Furniture of America Spring Creek CMBK602FOAK User manual

MODEL #
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
(Included)
Allen Wrench
Recommended
Phillips
Screwdriver
(Not Included)
CM-BK602F
1 / 14
3- People
EASY DIFFICULT
VERSION # 21-01-07

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ 1X4

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ XXXXX14

4/ XXXXXXX14

DAYBED
#1 1pc #2 1pc #3 2pcs
#5 2pcs #6 4pcs
#4 2pcs
CM-BK602F
Upper Side Rail Guardrail
#9 2pcs #10 2pcs #11 4pcs #12 1pc
#13 1pc
Support Leg
271x40x40mm
Full Slat Kit Twin Slat Kit
Guardrail Support Ladder Steps Ladder Rail (L)
Ladder Rail (R)
5 / 14
#7 1set #8 2set
Lower Headboard (L) Lower Headboard (R) Upper Headboard/Footboard Lower Side Rail

#A 24pcs #B 24pcs #C 2pcs #D 40pcs
#E 6pcs #F 4pcs #G 8pcs #H 2pcs
Bolt
Ø1/4" x 4-7/8" Screw
#4x40mm Screw
#4x30mm
#I 1pc
Allen Wrench 4mm
Screw
#4x20mm
Bolt
Ø1/4" x 1-3/16" Metal Dowel
Ø9 x 90mm
Barrel Nut
Ø1/4" x 1/2"
6 / 14
Screw
Ø3/16" x 2"

Exploded View
#1
#3
#4
#5
#6
#7
#8
#9
#2
#3
#11
#12
#13
#6
#10
#5
#10
7 / 14

CM-BK602F is packed in 2 cases
Carton Disignation Part Hardware
#1
CM-BK602F-2
#2
#9
#10
#3
#4
#5
#6
#7
#8
CM-BK602F-1
Lower Headboard (L)
Lower Headboard (R)
Upper
Headboard/Footboard
#11
#12
#13
Lower Side Rail
Upper Side Rail
Guardrail
Full Slat Kit
Support Leg
Guardrail Support
Ladder Steps
Ladder Rail (L)
Ladder Rail (R)
#Ax24pcs
#Bx24pcs
#Cx2pcs
#Dx40pcs
#Ex6pcs
#Fx4pcs
#Gx8pcs
#Hx2pcs
#Ix1pc
Twin Slat Kit
8 / 14

ASSEMBLY INSTRUCTIONS
1
2
9 / 14
Part #1 x 1pc
Hardware #A x 8pcs
Hardware #B x 8pcs
Hardware #D x 20pcs
Part #2 x 1pc
Part #7 x 1set
#B
#I
#2
#4
#1
#4
Part #4 x 2pcs
#7
#A
#D
Align side rails (#4) to the lower headboards (#1,2),
then secure by using bolts (#A) onto barrel nuts (#B).
Align slats (#7) to the lower bunk, then
secure by using screws (#D).

ASSEMBLY INSTRUCTIONS
3
4
10 / 14
Hardware #C x 2pcs
Part #3 x 2pcs
Part #9 x 2pcs
Hardware #A x 16pcs
Part #5 x 2pcs
Part #6 x 4pcs
Hardware #B x 16pcs
#C
#9
#A
#I
#B
#6
#3
#5
#6
#5
#3
Align support leg (#9) to the slats (#7), then secure by
using screws (#C).
Align guardrails (#6) and side rails (#5) to the upper
headboards (#3), then secure by using bolts (#A) onto
barrel nuts (#B).

ASSEMBLY INSTRUCTIONS
5
6
11 / 14
Hardware #E x 6pcs
Part #10 x 2pcs
Hardware #D x 20pcs
#10
#E
#10
#I
#D
#8
Part #8 x 2set
Align guardrail supports (#10) to the
guardrails (#6) and side rails (#5), then
secure by using bolts (#E).
Align slats (#8) to the upper
bunk, then secure by using
screws (#D).

ASSEMBLY INSTRUCTIONS
7
8
12 / 14
Hardware #F x 4pcs
Hardware #G x 8pcs
Part #11 x 4pcs
Part #12 x 1pc
Part #13 x 1pc
#F
#F
#F
#G
#I
#12
#11
#13
Insert dowels (#F) onto the lower
bunk, then carefully place the upper
bunk on top of lower bunk.
Align ladder rungs (#11) to the ladder rails
(#12,13), then secure by using screws (#G).

13 / 14
ASSEMBLY INSTRUCTIONS
9
Hardware #H x 2pcs
10
#H
Align ladder to bunk bed, then
secure by using screws (#H).

14/ 14
