Fujitsu Eternus DX80 S2 User manual

Read Me First
Read Me First
ETERNUS DX80 S2/DX90 S2 Disk storage system
The information in this document is subject to change without notice for improvement and functionality expansion of the
ETERNUS DX Disk storage system.
The latest version of this document, the latest information about the ETERNUS DX Disk storage system, and important service
and support contacts (see “Contact Fujitsu”) for Fujitsu Customer Service for your country of purchase is available at the following
website:
http://www.fujitsu.com/global/services/computing/storage/eternus/products/diskstorage/dx-entry/
Fujitsu would like to thank you for purchasing our ETERNUS DX80 S2/DX90 S2 Disk storage system (hereinafter referred to as
"ETERNUS DX Disk storage system").
Read this document and check the shipment package to confirm that no items are missing.
Check the workflow to set up the ETERNUS DX Disk storage system by referring to "Setup Procedures". For details on the
procedures, refer to the manuals that are described with the mark.
Refer to the provided manuals or any related manuals for the ETERNUS DX Disk storage system as necessary.
The company names and product names mentioned in this document are either registered trademarks or trademarks of their respective companies.
Read and understand the "Safety Precautions" before use.
"Safety Precautions"
Table of Contents
P3A M -4 872-11EN
Copyright 2013 FUJITSU LIMITED
Provided Manuals ......................................... 2
Related Materials .......................................... 2
Package Contents.......................................... 3
Setup Procedures .......................................... 7
Operation and Maintenance ....................... 16
Terms of Use ............................................... 17

2
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
Manual Title Manual Code Description
ETERNUS DX80 S2/DX90 S2 Disk storage system
Overview
P3AM-4812 Describes the specifications, features, and functions of the
ETERNUS DX Disk storage system.
ETERNUS DX80 S2/DX90 S2 Disk storage system
User's Guide -Site Planning-
P3AM-4822 Describes the onsite requirements for installation of the
ETERNUS DX Disk storage system.
ETERNUS DX80 S2/DX90 S2 Disk storage system
User's Guide -Installation-
P3AM-4832 Describes all the procedures that are required to start
operation of the ETERNUS DX Disk storage system.
ETERNUS DX80 S2/DX90 S2 Disk storage system
User's Guide -Operation-
P3AM-4842 Describes the operation management and maintenance of
the ETERNUS DX Disk storage system.
ETERNUS DX80 S2/DX90 S2 Disk storage system
Product List
P3AM-4852 Provides lists of the optional products for the ETERNUS DX
Disk storage system and describes possible combinations.
ETERNUS DX80 S2/DX90 S2 Disk storage system
Read Me First
P3AM-4872 Describes how the manuals are organized, package
contents, setup procedures, and the terms of use for the
ETERNUS DX Disk storage system. A manual booklet is also
provided.
ETERNUS DX80 S2/DX90 S2 Disk storage system
Read Me First for Optional Products
P3AM-5052 Describes the package contents of the optional products.
Manual booklets are also provided for optional products.
ETERNUS DX60 S2/DX80 S2/DX90 S2
Disk storage system
Read Me First for Optional Products
P3AM-5562
ETERNUS DX60 S2/DX80 S2/DX90 S2 Disk storage
system Safety Precautions
P3AM-5062 Describes the safety precautions that must be taken for the
ETERNUS DX Disk storage system. A manual booklet is also
provided.
ETERNUS Web GUI User's Guide
ETERNUS DX80 S2/DX90 S2, ETERNUS DX410 S2/
DX440 S2, ETERNUS DX8100 S2/DX8700 S2
P2X0-1090 Explains how to monitor and set the ETERNUS DX Disk
storage system via Graphical User Interface (GUI).
ETERNUS CLI User's Guide
ETERNUS DX80 S2/DX90 S2, ETERNUS DX410 S2/
DX440 S2, ETERNUS DX8100 S2/DX8700 S2
P2X0-1030 Explains how to monitor and set the ETERNUS DX Disk
storage system via Command Line Interface (CLI).
ETERNUS SMI-S User's Guide
ETERNUS DX80 S2/DX90 S2, ETERNUS DX410 S2/
DX440 S2, ETERNUS DX8100 S2/DX8700 S2
P3AM-4602 Explains how to use the SMI-S compliant general storage
management application to manage the ETERNUS DX Disk
storage system.
Other manuals for the ETERNUS DX Disk storage system are as follows:
Manual Title Manual Code Description
ETERNUS DX Disk storage systems User's Guide
-Server Connection- (*1) Explains how to connect the ETERNUS DX Disk storage
system to a server.
ETERNUS DX60 S2/DX80 S2/DX90 S2 Disk storage
system User's Guide -Power Synchronized Unit-
P3AM-2532 Explains how to use a power synchronized unit.
ETERNUS DX80 S2/DX90 S2 Disk storage system
Feature activation licenses
P3AM-5072 Explains how to activate the license for the Thin Provisioning
feature of the ETERNUS DX Disk storage system.
The Documentation CD that is provided with the ETERNUS DX Disk storage system includes the following manuals:
*1: Download the necessary manuals for the customer operating environment (for server OS, host interface type, etc.) from the specified website.
For the URL of the download website, refer to the Documentation CD provided with the ETERNUS DX Disk storage system.
Provided Manuals
Related Materials

