Fujitsu PRIMERGY RX220 User manual

PRIMERGY
PRIMERGY RX220
Serversystem
Options Guide
Monika Spanjaart
Fujitsu Siemens Computers GmbH Muenchen
33094 Paderborn
e-mail: email: [email protected]
Tel.:
Fax: 0 700 / 372 00001
RX220
Sprachen: En
Edition September 2005

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Fax forms for sending us your comments are included in
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademar s
Copyright © 2005 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

RX220 OptionsGuide
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Overview of the documentation . . . . . . . . . . . . . . . . . . 5
1.2 Extensions and conversions . . . . . . . . . . . . . . . . . . . . 7
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . 9
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . 13
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 19
5 Main Memory . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.1 Installation rules . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.2 Upgrading / exchanging main memory . . . . . . . . . . . . . 23
6 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.1 Installing a second processor . . . . . . . . . . . . . . . . . . 25
6.2 Exchanging the processor . . . . . . . . . . . . . . . . . . . 30
7 Accessible Drive . . . . . . . . . . . . . . . . . . . . . . . . 33
7.1 Installing a CD-ROM/DVD drive . . . . . . . . . . . . . . . . . 33
8 Controllers in Non-Hot-Plug PCI Slots . . . . . . . . . . . . 37
8.1 Installing controllers . . . . . . . . . . . . . . . . . . . . . . 38
9 RemoteView Components . . . . . . . . . . . . . . . . . . . 41
9.1 Installing the RemoteView Service Board S2 LP . . . . . . . . 41
10 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
10.1 Closing the server . . . . . . . . . . . . . . . . . . . . . . . 45
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

RX220 OptionsGuide 5
1 Preface
The PRIMERGY RX220 is an AMD Opteron-based server for mid-tier applica-
tions in server farms. The server is well suited for front end services as well as
for use as an e-mail server, Internet server, or general applications server.
1.1 Overview of the documentation
IPRIMERGY manuals are available in PDF format on the ServerBooks
CD which is supplied as part of the ServerView Suite package for every
server system.
These PDF files can also be downloaded free of charge from the
Internet: At http://manuals.fujitsu-siemens.com you will find an overview
page showing the online documentation available on the Internet. You
can go to the PRIMERGY Server documentation by clicking on “amd
based servers”.
Concept and target groups
This Options Guide shows you how you can expand and upgrade the server.
VCaution!
The activities described in this manual may only be performed by
specialist personnel with technical training.
IHow to install/remove the hot-plug components is described in the
Operating Manual for the server.
Additional documentation about the server
The PRIMERGY RX220 documentation comprises the following additional
manuals:
– The “Security” manual (printed copy always supplied with the server, and
available as a PDF file on the ServerBooks CD supplied)
– The “Guarantee” manual (printed copy always supplied with the server, and
available as a PDF file on the ServerBooks CD supplied)
– The Operating Manual for PRIMERGY RX220 (PDF available on the Server-
Books CD supplied)
– The Technical Manual for the system board D2130 (PDF available on the
ServerBooks CD supplied)

6 OptionsGuide RX220
Overview of the documentation Preface
– The “BIOS Setup” manual (PDF available on the ServerBooks CD supplied)
– The “Service Supplement for PRIMERGY RX220” (PDF available on the
ServerBooks CD supplied)
– The “ServerView Suite” manual (printed copy always supplied with the
server, and available as PDF file on the ServerBooks CD supplied)
– The “Ergonomics” manual (PDF available on the ServerBooks CD supplied).
IYou can order a supplementary ServerBooks CD by sending an e-mail to
the following address, quoting your server data:
[e-mail]
Further sources of information:
– Technical Manual on the relevant rack
– Manual on the monitor
– Manual on ServerView Server Management
– Manual on the RemoteView Remote Test and Diagnostics System
– Documentation on boards and drives
– Documentation on your operating system
– Information files on your operating system
(see also “Related publications” on page 53)

RX220 OptionsGuide 7
Preface Extensions and conversions
1.2 Extensions and conversions
Second processor
The system board can be upgraded with a second processor. Only processors
of the same type may be used on the system board. The second processor must
have the same clock frequency as the first processor.
Extension of the main memory
The eight slots for the main memory are suitable for PC-3200 DDR DIMM
memory modules. Their organization in four memory banks, 1 to 4, allows fast
memory access with two-way interleaving.
Memory modules must always be installed in pairs. A memory bank (two
modules) must always be fully equipped and with the same type of memory
modules.
Additional accessible drives
A CD-ROM/CD-RW/DVD accessible drive can be installed in the top bay. The
bay is intended for a 5.25 x 0.5 inch CD-ROM/DVD drive.
Additional controllers in non-hot-plug PCI slots
The system board offers two PCI expansion slots:
– PCI-X slot 1: 64 bit/133 MHz, max. length 315 mm
– PCI Express x8 slot 2: PCI Express 1.0a specifications
IBoth slots are not hot-pluggable.
RemoteView
RemoteView provides you with a comprehensive remote test and diagnostics
package.
RemoteView Service Board S2 LP
The RemoteView Service Board S2 “low profile” (RSB S2 LP) is a PCI board
with a completely independent system, i.e. it has its own operating system with
Web server and SNMP agents and can optionally be equipped with an external
power supply.

