DATASHEET FUJITSU STYLISTIC ST6012 TABLET PC
Page 1 / 6 http://ts.fujitsu.com/tabletpc
DATASHEET
FUJITSU STYLISTIC ST6012 TABLET PC
THE IDEAL MOBILE SOLUTION FOR INDOORS AND OUTDOORS
STYLISTIC ST6012
The STYLISTIC ST6012 is the perfect companion. The device weighs only 1.6kg, is very easy to carry yet
robust. It was specially developed for use when standing or walking.
The transmissive 30.7 cm (12.1-inch) TFT WXGA display offers the best image quality. Support for pen-
based functions helps you carry out your work anywhere and to present it convincingly.
A further advantage is the battery runtime which enables you to work for a long period. Take a good look
at the new housing. As well as being lightweight, the housing provides additional protection against damp
or dust.
UNLIMITED MOBILITY
Small, lightweight, very easy to carry, created for optimized mobility.
A4 format, only 1.6 kg, personalized keys for easy and fast access to your applications
HIGHEST SECURITY
Perfect data protection against non-authorized access.
Computrace®enabled BIOS, integrated SmartCard Reader, Fingerprint sensor & TPM module
EXTREME PRODUCTIVITY
Non-stop working, without any loss of speed
Intel®Core™2 Duo processor SU9400 (ULV)
CONNECTIVITY WHEREVER YOU ARE
Unlimited connectivity - indoors and outdoors.
Optional integrated high-speed UMTS, WLAN and Bluetooth

DATASHEET FUJITSU STYLISTIC ST6012 TABLET PC
Page 2 / 6 http://ts.fujitsu.com/tabletpc
COMPONENTS
MEMORY MODULES 1 GB (1 module(s) 1 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
HARD DISK DRIVES (INTERNAL) SSD SATA, 128 GB, 2.5-inch, S.M.A.R.T.
SSD SATA, 80 GB, 2.5-inch, S.M.A.R.T.
SATA, 5400 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
SATA, 5400 rpm, 160 GB, 2.5-inch, S.M.A.R.T.
Hard disk notes ShockSensor for HDD shock protection
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
Accessible capacity may vary, also depending on used software
Battery type Li-Ion battery 6-cell Li-Ion battery 9-cell
Battery power 56 Wh 84 Wh
Battery capacity 5.200 mAh 7.800 mAh
Battery features Dynamic charge supported (rapid charge)
Benchmark Mobile Mark 2005
Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features
utilized. Battery recharge time depends on usage.
WLAN (OPTIONAL) Atheros Minicard b/g 802.11 b/g
Intel®Wireless WiFi Link 5300 AGN 11/13ch
3G/UMTS (OPTIONAL) Sierra Wireless MC8790 (downlink 7.2 Mbit/s, uplink 2.0 Mbit/s)
BLUETOOTH (OPTIONAL) Bluetooth 2.1
Base unit STYLISTIC ST6012
GENERAL SYSTEM INFORMATION
Processor Intel®Core™2 Duo processor ULV SU9400 (1.4 GHz), 3 MB, 800 MHz
Chipset Intel®GS45, ICH9-M
BIOS features BIOS Flash EPROM
BIOS based on Phoenix TrustedCore Notebook
INTERFACES
Memory card slots 1 (SD)
PC Card slot (Type I/II) 1
SmartCard slot 1
SIM card slot 1
USB 2.0 total 2
VGA 1
Ethernet (RJ-45) 1
Audio: line-in / microphone 1
Audio: line-out / headphone 1
Internal microphones 2
Docking connector for Port Replicator 1
Kensington Lock support 1
WIRED COMMUNICATION
LAN Built-in 10/100/1000 MBit/s Intel®82567 LF
WIRELESS TECHNOLOGIES
Antennas 3 Dual band WLAN antennas, 2 UMTS antennas, 1 Bluetooth
WLAN notes Import and usage according to country-specic regulations.