3
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
Check the list of package contents for the purchased product to confirm that no items are missing. Tick off the checkbox of each
confirmed item.
If there is a missing item, contact your sales representative.
●Store the package contents in a safe and secure location, as they may be needed again when making changes to the system or
reinstalling the software.
●Note that the package may sometimes also contain an Errata sheet and/or other such unlisted documentation.
ETERNUS DX80 S2 (2.5inch) (Product ID: ET082 aCbU(*1))
ETERNUS DX80 S2 (3.5inch) (Product ID: ET082 aDbU(*1))
ETERNUS DX90 S2 (2.5inch) (Product ID: ET092 aCbU(*1))
ETERNUS DX90 S2 (3.5inch) (Product ID: ET092 aDbU(*1))
Package Contents
□Controller enclosure (x 1)
Drives that are purchased at the same time as the ETERNUS DX Disk
storage system are preinstalled according to the installation rules.
●2.5inch
●3.5inch
□Pin (x 1)
Used to push the FUNCTION button of the controller
enclosure.
□Flange cover (x 1)
□Rack rail kit
□Rack rail (x 1 set)
□Bracket (x 2)
□Plate (x 2) □Washer (x 8)
□M5 screw (x 4)
for mounting the enclosure
□M5 screw (x 8)
for attaching the rack rails
□Read Me First (this document) (x 1)
□Safety Precautions (x 1)
□Documentation CD (x 1)
:
: . . .
: . . .
:
□Network Settings label (x 1)
□DE_No. label (x 1)
□Label
□Destination label (x 1)
for the QSFP cable
□AC200V cable (x 2)
IEC60320-C13↔NEMA L6-15P (4m)
*1: An alphanumerical character is used for ato indicate the ETERNUS DX Disk storage system model.
D: dual-controller type
S: single-controller type
An alphanumerical character may also be used for bdepending on the purchased product.

4
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
Drive Enclosure (2.5inch) (Product ID: ETCAD aCU, ETEAD aCU(*1))
Drive Enclosure (3.5inch) (Product ID: ETCAD aDU, ETEAD aDU(*1))
□Rack rail kit
□Rack rail (x 1 set)
□Bracket (x 2)
□Plate (x 2) □Washer (x 8)
□M5 screw (x 4)
for mounting the enclosure
□M5 screw (x 8)
for attaching the rack rails
□AC200V cable (x 2)
IEC60320-C13↔NEMA L6-15P (4m)
□QSFP cable
QSFP↔QSFP (0.75m)
One QSFP cable is provided when afor the product ID is "1".
Two QSFP cables are provided when afor the product ID is "2".
□Flange cover (x 1)
□Drive enclosure (x 1)
Drives that are purchased at the same time as the ETERNUS DX Disk
storage system are preinstalled according to the installation rules.
●2.5inch
●3.5inch
*1: An alphanumerical character is used for ato indicate the number of I/O modules.
1: one I/O module
2: two I/O modules

