Fujitsu PRIMEQUEST 2000 Series Service manual

C122-E178-02EN
FUJITSU Server
PRIMEQUEST
2000 Series
Message Reference

Preface
i
C122-E178-02EN
Preface
This manual describes the functions and features of the PRIMEQUEST 2000 series. The manual is intended for system
administrators.
For details on the regulatory compliance statements and safety precautions, see the PRIMEQUEST 2000 Series Safety
and Regulatory Information (C122-E171XA).
Errata and addenda for the manual
The PRIMEQUEST 2000 Series Errata and Addenda (C122-E182EN) provides errata and addenda for the manual.
Read the PRIMEQUEST 2000 Series Errata and Addenda (C122-E182EN) thoroughly in reference to the manual.
Organization of this manual
This manual is organized as follows.
CHAPTER 1 Message Overview
Chapter 1 describes how to read PRIMEQUEST 2000 series messages.
CHAPTER 2 MMB Messages
Chapter 2 lists MMB messages by type.
CHAPTER 3 Dynamic Reconfiguration Messages
Chapter 3 lists Dynamic Reconfiguration messages.
CHAPTER 4 sadump Messages
Chapter 4 lists sadump messages.
Appendix A Replacement component list
Appendix A lists replacement component for Unit/Source in MMB SEL message.

Preface
ii
C122-E178-02EN
Revision History
Edition Date Revised location (type) (*1) Description
1 2014-02-18 - -
2 2014-04-10 CHAPTER2 MMB Message Updated and added MMB messages
*1: Chapter, section, and item numbers in the "Revised location" column refer to those in the latest edition of the
document. However, a number marked with an asterisk (*) denotes a chapter, section, or item in a previous
edition of the document.

Preface
iii
C122-E178-02EN
Product operating environment
This product is a computer intended for use in a computer room environment. For details on the product operating
environment, see the following manual:
PRIMEQUEST 2000 Series Hardware Installation Manual (C122-H007EN)
Safety Precautions
Alert messages
This manual uses the following alert messages to prevent users and bystanders from being injured and to prevent
property damage.
This indicates a hazardous (potentially dangerous) situation that is likely to result in death or serious
personal injury if the user does not perform the procedure correctly.
This indicates a hazardous situation that could result in minor or moderate personal injury if the user
does not perform the procedure correctly. This also indicates that damage to the product or other
property may occur if the user does not perform the procedure correctly.
This indicates information that could help the user use the product more efficiently.
Alert messages in the text
An alert statement follows an alert symbol. An alert statement is indented on both ends to distinguish it from regular text.
Similarly, one space line is inserted before and after the alert statement.
Only Fujitsu certified service engineers should perform the following tasks on this product and the
options provided by Fujitsu. Customers must not perform these tasks under any circumstances.
Otherwise, electric shock, injury, or fire may result.
- Newly installing or moving equipment
- Removing the front, rear, and side covers
- Installing and removing built-in options
- Connecting and disconnecting external interface cables
- Maintenance (repair and periodic diagnosis and maintenance)
The List of important alert items table lists important alert items.

Preface
iv
C122-E178-02EN
List of important alert items
This manual does not contain important alert items.
Warning labels
Never remove the warning labels.
Warning label location (the main cabinet top)

Preface
v
C122-E178-02EN
Warning label location (the main cabinet left)
Warning label location (PCI_Box)

Preface
vi
C122-E178-02EN
Notes on Handling the Product
About this product
This product is designed and manufactured for standard applications. Such applications include, but are not limited to,
general office work, personal and home use, and general industrial use. The product is not intended for applications that
require extremely high levels of safety tobe guaranteed (referred to below as "safety-critical" applications). Use of the
product for a safety-critical application may present a significant risk of personal injury and/or death. Such applications
include, but are not limited to, nuclear reactor control, aircraft flight control, air traffic control, mass transit control, medical
life support, and missile launch control. Customers shall not use the product for a safety-critical application without
guaranteeing the required level of safety. Customers who plan to use the product in a safety-critical system are requested
to consult the Fujitsu sales representatives in charge.
Storage of accessories
Keep the accessories in a safe place because they are required for server operation.
Adding optional products
For stable operation of the PRIMEQUEST 2000 series server, use only a Fujitsu-certified optional product as an added
option.
Note that the PRIMEQUEST 2000 series server is not guaranteed to operate with any optional product not certified by
Fujitsu.
Exportation/release of this product
Exportation/release of this product may require necessary procedures in accordance with the regulations of the Foreign
Exchange and Foreign Trade Control Law of Japan and/or US export control laws.
Maintenance
Only Fujitsu certified service engineers should perform the following tasks on this product and the
options provided by Fujitsu. Customers must not perform these tasks under any circumstances.
Otherwise, electric shock, injury, or fire may result.
- Newlyinstalling or moving equipment
- Removing the front, rear, and side covers
- Installing and removing built-in options
- Connecting and disconnecting external interface cables
- Maintenance (repair and periodic diagnosis and maintenance)
Only Fujitsu certified service engineers should perform the following tasks on this product and the
options provided by Fujitsu. Customers must not perform these tasks under any circumstances.
Otherwise, product failure may result. PRIMEQUEST 2000 Series General Description
- Unpacking an optional Fujitsu product, such as an optional adapter, delivered to the customer
Modifying or recycling the product
Modifying this product or recycling a secondhand product by overhauling it without prior approval
may result in personal injury to users and/or bystanders or damage to the product and/or other
property.

