Fuller Brush Tidy Maid FBTM-PW User manual

Before operating the vacuum,
please read these instructions completely.
OPERATING INSTRUCTIONS
FOR FULLER BRUSH UPRIGHT VACUUM
MODEL: FBTM-PW

Index
Important Safety Instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Two-Wire Polarization� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Parts Identification� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Replacement Bags and Filters � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
How to Assemble and Operate the Vacuum � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
How to Change the Vacuum Bag � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Handle Adjustments � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Filters � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Edge Cleaning Feature � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Automatic Self-Adjusting Rug Nozzle � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
Optional Cleaning Tools/Accessories � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
On-Board Tool Cleaning � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
How to Replace the Headlight Bulb & Vacuum Belt � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
How to Clean the Nozzle Hose � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Thermal Fuse Protection � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
For Best Performance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Customer’s Record
The model and serial numbers of this product may be found on the back side of the unit� You should complete
the enclosed warranty card and mail it back to us as soon as possible for your protection� Also, note the model and
serial numbers of your unit in the spaces provided below, and retain this book as a permanent record of your purchase�
Model Number: ____________________________________________________________________________________
Serial Number: _____________________________________________________________________________________
Date Purchased: ____________________________________________________________________________________
Your Fuller Brush vacuum cleaner is a product of high quality materials and superior workmanship� We urge you to
read these operating instructions carefully before you use this vacuum cleaner, in order to obtain the full performance and
satisfaction it can offer you�
Save These Instructions
Before you plug in your Fuller Brush vacuum cleaner, make sure the voltage indicated on the rating plate located on the
back of the vacuum cleaner is the same as your local supply�
1

IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
When using an electrical appliance, basic precautions should always be followed, including the following:
SAVE THESE INSTRUCTIONS.
WARNING: To reduce the risk of fire, electric shock or injury:
1� Do not leave appliance unattended when plugged in� Unplug from outlet when not in use and before servicing�
2� WARNING: ELECTRIC SHOCK COULD OCCUR IF USED OUTDOORS OR ON WET SURFACES�
3� Do not allow to be used as a toy� Close attention is necessary when used by or near children�
4� Use only as described in this manual� Use only manufacturer’s recommended attachments�
5� Do not use with damaged cord or plug� If appliance is not working as it should, has been dropped,
damaged, left outdoors or dropped into water, return it to a service center�
6� Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or
corners� Do not run appliance over cord� Keep cord away from heated surfaces�
7� Do not unplug by pulling on cord� To unplug, grasp the plug, not the cord�
8� Do not handle plug or appliance with wet hands�
9� Turn off all controls before unplugging�
10� Do not put any object into openings� Do not use with any opening blocked; keep free of dust, lint, hair and anything
that may reduce air flow�
11� Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts�
12� Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes�
13� Do not use without vacuum bag and/or filters in place�
14� Use extra care when cleaning on stairs�
15� Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may be present�
16� Do not attempt to service the unit while appliance is plugged in�
2

Two-Wire Polarized Cord
This product is equipped with a polarized alternating current line
plug (a plug having one blade wider than the other)�
This plug will fit into the power outlet only one way� This is a
safety feature� If you are unable to insert the plug fully into the
outlet, try reversing the plug� If the plug should still fail to fit, con-
tact an electrician to replace the obsolete outlet� Do not defeat
the safety purpose of the polarized plug�
3

On/Off switch
Bag compartment
Headlight
Furniture
guard
Self-adjusting nozzle
Quick cord release
Metal
telescopic
power wand
Quick clean-out
port
Quick clean-out
port
Power cord
Easy-carry
handle
Accessory
attachment
opening
Foot pedal
release
Thermal reset
button
Parts Identification
Replacement Bags and Filters
Cord storage hooks
Tools
• Genuine Fuller Brush Vacuum Bags
Part number 06.181
6 per package
• Genuine Fuller Brush Secondary Filter
Part number 06.250
• Genuine Fuller Brush HEPA Filter
Part number 06.288
4