5
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
□Disk Drive
Installed in the controller enclosure or the drive enclosure.
●2.5inch
●3.5inch
*1: An alphanumerical character is used for ato indicate the drive capacity.
3: 300GB
4: 450GB
6: 600GB
9: 900GB
An alphanumerical character is used for bto indicate the number of drives and the RAID type.
H: x1
M : x2 (RAID1)
P : x6 (RAID5)
D: x6 (RAID6)
S : x6 (RAID1+0)
An alphanumerical character is used for cto indicate the drive size and the drive speed.
C: Disk Drive (2.5inch) 10krpm
D: Disk Drive (3.5inch) 15krpm
E : Self Encrypting Disk Drive (2.5inch) 10krpm
G: Disk Drive (2.5inch) 15krpm
SAS Disk Drive (Product ID: ETCD a b c , ETED a b c (*1))
□Disk Drive
Installed in the controller enclosure or the drive enclosure.
●2.5inch
●3.5inch
*1: An alphanumerical character is used for ato indicate the drive capacity.
1: 1TB
2: 2TB
3: 3TB
4: 4TB
An alphanumerical character is used for bto indicate the number of drives and the RAID type.
H: x1
M : x2 (RAID1)
P : x6 (RAID5)
D: x6 (RAID6)
S : x6 (RAID1+0)
An alphanumerical character is used for cto indicate the drive size.
C: 2.5inch
D: 3.5inch
Nealine SAS Disk Drive (Product ID: ETCN a b c , ETEN a b c (*1))

6
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
□SSD
Installed in the controller enclosure or the drive enclosure.
●2.5inch
●3.5inch
SSD (Product ID: ETCS a b c , ETES a b c (*1))
*1: An alphanumerical character is used for ato indicate the drive capacity.
1: 100GB
2: 200GB
4: 400GB
8: 800GB
An alphanumerical character is used for bto indicate the number of drives and the RAID type.
H: x1
M : x2 (RAID1)
P : x4 (RAID5)
S : x6 (RAID1+0)
An alphanumerical character is used for cto indicate the drive size.
C or E: 2.5inch
D or F: 3.5inch
*1: An alphanumerical character is used for ato indicate the host interface type.
C: FCoE
F : 8Gbit/s FC
H: 16Gbit/s FC
L : 1Gbit/s iSCSI
S : SAS
Y : 10Gbit/s iSCSI
An alphanumerical character is used for bto indicate the number of ports on a host interface adapter.
2 : two ports
N
: two ports (without SFP+ modules)
□Host interface adapter (x 1)
Host interface adapters are installed in the following locations at the rear of the controller enclosure:
●single-controller type
Host Interface (Product ID: ETCH a1b, ETEH a1b(*1))
Thin Provisioning Feature (Product ID: ETCL aT, ETEL aT(*1))
□License label (x 1) □Release tie (x 1)
*1: An alphanumerical character is used for ato indicate the target model.
8: for ETERNUS DX80 S2 Disk storage system
9: for ETERNUS DX90 S2 Disk storage system
●dual-controller type
When one host interface adapter is purchased, the host interface
adapter is installed in the location that is indicated by .
When two host interface adapters are purchased, the host interface
adapters are installed in the locations that are indicated by
and by .
When two host interface adapters are purchased, the host interface
adapters are installed in the locations that are indicated by .
When four host interface adapters are purchased, the host interface
adapters are installed in the locations that are indicated by
and by .

