FUTABA 14SG User manual

14 CHANNEL COMPUTER SYSTEM
TM
TM
Technical updates and additional programming examples available at: http://www.futaba-rc.com/faq
Entire Contents © 2012

2<Table of Contents>
INTRODUCTION............................................... 4
●Support and Service ......................................... 4
●Application, Export, and Modication........... 5
●Denitions of Symbols...................................... 6
●Safety Precautions (do not operate without
reading) ............................................................. 6
BEFORE USE ................................................... 10
●Features of 14SG ............................................ 10
●Contents and technical specications ........... 11
●Accessories....................................................... 12
●Transmitter controls....................................... 13
Cautions on handling antenna ...................... 14
LED monitor................................................... 14
Switch (SA-SH)............................................... 15
Digital trim (T1-T4) ....................................... 15
Volume (LD, RD)............................................ 15
Slide Lever (LS, RS)....................................... 15
HOME/EXIT, U.MENU/MON. Button........ 15
Touch sensor ................................................... 16
Stick adjustment............................................. 17
SD card............................................................ 19
Connector/Plug............................................... 21
Installation and removal of the battery........ 22
●Receiver nomenclature................................... 24
●Receiver's antenna installation...................... 26
●Safety precautions when installing servos... 27
●S.BUS/S.BUS2 Installation ............................ 28
●S.BUS Wiring example................................... 29
●S.BUS2 System................................................ 30
●S.BUS/S.BUS2 Devicesetting ......................... 31
●Telemetry System............................................ 32
BASIC OPERATION ....................................... 33
●Battery Charging ............................................ 33
How to charge the NiMH Battery................. 33
●How to turn ON/OFF the transmitter .......... 34
When turning on ............................................ 34
When turning off............................................ 34
Low battery alarm and auto shut-down ...... 34
Warning display at power on ........................ 34
●Registration of the user's name ..................... 34
●Home screen .................................................... 35
User Menu....................................................... 36
●Link procedure (T14SG/R7008SB)............... 37
●Range testing your R/C system...................... 39
RACEIVER AND SERVO INSTALLATION. 40
●Receiver and servos connection..................... 40
●Servo connection by model type.................... 41
MODEL BASIC SETTING PROCEDURE ... 44
●Airplane/glider basic setting procedure........ 44
●Helicopter basic setting procedure................ 46
FUNCTIONS OF SYSTEM MENU................ 50
Trainer............................................................. 51
Display............................................................. 54
User Name....................................................... 55
Sound............................................................... 56
H/W Setting..................................................... 57
Start SEL. ....................................................... 59
Auto Lock ....................................................... 62
Information .................................................... 63
SBUS Servo .................................................... 64
FUNCTIONS OF LINKAGE MENU ............. 67
(Common Functions)
Linkage Menu functions table ...................... 67
Servo Monitor................................................. 68
Model Select.................................................... 69
Model Type...................................................... 71
TABLE OF CONTENTS

