH (no condensation)
Storage temperature –20 to +60°C (excluding paper)
Storage humidity 5 to 95% RH (no condensation)
Head temperature By thermistor (applied energy control, abnormal temperature detection)
Detection Paper out/Mark detect By photointerrupter (command set)
Head-up By microswitch
Paper width 114 mm
1 ply paper in roll : FTP-040P0020
SpecificationsItem
(Continued)
Power supply
Dimensions
Thermal head
Life
Environmental
conditions
Recommended thermal sensitive
paper*4
*1: The data to be printed is automatically read out by the printer driver equipment memory (host system frame
memory). The communication is parameter transfer.
*2: At 25°C, maximum applied voltage, minimum head resistance, specified paper, stable printing ratio.
*3: Temperature range for guaranteed printing density. It can operate at 0 to +40°C.
*4: Please contact us for other thermal papers.
+0
–1

4
FTP-641MCL351/352
■DIMENSIONS
Printer mechanism with cutter
Unit: mm
JAPAN
2.5 (Mounting hole)
11.8
Y Y
2-M3 Burring
66.6 (Center of paper & connector)
135.2 (Mounting hole) 161
21.9
14.2
68 (At cutter open)
60
35.5 (Mounting hole)
40.5
12
7.5 (300)
25.4
<FTP-641MCL351> <FTP-641MCL352>
Y-Y SECTION
71
(76)
123.8
300
Mounting screw
Paper insertion
Paper insertion Note:
All dimensions are nominal value.

5
FTP-641MCL351/352
Interface board
CN3 CN4 CN2
CN5 CN1 CN10
CN11
CN7
Unit: mm
Height of devices side
Height of solder side
17
5
23.6
139.7
129.6
113.1
22.9 14.0
(5.1)
88.9
78.8
(5.1)
(5.1)
14.0
88.9 (5.1)
(5.1)
28.0
25.4
4—ø3.6
1.6
CN12 CN13
22.3 27.4
31.8
CN6
15.3
■INTERFACE, COMMAND, OPTIONS
Please refer to the FTP-621DCL003/013 DATA SHEET for Interface, Command, and Options.

6
FTP-641MCL351/352
© 2001 Fujitsu Components America, Inc. All company and product names are trademarks or registered
trademarks of their respective owners. Rev. 09/2001
