Future Automation TSLM-MO-3 Instruction Manual

WWW
.
FUTUREAUTOMATION
.
NET
TSLM-MO-3
TECHNICAL SHEET
ISSUE 003
SHEET 1
MARINE OUTDOOR TELESCOPIC SCREEN LIFT
UK [phone] US [phone]

SPECIFICATION MEASUREMENTS
Product Dimensions 892mm (35 1/8") x 1280mm (50 3/8") x 240mm (9 7/16")
Minimum Screen Height 850mm (33 7/16")
Maximum Screen Height 1175mm (46 1/4")
Minimum Screen Width 1280mm (50 3/8") - (Lower Width option available apon request)
Maximum Weight Capacity
(Screen + Enclosure)
75Kg (165lb)
Product Weight 45Kg (99lb)
Packaging Dimensions TBC
Shipping Weight TBC
Movement Type Motorised
Power Supply Required 110V - 240V
Power Consumption Max. 250W
Power Consumption Standby 3W
Mounting Patterns Supported VESA 200, 300, 400 W x 200, 300, 400 H - (Other VESA patterns apon request)
Control Options IR Remote, RS232, Contact Closure
Product Options / Features Specific B&O and Loewe mounts / adapters, Custom RAL paint finishes, Outdoor suitable version
Package Contents Mechanism, IR remote control
Marine Suitable YES
Outdoor Suitable YES
WWW
.
FUTUREAUTOMATION
.
NET
TSLM-MO-3
TECHNICAL SHEET
ISSUE 003
SHEET 2
MARINE OUTDOOR TELESCOPIC SCREEN LIFT
UK [phone] US [phone]

Front access is required to install the lift.
Allow 20mm+ in front of the screen if
the mechanism is to be partially sunk
below floor level.
LID and ENCLOSURE - To be made by
others. Total allowable weight for all
timber work and the screen 75Kg .
Screen cables
enter here.
Screen
cables
enter here.
VESA 400 wide mounting
pattern covered. Brackets
have full height adjustment .
The lid must be easily removed if the
mechanism was stuck in the down
position. A lift off arrangement being
ideal. The fixings for the screen are
then accessible so it can then be lifted
off to give access to the motor.
TRIM PANEL - Not supplied.
This trim panel is lifted up as
the screen is lowered into the
cabinet. Brackets are
supplied to attach it.
GENERAL INFORMATION
WWW
.
FUTUREAUTOMATION
.
NET
TSLM-MO-3
TECHNICAL SHEET
ISSUE 003
SHEET 3
MARINE OUTDOOR TELESCOPIC SCREEN LIFT
UK [phone] US [phone]

A
A
BB
Screen Height
Min. 850 [33 7/16"]
Max. 1175 [46 1/4"]
Internal Cabinet Height = Screen Height + 55 [2 3/16"]
Box Enclosure Height = Screen Height + 30 [1 3/16"]
13/16"
20
Box Enclosure
Cap Height
34 15/16"
888
Mechanism Back Tray Height
C
SECTION A-A
SCALE 1 : 8
Screen Width
Box Enclosure Width = Screeen Width + 50 [1 15/16"]
Internal Cabinet Width = Screen Width + 100 [3 15/16"]
13/16"
20
Aperture Width = Screeen Width + 66 [2 5/8"]
SECTION B-B
SCALE 1 : 8
Box Enclosure Depth =
Screen Depth + 100 [3 15/16"]
Screen
Depth
Internal Cabinet Depth = Screen Depth + 230 [9 1/16"]
3 11/16"
93
Back of Cabinet
to Aperture
Aperture Depth =
Screen Depth + 116 [4 9/16"]
DETAIL C
SCALE 1 : 3
Recomended Cap Detail to prevent
water entering the cabinet
CABINET SIZING
All sizing calculations are based off a 20mm [0.79"]
box enclosure panel thickness. Any increases in
this thickness will increase the required space.
WWW
.
FUTUREAUTOMATION
.
NET
TSLM-MO-3
TECHNICAL SHEET
ISSUE 003
SHEET 4
MARINE OUTDOOR TELESCOPIC SCREEN LIFT
UK [phone] US [phone]