Preface
vii
C122-E178-02EN
Note on erasing data from hard disks when disposing of the product or transferring it
Disposing of this product or transferring it as is may enable third parties to access the data on the hard disk and use it for
unforeseen purposes. To prevent the leakage of confidential information and important data, all of the data on the hard
disk must be erased before disposal or transfer of the product.
However, it can be difficult to completely erase all of the data from the hard disk. Simply initializing (reformatting) the hard
disk or deleting files on the operating system is insufficient to erase the data, even though the data appears at a glance to
have been erased. This type of operation only makes it impossible to access the data from the operating system.
Malicious third parties can restore this data.
If you save your confidential information or other important data on the hard disk, you should completely erase the data,
instead of simply carrying out the aforementioned operation, to prevent the data from being restored. To prevent important
data on the hard disk from being leaked when the product is disposed of or transferred, you will need to take care to erase
all the data recorded on the hard disk on your own responsibility.
Furthermore, if a software license agreement restricts the transfer of the software (operating system and application
software) on the hard disk in the server or other product to a third party, transferring the product without deleting the
software from the hard disk may violate the agreement. Adequate verification from this point of view isalso necessary.
Product and service inquiries
For all product use and technical inquiries, contact the distributor where you purchased your product, or a Fujitsu sales
representative or systems engineer (SE). If you do not know the appropriate contact address for inquiries about the
PRIMEQUEST 2000 series, use the Fujitsu contact line.
Fujitsu contact line
We acceptWeb inquiries. For details, visit our website:
https://www-s.fujitsu.com/global/contact/computing/PRMQST_feedback.html
Warranty
If a component failure occurs during the warranty period, we will repair it free of charge in accordance with the terms of the
warranty agreement. For details, see the warranty.
Before requesting a repair
If a problem occurs with the product, confirm the problem by referring to 11.2 Troubleshooting in the PRIMEQUEST 2000
Series Administration Manual (C122-E175ENEN). If the error recurs, contact your sales representative or a field engineer.
Confirm the model name and serial number shown on the label affixed to the right front of the device and report it. Also
check any other required items beforehand according to 11.2 Troubleshooting in the PRIMEQUEST 2000 Series
Administration Manual (C122-E175ENEN).
The system settings saved by the customer will be used during maintenance.

