Furniture of America CM3350T User manual

MODEL #
CM3350T
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
1 / 11
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
ASSEMBLY RATING
EASY DIFFICULT
2 - People
Recommended
VERSION # 20-06-09

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ XXXXXXX11

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ XXXXXXX11

4 / 11

CM3350T
#1 x1pc #2 x1pc
#A 24pcs
Bolt Ø5/16" x 1-1/2" Flat Washer
#C 24pcs #D 1pc
Allen Wrench
#3 x2pcs #4 x2pcs
Lock Washer
#B 24pcs
Table Top Leaf Mounting Plate Pedestal
Base Bun Foot
#5 x2pcs #6 x6pcs
5 / 11
TABLE

CM3350T-1
#1
Table Top
Leaf #2
Base
Bun Foot
Mounting Plate #3
#5
#6
#A x 24pcs
#B x 24pcs
#Cx 24pcs
#D x 1pc
CM3350T-2 #4
Pedestal
6 / 11
Carton Disignation PartS Hardware
CM3350T is packed in 2 cartons

Exploded View
#1
#2
#4
#5
#6
7 / 11

ASSEMBLY INSTRUCTIONS
1
Hardware #A x8pcs
Hardware #B x8pcs
Hardware #C x8pcs
2
Hardware #A x8pcs
Hardware #B x8pcs
Hardware #C x8pcs
#D
#A
#B
#C
#3
#4
#5
#4
x 2
x 2
#D
#A
#B
#C
1. Prepare 4 bolt assemblies by first
inserting a lock washer (#B) onto
the bolt (#A) then a flat washer
(#C) onto that same bolt (#A).
2. Align the Mounting Plate (#3) to the
holes along the pedestal (#4), then
insert a bolt assembly into each
hole. Secure using the Allen wrench.
1. Prepare 4 bolt assemblies by first
inserting a lock washer (#B) onto
the bolt (#A) then a flat washer
(#C) onto that same bolt (#A).
2. Align the base (#5) to the
holes along the pedestal
(#4), then insert a bolt asse-
mbly into each hole. Secure
using the Allen wrench.
Parts #4 x 2pcs
Parts #3 x 2pcs
Parts #5 x 2pcs
8 / 11

ASSEMBLY INSTRUCTIONS
3
4
Hardware #A x8pcs
Hardware #B x8pcs
Hardware #C x8pcs
#6
#5
#1
x 2
#D
#A
#B
#C
#3
#1
Insert the threaded
ends of the bun foots
(#6) into the holes
along the bottom of
the base (#5). Turn
right to tighten.
Adjusting Level
1. Prepare 8 bolt assemblies by first inserting
a lock washer (#B) onto the bolt (#A) then a
flat washer (#C) onto that same bolt (#A).
2. Align the top of the Mounting Plate (#3) to
the holes along the table top (#1), then insert
a bolt assembly into each hole and secure.
Parts #6 x 6pcs
Parts #1 x 1pc
9 / 11

OPEN
#1
#1
#2
ASSEMBLY INSTRUCTIONS
5
6
Unlock the latches
located along the bottom.
Slide the outer side out-
ward, then place the leaf
(#2) onto the rails.
10 / 11

LOCK
#2
#1
ASSEMBLY INSTRUCTIONS
7
8
Slide the inward,
then lock the
latches along
the bottom.
11 / 11
