FW Murphy M-VIEW J1939 Series User manual

-1-
M‐VIEW™SeriesJ1939Module
Phone: [phone] Bulletin No. MVJ1939-A
Fax: [phone] Drawing No. LP1084
www.fwmurphy.com Effective 2018-11-30
FOR USE IN HAZARDOUS LOCATIONS:
Class I, Division 2, Groups A, B, C, and D
T4
CUS
UL
R
LISTED
IND.CONT. EQ.
E317425
•CONFIGURED USING M-VIEW DESIGNER 3.1
•DIGITALLY ISOLATED J1939 PORT CAPABLE OF
COMMUNICATING WITH ANY J1939 DEVICE
•POWERED AND CONFIGURED FROM M-VIEW HOST DEVICE
•BUILT-IN TERMINATION RESISTOR SELECTABLE THROUGH A
SWITCH
CUS LISTED
UL
R
IND. CONT. EQ.
E302106
II 3 G Ex nA IIC T4 Gc
-40°C ≤TAMB ≤75°C
DEMKO 14 ATEX 1387X
IECEx UL 15.0035X
GENERALDESCRIPTION
The MV-J1939 is a J1939 communication module designed for use
with CAN enabled devices using J1939 protocol. The module provides
the M-VIEW a J1939 communications port. It is built with digital isolation
to protect the M-VIEW from the J1939 bus and vice versa. It provides the
ability to communicate to any J1939 device. The MV-J1939 module has
a termination resistor built-in, and is selectable through a switch. The
connector is pluggable for easy removal of the MV-J1939 module from
the J1939 bus, without disturbing communications with other devices on
the bus.
The modules connect and communicate via proprietary USB
connection to the various M-VIEW devices. The M-VIEW devices,
equipped with serial ports as well as Ethernet port(s), allows the system
to share data with PCs, PLCs and SCADA systems. The maximum
number of modules varies for each M-VIEW device, see specific model
for details. Remove power from the host device before installing or
replacing any modules.
CONFIGURATION
The M-VIEW is configured with Windows®compatible M-VIEW
DESIGNER 3.1 software. The software is an easy to use, graphical
interface which provides a means of configuration and commissioning of
new systems, as well as routine module re-calibration.
SAFETYSUMMARY
All safety related regulations, local codes and instructions that appear
in this literature or on equipment must be observed to ensure personal
safety and to prevent damage to either the instrument or equipment
connected to it. If equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
Do not use this unit to directly command motors, valves, or other
actuators not equipped with safeguards. To do so can be potentially
harmful to persons or equipment in the event of a fault to the unit.
ORDERINGINFORMATION
A listing of the entire M-VIEW family of products and accessories can be
found at www.fwmurphy.com.
4.65
(118)
2.80 (71) 1.25 (32)
DIMENSIONSIninches(mm)
DESCRIPTION PART NUMBER
M-VIEW Module, J1939 Protocol Interface 50704942
WARNING - EXPLOSION HAZARD - DO NOT D
EQUIPMENT UNLESS POWER HAS BEEN SW
OR AREA IS KNOWN TO BE NON-HAZARDOU
CAUTION: Risk of Danger.
Read complete instructions prior to installation
and operation of the unit.
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF
OR AREA IS KNOWN TO BE NON-HAZARDOUS.
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF
OR AREA IS KNOWN TO BE NON-HAZARDOUS.
WARNING - EXPLOSION HAZARD - SUBSTITUTION OF
COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I,
DIVISION 2.

-2-
Bulletin No. MVJ1939-A Effective 2018-11-30
Drawing No. LP1084
SPECIFICATIONS
1. POWER: Power will be supplied by the M-VIEW host device. Some
modules, depending on usage may consume high levels of power. This
may limit the total number of modules that can be installed on a single
M-VIEW host. Check the M-VIEW module and M-VIEW host data
sheets for specific usage and power requirements.
MV-J1939 Max Power: 1.2 W
2. COMMUNICATIONS:
J1939 Port: The J1939 port has format and baud rates that are
software programmable up to 250K baud and is digitally isolated.
124 ohm, 1W termination is provided through a switch. This port
may be configured for various J1939 protocols.