Preface
viii
C122-E178-02EN
Manual
How to use this manual
This manual contains important information about the safe use of this product. Read the manual thoroughly to understand
the information in it before using this product. Be sure to keep this manual in a safe and convenient location for quick
reference.
Fujitsu makes every effort to prevent users and bystanders from being injured and to prevent property damage. Be sure to
use the product according to the instructions in this manual.
Exportation/release of this document may require necessary procedures in accordance with the regulations of the Foreign
Exchange and Foreign Trade Control Law of Japan and/or US export control laws.
Manuals for the PRIMEQUEST 2000 series
The following manuals have been prepared to provide you with the information necessary to use the PRIMEQUEST 2000
series.
You can access HTML versions of these manuals at the following sites:
Japanese-language site: http://jp.fujitsu.com/platform/server/primequest/manual/2000
Global site: http://www.fujitsu.com/global/services/computing/server/primequest/
http://manuals.ts.fujitsu.com/
Title Description Manual code
PRIMEQUEST 2000 Series Getting
Started Guide Describes what manuals you should read and how to access important information after unpacking the PRIMEQUEST 2000
series server. (This manual comes with the product.)
C122-E170XA
PRIMEQUEST 2000 Series Safety
and Regulatory Information Contains important information required for using the PRIMEQUEST 2000 series safely. C122-E171XA
PRIMEQUEST 2000 Series Errata
and Addenda Provides errata and addenda for the PRIMEQUEST 2000 series manuals. This manual will be updated as needed. C122-E182EN
PRIMEQUEST 2000 Series
General Description Describes the functions and features of the PRIMEQUEST 2000 series. C122-B025EN
SPARC Enterprise/ PRIMEQUEST
Common Installation Planning
Manual
Provides the necessary information and concepts you should
understand for installation and facility planning for SPARC
Enterprise and PRIMEQUEST installations.
C120-H007EN
PRIMEQUEST 2000 Series
Hardware Installation Manual Includes the specifications of and the installation location requirements for the PRIMEQUEST 2000 series. C122-H007EN
PRIMEQUEST 2000 Series
Installation Manual Describes how to set up the PRIMEQUEST 2000 series server, including the steps for installation preparation, initialization, and
software installation.
C122-E174EN
PRIMEQUEST 2000 Series User
Interface Operating Instructions Describes how to use theWeb-UI and UEFI to assure proper operation of the PRIMEQUEST 2000 series server. C122-E176EN
PRIMEQUEST 2000 Series
Administration Manual Describes how to use tools and software for system administration and how to maintain the system (component replacement and
error notification).
C122-E175EN

Preface
ix
C122-E178-02EN
Title Description Manual code
PRIMEQUEST 2000 Series Tool
Reference Provides information on operation methods and settings, including details on the MMB and UEFI functions. C122-E177EN
PRIMEQUEST 2000 Series
Message Reference Lists the messages that may be displayed when a problem occurs during operation and describes how to respond to them. C122-E178EN
PRIMEQUEST 2000 Series
REMCS Installation Manual Describes REMCS service installation and operation C122-E180EN
PRIMEQUEST 2000 Series
Glossary Defines the PRIMEQUEST 2000 series related terms and abbreviations. C122-E179EN
Related manuals
The following manuals relate to the PRIMEQUEST 2000 series.
You can access these manuals at the following site:
http://www.fujitsu.com/global/services/computing/server/primequest/
http://manuals.ts.fujitsu.com/
Contact your sales representative for inquiries about the ServerView manuals.
Title Description Manual code
ServerView Suite ServerView
Operations Manager Quick
Installation (Windows)
Describes how to install and start ServerView Operations
Manager in a Windows environment. None
ServerView Suite ServerView
Operations Manager Quick
Installation (Linux)
Describes how to install and start ServerView Operations
Manager in a Linux environment. None
ServerView Suite ServerView
Installation Manager Describes the installation procedure using ServerView Installation Manager. None
ServerView Suite ServerView
Operations Manager Server
Management
Provides an overviewof servermonitoring using ServerView
Operations Manager, and describes the user interface of
ServerView Operations Manager.
None
ServerView Suite ServerView
RAID Management User Manual Describes RAID management using ServerView RAID Manager. None
ServerView Suite Basic Concepts Describes basic concepts about ServerView Suite. None
ServerView Operations Manager
Installation ServerView Agents for
Linux
Describes installation and update installation of ServerView Linux
Agent. None
ServerView Operations Manager
Installation ServerView Agents for
Windows
Describes installation and update installation of ServerView
Windows Agent. None
ServerView Mission Critical
Option User Manual Describes the necessary functions unique to PRIMEQUEST (cluster linkage) and ServerView Mission Critical Option (SVmco),
which is required for supporting these functions.
None
ServerView RAID Manager
VMware vSphere ESXi 5
Installation Guide
Describes the installation and settings required to use ServerView
RAID Manager on the VMware vSphere ESXi 5 server. None

