G21 Emotion User manual

HEALTHYHEALTHY
BPA
FREE
Quiet
operation
180 W37 rpm High
juice yield
no cutting
fruit
Emotion
powerful blenders “Smoothie”Food processor “Promesso“
vertical juicers “Emotion” horizontal juicers “Chamber” and “Gourmet”
food dehydrators “Harmony”
more products G21

1
2
3
4
5
6 7 8 9 10
EN
1. Feeding chute
2. Drum lid
3. Juicing bowl
4. Smart cap
5. Base
6. Rotation wiper
7. Strainer
8. Juicing screw
9. Pusher
10.Cleaning brush
Parts:
Thank you for purchasing our product.
Before using this unit, please read this manual in order to avoid improper handling and use
ofthedevice.

Safety precautions:
When using the electrical appliances, basic safety precautions should always be followed inclu-
ding the following:
1. This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved.
2. Children shall not play with the appliance.
3. Do not use the appliance if the rotating sieve or the protecting cover is damaged or has visible
cracks.
4. Do not continuously operate the juicer for more than 30 minutes. This can damage the motor
from overheating. Process a maximum 5 kg carrot disposable. After continuous use, let the juicer
rest for 30 minutes to cool down before starting another session.
5. Do not use the appliance for other purposes than is intended.
6. Make sure the voltage mark on the appliance corresponds to the voltage in your home before
plugging in the power cord in order to avoid damage to the appliance.
7. To protect against electrical shock, do not place cord, plug, or base unit in water or other
liquids. Don’t operate machine with wet hands or place on a wet working surface. Do not let the
cord hang over the edge of the table or counter or touch hot surfaces.
8. If the electrical supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
9. Unplug from outlet when not in use.
10.It is prohibited to plug or unplug with wet hands to avoid electric shock.
11.To disconnect, remove plug from the electric outlet.
12.Check the strainer every time you want to use the appliance. If you detect any cracks or da-
mage, do not use the appliance and contact the nearest service center.
13.Always securely clamp in place all parts before the motor is turned on. Do not unfasten while
appliance is in operation.
14.Avoid contacting moving parts. Make sure the motor stops completely before disassembling.
15.Do not place the appliance on or near a hot gas or electric burner or in a heated oven.
16.Do not let the appliance continue operating when you are away from it.
17.Do not disassemble the base.
18.Do not allow the machine to operate in an idle state with no fruit or vegetable being juiced. Idling
time can’t exceed 1 minutes or it will damage the appliance.
19.During operation, please insert the food material slowly to avoid clogging rotation. If clogging
happens, please stop working immediately. Reverse the motor for a while then open the lid to take
out the food and continue working again in the forward motor setting.
20.Please use the special pusher stick to move food material into the feeder opening. Before use,
please take out seeds and cores or it will cause clogging.
21.If use a grains or legumes, we recommend to soak them first and than start juicing. This food
material will juice easily when it is soaked.
22.When using, if there are any abnormal sounds, smells, overheating, smoke, etc., immediately
turn off the power and apply to the service center for maintenance and repair.
23.Never scrub or wash the machine body on water-filled platform or pour water to wash the inside
of the machine to avoid fire, electric shock or damage to machine body, etc.

Step 1
Top-set assembly
Insert individual parts to the bowl. Red dots must be aligned on each
part and assemble in the order shown.
Step 2
Top-set and base assembly
Place the bowl on the base, the 3 holes of bowl lock into the 3
feet at the base.
1 2
Double size Food chute - One for whole apple, another for strip shaped vegetables.
1. Open the lid to insert the whole round fruits like apples, oranges. (Refer to picture 1)
2. Insert the strip shaped vegetables like carrots. (Refer to picture 2)
How to assembly

Step 1 Top-set assembly
Wash the parts before first use.
Check before operating:
Ensure that the compression silicone and silicone ring are assembled properly.
1. Firmly insert the compression silicone into
the slot below the pulp spout.
Note: The juicer may leak if not assembled properly. Note: The juicing screw needs to be locked in place in
order to close the drum lid.
3. Assemble the strainer into the rotation wiper
then place this assembly in to the juicing bowl
ensuring the red dot on the strainer is aligned
with the red dot on the juicing bowl.
2. Place the juicing screw into the strainer. Turn
and press down on it until it clicks into place.
4. Place the drum lid on to the juicing bowl
aligning the red dot on the drum lid with the
red dot on the juicing bowl. Turn clockwise to
close, aligning the red on the drum lid with the
lockmark.

Step 2 Top-set and base assembly
Tip: For easy assemble hold the drum lid by
grabbing the feeding tube and turn clockwise
as shown in the illustration.
5. Place the bowl on the base, the 3 holes of
bowl must lock into the 3 feet at the base.
7. Place the pulp cup under the pulp spout and
place the juice cup under the juice spout as
shown in the illustration.
Note: Juicer will not operate if parts are not assembled
properly.
6. Open/close mark on the top-set.

How to operate
Step 3 Insert the prepared ingredients one piece at a time
Note:
Fibrous leafy vegetables (celery, kale, etc.):
• Separate each stem. Cut the outer stems that are thick and tough to 10 cm long or less.
• Bundle up the leafy vegetables as inserting into the juicer. Alternate between leafy parts and
stems.
Before extracting, remove hard seeds or pits in ingredients.
When juicing frozen fruits with small seeds, ensure that even the seeds are completely thawed.
Insert the ingredients on piece at a time.
Tip:
After inserting ingredients, use the pusher when it is necessary. Too much use of the pusher may
affect the juice quality.
• Intermittently use the pusher for soft ingredients like tomatoes. Constant use of pusher for soft
ingredients may affect the juice quality.
Step 4 Use the smart cap to make mixed juices, stop juice from dripping, or rinse between
different juices.
Tip:
Juicing with the smart cap closed creates various mixed juice cerations when different fruits and
vegetables, milk, banana, beans etc. are selected.
After juicing, close the smart cap to stop the juice from dripping, especially when disassembling
the juicing bowl off the base.
When making different juices quickly rinse away any leftover flavors by running a glass of water in
the juicer with the smart cap closed.
Note:
Leave the smart cap open when juicing ingredients that create excessive foam during extraction,(e.g.
Apples, celery).
Pay close attention when operating with the smart cap closed. Juice may overflow if the juice
collected in the juicing bowl exceeds its capacity marked on the bowl.
Step 5 After juice and pulp are completely extracted, switch the unit OFF.
Note:
If the remaining ingredients in the juicing bowl have not been extracted completely, the drum lid
may not open easily. After each extraction, run the juicer for an additional 30 seconds to let the
juicer extract the remaining pulp.
When the drum lid is stuck, press the REVERSE-OFF-FORWARD button in this order; switching
back and forth 2 or 3 times to dislodge the ingredients.Then place hand on top of the drum lid and
firmly press down while simultaneously turning the drum lid counter clockwise to open.

Tips on operation
Step 1 After preparing the ingredients, plug the power cord into a wall outlet.
Note:
Do not touch the power cord with wet hands, It may cause electrical shock, short-circuit or fire.
Check the safety of the wall outlet.
Step 2 Press the FORWARD button to operate.
Note:
Forward: Pulls down and slowly masticates the ingredients.
Reverse: Pushes the ingredients back up to dislodge them.
If the ingredients become jammed in the screw and the drum lid does not open, press the OFF
button. Then press and hold the REVERSE button until the ingredients become dislodged.
Repeat REVERSE-OFF-FORWARD as often as needed to achieve the desired result.
If the juicer stops during operation:
Switch the button to OFF position then press and hold the REVERSE button until the ingredients
become dislodged.
Repeat REVERSE-OFF-FORWARD as needed.
FORWARD: Pulls down the food.
OFF: Stop the operation.
RESERVE: Pushes the food back up.
Note:
REVERSE: Pushes the ingredients back up to dislodge them.
• The REVERSE button only works while holding down the switch.
If the juicer does not work after these steps,disassemble and clean the parts before operating the
juicer again.
1. Operating the juicer without ingredients can cause damage to the screw.
2. Do not continuously operate the juicer for more than 30 minutes. This can damage the motor
from overheating. After continuous use, let the juicer rest for 30 minutes to cool down before
starting another session.
3. Do not put fingers or other objects into the feeding tube. Always use provided pusher when
needed. If other objects are inserted into the feeding tube during operation, such materials can get
stuck and damage the juicer parts and/or cause injury.
4. Do not use ingredients containing excessive amounts of vegetable oil or animal fat. Do not use
the juicer to extract vegetable oil from ingredients. If vegetable/animal oil gets on the juicing screw,
it may reduce performance and even damage the part.

How to clean the silicone wipers
The silicone wipers are removable for cleaning. After cleaning, place the silicone wipers back onto
the frame as shown in the picture.
5. Do not reinsert the extracted pulp into the juicer. This can cause the juicer to stop or cause the
drum lid not to open.
6. After juicing ingredients with seeds like grapes, thoroughly clean all the crevices on the bottom
of the juicing screw.
Technical specifications:
Voltage: AC 220~240V
Frequency: 50HZ
Power: 240W
Speed: 37RPM