How to Assemble and Operate the Vacuum
How to Attach the Handle to the Vacuum Cleaner
The vacuum and the handle are packed separately�
1� After first removing the handle screw, slide the handle into the slots
on top of the vacuum cleaner� (Fig� 1)
2� Line up the small hole on the handle with the small hole on the vac-
uum cleaner and insert the screw� Make sure the screw is tightened
securely�
4� Turn the upper cord storage hook to the upright position and wind the
power cord around the cord storage hooks when storing the
vacuum cleaner�
How to Release the Power Cord
1� The upper cord storage hook has a quick-release action�
To release the cord, rotate the hook downward and the cord will
drop off the handle for immediate use (Fig� 2)�
2� Return the hook to the upright position before attempting to rewind
the cord�
On/Off Switch (Fig. 2)
1� To turn the vacuum on, push the switch located on the side of the
bag compartment to the ( I ) position�
2� To turn the vacuum off, push the switch located on the side of the
bag compartment to the ( 0 ) position�
Fig� 1
Fig� 2
How to Change the Vacuum Bag
On/Off switch
Cord Release
Fig� 2
Fig� 3
Fig� 1
Always operate the vacuum cleaner with a vacuum bag installed�
How to Change the Vacuum Bag
1� Unplug the vacuum cleaner� Remove the bag compartment cover
(Fig�1)�
2� Remove the bag from the bag holder� Attach the new vacuum bag
onto the bag holder (Fig� 2)�
3� Pull the bottom corners of the new vacuum bag out to expand the
bag capacity (Fig� 3)�
4� Reinsert the tab on the end of the bag compartment cover into the
groove on the bag compartment housing� Press it into place closing
the bag compartment cover tightly�
5

Handle Adjustments
The handle on this vacuum cleaner can be set to one of three positions – upright,
middle or low�
How to Adjust the Handle
1� To release the handle, step on the foot pedal on the back left side of the vacuum
cleaner nozzle and pull back the handle (Fig�1)�
2� Middle position – for normal cleaning (Fig� 2)�
3� Upright position – for storage or when cleaning tools are used (Fig 3)� Handle locks in
this position�
4� Low position – for cleaning under furniture* (Fig� 4)�
*Once in the middle position, step on the foot pad again and pull back the handle
to place the vacuum in the low position� Fig� 1
Fig� 4
Filters
Your vacuum cleaner is equipped with a secondary filter and a HEPA filter� These filters
capture fine dust particles and protect the motor from dirt� Accumulated dirt in the bag com-
partment will be collected on the filters and may restrict motor performance� It is important to
change the filters regularly — approximately once a year or as needed�
To Change the Secondary Filter:
1� Unplug the vacuum cleaner� Remove the bag compartment cover and remove
the vacuum bag�
2� Remove the secondary filter by sliding it out from under the bag supporter� (Fig� 5)�
3� Insert a new filter and replace the bag compartment cover�
To Change the HEPA Filter:
1� Unplug the vacuum cleaner� Remove the bag compartment cover�
2� Remove the HEPA filter from the front of the bag compartment� (Fig� 6)�
3� Insert a new filter and replace the bag compartment cover�
Fig� 5
Edge Cleaning Feature
For best results when cleaning carpets near walls and stationary furniture, place the right side of the vacuum nozzle
along the wall or furniture�
Fig� 2 Fig� 3
Fig� 6
6

Automatic Self-Adjusting Rug Nozzle
Your Fuller Brush upright vacuum cleaner is designed with an Automatic Self-Adjusting Rug Nozzle� No manual adjust-
ments are required� The height of the rug nozzle is instantly and automatically adjusted to carpet pile height� This self-
adjusting feature allows the rug nozzle to float evenly over all carpet pile surfaces�
Optional Cleaning Tools/Accessories
On-Board Tool Cleaning
Deluxe Attachment Set 05.119 (Fig. 1)
15-foot crushproof hose
Curved wand
Extension wand (2 pieces)
Dusting brush
Crevice tool
Upholstery tool
Upholstery brush insert
Deluxe floor brush
Attachment Set 05.123 (Fig. 2)
7-foot crushproof hose
Curved wand
Deluxe floor brush
Extension wand (2 pieces)
Crevice tool
Upholstery tool
Connecting the hose assembly to the vacuum cleaner:
Open the lid located on the back side of the vacuum cleaner
and insert the plastic end of the hose assembly into the cleaning
attachment opening� Then connect the extension wand to the other end
of the hose assembly (Fig� 3)� Fig� 3
Fig� 4 Fig� 5
Fig� 1
Fig� 2
The Tidy Maid is equipped with on-board cleaning tools including
a metal telescopic Power Wand, stretch hose, dusting brush and a
crevice tool�
To use the cleaning tools, lift the hose handle straight up from1�
the vacuum (Fig� 4)�
Extend the wand by pushing the button back and pulling the2�
smaller wand out of the larger wand (Fig� 5)�
Attach any of the on-board tools to the end of the wand or3�
if you do not need the wand, any tool can be connected
directly onto the hose handle�
7

