Fujitsu Supercomputer PRIMEHPC FX700 Installation instructions

KM0205-00001
FUJITSU PRIMEHPC FX700
Disassembly and Recycling Instruction
January 2020

PRIMEHPC FX700 1 Disassembly and Recycling Instruction
Version history
Issue number
Reason for update
1.0 / January 2020
Initial rerease

PRIMEHPC FX700 2 Disassembly and Recycling Instruction
Contents
1Disassembly and recycling ............................................................................................................................................3
1.1 Recycling information...........................................................................................................................................3
1.2 Disassembly ..........................................................................................................................................................4
1.2.1 Removing the Chassis and Mounting Rail in the Rack.....................................................................................4
1.2.2 Removing the Top Cover................................................................................................................................11
1.2.3 Removing the BMCIFB..................................................................................................................................12
1.2.4 Removing the PANELB..................................................................................................................................14
1.2.5 Removing the BMCB and PSUBP..................................................................................................................16
1.2.6 Removing the Battery .....................................................................................................................................22
1.2.7 Removing the FAN.........................................................................................................................................23
1.2.8 Removing the CMB and CMBIFB .................................................................................................................26
1.2.9 Removing the M.2 SSD..................................................................................................................................30
1.2.10 Removing the PCI card...............................................................................................................................31

PRIMEHPC FX700 3 Disassembly and Recycling Instruction
1 Disassembly and recycling
1.1 Recycling information
This manual provides instructions to disassembly the PRIMEHPC FX700.
All materials can be disposed according to the regulation in the EU Directive
2012/19 / EU (Waste Electrical and Electronic Equipment (WEEE)).
Product group: Server
Model: PRIMEHPC FX700
Materials that must be disposed of separately
Description
Part
Number
Circuit boards
With a surface larger than 10 cm^2
BMCB
BMCIFB
PSUBP
CMB
CMUIFB
PANELB
PCI card
M.2 SSD
1
1
1
1-4
1-4
1
1-8
1-8
Batteries
Lithium battery CR2032
(on BMCB)
1
Mercury-containing components
-
-
Liquid crystal displays (optionally together with
the housing) with a surface of more than 100 cm^2
and backlit displays with gas discharge lamps
-
-
Cathode ray tubes
-
-
PCB-containing capacitors
(PCB: polychlorinated biphenyls)
-
-
Electrolytic capacitors containing substances of
concern (height> 25 mm, diameter:> 25 mm or
proportionally similar volume)
Power supply unit
2-3
External cables
-
-
Gas discharge lamps
-
-
Plastics containing brominated flame retardants
-
-

PRIMEHPC FX700 4 Disassembly and Recycling Instruction
1.2 Disassembly
Not all components are installed in the server depending on the
configuration.
1.2.1 Removing the Chassis and Mounting Rail in the Rack
Tools: Phillips PH2 / (+) No. 2 screw driver
Recycling parts
Metal
Several screws
1.2.1.1 Removing the all FANU
Figure 1 Removing the front panel
➢Unscrew the two screws(1) and remove the front panel in the direction of the arrow.
Toner cartridges, liquid and pasty, and color
toner
-
-
Asbestos waste and components containing
asbestos
Components containing refractory ceramic fibers
Components containing radioactive substances
Components containing Chlorofluorocarbons
(CFC), hydro chlorofluorocarbons (HCFC),
hydrofluorocarbons (HFC) or hydrocarbons (HC)
(1)
(1)

PRIMEHPC FX700 5 Disassembly and Recycling Instruction
Figure 2 Removing the FANU
➢While the first lock is unlocked (1), pull out the FANU in the direction of (2).
➢The following shows the holding positions when you remove a FANU.
Table 1 Holding Positions When Removing a FANU
Thumb
Index Finger
Right-hand operation
C
B
Left-hand operation
B
A
(2)
(1)
A
C
B
Figure 3 Holding Positions When Removing a FANU

PRIMEHPC FX700 6 Disassembly and Recycling Instruction
Figure 4 Pulling Out the FANU
➢While the second lock for fall prevention is unlocked (3), pull out the FANU.
1.2.1.2 Removing the all PSU
Figure 5 Removing the PSU
➢While the lock is unlocked, pull the handle to remove the PSU from the slot (1).
(3)