7
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
An installation space and network environment must be prepared in advance.
Prepare the following manuals:
●Documentation CD
●Related manuals, such as manuals for the server or the networking equipment that is used
Setup Procedures
Installation Space
-Site Planning- "2.5 Outlet/Socket Specifications"
Network Environment
●-Installation- "1.1 Connection Preparation"
●-Installation- "1.2 Setup Preparation"
●ETERNUS Web GUI User’s Guide
Preparation
STEP
●-Site Planning- "2.1 Installation Specifications"
●-Site Planning- "2.4 Installation Environment"
Installation space
Check that the installation area meets the space requirements of the rack in which the ETERNUS DX Disk storage
system is to be installed.
Environmental considerations for installation
Check if the installation area for the ETERNUS DX Disk storage system meets the environmental conditions and
installation environment conditions.
Power outlets
Check the type and the number of power outlets/sockets that are required to install the ETERNUS DX Disk storage
system.
Completing and attaching the Network Settings label
Write down the following information on the Network Settings label and attach it to the controller enclosure.
●IP address and subnet mask for the ETERNUS DX Disk storage system
●IP address for maintenance work
Settings for the PC
●Setup Network Environment
ƪIP address : 192.168.1.2
ƪSubnet mask : 255.255.255.0
●Set the Web browser
Refer to "ETERNUS Web GUI User’s Guide" for details on the settings that are required.

8
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
1. Adjust the rack rail size to fit the rack.
The rack rail needs to be attached to the rack and the controller enclosure or the drive enclosure needs to be
installed.
Front view Rear view
2U
[Right][Left]
6th position
(M5 centering screw)
2U
[Right][Left]
6th position
(M5 centering screw)
1st position
(M5 pan head screw)
1st position
(M5 pan head screw)
Base line
Rack rails
Base line
Rack rails
5th position
(M5 centering screw)
5th position
(M5 centering screw)
2nd position
(M5 pan head screw)
2nd position
(M5 pan head screw)
The M5 screw positions for the rack rails are determined by the controller enclosure or the drive enclosure base
line.
Insert the M5 screws in the 1st and 6th holes on the front rack pillars above the base line and in the 2nd and 5th
holes on the rear rack pillars above the base line to fasten the rack rails.
2. Attach the rack rails to the rack.
The size of the controller enclosure and each drive enclosure is 2U.
Installation in a Rack
STEP
●Drive enclosures must be installed above the controller enclosure. When installing multiple drive enclosures,
install them in the order of the "DE_No. label" numbers that are attached to the drive enclosures.
The DE_No. labels are attached on the following locations.
●The center of gravity must be taken into consideration to prevent a rack from toppling over. The controller
enclosure and drive enclosures should generally be installed from bottom to top to lower the center of
gravity and to ensure the safe use of racks.
IMPORTANT
DE_No. labels
Right front side of the drive enclosure Upper rear side of the drive enclosure
-Installation- "Chapter 3 Rack Installation"
[Right]
[Left]
(Front rack pillars)
(Rear rack pillars)
Rack rail (for right side)
Rack rail (for left side)
Washers
M5 screws
M5 screws
Washers
M5 screws
Plate
M5 screws
Plate

9
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
M5 screws
M5 screws
Flange cover
Flange cover
3. Install the controller enclosure or the drive enclosure in the rack.
4. Fasten the controller enclosure or the drive enclosure in the rack.
Use four M5 screws to fasten the controller enclosure or the drive enclosure to the rack pillars and attach the
flange cover.
5. Attach the brackets to the rack rails (for the left and right sides).
Use the thumb screws to attach the brackets at the specified locations on the rear side.
2.5" controller
enclosure
Attachment location of the bracket
3.5" controller
enclosure
2.5" drive
enclosure
3.5" drive
enclosure
Bracket
Thumb screw
Left Right 3.5" controller
enclosure
2.5" controller
enclosure
3.5" drive
enclosure
2.5" drive
enclosure
Make sure to install or remove the controller enclosure or the drive enclosure to or from a rack with two or
more people.
IMPORTANT