Isolation from MV-J1939 Communication ports to M-VIEW host device:
1000 VDC for 1 minute.
3. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: -40 to 75 °C, or lowest range among
equipment used in your M-VIEW system. Consult the user manual
for further details.
Storage Temperature Range: -40 to +85 °C
Operating and Storage Humidity: 85% max. relative humidity, non-
condensing.
Altitude: Up to 2000 meters
4. CERTIFICATIONS AND COMPLIANCES:
CE Approved
EN 61326-1 Immunity to Industrial Locations
IEC/EN 61010-1
RoHS Compliant
ATEX Approved
II 3 G Ex nA IIC T4 Gc
DEMKO 14 ATEX 1387X
EN 60079-0, -15
IECEx Approved
Ex nA IIC T4 Gc
IECEx UL 15.0035X
IEC 60079-0, -15
UL Listed: File #E302106
UL Hazardous: File #E317425
ABS Type Approval for Shipboard Applications
5. CONSTRUCTION: Case body is all metal construction.
6. CONNECTIONS: Removable wire clamp screw terminal blocks
Wire Gage: 28-14 AWG (0.32 mm - 1.63 mm) terminal gage wire
Torque: 1.95-2.21 inch-lbs (0.22-0.25 N-m)
7. MOUNTING: Screws to host
8. WEIGHT: 6.9 oz (196 g)
PORT 3
ETHERNET
D
ISOLATED
ISOLATED
ISOLATED
A
POWER
SUPPLY
+
-
VDC
M-VIEW HOST MV-J1939
PORT 2
C
COMMUNICATIONS
B
PORT 1
PROGRAMMING
POWER
SUPPLY
E
ISOLATED
PORT
Block Diagram for MV-J1939
EMCINSTALLATIONGUIDELINES
Although FW Murphy products are designed with a high degree of
immunity to Electromagnetic Interference (EMI), proper installation and
wiring methods must be followed to ensure compatibility in each
application. The type of the electrical noise, source or coupling method
into a unit may be different for various installations. Cable length, routing,
and shield termination are very important and can mean the difference
between a successful or troublesome installation. Listed are some EMI
guidelines for a successful installation in an industrial environment.
1. A unit should be mounted in a metal enclosure, which is properly
connected to protective earth.
2. Use shielded cables for all Signal and Control inputs. The shield
connection should be made as short as possible. The connection point
for the shield depends somewhat upon the application. Listed below
are the recommended methods of connecting the shield, in order of
their effectiveness.
a. Connect the shield to earth ground (protective earth) at one end
where the unit is mounted.
b. Connect the shield to earth ground at both ends of the cable, usually
when the noise source frequency is over 1 MHz.
3. Never run Signal or Control cables in the same conduit or raceway with
AC power lines, conductors, feeding motors, solenoids, SCR controls,
and heaters, etc. The cables should be run through metal conduit that
is properly grounded. This is especially useful in applications where
cable runs are long and portable two-way radios are used in close
proximity or if the installation is near a commercial radio transmitter.
Also, Signal or Control cables within an enclosure should be routed as
far away as possible from contactors, control relays, transformers, and
other noisy components.
4. Long cable runs are more susceptible to EMI pickup than short cable runs.
5. In extremely high EMI environments, the use of external EMI
suppression devices such as Ferrite Suppression Cores for signal and
control cables is effective.
Contact FW Murphy Technical Support for recommendation for your
application.
6. To protect relay contacts that control inductive loads and to minimize
radiated and conducted noise (EMI), some type of contact protection
network is normally installed across the load, the contacts or both. The
most effective location is across the load.
a. Using a snubber, which is a resistor-capacitor (RC) network or metal
oxide varistor (MOV) across an AC inductive load is very effective at
reducing EMI and increasing relay contact life.
b. If a DC inductive load (such as a DC relay coil) is controlled by a
transistor switch, care must be taken not to exceed the breakdown
voltage of the transistor when the load is switched. One of the most
effective ways is to place a diode across the inductive load. Most FW
Murphy products with solid state outputs have internal zener diode
protection. However external diode protection at the load is always a
good design practice to limit EMI. Although the use of a snubber or
varistor could be used.
7. Care should be taken when connecting input and output devices to the
instrument. When a separate input and output common is provided,
they should not be mixed. Therefore a sensor common should NOT be
connected to an output common. This would cause EMI on the
sensitive input common, which could affect the instrument’s operation.

