FUZRR FR9010 User manual

-1-

-2-
CONTENT
Warning 3
I. Brief Introduction 3
II.Range and Accuracy 4
III .Technical Specifications 4
IV. Structure 5
V. Operation Method 6
VI. Accessories 7

-3-
Warning
Thankyoufor purchasing our FR9010lightning protection special standard
resistor. In ordertouse thisproductbetter, please be sureto:
Readthisusermanual indetail.
Strictlyfollowthe safetyrulesand precautionslisted inthis manual.
uInanycase, theuseofthisinstrument shouldpayspecialattention to safety.
uPayattention to thelabeltext andsymbolsontheinstrument panelandbackpanel.
uPleaseusethefour-wire methodforcalibration,otherwisetheaccuracyrequirementswill
notbemet.
uDonotplace and store theinstrument foralongtimeunderhigh temperature andhumidity,
in aplace with condensationand directsunlight.
uUse,disassembly,andrepairofthis instrument must beperformedbyauthorized
personnel.
uDuetothereasonofthisinstrument,ifitisdangeroustocontinueusingit,itshouldbe
stoppedimmediatelyandsealedimmediately,and handledbyanauthorizedinstitution.
uThe “”hazardsymbol on theinstrument and manual,theuser must follow the
instructionsforsafe operation.
uThe “”extremelydangeroussigninthemanualmust beoperatedsafelybytheuser in
strictaccordance withtheinstructions.
. Brief ntroduction
FR9010lightningprotectionspecial standard resistor consistsof91/2Whigh precision
militarygradewire woundresistorseries.Whentheinstrument is calibrated,thereis no needto
changethelinefordirectshifting.Thetest is convenient,thehighestprecisionis upto 0.05%,
andthelong-termstabilityis good.Itisaspecialstandardresistorspeciallydesignedbyour
company.Its resistancevalueincludes1mΩ,10mΩ,100mΩ,1Ω,10Ω,100Ω,1KΩ,10KΩ,
100KΩ.Itfullymeets therangeof10-3~105asspecifiedinOrder No.31ofthe 《Measures
fortheAdministrationofDetectingQualifications ofLightningProtection Devices》.Mainly
usedforcalibrationofgrounding resistancetester, equipotentialtester, etc.

-4-
.Range and Accuracy
Model Accuracy(%)Temperature Coefficient（ppm）
0.001Ω2
±25
0.01Ω0.5
0.1Ω0.2
1.0Ω0.2
10Ω0.05
100Ω0.05
1KΩ0.05
10KΩ0.05
100KΩ0.1
Basecondition：23℃1℃50～60%RH
.Technical Specifications
Function Usedforcalibrationofground resistance tester, equipotentialtester, etc.
Range 1mΩ，10mΩ，100mΩ，1Ω，10Ω，100Ω，1KΩ，10KΩ，100KΩ
Wiring
method Four-wire method
Capacity
factor 1/2W
Temperature
coefficient
±25ppm
Size L/W/T：187*119*48mm
Test line
length Red 0.5m，black 0.5m each 2pcs
Weight About 550g
Working
temperature
-10℃～40℃；below70%rh

-5-
and
humidity
Storage
temperature
and
humidity
-20℃～60℃；below80%rh
Insulation
resistance Morethan 10MΩ(between thecircuitand the housing500V)
Pressure
resistance
AC 3700V/rms(between thecircuit and the housing)
Suitable
for safety
regulations
IEC61010-1,CATIII600V,pollutionlevel,JJG166-1993 《DCresistance
testprocedures》
V. Structure
1. Resistance outputjack(C1P1P2C2)
2. Softprotectivecover
3. Upper andlower cover
4. Shifting twist switch

-6-
V. Operation Method
Do not applymorethan 1/2W ofcapacity factor totheresistor,
otherwise the standard resistor will be damaged.
When calib
ratingthe instrument,it must becalibratedusingthe
four-
wire method,otherwisemeasurementaccuracycannotbe
guaranteed.
If youusethisstandardresistorto verify otherinstruments,
use the four-wire method whenever possible. If using the two-wire
method,use the C1 and C2 terminals.
Whencalibratingvariousresistancetestinstruments,first confirm thattheoutput power of
theinstrument doesnotexceedthecapacityfactorofthemeasuredresistance andthentest it.
Whentesting, usethefour-wiremethod asmuchaspossible.
Thewiring diagramsofvariousinstrumentsareasfollows.Afterconnectingtherear line,
hitthecorresponding fileandstarttheinstrument to betested.

-7-
V. Accessories
Instrument bag 1PC
Standard resistor 1PC
Test line 4PCS（Red,blackeach2PCS）
Manual、certificate
1SET

-8-
GuangZhou ZhengNeng ElectronicsTechnologyCo.
Address:2F, No.15 Baoshu Road, Taihe, Baiyun District,Guangzhou, Guangdong, China
Toll-free call：4000-1515-38
Tel：[phone]
Fax：[phone]
Post：510540
WebSite：www.znele.com
