Fujitsu PRIMERGY RX330 S1 User manual

PRIMERGY RX330 S1
Server
Options Guide
Edition August 2009

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected].
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
Copyright © 2009 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

RX330 S1 Options Guide
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Concept and target groups . . . . . . . . . . . . . . . . . . . 5
1.2 Overview of the documentation . . . . . . . . . . . . . . . . . 5
1.3 Extensions and conversions . . . . . . . . . . . . . . . . . . 7
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . . 8
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 Removing the air duct . . . . . . . . . . . . . . . . . . . . . 19
5 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.1 Installing a second processor . . . . . . . . . . . . . . . . . 21
6 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.1 Equipping rules . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.2 Extending/replacing the main memory . . . . . . . . . . . . 30
7 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . 33
7.1 Installing an accessible 5.25-inch drive . . . . . . . . . . . . 33

OptionsGuide RX330 S1
Contents
8 Expansion boards . . . . . . . . . . . . . . . . . . . . . . . . 37
8.1 Installing an expansion board . . . . . . . . . . . . . . . . . 37
8.2 Changing the riser card . . . . . . . . . . . . . . . . . . . . . 45
8.3 Installing the SAS RAID controller D2516 . . . . . . . . . . . 46
8.3.1 Assembling the SAS RAID controller D2516 . . . . . . . . . . . 46
8.3.2 Cabling SAS RAID controller . . . . . . . . . . . . . . . . . . . 50
9 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.1 Inserting the air duct . . . . . . . . . . . . . . . . . . . . . . 59
9.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 60
10 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
10.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

RX330 S1 Options Guide 5
1 Introduction
The PRIMERGY RX330 S1 server is an AMD-based server for small and
medium-sized networks. The PRIMERGY RX330 S1 is the perfect choice for
operational areas data centers, Internet- and application-hosting.
1.1 Concept and target groups
This Options Guide shows you how to extend and upgrade your server.
VCAUTION!
The activities described in this manual may only be performed by
technical specialists.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.
1.2 Overview of the documentation
More information on your PRIMERGY RX330 S1 can be found in the following
documents:
– “Quick Start Hardware - PRIMERGY RX330 S1” leaflet (only included as a
printed copy)
– “Quick Start Software - Quick Installation Guide” leaflet (only included as a
printed copy)
– “Safety notes and other important information” manual
– “Warranty” manual
– “Ergonomics” manual
– “Returning used devices” manual
– “Helpdesk” leaflet
– Technical manual for the system board D2440/D2932
– “PRIMERGY RX330 S1 Server Operating Manual”
– “PRIMERGY RX330 S1 Server Options Guide”

6 OptionsGuide RX330 S1
Overview of the documentation Introduction
– “ServerView RAID Manager Operating Manual”
– “Integrated RAID for SAS User’s Guide”
– “Integrated Mirroring User’s Guide”
– “LSI SATA Software RAID User’s Guide”
– “BIOS Setup” manual
IPRIMERGY manuals are available in PDF format on the ServerView
Suite DVD 2 (ServerBooks). This DVD is part of the ServerView Suite
supplied with every server.
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL:
http://manuals.fujitsu-siemens.com. The PRIMERGY server documentation
can be accessed using the Industry standard servers navigation option.
If you need a replacement copy of the ServerView Suite DVD2, send the
details of your server to the following e-mail address: Reklamat-PC-
[email protected]
Further sources of information:
– PRIMERGY Abbreviations and Glossary on the PRIMERGY
ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system

RX330 S1 Options Guide 7
Introduction Extensions and conversions
1.3 Extensions and conversions
Second processor
The server can be upgraded to a so-called dual processor system. A dual
processor system needs a multi processor operating system. The second
processor must have the same type and clock rate as the first.
Extension of the main memory
Eight slots (4 banks with 2 modules) are available for the main memory. Each
memory bank can be populated with 512 Mbyte (only D2440), 1 Gbyte, 2 Gbyte
or 4 Gbyte ECC DDR 2 SDRAM memory modules.
If the memory modules are populated in pairs, each pair must consist of
identical memory modules (2-way interleaved mode).
Additional accessible drive
One 5.25-inch bay is available for accessible drives.
Expansion boards in the PCI slots
The system board offers 1x PCI-Express x8 slot.
Additional the following slots are available by a riser card:
– 1 x PCI Express x8 slot, 1 x PCI Express x4 slot and
1 x PCI-X (64 Bit / 66 MHz, ZCR) slot, or
– 1 x PCI Express x8 slot, 1 x PCI-X (64 Bit / 66 MHz) slot and
1 x PCI-X (64 Bit / 66 MHz, ZCR) slot.