Preface
x
C122-E178-02EN
Title Description Manual code
MegaRAID SAS Software Provides technical information on using RAID controllers.
Refer to the manual from the SVS-ServerView Suite ServerBooks
DVD(Manual)2 supplied with the product or from the following
URL:
The Fujitsu Technology Solutions manuals server
http://manuals.ts.fujitsu.com/
None
MegaRAID SAS Device Driver
Installation Provides technical information on using RAID controllers. Refer to the manual from the SVS-ServerView Suite ServerBooks
DVD(Manual)2 supplied with the product or from the following
URL:
The Fujitsu Technology Solutions manuals server
http://manuals.ts.fujitsu.com/
None
Modular RAID Controller
Installation Guide Provides technical information on using RAID controllers. Refer to the manual from the SVS-ServerView Suite ServerBooks
DVD(Manual)2 supplied with the product or from the following
URL:
The Fujitsu Technology Solutions manuals server
http://manuals.ts.fujitsu.com/
None
Abbreviations
This manual uses the following product name abbreviations.
Formal product name Abbreviation
Microsoft ®Windows Server ® 2012 R2 Datacenter Windows, Windows Server 2012
Microsoft ®Windows Server ® 2012 R2 Standard
Microsoft ® Windows Server ® 2012 Datacenter
Microsoft ®Windows Server ® 2012 Standard
Microsoft ®Windows Server ® 2008 R2 Standard Windows, Windows Server 2008 R2
Microsoft ®Windows Server ® 2008 R2 Enterprise
Microsoft ®Windows Server ® 2008 R2 Datacenter
Red Hat ® Enterprise Linux ® 6 (for Intel64) Linux, RHEL6, RHEL
Novell (R) SUSE(R) LINUX Enterprise Server 11 Service Pack 3 SLES11 SP3
Oracle Linux 6 (x86_64) Oracle Linux, Oracle Linux 6
VMware vSphere (R)5 VMware, vSphere 5.x, VMware 5, VMware 5.x
VMware (R) ESXi (TM) 5 ESXi, ESXi 5, ESXi 5.x
Trademarks
- Microsoft,Windows, andWindows Server are trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries.
- Linux is a registered trademark of Linus Torvalds.
- Red Hat, the Shadowman logo and JBoss are registered trademarks of Red Hat, Inc. in the U.S. and other countries.

Preface
xi
C122-E178-02EN
- Intel, Intel Logo, Intel Inside、Intel Inside Logo, Intel Atom, Intel Atom Inside, Intel Core, Core Inside, Intel vPro, vPro
Inside, Celeron, Celeron Inside, Itanium, Itanium Inside, Pentium, Pentium Inside, Xeon, Xeon Phi, Xeon Inside,
Ultrabook are trademarks of Intel Corporation in the U.S. and/or other countries.
- Ethernet is a registered trademark of Fuji Xerox Co., Ltd. in Japan and is a registered trademark of Xerox Corp. in the
United States and other countries.
- VMware is a trademark or registered trademark of VMware, Inc. in the United States and other countries.
- Novell and SUSE Linux Enterprise Server are trademarks of Novell, Inc.
- Xen is a trademark or registered trademark of Citrix Systems, Inc. or its subsidiaries in the United States and other
countries
- Other company names and product names are the trademarks or registered trademarks of their respective owners
- Trademark indications are omitted for some system and product names in this manual.
Notation
This manual uses the following fonts and symbols to express specific types of information.
Font or symbols Meaning Example
Italics Title of a manual that you should refer to See the PRIMEQUEST 2000 Series
Installation Manual (C122-E174EN).
[ ] Window names as well as the names of
buttons, tabs, and drop-down menus in
windows are enclosed in brackets.
Click the [OK] button.
Notation for the CLI (command line interface)
The following notation is used for commands.
Command syntax
Command syntax is represented as follows.
- Variables requiring the entry of a value are enclosed in angle brackets < >.
- Optional elements are enclosed in brackets [ ].
- Options for optional keywords are grouped in | (stroke) separated lists enclosed in brackets [ ].
- Options for required keywords are grouped in | (stroke) separated lists enclosed in braces { }.
Command syntax is written in a box.
Remarks
The command output shown in the PDF manuals may include line feeds at places where there is no line feed symbol
(¥at the end of the line).
Notes on notations
- If you have a comment or request regarding this manual, or if you find any part of this manual unclear, please take a
moment to share it with us by filling in the form at the following webpage, stating your points specifically, and sending
the form to us:
https://www-s.fujitsu.com/global/contact/computing/PRMQST_feedback.html
- The contents of this manual may be revised without prior notice.
- In this manual, the Management Board and MMB firmware are abbreviated as "MMB."
- In this manual, IOU_10GbE and IOU_1GbE are collectively referred to as IO Units.