-3-
Effective 2018-11-30 Bulletin No. MVJ1939-A
Drawing No. LP1084
CONFIGURATION
Programming is done via M-VIEW™ DESIGNER 3.1 software, a
Windows®compatible configuration interface. Please see the M-VIEW
DESIGNER 3.1 User Manual for more information.
J1939PORTPROTOCOLS
The MV-J1939 module has one J1939 port.
Figure 3. MV-J1939 PORT PIN OUTS
TERMINATIONRESISTOR
An onboard termination resistor is selectable through a switch. The
termination resistor is rated for 124Ωat 1W. If a different termination
resistance is desired, slide the switch for no termination resistor. At this
point you will be required to connect your own termination resistor
between positions 2 and 4 of the five position connector.
CANGND
Position 1 of the pluggable connector provides a CAN ground
connection. This terminal is isolated from the M-VIEW host device.
CAN‐
Position 2 of the pluggable connector provides the CAN- bus line
(active low). This terminal is isolated from the M-VIEW host device.
RUN/ERROR
STS
(124 :, 1W)
TERMINATION RESISTOR
YES
NO
SHLD
V+ (N/C)
GND
CAN-
CAN+
TX/RX
2
4
1 CAN GND
CAN +
CAN -
+
-
ISOLATING
DC : DC
COMMUNICATINGWITHTHEMV‐J1939MODULE
WARNING: Disconnect all power
to the unit before installing or
removing modules.
WARNING - EXPLOSION HAZARD - DO NOT
CONNECT OR DISCONNECT CABLES WHILE
POWER IS APPLIED UNLESS AREA IS KNOWN
TO BE NON-HAZARDOUS.
REMOVE RUBBER
MODULE PLUG
HARDWAREINSTALLATION
The physical order of all installed modules must match the modules order in M-
VIEW DESIGNER 3.1. Torque screws to 6.0 pound-force inch [96 ounce-force
inch] (0.68 Nm).

-4-
Bulletin No. MVJ1939-A Effective 2018-11-30
Drawing No. LP1084
SHLD(CANSHIELD)
Position 3 of the pluggable connector is provided for shield
connections. This position is available to tie shield wires to earth ground.
The SHLD position is connected through a series RC network to
CHASSIS as noted in specification J1939-11. The SHLD connection is
internally tied to the M-VIEW host device enclosure
CAN+
Position 4 of the pluggable connector provides the CAN+ bus line
(active high). This terminal is isolated from the M-VIEW host device.
V+(OPTIONAL24VDC)
Position 5 of the pluggable connector is provided for optional 24 VDC
connections. This position is available only to tie 24 VDC wires together.
The MV-J1939 module neither provides 24 VDC power nor uses 24 VDC
power through this connection. The V+ position is not connected to any
circuitry internal to the MV-J1939 module or M-VIEW Host device.
LEDs
STS–STATUSLED
The Status LED is a green/red LED that provides information regarding
the state of the module. This includes indication of the various stages of
the start-up routine (power-up), as well as any errors that may occur.
StartupRoutine
ErrorStates
RUN/ERRORLED
FIRMWAREUPGRADE
The module’s firmware is stored in flash memory so that software/
hardware conflicts are avoided, and so features can be added in the
future.
During a download, M-VIEW DESIGNER 3.1 compares its own library
of firmware files with those stored in the module. If they do not match, M-
VIEW DESIGNER 3.1 will download the necessary firmware.
M‐VIEWTROUBLESHOOTING
If for any reason you have trouble operating, connecting, or simply
have questions concerning your new M-VIEW unit, contact FW Murphy’s
technical support.
Flashing Red Module is currently running the boot loader and/or
being flash upgraded by M-VIEW DESIGNER 3.1.
Green Module performing normally.
Flashing Green Module has lost communication with the Host.
Green
MV-J1939 module established communication with
other J1939 devices (RUN) and is communicating
normally.
Red
MV-J1939 module failed to establish
communications with other J1939 devices
(ERROR).
Phone: [phone]
Email: [e-mail]
Warranty - A limited warranty on materials and workmanship is given with this FW Murphy product. A
copy of this warranty may be viewed or printed by going to http://www.fwmurphy.com/warranty
