Fumex GS2-200 User manual

GS2-200
Air Filtration System
Operations Manual
READ AND SAVE THESE INSTRUCTIONS
WARNING:
Disconnect from power supply before performing maintenance procedures
such as cabinet cleaning, changing filters or servicing of electric motor or
other electric components
WARNING:
To reduce the risk of fire or electric shock, do not use this fan with any solid-
state speed control device.
WARNING:
For general ventilating use only. Do not use to exhaust hazardous or explosive
materials or vapors.
WARNING:
Use only a 10-Amp fuse.
CAUTION:
Do not operate without having all filters in place.
Do not operate any fan with a damaged cord or plug. Discard fan or return to an
authorized service facility for examination and/or repair.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners or
similar coverings. Arrange cord away from traffic area and where it will not be
tripped over.

2
GETTING STARTED
Initial set-up
1. Open all cartons and locate inlet, hose, hose clamps and wheels.Refer to Table 1 for the applicable part
numbers for your model.
2. Remove ALL filters and packing materials from cartons and the unit cabinet.
3. Place the unit on its side and install wheels in the bottom plate.
4. Attach the inlet to the top of the lid with the six screws provided.
5. Remove plastic wrap from gas/odor filter (refer to Table 1 for filter part numbers).
6. Place gas/odor filter into the bottom of the cabinet and secure with the provided threaded rod, retaining plate,
and wingnuts (NOTE: Pay attention to direction of airflow arrow).
7. Place the FX7 pre-filter on top of the gas/odor filter.
8. Close and latch the lid.
9. Attach power cord to the power receptacle located on the lower rear of the cabinet.
Locating the air cleaner
Placing the GS2-200 unit as close as possible to the pollution source reduces the amount of ducting needed,
reduces back-pressure, lowers power consumption, and improves overall performance. Placement should
minimize hose length and the number of bends. Use capture hoods with high efficiency entry whenever
possible. The unit exhausts through the bottom panel make sure to allow for adequate ventilation.
Inlet hose attachment
The GS2-200 unit ships standard with a 1 x 2”, 2 x 2” or 1 x 3” inlet. Attach flex hose over the metal air inlet tube
and tighten securely with the stainless-steel clamp. Connect the hose to a Fumex suction hood or place as close
as possible to the pollution source.
Electric power
GS2-200 series is manufactured with a universal blower/motor assembly (90-250/1/50-60) and must only use a 10-
Amp fuse. Default power cord/plug is US (120V). Contact Fumex for additional information or options.
Confirm that correct power supply is available.

3
CONTROLS
On/Off Switch
Simple one touch controls – The green light above the POWER button will illuminate confirming power to the
unit.
Blower/Fan
The GS2-200 unit utilizes a variable speed blower with three speed settings. Press the up and down arrow
buttons to increase/decrease blower speed. A green light next to the specific speed (Low, Med, or High) will
indicate speed setting. In the case of a blower failure, all 3 blower speed lights will flash. To reset the blower’s
internal thermal protection, disconnect the unit momentarily from its power source and reconnect. If the lights
continue to flash contact Fumex LLC. for replacement information.
Filter monitoring
The GS2-200 unit utilizes a pressure differential switch to monitor the status of the Pre-filter. The system
monitors across all filters simultaneously and the Red “FILTER” light will illuminate when the Pre-filter needs to
be replaced. The recommended procedure is to replace the Pre-Filter and then press the “FILTER RESET” button.
If the light remains illuminated or turns off and comes back on then contact Fumex for assistance.
The GS2-200 unit contains a VOC sensor to detect odors/gases in the exhaust stream. When the gas/odor filter
becomes saturated and breakthrough of the VOC occurs the “GAS” warning light will illuminate.
GENERAL FILTER CARE
Fumex’s GS2-200 air purifier features a multi-stage filtration system designed to remove a wide range of
pollutants from the process plume in an extremely efficient, cost-effective manner. The sytem utilizes a pressure
differential switch to indicate blocked / clogged filters. Once the warning lights illuminate, filters should be
checked and clogged filters replaced.
STANDARD FILTERS:
Part # FX7 – Polyester pre-filter
The disposable polyester pre-filter is the first stage of the filtration process. Its main function is to remove dust
particles 100µand larger in advance of the more expensive pleated panel filter.
Replacement:
The service life of the polyester pre-filter is determined by the type and volume of large particles collected.
Average service life is 4-6 weeks