Preface
xii
C122-E178-02EN
- Screenshots contained in this manual may differ from the actual product screen displays.
- The IP addresses, configuration information, and other such information contained in this manual are display
examples and differ from that for actual operation.
- The PDF file of this manual is intended for display using Adobe® Reader® in single page viewing mode at 100%
zoom.
This manual shall not be reproduced or copied without the permission of Fujitsu Limited.
Copyright 2014FUJITSULIMITED

Preface
xiii
C122-E178-02EN
Contents
Preface................................................................................................................................................................................................................i
Overview of Messages........................................................................................................................................................1CHAPTER 1
1.1 How to read the MMB messages.................................................................................................................................................1
1.1.1 System event log ......................................................................................................................................................................1
MMB Messages...................................................................................................................................................................3CHAPTER 2
2.1 MMB Message list.........................................................................................................................................................................3
2.1.1 Temperature sensor-related messages ..................................................................................................................................4
2.1.2 Voltage Sensor Related............................................................................................................................................................5
2.1.3 Fan Related...............................................................................................................................................................................7
2.1.4 PSU and DDC related..............................................................................................................................................................8
2.1.5 MMB related........................................................................................................................................................................... 11
2.1.6 SB/IOU/DU/MMB/OPL related.............................................................................................................................................. 21
2.1.7 Mezzanine related.................................................................................................................................................................. 22
2.1.8 PCI_Box related..................................................................................................................................................................... 23
2.1.9 PEXU related......................................................................................................................................................................... 24
2.1.10 Subsystem related............................................................................................................................................................ 26
2.1.11 FRU related....................................................................................................................................................................... 27
2.1.12 BMC related ...................................................................................................................................................................... 28
2.1.13 SYSTEM Status Sensor related ...................................................................................................................................... 48
2.1.14 MMB firmware related....................................................................................................................................................... 50
2.1.15 CPU related....................................................................................................................................................................... 52
2.1.16 Chipset related.................................................................................................................................................................. 53
2.1.17 Module related................................................................................................................................................................... 61
2.1.18 RAID Related.................................................................................................................................................................... 62
2.1.19 JX40 Related..................................................................................................................................................................... 68
2.1.20 Maintenance mode related............................................................................................................................................... 74
2.1.21 Power Saving related........................................................................................................................................................ 75
2.2 List of SVAS message IDs......................................................................................................................................................... 76
2.2.1 Linux related........................................................................................................................................................................... 76
2.2.2 Windows related.................................................................................................................................................................. 105
2.3 List of CLI messages................................................................................................................................................................114
2.4Window Display Error Messages.............................................................................................................................................140
Dynamic Reconfiguration Messages.............................................................................................................................182CHAPTER 3
3.1 Messages concerning incomplete system environment ........................................................................................................182
3.2 Messages concerning trouble that occurs in DR command ..................................................................................................182
3.3 Messages concerning trouble that occurs in the OS kernel...................................................................................................185
3.4 Messages concerning trouble that occurs outside of DR command other than OS kernel..................................................189
3.5 Messages concerning DR command progress......................................................................................................................189
sadump Messages .........................................................................................................................................................193CHAPTER 4
4.1 sadump Message list................................................................................................................................................................193
Appendix A Replacement component list...................................................................................................................................................195

Preface
xiv
C122-E178-02EN
Figures
FIGURE 1.1 Information area...................................................................................................................................................................1
FIGURE 1.2 [System Event Log] window................................................................................................................................................2

Preface
xv
C122-E178-02EN
Tables
TABLE 2.1 Messages sent even by Info .................................................................................................................................................3
TABLE A.1 Replacement component list...........................................................................................................................................195

Overview of Messages
1
C122-E178-02EN
Overview of MessagesCHAPTER 1
This chapter describes how to read the PRIMEQUEST 2000 series messages.
1.1 How to read the MMB messages
This chapter describes how to read the messages that are stored in the MMB. For the details on how to open the
MMB window, see ‘1.7 Basic operations of the Web-UI window’ in the PRIMEQUEST 2000 series User Interface
Operating Instructions (C122-E109). For the MMB messages, see Chapter 2 MMB Messages.
Note
If a [Part Number] or [Serial Number] UI (contents or information area) displays ‘Read Error’ check the
details of the error in ‘11.2 Troubleshooting’ in the PRIMEQUEST 2000 series Administration Manual’ (C122-
E108) . If the problem could not be resolved even then, contact your sales representative or field engineer.
Before contacting, confirm the model name and serial number shown on the label affixed to the main unit.
If ‘Read Error’ is displayed, do not perform operations in the partitions ([Reset] or [Force Power Off])
FIGURE 1.1 Information area
1.1.1 System event log
The events that occur in the PRIMEQUEST2000 series are stored as a system event log.
The MMB Web-UI [System Event Log] window displays the list.
The following section describes how to display the [System Event Log] window, and the display items, and
how to download the log data.
Displaying the [System Event Log] window
1. Select in the order of [System] — [System Event Log].
[System Event Log] window appears displaying the stored system event log.
‘FIGURE 1.2 [System Event Log] window’ shows an example of the [System Event Log] window.