PRIMEHPC FX700 7 Disassembly and Recycling Instruction
1.2.1.3 Removing the Dummy PSU
Figure 6 Removing the Dummy PSU
➢While the lock is unlocked(1), pull the handle to remove the dummy PSU from the slot (2).
1.2.1.4 Removing the all Blade
Figure 7 Removing the all Blade
➢While the lock is unlocked, pull the handle to remove the blade from the slot (1).
(2)
(1)
Handle

PRIMEHPC FX700 8 Disassembly and Recycling Instruction
1.2.1.5 Removing the all Dummy Blade
Figure 8 Removing the all Dummy Blade
➢Unlock the lock on the release lever, grasp the pull handle, and pull out the dummy blade from the
slot (1).
1.2.1.6 Removing the Chassis
Figure 9 Removing the Chassis

PRIMEHPC FX700 9 Disassembly and Recycling Instruction
1.2.1.7 Removing the Mounting Rail
Figure 10 Screw Positions on the Rail
➢Unscrew the four screws on the sliding part of the right rail.
Figure 11 Rear of the Rail
➢Unscrew the two screws rear of the rail.

PRIMEHPC FX700 10 Disassembly and Recycling Instruction
Figure 12 Front of the Rail
➢Unscrew the two screws front of the rail and removing the rail.

PRIMEHPC FX700 11 Disassembly and Recycling Instruction
1.2.2 Removing the Top Cover
Tools: Phillips PH2 / (+) No. 2 screw driver
Recycling parts
Metal
Several screws
Figure 13 Screw positions on the top cover
➢Unscrew the four screws on the top cover.
Figure 14 Removing the top cover

PRIMEHPC FX700 12 Disassembly and Recycling Instruction
1.2.3 Removing the BMCIFB
Tools: Phillips PH2 / (+) No. 2 screw driver
Nipper
Recycling parts
Metal
Several screws
Cable
Printed circuit board
Figure 15 Top of the Server
➢Disconnecting the cable connector(1).
➢Unscrew a screw(2).

PRIMEHPC FX700 13 Disassembly and Recycling Instruction
Figure 16 Removing the BMCIFU
➢Removing the BMCIFU from the chassis.
➢Cut the cable ties. (1)
➢Disconnecting a cable connector.(2)
Figure 18 Screw positions on the BMCIFB
➢Unscrew the three screws on the BMCIFB.
(1)
(1)
(1)
(2)
Figure 17 Removing the cable

PRIMEHPC FX700 14 Disassembly and Recycling Instruction
1.2.4 Removing the PANELB
Tools: Phillips PH2 / (+) No. 2 screw driver
Recycling parts
Metal
Plastic
Several screws
Cable
Printed circuit board
Figure 19 Top of the Server
➢Disconnecting a cable connector(1).
➢Unscrew a screw(2).
➢Removing a PANELU(3).
(1)
(2)
(3)

PRIMEHPC FX700 15 Disassembly and Recycling Instruction
Figure 20 Removing the PANELB, Screw, Bracket and Lends
Screw
PANELB
Screw
Bracket
Bracket
Lends
Figure 21 Disconnecting a cable connector

PRIMEHPC FX700 16 Disassembly and Recycling Instruction
1.2.5 Removing the BMCB and PSUBP
Tools: Phillips PH2 / (+) No. 2 screw driver
Phillips PH1 / (+) No. 1 screw driver
Recycling parts
Metal
Plastic
Several screws
Cable
Printed circuit board
Figure 22 Top of the Server
➢Unscrew the three screws.
Figure 23 Removing the BMCU

PRIMEHPC FX700 17 Disassembly and Recycling Instruction
Figure 24 Removing the PSUBP
➢Disconnecting a cable connector(1).
➢Unscrew the eight screws.
➢Removing the PSUBP and Bracket
PSUBP
(1)
Bracket

PRIMEHPC FX700 18 Disassembly and Recycling Instruction
Figure 26 Removing the Screw
Figure 25 Removing the Bus bar
➢Disconnecting a cable connector(1).
➢Unscrew the four screws.
➢Removing the two Bus bars.
(1)
Bus bar

PRIMEHPC FX700 19 Disassembly and Recycling Instruction
Figure 28 Removing a Bus bar
Figure 27 Removing the Cover
➢Removing the four screws and Cover.
➢Removing the five screws and Bus bar.
Cover
Bus bar