DATASHEET FUJITSU STYLISTIC ST6012 TABLET PC
Page 3 / 6 http://ts.fujitsu.com/tabletpc
KEYBOARD AND POINTING DEVICES
Fingerprint sensor
Launch keys
Status LED
Application buttons
Tablet Pen
Digitizer
Fingerprint sensor scroll
MULTIMEDIA
Audio type On board
Audio codec Realtek ALC269
Audio features Mono speaker
Camera Optional: Built-in webcam, 1.3 megapixel
GRAPHICS
Max. resolution external display 1920 x 1200 / true color / 85 Hz
Graphics brand name Mobile Intel®GMA 4500M HD
Graphics features DualView (Windows®XP & Windows®Vista)
POWER SUPPLY
AC adapter 16 V / 60 W (3.75 A)
Rated voltage range 100 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz
POWER CONSUMPTION
Power consumption note See white paper Energy Consumption
Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=405a7569-10c7-4be5-91ba-a51472338614
DIMENSIONS / WEIGHT / ENVIRONMENTAL
Dimensions (W x D x H) 325 x 220 x 23.8 - 31.7 mm
Weight 1.6 kg
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 5 - 35°C
Operating relative humidity 20 - 80 %
OPERATING SYSTEM
Operating system optional preinstalled TwinLoad Microsoft®Windows®XP Tablet PC Edition 2005 (DVD)
Microsoft®Windows Vista®Business 32-bit
Microsoft®Windows®7 Professional 32-bit
Operating system compatible Microsoft®Windows®XP Tablet PC Edition 2005
Operating system notes Driver support for Microsoft®Windows®XP
ADDITIONAL SOFTWARE
Additional software (preinstalled) Adobe Acrobat Reader
Application Panel
Drivers & Utilities DVD (DUDVD)
Microsoft® Ofce Ready (Trial)
Norton Internet Security (incl. Firewall) on Drivers & Utilities DVD for Microsoft Windows XP
Toshiba Bluetooth Stack (only with Windows Vista®or Windows®XP operating systems)
EasyGuide online user documentation
Tablet Button Utility
Additional software (optional) Windows Vista®recovery media
Drivers & Utilities DVD (DUDVD)
UMTS connection manager (optional with UMTS)
Recovery DVD (Windows®7)
Additional software (included as a CD/
DVD)
SmartCase Logon+
MANAGEABILITY
Manageability features DeskUpdate Driver management
Manageability type DeskView 10.x client management including:

DATASHEET FUJITSU STYLISTIC ST6012 TABLET PC
Page 4 / 6 http://ts.fujitsu.com/tabletpc
MANAGEABILITY
DeskView features On/Ofine remote client management
Detailed system inventory management and reports
BIOS Management
Remote power management
System notications
Security Remote Control
DeskView Helpdesk Integration
WoL (Wake on LAN)
Supported standards WMI
PXE
BootP (made4you)
Manageability link http://ts.fujitsu.com/solutions/it_infrastructure_solutions/manageability/featurender.html
SECURITY
Physical security Kensington Lock support
System security Computrace®enabled BIOS
Symantec Norton Internet Security (90 day test version)
Write protect option for the Flash EPROM
Control of all USB interfaces
Optional: Trusted platform module (TPM 1.2)
User security Integrated Fingerprint Sensor
Integrated SmartCard controller in PC Card with system lock support
Hard disk password
SystemLock 2 BIOS SmartCard Security
SmartCase Logon+ incl. Fingerprint software
User and supervisor BIOS password
COMPLIANCE
Model ST60xx
Europe CE
Nordic Swan in progress
EN 60601-1-2:2007 certied for use in environment with medical application (optional)
USA/Canada FCC Class B (depending on wireless conguration)
Global WiFi certied
ENERGY STAR®4.0
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
DOCKING DEVICES (OPTIONAL)
Tablet Dock
DC-in 1
Audio: line-out / headphone 1
USB 2.0 total 3
VGA 1
Ethernet (RJ-45) 10/100/GB LAN
Kensington Lock support 2
Drive name DVD Super Multi
AC Adapter S26391-F5031-L800
1st battery S26391-F421-L200 (6cell)
S26391-F421-L300 (9cell)
Memory (1GB) S26391-F436-L100
Memory (2GB) S26391-F436-L200
1st hard disk drive S26391-F727-L600 (SSD 128GB)
Port replicator S26391-K430-L300 (Tablet Doc)
Recommended cases S26391-F2584-L401
WARRANTY
Standard Warranty 2 years
Service level Collect & Return Service (depending on country)
MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION

DATASHEET FUJITSU STYLISTIC ST6012 TABLET PC
Page 5 / 6 http://ts.fujitsu.com/tabletpc
WARRANTY
Recommended Service 3 years, Collect and Return Service, where available: Executive On-site Service
Spare Parts availability 5 years
Service Weblink htttp://ts.fujitsu.com/Supportservice

DATASHEET FUJITSU STYLISTIC ST6012 TABLET PC
Page 6 / 6 http://ts.fujitsu.com/tabletpc
