Thank you for purchasing our product.
Before use, please read these instructions carefully. After reading the manual you will be sure that
you use the juicer safely, comfortably and efficiently and also that you are preventing improper
handling.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should always be followed including
the following:
1. Read all instructions before using.
2. To protect against risk of electrical shock, do not put main body (motor) in water or any liquid.
3. Children should be supervised to ensure that they to do not play with the appliance.
4. Do not operate any appliance with damaged cord or plug or after the appliance malfunctions,
or is dropped or damaged in any manner. Return the appliance to the nearest authorized service
centre for examination, repair or electrical or mechanical adjustment.
5. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent.
6. Unplug from outlet when not in use, before assembling or taking off parts and before cleaning.
7. Avoid contact with moving parts.
8. Do not use attachments not recommended or sold by the manufacturer as it may lead tofire,
electric shock or injury. Do not customize or upgrade machine without professional supervision.
Doing so will void the warranty of the appliance.
9. Always ensure you switch the juicer to the OFF position and the motor has stopped completely
before you disassemble the juicer.
10. Do not put your fingers or other objects into the juicer while it is in operation. If food becomes
lodged in the inlet, use the plunger to push it down, or use the reverse button on the machine
todislodge. If this is not possible turn juicer off and wait for motor to completely stop before di-
sassembling juicer to remove food.
11. Do not use outdoors.
12. Do not use appliance for other than the intended purpose.
13. Lift appliance with the handle only.
14. Do not put any parts into the dishwasher.
15. Do not use appliance for more than 20 minutes continuously as the motor may overheat
andstop working; use it after the appliance has cooled and the motor will work again.
16. Do not use the appliance to juice hard materials, including pits, ice, frozen fruit, large or hard
seeds (eg peach, plum, persimmon, rambutan, durian seeds).
17. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by person(s) responsible for their safety.
18. Switch off the appliance and disconnect from power supply before changing accessories
ortouching any moving parts.
EN

Installation and operating instructions
A. Component identification and content check list
Note: Do not turn the appliance on before the ingredients are inserted and do not operate
withanempty bowl.
Important: The hopper edge must point to close sign on the base in order for the machine toope-
rate properly. (Fig 1)
Main Components
A Hopper
B Squeezing Screw
C Strainer-less pulp
D Strainer-more pulp
E Spinning Brush
F Bowl
G Base
H Cleaning Brush
I Pusher
J Container
Fig 1
Pulp
outlet Juice
outlet

B. Assembly Instructions
Important: Prior to assembling the juicer please check this point: At the base of the bowl there
isarubber stopper. When in place the stopper ensures all of the juice only exits via the juice outlet.
Before juicing always ensure that the rubber stopper is firmly in place. (Fig 2)
1. Assemble the bowl on the base. (Fig3)
A. Make sure the bowl is placed all the way into the shaft of the base.
2. Choose which strainer you need to use. The Yellow Strainer is a fine strainer and will redu-
ce theamount of pulp in your juice. The Orange Strainer is a coarse strainer and will increase
the amount of pulp in your juice. Insert the strainer into the spinning brush. Align the red dot
onthestrainer with the red dot on the bowl and insert strainer + spinning brush into the bowl.
When the dots are correctly aligned the strainer + spinning brush will lock in place. (Fig 4)
3. Insert the squeezing screw into the strainer and turn until it drops into position. (Fig 5)
4. Assemble the hopper onto the bowl. (Fig 6)
A. Align the small arrow on the hopper with the red dot on the bowl.
B. Twist the hopper so that the plastic tab with the arrow on it points to the closed sign
onthebase. (Fig 7)
Note: The small arrow from part 4. A will no longer be aligned with the red dot once the hopper
islocked to the close position. (Fig 7)
Fig 2
Fig 3 Fig 4
Fig 7
Fig 5 Fig 6
bowl
base

C. Operating Instructions
Warning:
• Do not operate the juicer with wet hands as it may cause an electric shock.
• Do not operate the juicer untill the juice ingredients are inserted.
• Do not operate for more than 20 minutes at one time.
Important: The Juicer has an auto shut down feature to protect the motor and hence providing you
with a long lasting machine. If the components are not aligned or installed correctly; or the motor
overheats due to extended juicing; or the strainer becomes clogged, the juicer will automatically
shut down. This is normal and prevents permanent damage to your slow juicer.
Switch the machine off if this happens. Check components are correctly installed and there is no
food clogged in the strainer. Wait 5 minutes for the motor to cool then resume normal operation.
1. Plug in the juicer.
2. Place a container below the juicer outlet and a container below the pulp outlet.
3. The juicer power button (located at the top of the handle) has 3 positions.
A. ON-This starts the motor and juicing process
B. OFF-This is the central position of the button. It switches off the appliance.
C. REV-Reverse. Only use this function when something is stuck in the juicer and it needs
tobe unclogged.
4. Prepare the material you wish to juice and insert into the hopper
Ensure pieces are not larger than 4cm for optimal juicer extraction.
Remove any large pits or seeds.
Always pre-wash food before juicing.
Do not overstuff the hopper or force food in. Insert food slowly
toallow the juicer time to work. The pusher is only be used if food
becomes stuck. (Fig 8)
5. Switch the power button to “ON”.
Feed material into the hopper, a segment at a time. Allow juicer time
to work and process the material before adding more.
Do not overstuff the hopper or force food in. The pusher is only to be
used if food becomes stuck.
6. When you are finished switch the power button to ‘OFF’.
Note: If you are making different juices in one session and want to
avoid mixing of flavors, pour water into the hopper and let the machi-
ne run fora minute to clean the unit. Discard the rinsing water.
Fig 8
REVERSE

D. If the machine becomes clogged and inoperable
1. Turn the machine off and press the reverse button for a few seconds then try operating again.
Note: The reverse button works with a ‘pulse’ motion.
2. If the reverse button does not work turn off the machine and switch off at the power point. Di-
sassemble the unit to dislodge any material then reassemble as per the instructions and try again.
Cleaning Tips:
Periodically remove the silicone brushes from the spinning brush and clean thoroughly before re-
assembling. Clean thoroughly immediately after each use to minimize staining. Pull out the rubber
stopper on the base of the bowl to clean bowl effectively. Always ensure the rubber stopper isre-
-inserted prior to juicing otherwise it may cause a leak. Do not use harsh abrasives or chemicals
toclean the juicer. Do not clean in the dish washer.
E. How to disassemble and clean the unit
1. Switch off the unit.
2. Twist the bowl and hopper as one piece
tothe right so that the arrow on the hopper mo-
ves away from the close position. Lift off. (Fig 9)
3. Disassemble the parts in the order shown
by the diagram. (Fig 10)
4. Use the brush to clean all of these parts
thoroughly in warm soapy water then dry tho-
roughly. Ensure the pulp outlet of the bowl
isclear. (Use the flat end of the cleaning brush
to clear trapped material from the pulp outlet).
Unplug the rubber stopper for easier access
tothe pulp outlet.
5. Use a damp cloth or dry towel to wipe
down the base of the unit. Do not rinse
thebase withwater.
Technical data
Product Name- Slow Juicer
Input Voltage- AC 220 - 240V
Frequency- 50 Hz
Power- 150 W
Speed- 80 rpm
Motor- Single Phase Induction
Maximum Usage time- 20 min
Fig 9
Fig 10
Images used in this manual are for illustrational
purposes only and may differ from the actual
product.

Frequently Asked Questions
? What are the things I should not put into Juicer?
Any produce with large or hard seeds (eg persimmon, peach, plum, durian, rambutan, etc).
Iceandfrozen fruit/vegetables are also not recommended.
? Can the juicer be used as a food grinder or mill?
No, this is not designed to grind or mill (eg rice, grains, peppercorns etc). You may use thejuicer
toextract milk from grains etc AFTER it has been soaked for at least 6 hours.
? Must I disassemble and clean after using Juicer?
Yes, simple cleaning by pouring water into the feeding chute is not enough. You need to disassem-
ble all attachments and clean thoroughly with warm water.
? If the juicer gets stuck and the cover cannot be opened after juicing, is this a defect? Should
I contact customer service?
When juicing fibrous vegetables, the fibres may tend to get clogged or stuck at the pulp out-
letandthis may cause the juicer to stop working. Another reason may be inserting the produce
toofast into the feeding chute too fast. Press the REVERSE button for 1 minute and then press ON
for 2-3minutes, this process will unclog stuck fibres. You can also pour water through thechute
todo simple cleaning that will help to unclog fibres. If you still have problems with disassembling
themachine, contact our customer service.
Problem Possible Causes What To Do
No power to juicer Juicer is not plugged in.
Incorrect assembly.
Check the juicer is plugged in.
Reassemble the juicer according
to the instructions.
Motor has stopped Bowl has been overfilled
withmaterial.
Overuse has caused the motor
to shut down as a precaution
tooverheating.
Press the reverse power button
to try to clear the clog. You may
need to repeat this a few times.
Switch off and let the motor cool
before using again.
Leaking from beneath
the bowl
Rubber plug on base of bowl is
not correctly inserted.
Ensure the rubber plug on base
of bowl is completely inserted.
Stain on the bowl, Strai-
ner, Spinning brush
Natural color from juicing
materials.
This is perfectly normal. Tore-
duce discoloration ensure you
rinse and clean the appliance
immediately after use.
Squeaking noise during
operation
Juicing noise from squeezing
screw.
This is perfectly normal. Ensure
you do not overload the juicer.
Damage to the strainer Frozen foods, ice, pits, seeds,
unknown substance or too
much material in the bowl.
Ensure you read the instruc-
tions carefully on the correct
use ofthejuicer. Do not overfill
thejuicer.
Troubleshooting
Before you call for service, review these troubleshooting tips:

RECIPES
Apple natural ice cream
Ingredients:
• 600 grams of apples
• 4 spoons of milk powder
• 2 spoons of condensed milk
Process:
Wash the apples and cut them into small pieces.
Put prepared apples into juicer.
Milk powder does not dissolve easily, so use
asmaller amount of prepared apple juice to which
mix condensed milk. ( preferably use blender G21
Perfect Smoothie)
Mix the juice with mixture of milk.
Put into the large bowl.
Put into the freezer for at least 1-2 hours.
Pineapple ice cream
Ingredients:
• 500 grams of pineapples
• 1 white yoghurt
• 3 spoons of condensed milk
Process:
Remove the rind of pineapple, cut it into small pie-
ces and put it into blender.
Mix the juice with yoghurt and condensed milk.
Put mixture into the freezer for 1-2 hours.
Juice to cleanse your body
Ingredience:
• 300 grams of carrot
• 200 grams of spinach
• 250 grams of carrot
• 150 grams of lettuce
• 100 grams of spinach
• 300 grams of carrot
• 100 grams of beetroot
• 100 grams of cucumber
• 300 grams of carrot
• 75 grams of beetrot
• 125 grams of pomegranate
Juice against headaches and migraines
Ingredients:
• 300 grams of carrot
• 100 grams of dandelion
• 144 grams of spinach
• 300 grams of carrot
• 200 grams of celery (if you use celery
stick, change shares to 350 grams of carrot
and150grams of celery)
Juice against colds
Ingredients:
• 250 grams of carrot
• 150 grams of celery
• 100 grams of radish
• 200 grams of grapefruit
• 10 grams of lemon
• 200 grams of orange
The recipes were developed in cooparation with www.centrumzdravibrno.cz, unique and com-
prehensive measurement of the overall state of organism, consulting, health information andse-
minars, courses and RAW food school.

Warranty card
To be filled in by the sales representative
Productname:
Product type............................................................
Serial number............................................................
Warranty period......................24..............................
Customer name ...................................................Customer address ...................................
Dealer signature ...................................................Date of sale .............................................
The above specified product was handed to the customer free of any defects including all accessories and trade
andtechnical documentation. Customer was properly familiarized with the principles of safe use, operation andtech-
nical maintenance of the product.
WARRANTY TERMS
Object of warranty:
Warranty applies to the product itself including all supplied accessories.
Warranty period:
Warranty period is 24 months from date of sale to the customer. The period between applying of the warranty claim
until the date of customer’s duty to pick the product up upon the warranty repair does not count into the warranty
period.
Dealer is obliged to provide the customer with the confirmation of the warranty claim date and also warranty repair
and repair duration. If the product is replaced under warranty, a new warranty period starts from the date when cus-
tomer receives the new product.
Warranty coverage and importer duties:
Importer is responsible for the product having the characteristics typical for this goods category and given product
parameters during the whole warranty period.
Importer is not responsible for any defects caused by usual wear or improper use of the product.
Warranty expiration:
The right for warranty claim is cancelled in following cases:
a. If the product was not used and maintained according to the user manual or if it was damaged by unqualified
action of the user.
b. If the product was used in inappropriate conditions or for different purposes than the ones applicable to this
product category.
c. If the user can not present the warranty card.
d. If any data in the original manufacturer, dealer or service documentation was intentionally modified.
e. If any part of the product was replaced by an unoriginal part.
f. If the product was damaged or excessively worn because of insufficient maintenance.
g. If the product was damaged by force majeure
h. If the product was modified without the manufacturer consent.
i. If the defect was caused by improper storage of the product.
j. If the damage was caused by natural and regular wear of the product.
k. If the product was connected or used with another device which was not approved by the importer or manu-
facturer.
Warranty claims:
Warranty claims should be filed at the dealer. The user is obliged to present a filled in warranty card or proof of pur-
chase. Warranty repairs are carried out by the dealer / importer or approved service centers.
Legal:
Other relationships between the seller (dealer / importer) and buyer (customer) are regulated by the applicable civil
or commercial code.
Distributor for CZ: PENTA CZ s.r.o Distributor for SK: PENTA SK s.r.o. Distributor for other countries Penta CZ s.r.o.
Stamp seller
EN
