Fujitsu FPCCC24 User manual

These instructions provide details on using the
FPCCC24 Bump Case. This case is designed for
use with your Tablet PC. The bump case provides
added protection when transporting, using, or
storing the Tablet PC.
We strongly recommend that you read these
instructions prior to using the bump case with
your computer.
INSTRUCTIONS
Bump Case User’s Guide
FPCCC24
Fujitsu Computer Systems
FPC58-0721-03.fm Page 1 Thursday, January 22, 2004 2:01 PM

2
Figure 1. Bump case - Front
DC-In access
LAN/Modem Access
Air vents
Navigation
button access
IR keyboard
port access
Speaker
access Application
button access
USB port
access
Infrared
port access
PC Card
access
Power On/
Suspend/
Resume/
Microphone
access
Pen holder
FPC58-0721-03.fm Page 2 Thursday, January 22, 2004 2:01 PM

3
Installing the Tablet PC
Figure 2. Bump case - Rear
To install your Tablet PC into the bump case, position the
case face down as shown in Figure 2. Open the right side flap
of the case (as seen from the back). The flap is secured by a
long strip of Velcro® that is attached to the back of the bump
Prior to installing the Tablet PC into the bump
case, remove the pen. Once the system is
installed, you won’t be able to remove the pen.
Store the pen in the pen holder. (See Fig. 1)
Side Flap
Pen holder
Side Flap
Velcro
Strips
Hand
straps
D-Rings
(4 places)
Battery
Release
Latch access
FPC58-0721-03.fm Page 3 Thursday, January 22, 2004 2:01 PM

4
case. Note that the flap on the left side also opens for port
access, but restraining straps prevent the system from being
inserted or removed from that side.
Slide the system into the bump case, with the screen facing
the open window. (See Figure 3). Reattach the flap to the
side of the case.
Figure 3. Inserting Tablet PC into Bump Case
The ends of the elasticized handstraps have D-rings to which
you can attach the shoulder strap. To secure the shoulder
strap, attach the strap clips to two of the D-rings. The bump
case can be carried vertically, horizontally, or diagonally,
depending on how you orient the clips.
You can also use one of the D-rings to attach a pen tether.
Bump case
(rear, with side flap open) Tablet PC
FPC58-0721-03.fm Page 4 Thursday, January 22, 2004 2:01 PM

5
Caring for the bump case
The bump case is made of rugged materials, and is designed
to withstand daily use. Treat the case as you would a brief-
case or purse.
Occasionally, the bump case may become soiled. To clean it,
use a clean cloth and warm soapy water to wash the soiled
area.
FPC58-0721-03.fm Page 5 Thursday, January 22, 2004 2:01 PM

6
FPC58-0721-03.fm Page 6 Thursday, January 22, 2004 2:01 PM

7
FPC58-0721-03.fm Page 7 Thursday, January 22, 2004 2:01 PM

8
Fujitsu Computer Systems Corporation
1250 E. Arques Avenue (M/S 122),
Sunnyvale, California 94085
For more information, call
1-877-372-3473 or visit our Web site at:
us.fujitsu.com/computers
For technical support call: 1-800-8Fujitsu (1-800-838-5487)
or e-mail us at: [email protected]jitsu.com
