Fujitsu FTP-638WSL110 Series User manual

FUJITSU Component Thermal Printer
Mobile Printer
FTP-638WSL110 Series
User's Guide
FUJITSU COMPONENT LIMITED

1
I
In nt tr ro od du uc ct ti io on n
Thank you for purchasing the FTP-638WSL110 Series Mobile Printer (hereafter
referred to as “this product”).
This User's Guide (hereafter referred to as “this guide”) contains precautions to
use it safely and correctly.
Before using this product, please read the complete this guide.
In addition, please keep this guide handy for future reference.
If you have any suggestions or comments about this guide, please do not
hesitate to contact us.
Bluetooth
®is registered trademark of Bluetooth SIG.
Apple, iPod, iPhone and iPad are trademarks of Apple Inc, registered in the U.S. and
other countries.
Android is trademarks of Google Inc.
All other product names and service names are trademarks or registered trademarks of
their respective companies.
All Rights Reserved, Copyright FUJITSU COMPONENT LIMITED 2015

2
C
Ca au ut ti io on ns s
■ Change of content
The contents of this guide and this product are subject to change without prior
notice.
■ Use in high safety applications
This product is designed, developed and manufactured for general use, such as
standard industrial, general, personal and household use. This product is not
designed, developed and manufactured for “high safety applications”, such as an
application which requires extremely high safety, which may have a serious effect
on society, expose individuals to serious danger (death, personal injury, severe
physical damage or other loss), if extremely high safety is not assured (including,
without limitation, nuclear reaction control in a nuclear facility, aircraft automatic
flight control, air traffic control, transport control in a mass transport system,
medical equipment for life support, missile launch control of a weapons system), or
an application which requires extremely high reliability (including, without
limitation, submarine relay, space satellite).
If you wish to use this product in an environment that requires high safety, please
consult with our sales representatives.
■ Copyright
This product and this guide are copyrighted works of
FUJITSU COMPONENT LIMITED.
This product and this manual must not be reproduced, duplicated, used, or modified,
partially or in full, without permission.

3
■ Regulatory Compliance
For Customers in USA (FCC)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority
to operate this equipment. (Example- use only shielded interface cables when
connecting to computer or peripheral devices).

4
For Customers in CANADA (Industry Canada)
This equipment complies with Industry Canada RSS210 rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received,
including interference that may cause undesired operation.
Cet appareil numerique de est conforme aux normes canadiennes licence-exempt
RSS standard(s)
Son fonctionnement est soumis aux deux conditions suivantes :
1) cet appareil ne doit pas causer d'interference et
2) cet appareil doit accepter toute interference, notamment les
interferences qui peuvent affecter son fonctionnement.
For Customers in EU (CE Marking)
This product is in conformance with the requirements of European Council
Directive:
R&TTE Directive 1995/5/EC
Applied standards:
EN 60950-1
EN 300 328
EN 301 489-1
EN 301 489-17
EN 50581

5
■ Export
This device may contain commodities, technology or software subject to export laws
and regulations from the US and other countries. Diversion contrary to the country
law is prohibited.
■ Warranty
We shall not be responsible for any failure caused by wrong operation or usage in
the wrong environment.
Moreover, we cannot be responsible for the loss, the passive damages or the claim
by a third party, even if it is caused by use or failure of this product.
In addition, this product’s range of failure will never exceed the amount of money
paid for it.

6
S Sa af fe et ty y C Ca au ut ti io on ns s
■ Explanation of Symbols
The following symbols are used in this guide. Please read and understand
the meaning of each symbol in this guide.
If this product should malfunction, immediately stop using it, and contact
your sales representative.
Danger
Indicates an imminent risk of causing severe personal
injury or death if not used properly.
This level is not described in this document.
Warning
Indicates possibility of causing severe
personal injury or death if not used properly.
Caution
Indicates that a minor or some personal injury may occur
or that the product itself or other user’s property may be
damaged.
Indicates an action that must not be performed.
Detailed description is on the side of this symbol.
Indicates danger, warning and caution.
Detailed description is on the side of this symbol.
Indicates an action that must be performed.
Detailed description is on the side of this symbol.
Important
Indicates important points by using this product.