8 OptionsGuide RX220
Extensions and conversions Preface
The RSB S2 LP is inserted into a PCI-X slot in the riser card and connected to
the system board by means of two cables.
The RSB S2 LP permits remote diagnosis for system analysis, remote system
configuration and remote restart even in the event of operating system failure or
hardware faults. It has its own LAN connection and its own COM port. All the
functions of the RSB S2 LP are thus available either via LAN or via modem.

RX220 OptionsGuide 9
Preface Notational conventions
1.3 Notational conventions
The following notational conventions are used in this manual:
Italics indicate commands, menu items or software programs.
“Quotation marks” indicate names of chapters and terms that should be
emphasized.
Êtext which follows this symbol describes activities that
must be performed in the order shown.
VCAUTION! pay particular attention to text marked with this symbol.
Failure to observe this warning may endanger your life,
damage the server, or lead to loss of data.
Isupplementary information, remarks and tips follow this
symbol.
Table 1: Notational conventions

RX220 OptionsGuide 11
2Procedure
VCAUTION!
●The actions described in this manual should only be performed by
engineers, service personnel or technical specialists.
●Equipment repairs should only be performed by authorized, qualified
staff.
●Any failure to observe the guidelines in this manual, and any unautho-
rized openings and improper repairs could expose the user to risks
(e.g. electric shock, fire hazards) and could also damage the
equipment.
●Please note that any unauthorized opening of the device will result in
the invalidation of the warranty and exclusion from all liability.
ÊFirst of all please familiarize yourself with the safety instructions in the
chapter “Safety Instructions” on page 13.
ÊMake sure that all required manuals (see “Additional documentation about
the server” on page 5) are available, printing out the PDF files if necessary.
You will definitely need
– the Operating Manual for the server and
– the Service Supplement for the server
– the Technical Manual for the system board.
ÊShut down the server correctly, switch it off, pull out the power plug, and
open the server as described in the chapter “Preparation” on page 19ff.
ÊExtend or upgrade your server as described in the relevant chapter.
IHow to install/remove the hot-plug components is described in the
Operating Manual for the server.
ÊClose the server as described in the chapter “Completion” on page 45ff.
ÊStart the operating system and, if necessary, configure it as required (see
the Operating Manual).

RX220 OptionsGuide 13
3 Safety Instructions
IThe following safety instructions can also be found in the manual entitled
“Safety”.
This device complies with the relevant safety regulations for data processing
equipment, including electronic office machines for use in an office
environment.
If you have any questions as to whether you can set up the device in your
particular environment, please contact your sales outlet or our customer service
centre.
VCAUTION!
●The actions described in this manual should only be performed by
engineers, service personnel or technical specialists.
●Equipment repairs should only be performed by qualified staff.
●Any failure to observe the guidelines in this manual, and any unautho-
rized openings and improper repairs could expose the user to risks
(e.g. electric shock, fire hazards) and could also damage the
equipment.
●Please note that any unauthorized opening of the device will result in
the invalidation of the warranty and exclusion from all liability.
Before setting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for you device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the machine.
Before operating the device, wait until it is absolutely dry and has
reached approximately the same temperature as the installation site.
Failure to observe these guidelines can lead to material damage of
the device.
●Transport the device only in its original packaging or in packaging
which protects it from knocks and jolts.

14 OptionsGuide RX220
Safety Instructions
Installation and operation
VCAUTION!
●If the rack model is integrated in an installation that receives power
from an industrial (public) power supply network with the IEC309
connector, the (public) power supply protection must comply with the
requirements for the non-industrial (public) power supply networks for
the type A connector.
●The server automatically adjusts to a mains voltage between 100 V
and 240 V. Make sure that the local mains voltage is neither above nor
below this range.
●This device has safety-tested power cables and must only be
connected to properly grounded power outlets.
●Make sure that the power socket on the device or the grounded mains
outlet is freely accessible.
●The power switch does not disconnect the device from the mains
voltage. To completely disconnect it from the mains voltage, you must
remove the power plug from the power outlet.
●Always connect the device and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
a power outage occurs and the central processing unit is still running
but the peripheral device (e.g. a storage subsystem) has failed.
●Data cables must be adequately shielded to avoid interference.
●For the LAN wiring, the requirements according to standards EN
50173 and EN 50174-1/2 apply. The minimum requirement is the use
of a protected LAN line of category 5 for 10/100 Mbps Ethernet,
and/or of category 5e for Gigabit Ethernet. The requirements of the
specification ISO/IEC 11801 must also be taken into account.
●Route the cables in such a way that they do not form a potential
hazard (tripping) and that they cannot be damaged. When connecting
the device, refer to the relevant notes in the operating manual.
●Do not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).

