Furinno 12095 User manual

Assembly Instruction
Customer Service
Tel/Fax: [phone]
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: [email protected]
its Space. its Budget
www.furinno.com
Furinno Econ Multipurpose Home Office
Computer Writing Desk w/Bin
1209520140523
MODEL : 12095
39.4”(W) x 34.1”(H) x 15.8”(D)DIMENSION :
Tools Required
Recomm. 2 Person
Approx. 30 minutes
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
1
2
3
18pcs
12pcs
6pcs
A 1pcs
Top Panel 1
Nail Leg
No Hardware List Qty No QtyParts List
Screw
Wooden Dowel
4
5
6
7pcs
7pcs
12pcs
Power Pin
Cam-Lock Nut
Cam-Lock Screw
7
8
9
1pcs
8pcs
1pcs
Non-Wooven Bin
Drawer Slide
Keyboard Screw
B
C
1pcs
1pcs
Left Side Panel
Top Panel 2
D
E
F
1pcs
1pcs
1pcs
Top Support Panel 1
Right Side Panel
Side Support Panel
G
H
1pcs
1pcs
Bottom Side Panel
Top Support Panel 2
I
J
K
1pcs
1pcs
1pcs
Back Panel
Shelf Panel
Bottom Panel
L
M
1pcs
1pcs
Back Cover
Keyboard Panel
9
FG
KM
L
L
J
I
A
B
C
D
E
H
STEP 2
Install Nail Leg(3)to the bottom of
Panel(C)(D)&(H)using hammer.
Screw Cam-Lock Screw(5)into the
pre-drilled holes on Panel(A)(B)&(I).
STEP 3
STEP 1
Insert Dowel(2)and Cam-Lock Nut(4)into the pre-drilled holes on Panel(C,D,E,F,G,H).
(3)x2pcs
(5)x7pcs
Arrow on Cam-Lock
Nut(4) should be polnting
towarcls holes. 4
(4)x2pcs
(2)x2pcs
STEP 5
Fix Drawer Slide(7)to Panel(C)&(D)using Screw(8).
Note: Please make sure L&R Side of Drawer Slide(7) before attach it.
STEP 4
Fix Drawer Slide(7)to Panel(L)using Screw(8).
Note: Please make sure L&R Side of Drawer Slide(7) before attach it.
(8)x4pcs
(8)x4pcs
Front Side

STEP 8
Attach the assembled unit to Panel(D)&(K) using Screw(1),as shown.
STEP 6
Attach Panel(E)to Panel(I)using Screw(1).
STEP 7
Attach Panel(J)to Panel(H)using Screw(1)
and tighten Cam-Lock Nut(4)on Panel(H)
using screwdriver.
(1)x2pcs
(1)x6pcs
(1)x2pcs
STEP 10
10.1 Attach Panel(G)to Panel(F)using Screw(1).
10.2 Attach Panel(F)&(G)to Panel(A)using Screw(1).
STEP 9
Attach Panel(C)to the assembled unit using Screw(1).
(1)x2pcs
(1)x4pcs
(1)x4pcs
STEP 12
12.1 Upright the unit and slide in Keyboard Panel(L).
12.2 Attach Panel(B)to Panel(E)(F)&(G)and tighten Cam-Lock Nut(4)using screwdriver.
STEP 11
Attach Panel(A)to Panel(C)&(D)and tighten Cam-Lock Nut(4)using screwdriver.
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
Unfold Bin(9)and slide into the shelf.
STEP 14
Attach Back Panel(M)to the back of
assembled unit using Power Pin(6).
STEP 13
Recommended Maximum Weight
*Unit in Pound(lbs)
10
15
10
(6)x12pcs