10
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
●FC, iSCSI 10Gbit/s, FCoE
(for FC cable connection)
●1Gbit/s iSCSI
●SAS
Connect a Host Interface cable to each of these ports.
Controller enclosure
CA#0 CA#1 CA#0 CA#1
1Gbit/s iSCSI
Port#0 Port#1
SAS
Port#0 Port#1
Port#0 Port#1 Port#0 Port#1
FC, iSCSI 10Gbit/s, FCoE
(for FC cable connection)
iSCSI 10Gbit/s, FCoE
(for Copper Twinax cable connection)
Various cables need to be connected to the rear of the ETERNUS DX Disk storage system.
Controller enclosure
Controller (CM#0) Controller (CM#1)
RMT port MNT port RMT port MNT port
Rear viewCable
Rear viewCable
Connect a LAN cable (for operation management) to each MNT port.
Cable Connection
STEP
Host Interface Cable
LAN Cable (for Operation Management)
●iSCSI 10Gbit/s, FCoE
(for Copper Twinax cable
connection)
●To help with cable management and prevent incorrect connection, attach labels to the cables and make a
note of connection origins and destinations.
●This step describes dual controller type as an example. Note that there is only controller 0 (CM#0) for single
controller type.
Point
The cables should never be bent, twisted or pulled.
IMPORTANT
-Installation- "4.1 LAN Cable Connection (For Operation Management)"
-Installation- "4.2 Host Interface Connection"

11
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
●DI (OUT) side plug
●DI (IN) side plug
Rear viewCable
Attach the destination labels to
the QSFP cable plugs
When drive enclosures are installed, QSFP cables are used to connect between the DI ports of the enclosures.
QSFP Cables
Drive enclosure 2
Drive enclosure 1
Controller enclosure
●Controller enclosure
●Drive enclosure
●Example for connection of QSFP cable
(when two drive enclosures are installed)
Connect the QSFP cables in order. Connect the DI (OUT) port of the
controller enclosure and the DI (IN) port of drive enclosure 1 first, and then
connect the DI (OUT) port of drive enclosure 1 and the DI (IN) port of drive
enclosure 2, and so on.
The drive enclosure number can be checked with the "DE_No. label" that is
attached on the right front end of drive enclosures.
DI (OUT) port DI (IN) port
The DI (OUT) port is on the left side and the DI (IN) port
is on the right side of each controller.
Plug the connectors on which the " " symbol is printed
into the DI (OUT) ports.
Plug the connectors on which the " " symbol is printed
into the DI (IN) ports.
The " " symbol is
printed here.
The " " symbol is
printed here.
DI (OUT) port
The controller enclosure only has DI (OUT) ports.
Connect the connectors on the side where the " " symbol is printed.
-Installation- "4.3 Drive Enclosure Connection"

12
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
Use ETERNUS Web GUI to perform a basic setup of the ETERNUS DX Disk storage system.
Connect a PC terminal to the ETERNUS DX Disk storage system.
Connect the PC terminal to the MNT port of Controller 0 (CM#0) on the controller enclosure directly with the LAN
cable (for operation management).
Turn on the PC terminal and the ETERNUS DX Disk storage system.
Controller enclosure
Drive enclosure
Drive enclosure
Power switch
LAN port
PC terminal LAN cable
MNT port of Controller 0 (CM#0)
Controller enclosure
ETERNUS DX Disk Storage System and PC Terminal Connection
Basic Setup
STEP
Powering On
Connect the power cords to the inlets of the power supply unit.
Use release ties to hold the power cords in place.
Drive enclosure 1
Controller enclosure
Rear viewCable
Power Cords
-Installation- "4.5 Power Cord Connection"
●When the LAN cable for the MNT port of Controller 0 (CM#0) is connected to a network device, connect the
cable to a PC terminal.
●Remove the LAN cable that is connected to the MNT port of Controller 1 (CM#1).
IMPORTANT
-Installation- "5.1.1 ETERNUS DX Disk Storage System and PC Terminal Connection"
-Installation- "5.1.2 Powering On"
When turning on the ETERNUS DX Disk
storage system for the first time, volume
formatting operation, which is set as factory
default, may be performed. However, the
ETERNUS DX Disk storage system setting
operation can be continued.
IMPORTANT