RX220 OptionsGuide 15
Safety Instructions
VCAUTION!
●Be careful to ensure that no objects (e.g. jewelry, paper clips etc.) or
liquids get inside the device (electric shock, short circuit).
●In emergencies (e.g. damaged casing, elements, or cables,
penetration of liquids or foreign bodies), switch off the device immedi-
ately, remove the power connector from the grounded power outlet,
and contact your customer service centre.
●Proper operation of the device (in accordance with IEC 60950/DIN
EN 60950) is only ensured if the casing is completely assembled and
the rear covers for the installation openings have been put in place
(electric shock, cooling, fire protection, interference suppression)
●Install only system extensions that satisfy the requirements and rules
governing safety, electromagnetic compatibility, and telecommunica-
tions terminal equipment.
If you install other extensions, you may damage the system or violate
these safety regulations.
Information on which system extensions are suitable can be obtained
from the customer service centre or your sales outlet.
●The components marked with a warning label (e.g. lightning symbol)
may only be opened, removed, or exchanged by authorized, qualified
personnel.
●The warranty is invalidated if the device is damaged during the instal-
lation or replacement of system extensions.
●You may set only those resolutions and refresh rates specified in the
operating manual for your monitor.
Otherwise, you may damage the monitor. If you are in any doubt,
contact your sales outlet or customer service centre.

16 OptionsGuide RX220
Safety Instructions
Batteries
VCAUTION!
●Incorrect replacement of batteries may lead to risk of explosion. The
batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer (see the Technical Manual for the
system board under “Related publications” on page 53).
●Do not throw batteries into the trash can. They must be disposed of
in accordance with local regulations concerning special waste.
●Replace the lithium battery on the system board in accordance with
the instructions in the Technical Manual for the system board (see
“Related publications” on page 53).
●All batteries containing pollutants are marked with a symbol (a
crossed-out garbage can). The marking also contains the chemical
symbol of the heavy metal that determines the classification as a
pollutant:
Cd Cadmium
Hg Mercury
Pb Lead
Notes on handling CDs in CD-ROM/DVD drives
VCAUTION!
●Use only CDs in proper condition in the CD-ROM/DVD drive of your
server to prevent data loss, damage to the device, or injuries.
●Therefore, check each CD for damage, cracks, breakage etc. before
inserting it in the drive.
●Please note that any additional labels applied may change the
mechanical properties of a CD and cause imbalance.
●Damaged and imbalanced CDs can break at high drive speeds (data
loss).
●Under certain conditions, sharp-edged pieces of broken CDs can
penetrate the cover of the drive (cause damage to the device) and be
thrown out of the device (therefore causing injury to uncovered body
parts, particularly the face or neck).

RX220 OptionsGuide 17
Safety Instructions
ITo protect the CD-ROM/DVD drive and prevent mechanical damage, as
well as premature wearing of the CDs, you should observe the following
advice:
– Only insert the CDs in the drive when needed and remove them after
use.
– Store the CDs in suitable sleeves.
– Protect the CDs from exposure to heat and direct sunlight.
Note on the laser
The CD-ROM/DVD drive contains a light-emitting diode (LED) classified
according to IEC 825-1:1993:LASER CLASS 1.
VCAUTION!
The CD-/DVD-ROM drive contains a laser diode (LED). Sometimes the
LED produces a stronger laser beam than laser class 1. Direct view into
this laser beam is dangerous.
Never remove parts of the CD-/DVD-ROM drive assembly!
Modules with electrostatic-sensitive devices
Electrostatic-sensitive components are identified by the following sticker:
Figure 1: ESD label
VCAUTION!
When you handle components fitted with ESDs, you must observe the
following points under all circumstances:
●Remove the power plug from the power socket before inserting or
removing components containing ESDs.

18 OptionsGuide RX220
Safety Instructions
●You must always discharge static build-up (e.g. by touching a
grounded object) before working with such components.
●The equipment and tools you use must be free of static charge.
●Use a grounding cable designed for this purpose to connect yourself
to the system unit as you install components.
VCAUTION!
●Always hold components with ESDs at the points marked green
(touch points).
●Do not touch any exposed pins or conductors on a component.
●Place all components on a static-free base.
IYou will find a detailed description of handling ESD components in the
relevant European or international standards (EN 61340-5-1,
ANSI/ESD S20.20).

RX220 OptionsGuide 19
4 Preparation
VCAUTION!
Please observe the safety information in the chapter “Safety Instructions”
on page 13ff.
4.1 Opening the server
ÊExit all applications and shut down the server correctly.
ÊPress the on/off button.
ÊUnplug the power plugs.
Figure 2: Removing the server
ÊUndo the knurled screws (1) and pull the server carefully out of the
rack (2) as far as possible.
2
1
1

20 OptionsGuide RX220
Opening the server Preparation
ÊIn the majority of cases it makes sense to remove the server from the rack.
VCAUTION!
There is no cable management for the server in the rack!
Before you remove the server from the rack, you must therefore
unplug all cables connected to the server from their sockets.
IHow to remove the server from the rack is described in the operating
manual.
Figure 3: Removing the cover
ÊUndo the knurled screw (1)on the back of the device.
ÊPush the server cover backward (2) a few centimeters using the recessed
grips (3).
ÊLift up the server cover and remove it.
