Fujitsu LR 6611 Installation instructions

LR 6611
HARDWARE GUIDE
TV Tuner Card
Hardware Specifications
Connecting Input & Output Devices
Contents
All manuals and user guides at all-guides.com
all-guides.com

Hardware Interface
Compatibility
TV Tuner
!
!
!
!
!
!
!
!
!
32-bit PCI 2.2 bus mastering
Plug-n-Play compliant
Video Standards
Connectors
Graphics drivers must include DirectX 9.0 or later
software
Support PAL, NTSC, SECAM
PAL/B/G + D/K+I+SECAM L/L
Full 181 channels supported
1 TV RF connector
1 Mini DIN 9-pin connector for input of S-Video &
Composite & Audio
1 IEC FM connector (male)
Hardware Specifications
All manuals and user guides at all-guides.com

Connectors
Connect Input & Output Devices
From Cable TV
or Antenna
Sound Card/Motherboard
audio-in connector
AV Line-in
Audio
Out
FM Antenna
RL
VCR
Input sources
DVD/VCD Player
CCD cameraCCD camera Camcorder
SELECT START
ANALOG
SONY
PlayStation
Video Game Console
red-Audio IN
withe-Audio IN
yellow-Composite IN