How to Replace the Headlight Bulb and the Vacuum Belt
CAUTION:
First, unplug the vacuum cleaner�
How to Remove the Bottom Plate.
1� Place vacuum cleaner in the low position by stepping on the foot pad and pulling
back the handle twice� Then, turn the vacuum cleaner over, exposing the underside�
2� Remove the four screws holding the lower plate in place (Fig� 1)�
3� Now remove the bottom plate�
How to Replace the Bulb.
1� Place vacuum cleaner in the low position by stepping on the foot pad and pulling
back the handle twice� Remove the bottom plate as described above�
2� To remove the old bulb, pull it straight out (Fig� 2)�
3� To install a new bulb, press it in until it clicks into place� These bulbs are
standard and may be obtained from most appliance repair shops�
4� Replace the bottom plate with four screws�
How to replace the belt.
1� Turn the unit over and remove the bottom plate as described above (Fig� 1)�
2� Take out the agitator assembly and remove the belt (Fig� 3)�
3� Loop the new belt around the agitator pulley and the motor drive shaft�
4� Reinsert the agitator assembly back into housing (Fig 4)� Turn the agitator assembly
by hand, making sure the belt is not twisted and all rotating parts move smoothly
(Fig� 5)� Make sure the arrows on end are facing down into the nozzle�
5� Press the bottom plate into place and fasten it by four screws�
NOTE: To ensure maximum cleaning efficiency, the belt should be checked
regularly to be sure it is in good condition� Check to see if the belt is stretched,
cracked, or if excessive slipping is occurring� Replace the belt if needed�
Fig� 1
Fig� 2
Fig� 3
Fig� 4
Fig� 5
8

CAUTION:
Unplug the vacuum cleaner�
How to Clean the Nozzle Hose
Remove the wand from the wand/hose holder as shown on page 7�1�
Squeeze the tabs on both sides of the quick clean-out port and pull away2�
from the vacuum (Fig� 1)�
Check above and below the port opening for obstructions�3�
Remove any obstructions�4�
Replace the quick clean-out port by squeezing both tabs and pushing it back5�
into the wand/hose holder�
How to Clean the Nozzle Hose
Fig� 1
Your Fuller Brush vacuum cleaner comes equipped with a Manual Reset Thermal Fuse Protector� This thermal
protector is designed to protect your vacuum cleaner from overheating due to restricted airflow (i�e� clogged hose, oper-
ating the vacuum without a bag)� Should this situation occur, the thermal fuse protector will safely shut off your vacuum
cleaner to avoid any potential damage�
NOTE: To determine that it was the thermal fuse protector that turned off your vacuum cleaner and not some other reason,
please refer to the vacuum cleaner’s headlight� If the headlight is on while the motor is off, then the thermal
fuse did safely shut down the motor. If the headlight and motor are off, then there is some reason other than the
thermal protector (i�e� pulled plug) the vacuum cleaner has shut down�
To reset the thermal fuse:
1� Unplug the vacuum cleaner�
2� Check for problem (over-filled bag, clog in hose, clogged filters, etc�)�
3� Correct problem�
4� Locate “tripped” fuse — the small white or red button located on the bottom of the back side of the main body
(roughly one inch to the right of the left wheel)�
5� Using a pencil, paper clip, or other pointy object, push the reset button�
6� Plug vacuum cleaner in and begin using�
Please contact your Fuller Brush retailer with any questions�
Thermal Fuse Protection
9

• Keep machine and all accessories clean and in good operating condition.
• Change vacuum bags and filters as recommended to maintain optimum cleaning efficiency.
• Always use genuine Fuller Brush vacuum bags, filters and parts as use of other products may result in poor cleaning or
filtration performance� Fuller Brush filtration products are designed for maximum performance�
• Have machine checked periodically by a qualified vacuum technician�
• Store machine carefully in dry area.
• For optimum cleaning performance and safety, follow your Owner’s Manual and keep it for future reference.
For Best Performance
10

Fuller Brush Vacuum Cleaners
PO Box 730
Fenton, MO 63026
Should your vacuum ever need service, simply call the retailer where original purchase was made�
©2010 Fuller Brush Vacuum Cleaners�
