Fusion MS-IPDOCKG2 User manual

42.0
128.0
R
6.0
48.0
136.0
4.0
158.0
69.017.5
DOOR OPENING CLEARANCE
PRODUCT OUTLINE
CUTOUT
MOUNTING TEMPLATE CUT OUT
MARINE DOCK FOR iPod
MS-IPDOCKG2
INSTALLATION GUIDELINES
BULKHEAD MOUNT
Open the front panel cover and feed the Marine Dock for iPod through
the front cover, as shown in fig 1. Use the included gasket if needed,
to ensure the front panel is fitted tightly to the dock.
Attach the Dock to the bulkhead using the screws provided.
MOUNTING DIMENSIONS: 126mm x 40mm
MOUNTING SCREW HOLES: 136mm x 48mm
WALL MOUNT
Attach the dock to a wall or shelf as illustrated in fig 2, using the two
screws provided. This mounting option is suitable for interior installation
where the dock is not exposed to the marine elements.
The dock connects directly to the Marine Stereo, via the white iPod
connector.
MOUNTING DIMENSIONS: 145mm x 121mm x 34mm
MOUNTING SCREW HOLES: 90mm
»
»
THE MARINE DOCK FOR iPod IS COMPATIBLE WITH THE
FOLLOWING 500 AND 600 SERIES, MARINE STEREO UNITS.
(MS-CD500, MS-CD600, MS-AV600)
optional gasket
g 2
g 1
SEE REVERSE FOR DOCK SLEEVE GUIDE
www.fusionelectronics.com
v 4.0

v 4.0
DOCK SLEEVES
A different set of dock sleeves are used for each iPod model. The different
dock sleeve combinations are outlined in the chart below:
Please note: For the iPod nano (Gen 3), the iPod must be placed inside
the adapter sleeve, and then placed inside Dock sleeve combination A.
Please note: Place the sleeves inside the dock before inserting your iPod.
iPod Top Sleeve Bottom Sleeve
iPod with video, 30GB A A
iPod with video, 60GB 80GB A B
iPod classic, 80GB B A
iPod classic, 160GB (2007) B B
iPod classic, 120GB B A
iPod classic, 160GB (2009) B A
iPod touch, D D
iPod touch, 2nd gen D D
iPod touch, 2nd gen (2009) D A
nano, 3rd Gen A A + adapter
nano, 4th Gen E E
nano, 5th Gen G G
Other F F
RECORD YOUR PURCHASE DETAILS HERE:
MODEL NUMBER
DATE OF PURCHASE
AFFIX RECEIPT HERE