3
<Table of Contents>
System ............................................................. 73
Function .......................................................... 76
Sub-Trim ......................................................... 78
Servo Reverse ................................................. 79
Fail Safe........................................................... 80
End Point ........................................................ 81
Servo Speed .................................................... 82
Throttle Cut (Air/Heli only) .......................... 83
Idle Down (Air only) ...................................... 84
Swash Ring (Heli only) .................................. 85
Swash (Heli only, except H-1)........................ 86
T1-T4 Setting .................................................. 89
Warning........................................................... 90
Telemetry......................................................... 91
Telemetry:Rx-batt .......................................... 92
Telemetry:Ext-volt ......................................... 93
Telemetry:temp............................................... 94
Telemetry:rpm................................................ 95
Telemetry:altitude .......................................... 96
Telemetry:vario .............................................. 97
Telemetry:battery........................................... 98
Telemetry:distance ......................................... 99
Telemetry:speed............................................ 101
Sensor ............................................................ 102
Sensor:reload ................................................ 103
Sensor:register.............................................. 103
Sensor:relocate ............................................. 104
Sensor:set slot ............................................... 104
Data Reset ..................................................... 105
FUNCTIONS OF MODEL MENU ............... 106
●Common Functions ...................................... 106
Servo Monitor (Linkage Menu)
Condition Select (Glid/Heli only)................ 107
Dual Rate ...................................................... 109
Program Mix..................................................111
Fuel Mix (Air/Heli only) .............................. 113
●Airplane/Glider Functions........................... 115
Model Menu functions list........................... 115
Pitch Curve (Air/Glid) ................................. 117
THR Curve (Air only).................................. 118
THR Delay (Air only)................................... 119
AIL Differential (Except 1-AIL) ................. 120
Flap Setting (2-FLP and up)........................ 121
AIL to Camber FLP (2-AIL+2-FLP and up)122
AIL to Brake FLP (Glid only, 4-FLP) ........ 123
AIL to RUD................................................... 124
RUD to AIL................................................... 125
Camber Mix (Except 1-AIL)....................... 127
ELE to Camber (Except 1-AIL).................. 129
Camber FLP to ELE (2-AIL+1-FLP and up) 130
Buttery (Glid only, normal wing 2-AIL and
up, ying wing 2-AIL+1FLP and up) ...... 131
Trim Mix (Glid only, 2-AIL and up)........... 133
Airbrake (Air only, 2-AIL and up) ............. 135
Gyro (Air only, for GYA type gyro)............ 137
V-tail .............................................................. 139
Ailevator........................................................ 140
Winglet (Flying wing only) .......................... 141
Motor............................................................. 142
RUD to ELE (Air only)................................ 144
Snap Roll (Air only) ..................................... 145
●Helicopter Functions .................................... 147
Model Menu functions list........................... 147
PIT Curve/Pit trim....................................... 148
THR Curve/Throttle hover trim/Throttle
limiter ......................................................... 151
THR Hold...................................................... 154
Swash Mix..................................................... 155
THR Mix ....................................................... 156
PIT to RUD (Revolution mix) ..................... 157
Gyro (for GY type gyro) .............................. 158
Governor ....................................................... 161
APPENDIX...................................................... 164
Timer ST1/ST2 ............................................. 164
Switch Setting Method................................. 166

4<Introduction>
INTRODUCTION
Thank you for purchasing a Futaba®FASSTest-2.4GHz* 14SG series digital proportional R/C system. This
system is extremely versatile and may be used by beginners and pros alike. In order for you to make the
best use of your system and to y safely, please read this manual carefully. If you have any difculties
while using your system, please consult the manual, our online Frequently Asked Questions (on the web
pages referenced below), your hobby dealer, or the Futaba Service Center.
*FASSTest: Futaba Advanced Spread Spectrum Technology extend system telemetry
Due to unforeseen changes in production procedures, the information contained in this manual is subject to
change without notice.
Support and Service: It is recommended to have your Futaba equipment serviced annually during your
hobby’s “off season” to ensure safe operation.
IN NORTH AMERICA
Please feel free to contact the Futaba Service Center for assistance in operation, use and programming.
Please be sure to regularly visit the 14SG Frequently Asked Questions web site at www.futaba-rc.com/
faq/. This page includes extensive programming, use, set up and safety information on the 14SG radio
system and is updated regularly. Any technical updates and US manual corrections will be available on this
web page. If you do not nd the answers to your questions there, please see the end of our F.A.Q. area for
information on contacting us via email for the most rapid and convenient response.
Don’t have Internet access? Internet access is available at no charge at most public libraries, schools, and
other public resources. We nd internet support to be a fabulous reference for many modelers as items can
be printed and saved for future reference, and can be accessed at any hour of the day, night, weekend or
holiday. If you do not wish to access the internet for information, however, don’t worry. Our support teams
are available Monday through Friday 8-5 Central time to assist you.
FOR SERVICE ONLY:
Futaba Service Center
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Phone: [phone]
www.futaba-rc.com/service.html
Email: [email protected]
FOR SUPPORT :
(PROGRAMMING AND USER QUESTIONS)
Please start here for answers to most questions:
www.futaba-rc.com/faq/
Fax: [phone]
Phone: [phone] option 2
OUTSIDE NORTH AMERICA
Please contact your Futaba importer in your region of the world to assist you with any questions, problems
or service needs.
Please recognize that all information in this manual, and all support availability, is based upon the systems
sold in North America only. Products purchased elsewhere may vary. Always contact your region’s support
center for assistance.

5
<Introduction>
Application, Export, and Modication
1. This product may be used for model airplane or surface (boat, car, robot) use. It is not intended for use
in any application other than the control of models for hobby and recreational purposes. The product is
subject to regulations of the Ministry of Radio/Telecommunications and is restricted under Japanese law to
such purposes.
2. Exportation precautions:
(a) When this product is exported from the country of manufacture, its use is to be approved by the laws
governing the country of destination which govern devices that emit radio frequencies. If this product is
then re-exported to other countries, it may be subject to restrictions on such export. Prior approval of the
appropriate government authorities may be required. If you have purchased this product from an exporter
outside your country, and not the authorized Futaba distributor in your country, please contact the seller
immediately to determine if such export regulations have been met.
(b) Use of this product with other than models may be restricted by Export and Trade Control Regulations,
and an application for export approval must be submitted. This equipment must not be utilized to operate
equipment other than radio controlled models.
3. Modification, adjustment, and replacement of parts: Futaba is not responsible for unauthorized
modification, adjustment, and replacement of parts on this product. Any such changes may void the
warranty.
Compliance Information Statement (for U.S.A.)
This device, trade name Futaba Corporation of America, model number R7008SB, complies with part 15 of
the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
The responsible party of this device compliance is:
Futaba Service Center
3002 N Apollo Drive Suite 1, Champaign, IL 61822 U.S.A.
TEL [phone] or E-mail: [email protected] (Support)
TEL [phone] or E-mail: [email protected] (Service)
The RBRC. SEAL on the nickel-cadmium battery contained in Futaba products indicates that
Futaba Corporation of America is voluntarily participating in an industry-wide program to collect
and recycle these batteries at the end of their useful lives, when taken out of service within the
United States. The RBRC. program provides a convenient alternative to placing used nickel-
cadmium batteries into the trash or municipal waste system, which is illegal in some areas.
(for USA)
You may contact your local recycling center for information on where to return the spent battery. Please
call 1-800-8BATTERY for information on NiCd battery recycling in your area. Futaba Corporation of
America's involvement in this program is part of its commitment to protecting our environment and
conserving natural resources.
*RBRC is a trademark of the Rechargeable Battery Recycling Corporation.

6<Introduction>
Federal Communications Commission Interference Statement (for U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Consult the dealer or your Futaba Serivce center for help.
CAUTION:
To assure continued FCC compliance:
Any changes or modications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
Exposure to Radio Frequency Radiation
To comply with FCC RF exposure compliance requirements, a separation distance of at least 20cm must be
maintained between the antenna of this device and all persons.
This device must not be co-located or operating in conjunction with any other antenna or transmitter.
Meaning of Special Markings
Pay special attention to safety where indicated by the following marks:
DANGER - Procedures which may lead to dangerous conditions and cause death/serious injury if not
carried out properly.
WARNING - Procedures which may lead to a dangerous condition or cause death or serious injury
to the user if not carried out properly, or procedures where the probability of supercial injury or
physical damage is high.
CAUTION - Procedures where the possibility of serious injury to the user is small, but there is a
danger of injury, or physical damage, if not carried out properly.
= Prohibited = Mandatory
Warning: Always keep electrical components away from small children.
FLYING SAFETY
WARNING
To ensure the safety of yourself and others, please observe the following precautions:
Have regular maintenance performed. Although your 14SG protects the model memories with
non-volatile EEPROM memory (which does not require periodic replacement) and not a battery, the
transmitter still should have regular checkups for wear and tear. We recommend sending your system
to the Futaba Service Center annually during your non-ying-season for a complete checkup and
service.

7
<Introduction>
NiMH/NiCd Battery
Charge the batteries! (See Charging the NiCd batteries, for details.) Always recharge the transmitter
and receiver batteries before each ying session. A low battery will soon die potentially, causing loss
of control and a crash. When you begin your ying session, reset your T14SG’s built-in timer, and
during the session pay attention to the duration of usage.
Stop ying long before your batteries become low on charge. Do not rely on your radio’s low
battery warning systems, intended only as a precaution, to tell you when to recharge. Always
check your transmitter and receiver batteries prior to each ight.
Where to Fly
We recommend that you fly at a recognized model airplane flying field. You can find model clubs
and fields by asking your nearest hobby dealer, or in the US by contacting the Academy of Model
Aeronautics.
You can also contact the national Academy of Model Aeronautics (AMA), which has more than 2,500
chartered clubs across the country. Through any one of them, instructor training programs and insured
newcomer training are available. Contact the AMA at the address or toll-free phone number below.
Academy of Model Aeronautics
5161 East Memorial Drive
Muncie, IN 47302
Tele. [phone]
Fax [phone]
or via the Internet at http:\\www.modelaircraft.org
Always pay particular attention to the ying eld’s rules, as well as the presence and location
of spectators, the wind direction, and any obstacles on the eld. Be very careful ying in areas near
power lines, tall buildings, or communication facilities as there may be radio interference in their
vicinity.

8<Introduction>
NiMH/NiCd Battery Safety and Handling instructions
IMPORTANT!
Use only the Futaba special charger included with this set or other chargers approved by Futaba to
charge the NiMH batteries in the T14SG transmitter included with this set.
It is important to understand the operating characteristics of NiMH/NiCd batteries.Always read the
specications printed on the label of your NiMH/NiCd battery and charger prior to use. Failure to follow
the proceeding precautions can quickly result in severe, permanent damage to the batteries and its
surroundings and possibly result in a FIRE!
IMPORTANT PRECAUTIONS
Do not attempt to disassemble NiMH/NiCd packs or cells.
Do not allow NiMH/NiCd cells to come in contact with moisture or water at any time.
Always provide adequate ventilation around NiMH/NiCd batteries during charge, discharge, while in
use, and during storage.
Do not leave a NiMH/NiCd battery unattended at any time while being charged or discharged.
Do not attempt to charge NiMH/NiCd batteries with a charger that is NOT designed for NiMH/NiCd
batteries, as permanent damage to the battery and charger could result.
Always charge NiMH/NiCd batteries in a reproof location. Do not charge or discharge NiMH/NiCd
batteries on carpet, a cluttered workbench, near paper, plastic, vinyl, leather or wood, or inside an R/
C model or full-sized automobile! Monitor the charge area with a smoke or re alarm.
Do not charge NiMH/NiCd batteries at currents greater than the “1C” rating of the battery (“C”
equals the rated capacity of the battery).
Do not allow NiMH/NiCd cells to overheat at any time! Cells which reach greater than 140 degrees
Fahrenheit (60°C) should be placed in a reproof location.
NiMH/NiCd cells will not charge fully when too cold or show full charge.
It is normal for the batteries to become warm during charging, but if the charger or battery becomes
excessively hot disconnect the battery from the charger immediately!! Always inspect a battery which
has previously overheated for potential damage, and do not re-use if you suspect it has been damaged
in any way.
Do not use a NiMH/NiCd battery if you suspect physical damage has occurred to the pack. Carefully
inspect the battery for even the smallest of dents, cracks, splits, punctures or damage to the wiring
and connectors. DO NOT allow the battery’s internal electrolyte to get into eyes or on skin—wash
affected areas immediately if they come in contact with the electrolyte. If in doubt, place the battery
in a re-proof location for at least 30 minutes.
Do not store batteries near an open ame or heater.
Do not discharge NiMH/NiCd batteries at currents which exceed the discharge current rating of the
battery.
Always store NiMH/NiCd cells/packs in a secure location away from children.
Never remove the SD card or turn off power
while entering data.
Never store the SD card where it may be
subject to strong static electricity or magnetic
elds.
Do not expose the SD card to direct sunlight,
excessive humidity or corrosive environments.
Do not expose the SD card to dirt, moisture,
water or uids of any kind.
Always hold the SD card by the edges during
installation and removal.
Be certain to insert the SD card in the correct
direction.
Secure Digital (SD) Memory Card Handling Instructions
(SD card is not included with this set)