4
Gas/Odor Filters
Most process plumes contain several gases, some odorous – some not, some toxic at elevated concentrations
– some completely harmless regardless of concentration. To ensure employee safety the type and
concentration of pollutants must be determined. Please contact Fumex Engineering for filter selection
assistance.
Part # FX1
Filled with virgin-grade activated carbon pellets and is UL Class 2 rated compliant. It will not produce flame
when attacked by flame and emits only negligible amounts of smoke.
Part # FX1K
Virgin-grade activated carbon specially treated to eliminate exothermal reactions.
Part # FX2
These filters utilize a blended activated carbon and activated alumina impregnated with KMnO4 filter to
capture and treat gases/odors. This combination of materials provides protection across a broad range of
gases commonly found in industrial manufacturing processes.
Part # FX4
Blend of FX1 with FX2 for broad spectrum gas treatment.
SELECTING GAS/ODOR ADSORBENT FILTERS
Media Selection and Service Life
Fumex offers different media types, each formulated to target the removal of various types of gas and odor.
Any of the following factors will impact service life and efficiency.
Concentration of the gas – higher concentrations improve capacity (increased pressure forces adsorption
deeper into the media).
Relative humidity – high RH substantially decreases capacity (except water miscible gases).
Temperature– high operating temperatures reduce efficiency and capacity and increase desorption.
Competitive adsorption – numerous gases confound capacity and efficiency estimates.
Exothermic Reactions
Certain gases such as ketones can undergo oxidation or other chemical reactions that can liberate hazardous
levels of heat in the presence of standard activated carbon. In the presence of such gases use only Fumex
FX1K adsorbent to eliminate this hazard.

5
GENERAL MAINTENANCE
1) The blower motor is a sealed unit, 24,000 hr. MTBF rated. It is permanently lubricated and does not require
oiling – keep it free of dust accumulations to prevent overheating.
2) Remove any loose accumulations of dust/debris from the air filter chamber periodically.
“This product employs overload protection (fuse). A blown fuse indicates an overload or short-circuit situation. If
the fuse blows, unplug the product from the outlet. Replace the fuse as per the user servicing instructions (only
10-Amp fuse) and check the product. If the replacement fuse blows, a short circuit may be present and the
product should be discarded or returned to an authorized service facility for examination and/or repair”.
Remote Interface and Connectivity Function
The GS2-200 unit can be supplied with an optional interface package providing remote start/stop and filter
monitoring capabilities (Part # FA228). Please see instructions below for Relay Activation/De-Activation
procedures and refer to the drawing in Figure 1 for remote connections.
WARNING
“To Prevent the Risk of Electrical Shock, Connect Remote Interface
Cable to 24v, Class 2 Power Supply Only”
WARNING
“Disconnect From All Power Supplies Before Servicing”

6
Replacement Parts
Part #
Item
Part #
Item
Cabinetry
Electrical
FA106A
Flanged air inlet 3”∅
FAAU500
Universal blower motor / assembly – 90-250/1/50-60
FA106B
Flanged air inlet 2 x 2”∅
FA004
Control board assembly
FA106C
Flanged air inlet 1 x 2”∅
FA113
Fuseholder
FA108
Wheels, standard
FA114
Fuse, 10 amp (120VAC)
FA109
Vibration Isolators
FA115
Cordset (120VAC)
FA117
Cabinet latch
FA115B
Cordset (230VAC)
FA118
Cabinet hinge
Filters Gas/ Odor Filters
FX7
Polyester pre-filter w/ tackifier
FX1
Virgin grade activated carbon
FX1K
Virgin grade activated carbon-specially treated
FX2
Blended carbon media
FX4
FX1 blended with FX2
Table 1
Warranty and Liability Limitations:
Fumex FA1 air cleaners are guaranteed for 24 months from date of invoice to be electrically and mechanically sound. This warranty covers the material
and workmanship only. Any defective item will be repaired or replaced, at our option, free of charge provided it has not been misused, abused, or
otherwise damaged and is returned PREPAID to:
Fumex, LLC. 1150 Cobb International Pl., Kennesaw, GA 30152
There are no warranties which extend beyond the descriptions set forth in this warranty, notwithstanding any knowledge of Fumex, LLC. regarding the
use or uses intended to be made of goods, proposed changes or additions to goods, or any assistance or suggestions that may have been made by
Fumex personnel. Customer is responsible for determining the suitability of Fumex products for customer’s use or resale, or for incorporating them into
objects or applications which customer designs, assembles, constructs or manufactures.
Fumex reserves the right to discontinue any item and to make changes in the specifications, terms and conditions or prices at any time without prior
notice. Information furnished in the specifications is believed to be accurate and reliable at time of printing, however Fumex accepts no responsibility for
product use, or the effect of future design or specification changes.
For Assistance or Technical Support please Contact Fumex LLC.
phone [phone] fax [phone]
USA toll-free 800-432-7550
www.fumexinc.com
Fumex, LLC.
1150 Cobb International Place
Kennesaw, GA USA 30152
Fumex, LLC., 2017, all rights reserved.
Specifications subject to change without notice

