Fujitsu ETERNUS LT20 S2 User manual

ETERNUS LT20 S2
(LT20S2JNXU)
ETERNUS LT40 S2
(LT40S2JNXU)
ETERNUS LT60 S2
(LT60S2JNXU)
Tape Library
User's Guide
-Monitoring Software Setup Procedure-
P3AM-5262-01ENZ0

P3AM-5262-01ENZ0
FOR SAFE OPERATION
This manual contains important information regarding the use and handling of
this product. Read this manual thoroughly. Pay special attention to the section
"FOR SAFE OPERATION" Use the product according to the instructions and
information available in this manual. Keep this manual handy for further
reference.
Fujitsu makes every effort to prevent users and bystanders from being injured or
damage to their property. Use the product according to this manual.
ABOUT THIS PRODUCT
This product is designed and manufactured for use in standard applications such
as office work, personal devices and household appliances. This product is not
intended for special uses (atomic controls, aeronautic or space systems, mass
transport controls, medical devices for life support, or weapons firing controls)
where particularly high reliability requirements exist, where the pertinent levels of
safety are not guaranteed, or where a failure or operational error could threaten a
life or cause a physical injury (hereafter referred to as "mission-critical" use).
Customers considering the use of these products for mission-critical applications
must have safety-assurance measures in place beforehand. Moreover, they are
requested to consult our sales representative before embarking on such
specialized use.
TRADEMARKS ACKNOWLEDGEMENTS
- Microsoft, Windows,and MS are registered trademarks of Microsoft
Corporation in the United States or certain other countries.
- All other corporation names and product names mentioned herein are the
trademarks or registered trademarks of their respective owners.

P3AM-5262-01ENZ0
RADIO FREQUENCY INTERFERENCE STATEMENT
The following notice is for EU users only.
WARNING: This is a product which meets Class A of EN55022. In a domestic
environment this product may cause radio interference in which case the user
may be required to take adequate measures.
The following notice is for USA users only.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Measures against instantaneous voltage drop
The LT20 S2/LT40 S2/LT60 S2 may be affected by instantaneous voltage drop
due to lightning strikes or other factors. To protect the LT20 S2/LT40 S2/LT60
S2 against instantaneous voltage drop, the user should preferably provide an AC
uninterruptible power supply or the like for the LT20 S2/LT40 S2/LT60 S2.
Copyright 2011 FUJITSU LIMITED

P3AM-5262-01ENZ0
Revision History
(1/1)
Edition Date Revised location (type) (*1) Revision
01 June, 2011 −−
*1 Items in the "Revised location" column refer to the latest edition unless the
item is marked with an asterisk. An asterisk indicates an item in an older
edition.

P3AM-5262-01ENZ0 i
Preface
Thank you for your purchasing the ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape
Library.
To ensure the proper handling of this product, read this manual, the other
manuals supplied with this product, and the manuals supplied with the server and
software thoroughly and carefully before using it.
This manual explains the settings for using monitoring software "ETERNUS SF
Storage Cruiser" with the ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library.
The purpose of this manual is to explain in detail how to set SNMP for this library
(hereafter called "tape library," "library," or "this device"), how to set up
"ETERNUS SF Storage Cruiser," and how to confirm SNMP trap sending with
this device.
This manual is intended for users who have a basic knowledge of magnetic tape
libraries and the usage of the tape libraries in computer systems. The
organization of the manuals related to this device and the coverage of this
manual are shown in "Manual Organization" provided later in this manual. Use
other manuals as well when necessary.
The organization and contents of this manual are explained below. This
information is followed by the symbols for alert messages with their meanings.
Organization and contents of This Manual
This manual has four chapters below.
Chapter 1 Setting up SNMP
Explains how to set up SNMP with this device.
Chapter 2 Setting up Monitoring Software
Explains how to set up monitoring software "ETERNUS SF Storage Cruiser."
Chapter 3 Confirming the SNMP Trap Settings
Explains how to send SNMP traps with this device.
Chapter 4 Event List
Explains the events that are reported by SNMP of this device.

Preface
ii P3AM-5262-01ENZ0
Abbreviation
In this manual, the product names are abbreviated as follows:
Long title Abbreviation
Microsoft® Windows® XP Professional operating system
Microsoft® Windows® XP Home Edition operating system
Windows XP
Microsoft® Internet Explorer® Internet Explorer IE

P3AM-5262-01ENZ0 iii
Note on Safety
Safety Precautions
Read thoroughly this manual to use this product safely and correctly.
Use the unit correctly according to this manual so that damage should not reach
the human body and your property.
Keep this Monitoring Software Setup Procedure at hand for quick reference at
anytime necessary.
In this User's Guide, the following indications are used to use the product safely
and correctly. Thoroughly understand the meaning of the indication before using
this product.
Warning Failure to heed this sign could result in serious injury or
death.
Caution Failure to heed this sign could result in personal injury or
damage to properties.
Precautions and notices against hazards are presented with one of the following
symbols.
Indicates that improper use may cause fumes or fire.
Indicates that improper use may cause explosion.
Indicates that improper use may cause an electric shock.
Indicates that improper use may cause personal injury due to toxic material.
Indicates that improper use may cause hands or fingers to be caught.
Indicates a general prohibited action or warning that cannot be specifically
identified.

Note on Safety
iv P3AM-5262-01ENZ0
Indicates that the disassembling and modification of the product is inhibited.
Indicates that the user is inhibited to touch the product.
Indicates a general mandatory action or warning that cannot be specifically
identified.
Indicates an instruction to unplug the power cord from the outlet and turn off the
circuit breaker of power distribution panel.

P3AM-5262-01ENZ0 v
Manual Organization
ETERNUS LT20 S2
LTO Library
Installing, Starting Up
and Maintaining
(P3AM-5382)
1. Preface
2. Product Description
3. Installing the Tape Library
4. Operating the LTO Library
5. Troubleshooting
6. Servicing
7. Packaging before Transportation
8. Technical Specifications
9. Recycling and Disposal
10. Regulatory Information
ETERNUS LT40 S2/
LT60 S2 LTO Library
Installing, Starting Up
and Maintaining
(P3AM-5392)
1. Preface
2. Product Description and Features
3. Installing the Tape Library
4. Operating the Tape Library
5. Troubleshooting
6. Servicing the Tape Library
7. Technical Specifications
8. Packaging Before Transportation
9. Recycling and Disposal
10. Regulatory Information
ETERNUS LT20 S2/
LT40 S2/LT60 S2
Tape Library
User's Guide
-Monitoring Software
Setup Procedure-
(P3AM-5262)
<This manual>
1. Setting up SNMP
2. Setting up Monitoring Software
3. Confirming the SNMP Trap Settings
4. Event List