8 OptionsGuide RX330 S1
Notational conventions Introduction
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands, menu items or software programs.
“Quotation marks” indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

RX330 S1 Options Guide 9
2Procedure
VCAUTION!
●The actions described in this manual should only be performed by
technical specialists.
●Equipment repairs should only be performed by service personnel.
●Any unauthorized opening and improper repairs could expose the
user to risks (electric shock, energy hazards, fire hazards) and could
also damage the equipment.
●Any unauthorized opening of the device will result in the invalidation
of the warranty and exclusion from all liability.
ÊFirst of all please familiarize yourself with the safety instructions in the
section chapter “Safety notes” on page 11 et seq. .
ÊEnsure that all required manuals (see “Overview of the documentation” on
page 5) are available, printing out the PDF files if necessary. You will
definitely need the Operating Manual for the server and the Technical
Manual for the system board.
ÊShut down the server correctly, switch it off, pull out the power plug(s),
and open the server as described in the chapter “Preparation” on page 17 et
seq. .
ÊExtend or upgrade your server as described in the relevant chapter.
IThe Operating Manual for the server describes how you
install/remove the hot-plug components.
ÊClose the server, connect it to the power outlet, and switch it on as described
in the chapter “Completion” on page 59 et seq. .
ÊStart the operating system and, if necessary, configure it as required (see
the Operating Manual).

RX330 S1 Options Guide 11
3 Safety notes
IThe following safety instructions are also provided in the manual “Safety
notes and other important information”.
This device complies with the relevant safety regulations for data processing
equipment. If you have any questions about where you can set up the device,
contact your sales outlet or our customer service team.
VCAUTION!
●The actions described in this manual should only be performed by
technical specialists.
●Equipment repairs should only be performed by service personnel.
●Any unauthorized opening and improper repairs could expose the
user to risks (electric shock, energy hazards, fire hazards) and could
also damage the equipment.
●Any unauthorized opening of the device will result in the invalidation
of the warranty and exclusion from all liability.
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the device.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.

12 Options Guide RX330 S1
Safety notes
Installation and operation
VCAUTION!
●If the device is integrated in an installation that receives power from
an industrial (public) power supply network with the IEC309
connector, the (public) power supply protection must comply with the
requirements for the non-industrial (public) power supply networks for
the type A connector.
●The device automatically sets itself to a voltage in the range of
Wert. Make sure that your local voltage is within this range.
●This device has a specially approved power cable and must only be
connected to a safety socket on the rack mains socket strip.
●The ON/OFF button does not disconnect the device from the mains
voltage. To completely disconnect it from the mains voltage, remove
the power plug from the safety socket.
●Always connect the device and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
the server is still operating but the peripheral device (e.g. storage
subsystem) has failed during a power outage.
●Take notice that the data cables to peripheral devices are adequately
shielded.
●To the LAN wiring the requirements apply in accordance with the
standards EN 50173 and EN 50174-1/2. As minimum requirement
the use of a protected LAN line of category 5 for 10/100 MBps
Ethernet, and/or of category 5e for Gigabit Ethernet is considered.
The requirements of the specification ISO/IEC 11801 are to be
considered.
●Route the cables in such a way that they do not form a potential
hazard and that they cannot be damaged. When connecting up a
device, refer to the relevant notes in this manual.
●Never connect or disconnect data transmission lines during a storm
(lightning hazard).

RX330 S1 Options Guide 13
Safety notes
VCAUTION!
●Make sure that no objects (such as bracelets or paper clips) fall into
or liquids spill into the device (risc of electric shock or short circuit).
●In emergencies (e.g. damaged casing, controls or cables, penetration
of liquids or foreign matter), switch off the device immediately, remove
the power plug from the safety socket and contact your sales outlet or
customer service team.
●Proper operation of the device (in accordance with IEC 60950-1/
EN 60950-1) is only ensured if the casing is completely assembled
and the rear covers for the installation openings have been put in
place (electric shock, cooling, fire protection, interference
suppression).
●Only install system expansions that satisfy the requirements and
rules governing safety and electromagnetic compatibility and relating
to telecommunications terminal equipment. If you install other expan-
sions, you may damage the system or violate the safety regulations
and regulations governing RFI suppression. Information on which
system expansions are suitable can be obtained from the customer
service centre or your sales outlet.
●The components or parts marked with a warning label (e.g. lightning
symbol) may only be opened, removed or exchanged by authorized,
qualified personnel.
●The warranty expires if the device is damaged during the installation
or replacement of system expansions.
●You may only set those resolutions and refresh rates specified in the
operating manual of the monitor. Otherwise, you may damage your
monitor. If you are in any doubt, contact your sales outlet or customer
service centre.