7
RELAY ACTIVATION PROCEDURES FOR GS2-200 UNITS
CAUTION
DO NOT WORK ON PANEL WITH POWER APPLIED!
1. Disconnect all power sources from GS2-200 unit.
2. Remove the 8 screws securing the bottom panel and gently pry bottom panel loose.
3. Locate relay activation switch on the rear of the control panel as shown in Figure 2.
4. Flip the Relay Activation Switch to the “ON” position as indicated in Figure 3.
5. Reinstall bottom panel using the 8 screws removed in step 2.
6. Apply incoming power to the unit by connecting the power cord and turning the power switch located near
the power cord on. Make sure the blower is not running and the green power light is off. This is called the
“Soft On” state.
7. Now that the physical switch is activated and the unit is in the “Soft On” state, the software will need to be
reprogramed via a flash drive with a configuration file and the USB port on the control board. (Contact Fumex
to acquire the correct configuration file for your unit).
8. Reprogram the software by changing the “remoteSwitchOnly” setting in the configuration file to “1”. This
will lock out the Control Board power button. The ON/OFF function will only be able to be controlled
remotely.
9. After changing and saving the configuration file, plug the flash drive into the USB port on the front of the
control board. (Make sure the unit is in the “Soft On” state before plugging in the flash drive.)
10. After the reprogramming is complete the light above the USB port will turn green and remain lit until the flash
drive is removed from the USB port.
11. Remove the flash drive and apply 0-24 VDC to the start relay according to the wiring diagram in Figure 3 to
start the unit.
Once the relay activation switch is turned on and the configuration file has been
reprogrammed the unit will only start by applying the proper voltage to the
start/stop relay.

8
RELAY DE-ACTIVATION PROCEDURES FOR GS2-200 UNITS
CAUTION
DO NOT WORK ON PANEL WITH POWER APPLIED!
1. Disconnect all power sources from GS2-200 unit.
2. Remove the 8 screws securing the bottom panel and gently pry bottom panel loose.
3. Locate relay activation switch on the rear of the control panel as shown in Figure 1.
4. Flip the Relay Activation Switch to the “OFF” position as indicated in Figure 2.
5. Reinstall bottom panel using the 8 screws removed in step 3.
6. Apply incoming power to the unit by connecting the power cord and turning the power switch located near
the power cord on. Make sure the blower is not running and the green power light is off. This is called the
“Soft On” state.
7. Now that the physical switch is activated and the unit is in the “Soft On” state, the software will need to be
reprogramed via a flash drive with a configuration file and the USB port on the control board. (Contact Fumex
to acquire the correct configuration file for your unit).
8. Reprogram the software by changing the “remoteSwitchOnly” setting in the configuration file to “0”. This
will unlock the Control Board power button. The ON/OFF function will only be able to be controlled by the
front panel on the unit.
9. After changing and saving the configuration file, plug the flash drive into the USB port on the front of the
control board. (Make sure the unit is in the “Soft On” state before plugging in the flash drive.)
10. After the reprogramming is complete the light above the USB port will turn green and remain lit until the flash
drive is removed from the USB port.
11. Remove the flash drive and start the unit as described in the “Controls” section.
Once the relay activation switch is turned off and the configuration file has been
reprogrammed the unit will only start by using the front control panel. All relays
will become non-functional.

9
DRAWINGS AND FIGURES
Figure 1

10
DRAWINGS AND FIGURES
Figure 2
Figure 3
ON
OFF
Relay Activation
Switch