Overview of Messages
2
C122-E178-02EN
FIGURE 1.2 [System Event Log] window
[System Event Log] window display items
For details on the display items of the [System Event Log] window, see 1.2.2 [System Event Log] window in
the PRIMEQUEST 2000 series Operations Management Tool Reference (C122-E110).
Downloading the data
Save the system event log as it is important information for investigation. It is important material when
contacting your sales representative or a field engineer. To download it, click the [Download] button.

MMB Messages
3
C122-E178-02EN
MMB MessagesCHAPTER 2
This chapter lists MMB messages by type. For details on how to open an MMB window, see 1.7 Basic
Operations in the Web-UI Window in the PRIMEQUEST 2000 Series User Interface Operating Instructions
(C122-E109EN).
2.1 MMB Message list
This chapter describes the messages of the system even log which is displayed in the MMB Web-UI. The
messages are arranged in the ascending order of the Event ID.
‘$’ represents the Wild card character.
The following Severity items indicate the severity of messages.
Error: Serious system problem
Warning: Event which is not necessarily serious, but will be a potential problem in future
Info: Notification event
Remarks
Even in a message that normally displays ‘Info’, High Severity would be displayed if the severity is high in
the same unit.
Example of 2C6F02FF:
If an FRU Communication Lost Error has already occurred in the FRU Sensor, ‘Error’ is displayed instead of
the normally displayed ‘Info’.
‘Error’ ‘Warning’ messages are sent via REMCS, Mail, or SNMP trap.
Note that even if the severity is ‘Info’, the following messages are sent via REMCS or SNMP trap.
The following table shows if messages have been sent.
TABLE 2.1 Messages sent even by Info
Event ID
Message
Sent via REMCS
Sent via SNMP trap
C06F00FF
Power Off
Not sent
Sent
C06F01FF
Power On In Progress
Not sent
Sent
C06F02FF
Reset
Not sent
Sent
C06F05FF
OS Running
Not sent
Sent
C06F06FF
OS Shutdown
Not sent
Sent
C06F07FF
Panic
Sent
Sent
C06F08FF
Power Off In Progress
Not sent
Sent
C06F09FF
Fatal
Not sent
Sent
C06F0AFF
Dumping
Not sent
Sent
C06F0BFF
Halt
Not sent
Sent
C06F0CFF
Stop Error
Sent
Sent

MMB Messages
4
C122-E178-02EN
2.1.1 Temperature sensor-related messages
Temperature Sensor related messages are listed below.
010100FF
Lower Non-critical - going low Assert $$$0C threshold: $$$0C
Meaning:
Low temperature warning has occurred.
Corrective action:
Check whether the monitored temperature has decreased as shown below, in the environment of the server
installed locations.
• Window left open in cold weather
• Air conditioner temperature setting, etc.
For PSU_S and PSU_P:
If the Inlet Temp is normal and PSU_S or PSU_P Temp is abnormal, please replace PSU_S or PSU_P.
Severity:
Warning
010107FF
Upper Non-critical - going high Assert $$$0C threshold$$$0C
Meaning:
High temperature warning has occurred.
Corrective action:
For Inlet Temp: Check the installation environment.
For PCIeSW Temp:
If the Inlet Temp is normal but the PCIe SW Temp is abnormal, check the inside and outside of the cabinet
for clogged filter or waste paper being stuck, that is interfering with the cooling.
Severity:
Warning
010109FF
Upper Critical - going high Assert $$$0C threshold: $$$0C
Meaning:
High temperature error has occurred.
Corrective action:
For Inlet Temp: Check the installation environment.
For PCIe SW Temp:
If the Inlet Temp is normal, but the PCIe SW Temp is abnormal, check the inside and outside of the cabinet
for clogged filter or waste paper being stuck, that is interfering with the cooling.
When the situation does not improve it, replace the unit.
Severity:
Error
01010BFF
Upper Non-recoverable - going high Assert $$$
℃
threshold: $$$
℃
Meaning:
High temperature error has occurred.
Corrective action:
For Inlet Temp: Check the installation environment.
For PCIe SW Temp:
If the Inlet Temp is normal, but the PCIe SW Temp is abnormal, check the inside and outside of the cabinet
for clogged filter or waste paper being stuck, that is interfering with the cooling.
When the situation does not improve it, replace the unit.
Severity:
Error
