Further Tech Net-TV Box User manual

User’s Manual
Version 1.0

Preface
Congratulations on your purchase of this product. Read this manual carefully and keep it in a safe place for
future reference.
About this manual
This user manual has been designed to help you make the most of your IP camera and its many features and
functions. Information in this document has been carefully checked for accuracy; however, no guarantee is
given to the correctness of the contents. The information in this document is subject to change without notice.
Copyright
© Copyright 2008
This manual contains proprietary information, protected by copyright.All rights reserved

Contents
WX
3
Contents
Introduction..................................................................................................................................6
Key Features............................................................................................................................................... 6
System Requirements................................................................................................................................ 8
Computer System Requirements........................................................................................................... 8
Box System Requirements .................................................................................................................... 8
Specification ............................................................................................................................................... 9
Package Contents..................................................................................................................................... 10
Identifying Parts and Controls................................................................................................................. 11
Front Panel ...........................................................................................................................................11
Rear Panel........................................................................................................................................... 13
Installation..................................................................................................................................15
Hardware Installation................................................................................................................................ 15
Software Installation................................................................................................................................. 20

Contents
WX
4
Remove Software...................................................................................................................................... 22
Network Configuration ..............................................................................................................23
Easy Setup ................................................................................................................................................ 23
Change the Network configuration ...................................................................................................... 23
Analyze the unknown network configuration........................................................................................ 31
UPnP Testing ....................................................................................................................................... 39
The setting for UPnP-disabled or non-UPnP routers............................................................................. 43
Get internet access via the DMZ function of the router ........................................................................ 52
Getting to know netTV Player...................................................................................................54
For the initial operation............................................................................................................................ 54
Main Panel Instructions ........................................................................................................................... 58
Remote Control Interface Instructions ................................................................................................... 61
Mouse and keyboard operations............................................................................................................. 65
Property Setting Page Instructions......................................................................................................... 69
Local File Interface Instructions.............................................................................................................. 78

Contents
WX
5
Using netTV Player ....................................................................................................................79
Settings of the Virtual Remote Control................................................................................................... 79
To Load Profile.......................................................................................................................................... 85
USB Recording Device............................................................................................................................. 88
Download/Playback the recorded files from netTV Box........................................................................ 91
Favorite Channel Setting ......................................................................................................................... 93
Firmware Update........................................................................................................................95
Troubleshooting.........................................................................................................................99

Introduction
WX
6
Introduction
netTV Box is an IPTV Box receiving TV sources from Wall or Set-Top-Box via TV Tuner, RCA or S-Video on the
one end, compressing the video in the format of H.264 & the audio in the format of AAC, and transmitting the
compressed media to the internet or intranet on the other end. With the application software installed on your
computer, 3G mobile phone or Wi-Fi PDA, you could control the TV Tuner or Set-Top-Box via IR connection between
IPTV Box & Set-Top-Box, and watch & record TV programs on the go.
Key Features
No monthly fee. (All TV contents can be accessed.)
Using a high-performance H.264 video compression chipset, requires smaller bandwidth and implements better
video quality.
Network video and security monitoring.
With the player installed on PC, 3G mobile phone or Wi-Fi PDA, the user could control the TV Tuner or
Set-Top-Box via IR connection between IPTV Box & Set-Top-Box, and watch & record TV programs on the go
(Option).
D1/Half-D1/DCIF/CIF/QCIF Real Time Compression Supported.
Automatic adjustment of encoder parameters based on dynamic algorithm of the available network bandwidth

Introduction
WX
7
ensures the smooth video stream transport on the network.
P2P service and UPnP compatibility make an easy network connection.
The IR Remote Control Learning function supports all types of A/V devices including PVRs, Digital Cable Boxes,
and Satellite TV Receivers.
Scheduled or real-time recording on PC or Box (by USB port) supported.
TV sources can be received from Wall (Cable) via TV Tuner of this netTV Box, or from Set-Top-Box via RCA or
S-Video of this netTV Box.
System Software Upgrade via Network supported.
NTSC and PAL standards auto detection supported.
External USB hard disk support.
**TV Tuner supports both PAL and NTSC TV standards.

