Fujitsu FI-6140c Configuration guide

Consumables Part Number
Brake Roller PA03540-0001
Pick Roller PA03450-0002
Cleaning Materials SC-CLE-KIT1
2
3
4
1Brake Rollers x 2
Clean lightly taking care not to scratch the surface.
ADF Glass Surfaces x 2
Clean lightly.
Clean lightly taking care not to scratch the surface.
Pick Roller x 2
Clean lightly while rotating with your finger. Take care not to roughen the surface.
Plastic Rollers x 4
Turn the Scanner OFF while cleaning the following locations
It is recommended that these items be
cleaned EVERY 1,000 SCANS
Using cleaning paper moistened with F1 Cleaner
Cleaning Instructions for
fi-6140C Scanner
2
3
4
1
5Brake Rollers
Glass
Eject Rollers
Pick Rollers
Feed Rollers
P.T.O.
BEFORE CLEANING
Open the ADF while pulling the cover open lever
1ADF Open Lever
6
Plastic
Rollers

Turn the Scanner ON while cleaning the following locations
Using cleaning paper moistened with F1 Cleaner
December 2007
Cleaning Instructions for fi-6140C ScannerFujitsu Europe LImited
For further information please refer to the
fi-6140C Image Scanner Operators Guide
which can be found on our Website:
www.fel.fujitsu.com/scanner
6
Clean lightly taking care not to roughen the surface.
Feed Rollers x 2
Open the ADF only if the Function Number Display is showing “1”
through “9”.
Simultaneously hold down the “Send to” and “Scan”
buttons on the operator panel. The rollers will start
to rotate slowly
Hold a soft dry, moistened cleaning paper against the
surface of the rotating rollers, lightly cleaning the
surface.
As a guideline, 7 presses of the “Send to” and
“Scan” buttons make the rollers rotate one full turn.
12
“Send to” Button “Scan” Button
2
3
4
1
5Brake Rollers
Glass
Eject Rollers
Pick Rollers
Feed Rollers
6
Plastic
Rollers
5Eject Rollers x 2