14 Options Guide RX330 S1
Safety notes
Batteries
VCAUTION!
●Incorrect replacement of batteries may result in a risk of explosion.
The batteries may only be replaced with identical batteries or with a
type recommended by the manufacturer (see the technical manual for
the system board).
●Replace the lithium-battery on the system board in accordance with
the instructions in the technical manual for the system board.
Working with CDs/DVDs and CD/DVD drives
When working with devices with CD/DVD drives, these instructions must be
followed.
VCAUTION!
●Only use CDs/DVDs that are in perfect condition in your server's
CD/DVD drive, in order to prevent data loss, equipment damage and
injury.
●Check each CD/DVD for damage, cracks, breakages etc. before
inserting it in the drive.
Note that any additional labels applied may change the mechanical
properties of a CD/DVD and cause imbalance.
Damaged and imbalanced CDs/DVDs can break at high drive speeds
(data loss).
Under certain circumstances, sharp CD/DVD fragments can pierce
the cover of the CD/DVD drive (equipment damage) and can fly out
of the device (danger of injury, particularly to uncovered body parts
such as the face or neck).
IYou can prevent mechanical damage and damage to the CD/DVD drive,
as well as premature CD/DVD wear, by observing the following sugges-
tions:
●Only insert CDs/DVDs in the drive when needed and remove them
after use.
●Store the CDs/DVDs in suitable sleeves.
●Protect the CDs/DVDs from exposure to heat and direct sunlight.

RX330 S1 Options Guide 15
Safety notes
ILaser information
The CD/DVD drive complies with IEC 60825-1 laser class 1.
VCAUTION!
The CD/DVD drive contains a light-emitting diode (LED), which under
certain circumstances produces a laser beam stronger than laser
class 1. Looking directly at this beam is dangerous.
Never remove parts of the CD/DVD drive casing!
Modules with electrostatic-sensitive components
Systems and components that might be damaged by electrostatic discharge
(ESD) are marked with the following label:
Figure 1: ESD label
When you handle components fitted with ESDs, you must observe the following
points under all circumstances:
●Remove the power plug before installing or removing components
containing ESDs.
●You must always discharge yourself of static charges (e.g. by touching a
grounded object) before working.
●The equipment and tools you use must be free of static charges.
●Only touch the components at the positions highlighted in green (touch
points).
●Do not touch any exposed pins or conductors on a component.
●Use a grounding cable designed for this purpose to connect yourself to the
system unit as you install components.

16 Options Guide RX330 S1
Safety notes
●Place all components on a static-safe base.
IYou will find a detailed description for handling ESD components in the
relevant European or international standards (DIN EN 61340-5-1,
ANSI/ESD S20.20).

RX330 S1 Options Guide 17
4 Preparation
VCAUTION!
Observe the safety instructions in the chapter “Safety notes” on page 11
et seq. .
4.1 Opening the server
ÊTerminate all applications and shut down the server correctly.
ÊIf your operating system has not switched off the server, press the on/off
button.
ÊPull all power connectors out of the safety sockets.
ÊDisconnect all cables on the rear of the server.
Figure 2: Pulling the server out of the rack
ÊLoosen the two knurled screws (1) and pull the server as far as possible out
of the rack.
If the server is difficult to reach in the rack cabinet after you have pulled it out or
partially extending telescopic rails are used, remove the server completely from
the rack cabinet. If you do not want to remove the server, skip the following two
steps.
ÊPush the safety springs (2) on both sides and carefully pull the server
outward.
ÊPull the server out of the rails and place it on a table, for example.
1
2

18 Options Guide RX330 S1
Opening the server Preparation
Figure 3: Loosening the screws
ÊUnlock the top cover by removing the knurled screw at the rear side.
ÊPull the top cover approxiate 2 cm frontward using the handle.
ÊRemove the top cover.

RX330 S1 Options Guide 19
Preparation Removing the air duct
4.2 Removing the air duct
ÊRemove the top cover as described in section “Opening the server” on
page 17.
Figure 4: Removing the air duct
ÊTake out the air duct.