13
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
Perform the settings that are required before operation of the ETERNUS DX Disk storage system on the initial setup
screen.
After the settings are complete, close the Web browser and then remove the LAN cable (for operation management)
from the PC terminal. Connect LAN cables (for operation management) to the customer network from the MNT ports
on both controller 0 and controller 1.
Then start the web browser from the PC terminal that is connected to the network and log in to ETERNUS Web GUI
again with the IP address that is set in "Set Network Environment". After login, the Overview screen appears.
Perform the following settings according to the wizard
screen:
●Set Storage Name
●Set Date and Time
●Change Password
●Register Thin Provisioning License
●Register Copy License
●Register SED Authentication Key
●Set Network Environment
Initial Setup
1. Open the Web browser on the PC terminal.
2. Enter either of the following URLs in the address bar
of the Web browser.
http://192.168.1.1/
The login screen for ETERNUS Web GUI appears.
3. To change the user interface language, click the
[Option] button and select "English" or "Japanese" in
"Language".
4. Enter the Username and Password.
User name: root
Password: root (by default)
After logging in, the Initial Settings screen of ETERNUS
Web GUI appears.
ETERNUS Web GUI Startup
-Installation- "5.1.3 ETERNUS Web GUI Startup"
-Installation- "5.1.4 Initial Setup"

14
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
Use ETERNUS Web GUI to set RAID configurations in the ETERNUS DX Disk storage system.
Perform the following settings:
●RAID group creation
●Volume creation
●Hot spare registration
□RAID group creation
Create RAID groups to create volumes.
To display the screen to create RAID groups:
Click [Create] in [Action] on the [RAID Group] tab.
□Volume creation
Create volumes in the RAID group.
To display the screen to create volumes.
Click [Create] in [Action] on the [Volume] tab.
□Hot spare registration
Register the hot spare for the failure of a drive.
To display the screen to register the hot spare:
Click [Disks] in [Category] on the [Component] tab.
ƪGlobal Hot Spare registration
Select the drive that is to be registered as the
Global Hot Spare and click [Assign Global HS] in
[Action].
ƪDedicated Hot Spare registration
Select the drive that is to be registered as the
Dedicated Hot Spare and click [Assign Dedicated
HS] in [Action].
RAID Configuration Settings
Default RAID groups, volumes and LUN mappings are preset in the factory. Refer to "ETERNUS Web GUI User's
Guide" if the preset values are to be changed.
Point
-Installation- "5.1.5 RAID Configuration Settings"

15
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
The host affinity settings ensure security when multiple servers are connected by assigning the host interface ports
that the hosts (servers) can access and the volumes that the hosts (servers) can recognize.
Follow the procedure below to set host affinity by associating a host group, a CA port group and a LUN group.
Host Affinity Settings
1. Host group addition
Add the information on the hosts (servers) that access
the ETERNUS DX Disk storage system.
To display the screen to add the host groups (example
for FC or FCoE host groups):
Click [Add FC/FCoE Host Group] in [Action] under
[Host Group] in [Category] on the [Connectivity] tab.
2. Port parameter settings
Set the connection information between the host
interface port and the server.
To display the screen to set the port parameters
(example for FC Port):
Click [FC] under [Port Group] in [Category] on the
[Connectivity] tab. Select the checkbox for the FC port
to set the port parameters for on the
[FC Port Group] screen and then click [Modify FC Port
Parameters] in [Action].
3. Port group creation
Create a port group for a host to access the ETERNUS
DX Disk storage system.
To display the screen to create a port group (example
for FC Port):
Click [Create FC Port Group] in [Action] under
[Port Group] in [Category] on the [Connectivity] tab.
4. LUN group addition
Add a group of volumes that can be recognized by the
host (LUN group).
To display the screen to add a LUN group.
Click [Add LUN Group] in [Action] under
[LUN Group] in [Category] on the [Connectivity] tab.
5. Host affinity creation
Create an association between a host group and a
port group and an association between a host group
and a LUN group.
To display the screen to create a host affinity.
Click [Create Host Affinity] in [Action] on the
[Connectivity] tab.
-Installation- "5.1.6 Host Affinity Settings"