Introduction
WX
8
System Requirements
In general, if your desktop PC or laptop is purchased within 3 to 4 years, and runs a modern OS like Windows XP
or Windows Vista, you should be able to install the player. Please see the specific requirements below:
Computer System Requirements
CPU：Intel Pentium 4 2.0GHz or above
RAM：512MB or above
Operating system：Windows XP SP2 or Windows Vista
Hard disk：at least 100MB capacity or above
Windows-compatible Graphics Card with DirectDraw Overlay Support
Sound Card：PCI sound card or on-board audio
Network：10/100Mbps Ethernet LAN port connection ability
Microsoft DirectX 9.0c or above
Box System Requirements
Router with NAT and UPnP features
Broadband Internet Access (Cable Modem or ADSL) with minimum upload bandwidth of 512Kbps or faster
TV signal (Air or Cable) or external input (Set-top box or DVD player)

Introduction
WX
9
Specification
Processor: Multi Core: ARM 9 CPU + DSP,240Mhz SDRAM: 32MB
Flash: 16MB Network Interface: RJ-45 Ethernet (10/100Mbps auto
switching)
Network protocol: HTTP,UDP, TCP/IP,SMTP,
FTP, PPPoE, DHCP, NTP, DDNS TBA
Video Input/Output: 1.NTSC + PAL TV Tuner (IEC
169-2 ); 2.Composite video (Female RCA);
3.S-Video (Female4-pin mini-DIN)
Audio Input/Output: L/R Stereo Audio (Female RCA) Video Frame Rate: Up to 30fps
Video Bitrate (Auto Mode): Automatic bitrate
adjustment depending on network condition
Video Bitrate (Manual Mode): Adjustable from
64Kbps to 2Mbps
Video Compression: H.264 (Hardware Encode) Video Resolution: D1、HALF-D1、CIF、QCIF
Supported Client OS: Windows XP / Vista Power Requirement: 5VDC, 2A
IR Blaster: To control an external cable/satellite box Dimension: 185(L)x124(W)x28.5(H)mm
Weight: 875g (Full Package) Environment Conditions: Operating temperature
0~45oC;
Storage temperature -20~60oC

Introduction
WX
10
Package Contents
After unpacking, check that all the following items have been included:
*One ID key for netTV Player is enclosed.

Introduction
WX
11
Identifying Parts and Controls
Front Panel
Green LED Indicator (Power Light)：It is lit when netTV Box is powered on.
Red LED Indicator (Network Activity Light)：It is lit when netTV Box is connected to network.
Remote Sensor：It receives the IR signals from the IR remote control to implement the Remote Control
Button Learning function.
IR Blaster：It connects the enclosed IR Blaster Cable which aims at the IR receiver of the STB or DVR on the
other end. Then, the netTV Player can control the STB or DVR remotely.
USB：For use of external storage.

Introduction
WX
12
Status Description of LED Indicators 1(Power Light) & 2(Network Activity Light)
Status Green LED（Power）Red LED（Network）
Power on(8 seconds) On Off
Starting (12 seconds) Blinking Off
Starting completed, internet connect setting successful On On
Starting completed, internet connect setting failed On Off
Login (working) On Quick blinking
IR Learning Quick blinking 2 times Blinking
Reset (3 seconds) Blinking 3 times Blinking 3 times
Above table related connect ways to internet all mean the Box’s connect way to internet. When the box is on standby,
the red led indicator is constantly on. It means that Box is successfully connected to internet.

Introduction
WX
13
Rear Panel
RESET：Press and hold for 3 seconds, the green led and the red led both blink three times at the same time
(blinking one time per second), then the box has been reset to factory defaults. If the power is off suddenly
before the leds blink, the [RESET] won’t take effect, but you can start your box. If the power is off suddenly
when the leds are blinking, the [RESET] has been effective, after finishing the [RESET], the box will proceed
to [Power on] and [Starting]. (Caution: The use of this button will result in the loss of existing
configuration. Maybe you should reset the network configuration of Box to connect to internet. )
TUNER: IN：It connects the CATV cable to receive the TV RF signals. OUT：It connects the RF IN of
your TV set via the enclosed Coaxial Cable to loop through the TV RF signals.