7
■ General Cautions
Warning
Break-
down
- Do not use in the environment with corrosive gas or salt wind is
present.
Failure to observe this may cause failure.
Modify
- Do not modify or disassemble.
Failure to observe this may cause fire, explosion or
breakdown.
Fire
- Do not burn or heat.
Failure to observe this may cause smoke, fire or breakdown.
Fire
- Do not pour water.
This equipment is not waterproof. Failure to observe this may cause
fire, explosion or breakdown.
Fire
- Do not use or store the equipment in a hot environment.
Failure to observe this may cause smoke, fire or breakdown.
Fire
- Do not throw or drop.
Failure to observe this may cause fire, explosion or
breakdown.
Fire
- Do not use with wet hands. Do not drip or drop liquid such as
drinking water, clips or other foreign matter.
Failure to observe this may cause fire or electric shock.
Fire
- In the event of heat, unusual smells, smoke or excessive noise
while using the product, please stop using it immediately. Unplug
the power cable, remove the battery.
Failure to observe this may cause fire.

8
Caution
Injury
- Do not use while driving a vehicle or walking.
Failure to observe this may cause traffic accidents and injuries.
Break-
down
- Do not use the printer near the equipment that generates large
radiation noise, such as a high voltage device and a large motor.
Failure to observe this may cause malfunction or breakdown.
Fire
- Do not use under direct sunlight or dusty environment that
contains the oil and iron.
Failure to observe this may cause heat, fire or failure.
Fire
- If charging is not completed within the specified time, unplug the
charger and stop charging.
The battery may leak by overcharging.
Fire
- Do not apply force to the cable.
Failure to observe this may cause fire or electric shock.
Break-
down
- Keep the power line away from other devices which generate
noise. (Large motor etc.)
Failure to observe this may cause malfunction or breakdown.
Failure
- Before using this product, be sure to read complete user's guide.
It may cause the failure by incorrect use.

9
■ Printer
Warning
Accident
- Do not use the printer in a location where radio wave generation is
prohibited.
Might cause accidentally a malfunction of the instrument.
Burn
- During or immediately after operation, do not touch the print
head, the support plate and the motor. Heat is not immediately
discharged.
Failure to observe this may cause burn injury.
Fire
- Do not put metal objects or flammable objects into the gaps of the
case.
Failure to observe this may cause fire or electric shock.
Burn
- Surely turn off the printer's power and confirm that the printer
head is sufficiently cooled down before cleaning.
Failure to observe this may cause burn injury.
Caution
Injury
- Never insert fingers or metal into the paper insertion and/or eject
slots of the paper cutter.
Failure to observe this may cause equipment failure or injury.
Injury
- Be careful not to get a hand or hair caught in moving parts.
Failure to observe this may cause burn injury.

10
■ Battery
Warning
Break-
down
- Do not use the battery for other device or purpose.
Failure to observe this may cause destruction.
Modify
- Do not disassemble the battery.
Failure to observe this may cause heat, fire or destruction.
Fire
- Only use the specified battery.
Failure to observe this may cause fire or electric shock.
Fire
- Only charge the battery with the charger specified.
Failure to observe this may cause fire or destruction.
Fire
- Do not short-circuit the electrode of the battery.
Failure to observe this may cause heat, fire or destruction.
Fire
- Do not solder the terminal of battery.
Failure to observe this may cause heat, fire or destruction.
Fire
- Do not make impact or pressure on battery.
Failure to observe this may cause heat, fire or destruction.
Caution
Break-
down
- Remove the battery if the printer is not expected to be used for
long period.
Failure to observe this may cause deterioration of the battery and
over-discharge state.
Break-
down
- Turn off the power of the printer before removing the battery.
Failure to observe this may cause destruction.