9
<Introduction>
At the ying eld
To prevent possible damage to your radio gear, turn the power switches on and off in the proper
sequence:
1. Pull throttle stick to idle position, or otherwise disarm your motor/engine.
2. Turn on the transmitter power and allow your transmitter to reach its home screen.
3. Conrm the proper model memory has been selected.
4. Turn on your receiver power.
5. Test all controls. If a servo operates abnormally, don’t attempt to y until you determine the cause of
the problem.
Test to ensure that the FailSafe settings are correct after adjusting them. Turn the transmitter off and
conrm the proper surface/throttle movements. Turn the transmitter back on.
6. Start your engine.
7. Complete a full range check.
8. After ying, bring your throttle stick to idle position, engage any kill switches or otherwise disarm
your motor/engine.
9. Turn off receiver power.
10. Turn off transmitter power.
If you do not turn on your system in this order, you may damage your servos or control surfaces,
flood your engine, or in the case of electric-powered or gasoline-powered models, the engine may
unexpectedly turn on and cause a severe injury.
While you are getting ready to y, if you place your transmitter on the ground, be sure that the
wind won't tip it over. If it is knocked over, the throttle stick may be accidentally moved, causing
the engine to speed up. Also, damage to your transmitter may occur.
In order to maintain complete control of your aircraft it is important that it remains visible at all
times. Flying behind large objects such as buildings, grain bins, etc. is not suggested. Doing so may
result in the reduction of the quality of the radio frequency link to the model.
Do not grasp the transmitter's antenna during ight. Doing so may degrade the quality of the
radio frequency transmission.
As with all radio frequency transmissions, the strongest area of signal transmission is from the sides
of the transmitter's antenna. As such, the antenna should not be pointed directly at the model. If your
ying style creates this situation, easily move the antenna to correct this situation.
Don’t fly in the rain! Water or moisture may enter the transmitter through the antenna or stick
openings and cause erratic operation or loss of control. If you must fly in wet weather during a
contest, be sure to cover your transmitter with a plastic bag or waterproof barrier. Never fly if
lightning is expected.

10 <Before Use>
BEFORE USE
Features
FASSTest system
The T14SG transmitter has adopted the newly developed bidirectional communication system
"FASSTest".Data from the receiver can be checked in your transmitter. FASSTest is a maximum 14
channels (linear 12 channels + switch 2 channels) 2.4GHz dedicated system.
S.BUS2 system
By using the S.BUS2 system multiple servos, gyros and telemetry sensors are easily installed with a
minimum amount of cables.
Model types
Six swash types are available for helicopters. Six types of main wings and three types of tail wings are
available for airplanes and gliders. Functions and mixing functions necessary for each model type are set in
advance at the factory.
Data input
Large graphic LCD and new type Touch Sensor substantially improve ease of setup.
Stick
Improved feel, adjustable length and tension.
Ni-MH battery
T14SG is operated by a 6.0 V/1,800 mAh Nickel-Metal Hydride battery.
SD card (Secure Digital memory card) (Not included)
Model data can be saved to an SD card (SD:32MB-2GB SDHC:4GB-32GB). When T14SG transmitter
software les are released, the software can be updated by using an SD card update.
Edit button
Two edit buttons are provided, and the operating screen can be immediately “Returned” to the HOME
screen during operation. Setting operation can be performed easily by combining this button with a touch
sensor.
Vibration function
Selects a function that alerts the operator to various alarms and timers by vibrating the transmitter in
addition to sounding a buzzer.