25 3/16"
640
44 7/8"
1140
22 1/16"
560
31 7/8"
810
11 13/16"
300
13/16"
20
Lid Thickness
D
D
Optional ventilation
Fixing
Brackets
1/2"
12
13/16"
20
23 5/8"
600
3 9/16"
90
SECTION D-D
Enclosure also fixed along here
Blocks to locate lid.
22 13/16"
580
13 3/8"
340
1/4"
7
Trim Panel
BOX ENCLOSURE DETAILING
The Screen, Enclosure, Lid and the Trim
panel must weigh no more than 75Kg .
WWW
.
FUTUREAUTOMATION
.
NET
TSLM-MO-3
TECHNICAL SHEET
ISSUE 003
SHEET 5
MARINE OUTDOOR TELESCOPIC SCREEN LIFT
UK [phone] US [phone]

F
F
Enclosure
Either or both
cable tracks can
be used.
Trim Panel
Fixing holes
Mount bracket
Down Switch
Up Switch
Fixing holes
Mount fixing bolts
SECTION F-F
INSTALL INSTRUCTIONS
Check that the cabinet, enclosure, lid and the trim panel are
made to the details shown on the previous pages.
You can stand the mechanism up on its base to test it •
before putting in the cabinet. See control document for
details. Use the IR remote with caution and always cover
the STOP button in case of issues.
Centrally fix the mechanism to the back of the cabinet in •
the places shown.
Run up and down and then add the enclosure. •
Adjust the position of the enclosure and adjust the up •
and down switches with caution. Temporarily add lid to
check height.
Run screen cables up into enclosure. Secure cables as •
they enter and leave the cable tracks with cable ties.
Make sure no cables can get tangled or caught as the
mechanism moves.
Add trim panel. And adjust. This trim panel moves up •
into position as the TV lifts. Observe this movement and
understand it before fixing.
The upright plate can be adjusted in height by moving it •
to a different set of keyholes. Fix the plate to the back of
the screen and mount to mechanism using the keyholes.
Ensure the plate is secured using the fixing bolts located
at the top of the keyhole plates.
Check movement with screen with caution. •
WWW
.
FUTUREAUTOMATION
.
NET
TSLM-MO-3
TECHNICAL SHEET
ISSUE 003
SHEET 6
MARINE OUTDOOR TELESCOPIC SCREEN LIFT
UK [phone] US [phone]

9 1/4"
235
12 3/8"
315
9 7/8"
251.5
5 1/16"
128
118 1/8"
3000
CABLE LOOM
LENGTH APPROX.
6 11/16"
169.6
9 13/16"
249.6
1/16"
R2.25
2 CORE CABLE
LIFTING MOTOR
10mm [0.4"] dia.
EU SPEC: 1.5mm²
US SPEC: 16AWG
6 CORE CABLE
MAINS SUPPLY
4.5mm [0.25"] dia.
EU SPEC: 0.2mm²
US SPEC: 24AWG
3 CORE CABLE
SWITCH LIMITS
6mm [0.25"] dia.
EU SPEC: 0.2mm²
US SPEC: 24AWG
3 CORE CABLE
IR RECEIVER
3mm [0.12"] dia.
EU SPEC: 0.12mm²
US SPEC: 25AWG
FUTURE AUTOMATION
UDC3 CONTROL BOARD
POWER SUPPLY UNIT
INPUT = 110V (6A) OR 240V (3A) AC MAINS
OUTPUT = 24V DC, 21A
NOTES
ENCLOSURE AND CABLE GLANDS RATED TO IP56. •
ENCLOSURE AND LID FIXINGS ALL MADE FROM GEWISS GW PLAST 75. •
ENCLOSURE MATERIAL SUITABLE FOR TEMPERATURES +60
C TO -25 C. •
POWER SUPPLY UNIT (PSU) WILL ALLOW 110V OR 240V AC INPUT. THE SAME PSU IS USED FOR EU OR US MAINS SUPPLIES. •
OTHER THAN CONTROL CABLES, ALL CABLES TERMINATE AT CONTROL BOARD VIA STANDARD PHOENIX CONNECTORS. •
CABLE LOOM LENGTH SUPPLIED AT APPROX. 3m [118"]. LOOM CAN BE EXTENDED UP TO MAXIMUM OF APPROX. 10m [400"]. •
MINIMUM CABLE BEND RADIUS 25mm [1"]. •