11
■ AC Adapter
Warning
Break-
down
- Do not use the AC adapter for any other devices or purposes.
Failure to observe this may cause damage to the printer and/or
battery.
Fire
- Only connect the AC adapter to the specified voltage and/or
frequency.
Failure to observe this may cause fire or electric shock due to cable
disconnection.
Fire
- Only use the specified AC adapter.
Failure to observe this may cause heat, fire or destruction.
Caution
Fire
- Please connect or remove the AC adapter after the power is turned
off.
Failure to observe this may cause breakdown.
Break-
down
- If you do not use the AC adapter for a long time, please unplug the
power cable.
Failure to observe this may cause electric shock or fire due to dust and
moisture.

12
■ Warning Label of Product
This product comes with the following warning label.
This label must not be peeled off or erased from the display.
Moreover, please contact the distributor when the label is difficult to
see due to dirt, scratching etc.
Warning display
Content
HEAD ヘッド
Do not touch the printer head and its support
plate directly, because it becomes hot during
printing.
GEAR & HOOK
ギア・フック
Pay attention that fingers and hair do not get
caught in moving parts such as a gear or hook.
CAUTION 注意
Please do not touch the cutter blade when you
exchange the paper roll because it may cause an
injury.

13
T Ta ab bl le e o of f C Co on nt te en nt ts s
1 Preparation to Print .................................................................................14
1.1 Packaging ....................................................................................14
1.2 Getting to Know the Printer..........................................................15
1.3 Inserting the Battery ....................................................................19
1.4 Connecting AC Adapter (Charging)...............................................20
1.5 Inserting the Paper ......................................................................21
2 Operating Procedures .............................................................................22
2.1 Power On......................................................................................22
2.2 Test Print ......................................................................................23
2.3 Bluetooth Communication ...........................................................25
2.4 Printer Error..................................................................................26
3 Indicator Lights.......................................................................................28
3.1 Normal Operation ........................................................................28
3.2 Printer Error..................................................................................29
3.3 Charging.......................................................................................30
3.4 Maintenance Mode ......................................................................30
4 Maintenance...........................................................................................31
4.1 Thermal Head...............................................................................31
4.2 Platen Roller.................................................................................32
4.3 Paper Sensor ................................................................................32
5 Troubleshooting .....................................................................................33
6 Specifications .........................................................................................37
6.1 Printer Specifications....................................................................37
6.2 Paper Specifications .....................................................................38
7 Recycle....................................................................................................39
8 Appendix ................................................................................................40
8.1 Bluetooth Communication ...........................................................40
9 Product Support ......................................................................................42

1 Preparation to Print
14
1
1 P Pr re ep pa ar ra at ti io on n t to o P Pr ri in nt t
1.1 Packaging
The following items are included.
There may be attachment of optional parts depending on a product
type.
If anything is missing, please contact the distributor.
Printer
Battery
AC adapter
Safety Cautions
AC Cable
Roll Paper

1 Preparation to Print
15
1.2 Getting to Know the Printer
■ Front Side (Cover Closed)
Paper Cover : Cover to open and load paper.
Paper Cutter : To cut paper.
Operation Panel : Operates and Displays status of the printer.
Cover Open Lever : To open the cover.
IrDA : To connect to PC etc.
AC Adapter Jack : Open and connect AC adapter.
6
5
4
3
2
1
1
2
4
5
3
6

1 Preparation to Print
16
■ Operation Panel
Power Switch : To turn the power supply ON or OFF.
FEED Switch : To feed paper.
Re-Print switch : To issue recent print.
Buzzer switch : To change the volume of the buzzer.
Bluetooth switch : To turn the Bluetooth power supply ON or OFF.
Charge LED : Displays charging status of the printer.
Status LED : Displays printer status.
Battery LED : Displays Battery status.
11
14
13
12
10
9
8
7
7
8
9
14
10
12
11
13

1 Preparation to Print
17
■ Front Side (Cover Open)
Platen Roller : To feed paper.
Warning Label : This shows warning when using printer.
Paper Sensor : This sensor detects the status of paper.
■ Back view (Cover Open)
Thermal Head : This applies heat to paper.
17
18
16
15
18
17
15
16

1 Preparation to Print
18
■ Rear Side
Screw for Soft Case : This attaches the Soft Case. (Optional)
Battery cover : Cover to open and insert the battery.
Product Label : Displays printer type and
other product information.
21
20
19
20
21
19