Introduction
WX
14
AV1 IN: (S-VIDEO/VIDEO/AUDIO) terminal：Connect audio cables and either a video or S-Video cable from
your STB or DVR or Camera.
AV1 OUT：Loop through the Audio/Video signals from AV1 IN to your TV set.
ETHERNET：RJ-45 Connector for IP Router or ADSL/ Cable Modem.
DC IN：DC Power input (Specification: 5V DC 2A)
Please use the [Reset] button carefully, all parameters of hardware of the Box will restore to factory default after
[Reset]. Before [Reset], we recommend save the restoring information, such as channel table, IR learning files .rpl
format), and network configuration.

Installation
WX
15
Installation
Hardware Installation
Step1: Verify Your Network Condition
netTV Box is a plug-n-play IP TV Box. As long as your home network is the same as the diagram below, you could
easily complete the installation and start enjoying your TV on the go - just through the following simple steps.( If your
connection structure is not the same as the following diagram, please refer to the next Chapter [Network
Configuration] for help.)
Use IP Router with UPnP function to connect netTV Box to your ADSL/Cable Modem which directs you to internet. (If
you have a switch or hub, you can also connect it between the netTV Box and IP Router or between the IP Router
and Modem for your convenience.)

Installation
WX
16
Step 2: Connect to Your Network
Take the enclosed RJ-45 Ethernet Cable and plug it into
the LAN port of your IP router; plug the other end of the
RJ-45 Ethernet Cable into the ETHERNET port at the back
of netTV Box.

Installation
WX
17
Step 3: Connect to TV Sources
CONNECTING CABLE OR
ANTENNA
Disconnect the existing Coaxial/RF cable from
your TV's RF/Antenna IN and reconnect it to
the Antenna IN of netTV Box.
Use the enclosed RF cable and RF adapter to
connect the Antenna OUT of your netTV Box to
the RF IN of your TV.
CONNECT AUDIO/VIDEO
SOURCE
Use the enclosed Composite Cable or S-Video
Cable(i.e., not supplied) to connect the AV
OUT of your video device to the AV1 IN of
netTV Box labeled VIDEO, AUDIO-L, AUDIO-R,S-VIDEO.
We recommend you to connect Video IN to a Camera and S-Video & Audio IN to your Cable/Satellite box or DVR devices.
Therefore, you could have a better video quality and the optimal use of the video inputs of this product.
CONNECT OUTPUT (OPTIONAL)
Use the enclosed A/V output cable to connect the terminal marked “AV1 OUT” on the netTV Box. Connect the same cable
type for the output back to your TV as you used for the input to the netTV Box

Installation
WX
18
Step 4: Connect the IR Blaster Cable
（If you don’t install other video sources except TV, skip the step）
With netTV Player, the netTV Box can learn
signals of the remote control of a video
device to control the video devices with the
on-screen virtual remote control. Place the
IR Blaster cable heads on the top and
bottom of your video device so they point at
its remote sensor.
Connect the IR Blaster cable to the IR
Blaster port on the front of netTV Box.
While conducting the learning of the
physical remote control, please aim your physical remote control at the front LED cap of netTV Box. Keep the distance
between the physical remote control and netTV Box within 2 inches.
In order to learn remote control precisely, please move far from the devices with IR function. (i.e., move far from
mobile phone, notebook and so on.)

Installation
WX
19
Step 5: Connect Power Source
Connect the power adapter to netTV Box’s port labeled DC IN. Plug the
power adapter into an electrical outlet.
When plugged in, the power light comes on, and the light blinks many times
as the netTV Box starts up.

Installation
WX
20
Software Installation
Before installing netTV Box, please make sure the package contents are in accordance with the product
checklist including all cables required for getting onto the Internet equipment via RJ-45 WAN Port. Ensure that your
PC meets the minimum system requirement and is equipped with a CD drive and a HDD of at least 100MB free
space.
Install netTV Player on your computer:
Under the Operating System of Windows XP / Windows Vista, put the
enclosed CD onto your CD drive and run the 「setup」file of the CD.