16
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
Perform the ETERNUS DX Disk storage system monitoring setup if required.
●Notification of the ETERNUS DX Disk storage system problems as they occur is possible if the event notification
method and level have been set.
●If remote support is required, the ETERNUS DX Disk storage system needs to be set to notify the remote support
center of failures.
Perform the settings required to connect to the server and install the required drivers. Perform the settings required
for network devices connecting the server and the ETERNUS DX Disk storage system.
After the server connection setup, confirm that the volumes in the ETERNUS DX Disk storage system can be
recognized by the server.
All necessary settings are complete, and the ETERNUS DX Disk storage system is now ready for normal operation.
Monitoring Setup
STEP
Server Connection
STEP
Operation and Maintenance
Remote support allows prompt detection and resolution of trouble.
Point
-Installation- "5.2 ETERNUS DX Disk Storage System Monitoring Setup"
●-Installation- "5.4 Server Connection Setup"
●-Server Connection-
Status check
The status of the ETERNUS DX Disk storage system should be regularly monitored by checking the LEDs and using ETERNUS Web
GUI.
Data backup
Important data should be regularly backed up to a tape drive or similar device as a precaution against system failures.
Maintenance support period
The standard maintenance support period for ETERNUS DX Disk storage system is five years from the date of purchase, or is
defined in your service level agreement (SLA). Contact your sales representative for details if you prefer to extend the period.
●-Operation- "4.2 Monitoring ETERNUS DX Disk Storage System Status"
●-Operation- "6.1 Periodic Backup"
●-Operation- "6.4 Maintenance Service"

17
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
●Applicable Environment
The ETERNUS DX Disk storage system was designed and manufactured for general office use, with user safety in mind. When using the ETERNUS DX Disk storage
system, follow the handling instructions, placement and cautionary notes listed in this guide. If used beyond the limits described, the users may be at risk of personal
injury and/or material damage.
●Using the Manuals
The manuals provided with the ETERNUS DX Disk storage system contain important information regarding safe usage.
Please read this manual carefully before using the ETERNUS DX Disk storage system. Pay special attention to "ETERNUS DX80 S2/DX90 S2 Disk storage system Safety
Precautions", and understand the contents thoroughly before connecting.
Keep these manuals in a safe place for future reference.
Fujitsu pays careful attention to the safe use of its products to prevent user injury and/or material damage. To use the ETERNUS DX Disk storage system properly,
please follow the instructions in this manual.
●Compliance Standards
Class 1 laser product
This Product is designed, developed and manufactured as contemplated for general use, including without limitation, general office use, personal use, household use,
and ordinary industrial use, but is not designed, developed and manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely
high safety is secured, could lead directly to death, personal injury, severe physical damage or other loss (hereinafter "High Safety Required Use"), including without
limitation, nuclear reaction control in nuclear facility, air craft flight control, air traffic control, mass transport control, medical life support system, missile launch control
in weapon system. You shall not use this Product without securing the sufficient safety required for the High Safety Required Use. If you wish to use this Product for High
Safety Required Use, please consult with our sales representatives in charge before such use.
Product safety UL60950-1, CSA-C22.2 No. 60950-1, EN60950-1, IEC60950-1, GOST-R
Electromagnetic Compatibility CNS13438(C6357) Class A, FCC CFR47 part 15 Class A, ICES-003 Class A,EN55022 Class A, VCCI Class A,
AS/NZS CISPR22 Class A
Electromagnetic Immunity EN55024
CE certification Electromagnetic Compatibility Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
Environmental compliance RoHS-compliant (Restriction of hazardous substances)
WEEE-compliant (Waste electrical and electronic equipment)
Terms of Use
Electronic intelligence product pollution control mark of the People's Republic of China.

18
ETERNUS DX80 S2/DX90 S2 Disk storage system Read Me First
Copyright 2013 FUJITSU LIMITED P3AM-4872-11EN
●The content of this manual is subject to change without notice.
●This manual was prepared with the utmost attention to detail.
However, Fujitsu shall assume no responsibility for any operational
problems as the result of errors, omissions, or the use of
information in this manual.
●Fujitsu assumes no liability for damages to third party copyrights
or other rights arising from the use of any information in this
manual.
●The content of this manual may not be reproduced or distributed in
part or in its entirety without prior permission from Fujitsu.
ETERNUS DX80 S2/DX90 S2 Disk storage system
Read Me First
P3A M-4 872-11EN
Date of issuance: June 2013
Issuance responsibility: FUJITSU LIMITED
