Gabarron Elnur ECOMBI SSH Series User manual

Please read these instructions carefully before
installing or using this appliance for the first time.
Installation Instructions
ECOMBI SSH
Digital Smart Storage Heaters
ECOSSH158 | ECOSSH208 | ECOSSH308 | ECOSSH408

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 2
• Keep combustible materials, such as furniture, pillows,
bedding, papers, clothes, etc. and curtains at least
a foot (30cm) from the front, sides and rear of the
heater. It is essential that the indicated minimum
clearances are maintained.
• CAUTION — Some parts of this product can become
very hot and cause burns. Particular attention must
be given where children and vulnerable people
are present.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards
involved. Children must not play with the appliance.
Cleaning and user maintenance must not be made
by children without supervision.
• Children aged from 3 years and less than 8 years
shall only switch on/off the appliance provided
that it has been placed or installed in its intended
normal operating position and they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand
the hazards involved. Children aged from 3 years
and less than 8 years shall not plug in, regulate and
clean the appliance or perform user maintenance.
• Children of less than 3 years should be kept away
unless continuously supervised.
• Do not operate any heater after it malfunctions.
Disconnect power at service panel and have heater
inspected by a reputable electrician before reusing.
To disconnect heater, turn controls to off, and turn off
power to heater circuit at main disconnect panel.
• Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause
an electric shock or fire or damage the heater.
• Do not use this heater to dry clothes. To prevent
a possible fire, do not block air intakes or exhaust
in any manner. Air inlets and outlets provide proper
operation of the appliance and prevent its overheating.
DO NOT cover air inlet and outlet grills.
• A heater has hot and arcing or sparking parts inside.
Do not use in areas where gasoline, paint, or
flammable vapours or liquids are used or stored.
The use of these heaters is forbidden in any area
where there is a presence of gases, explosives or
inflammable objects. Never open a charged heater.
• SAVE THESE INSTRUCTIONS. This guide must be
kept and given to any new user. Use this heater
only as described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The warranty of
the heater will not cover any damage caused by non
observance of any of these instructions.
• Do not use this heater outdoors.
1. IMPORTANT INFORMATION
When using electrical appliances, basic precautions should always be followed
to reduce the risk of fire, electric shock, and injury, including the following:
WARNING: In order to avoid overheating do not cover the heater.
!

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 3
2. INSTALLATION INSTRUCTIONS
The symbols used in the text are explained below:
WARNING This indication shows the possibility of causing death from electric shock.
WARNING This indication shows the possibility of causing death or serious injury.
CAUTION This indication shows the possibility of causing injury or damage to
properties only.
Symbol for useful information.
IMPORTANT: Wiring procedures and connections shall
be in accordance with the national and local codes
having jurisdiction.
• The installation must be carried out in accordance
with the current local electrical regulations.
Any installation or reinstallation has to be carried
out by an experienced technician.
• Neither the connecting cable nor any other object
must come into contact with the hot unit.
• Please check that the voltage in the rating label fits
the power supply. The nominal charging period of this
heater is indicated in the rating label. This appliance
must be grounded.
• The appliance should not be installed just below an
electrical socket.
• The appliance must be installed in such a way that
it is impossible for anyone using a bath or shower,
to touch the controls.
• If during any installation the thermal insulation shows
any sign of damage, it must be replaced.
• This heater should be switched off at the circuit
breaker before any repair work is carried out.
This should also be done during times of the year
when heat is not required.
• This appliance is only for permanent connection to
a fix installation. The supply circuit to the heater must
incorporate a double pole isolating switch having a
contact separation of at least 3 mm.
• After installation a survey of the first charging cycle
should be carried out to ensure that the main input
thermostat switches off. Ventilate the room during
this first cycle.
• To maintain stability, it is essential that the heater is
placed on a level surface and care should be taken
to avoid irregular surfaces, such as may result from
carpets or tiled surrounds partially protruding under
the heater.
• The presence of air particles of smoke, dust and
other pollutants could, in time, discolour the walls
and surfaces around the heater.
• Incorrect time settings, erroneous programming of the
reduced rate time and too high temperature settings
may result in a high cost of your electricity bill.
In order to achieve a correct installation of this device,
follow these steps:
1. Choose the right location to install ECOMBI SSH.
The minimum clearances must be respected from
the appliance to any combustible material such as
furniture or curtains. To reduce the risk of fire,
do not store or use gasoline or other flammable
vapours and liquids in the vicinity of the heater.
2. Open the carton at the indicated side and install the
supporting feet without removing the heater.
!
!
!

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 4
Check that all parts have been delivered and are intact.
- 1 Ecombi SSH heater casing.
- 1 bag containing 2 screws and 2 rawl plugs.
- 2 supporting feet.
- This guide.
- 1 superior fixing fitting.
- 2 lateral fixing fitting, already installed on the heater
Turn the carton upside down to allow the heater to stand on its feet and remove the carton.
Check that it is the correct model and that it is in good conditions.
The casing and storage bricks are supplied separately. Check the supplied bricks
packages correspond to the ones indicated on the heater carton.
!
The heater operation is not affected if bricks with minor damage are used.
!
3. Take off the front panel by removing the two screws located at the bottom. Fix the lateral fittings to the
metal structure by using the appropriate screws.
4. Place ECOMBI SSH in your selected installation area. Use the heater fixing holes as a template and mark the
wall through the fixing holes with a pencil. Drill the required holes into the wall. Place the rawl plugs and screws
into the holes before the appliance installation but do not fasten them tightly.
5. Attach ECOMBI SSH to the rawl plugs with the screws. IT MUST NOT BE HUNG ON THE SCREWS; these are used
only to prevent the device from overturning and not to support it. If there is any doubt concerning the wall
strength, consult the corresponding construction specialist. The appliances are heavy; it is the installers
responsibility to ensure the correct installation and wall support of these devices to prevent them from overturning.
6. Connect the heater using the wiring diagram included at the end of this manual. Tighten properly the
connection block screws. Do not leave any remaining wire inside the heater.
Touching live connections can cause serious personal injury.
!

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 5
7. Disconnect the aluminium heating element by removing the FAST-ON terminal on each end of the element.
WARNING: Steel edges can cut.
!
Next unscrew the inner panel and remove it.
CAUTION: In the interior part of this inner panel there is a very delicate thermal insulation
MICROTHERM panel. It has to be handled with extreme care. AVOID TOUCHING IT.
!

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 6
8. Do not disconnect the electrical heating elements. Remove the packing cardboard. Lift and tilt the elements
outwards being careful not to damage the insulation on the bottom of the heater.
9. Place the storage bricks carefully, with the flat side facing the back of the heater.
Arrange two row levels of bricks.
10. Place the heating elements back into their original position. Place the other two rows of storage bricks
with the flat side facing out and always on the heating elements supporting tabs.

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 7
11. Replace the inner front panel. If the bricks have been fitted correctly you will have no difficulty in replacing
the panel. Make sure the bottom edge of the inner panel is inside the front lip of the heater. Please see below:
Right Position Wrong Position
12. Reconnect the two FAST-ON terminals to the aluminium heating element attached to the inner panel
at both ends.
13. When replacing the exterior front panel, align the 2 plastic upper pegs on the heater with the holes in
the exterior panel. Push the top up into place and push the bottom in until it rests on the plastic feet.
14. Replace the front panel with screws.
RELOCATION
If during reinstallation the thermal insulation shows any sign of damage, it must be removed and replaced
by an identical part.
WARNING: Relocation to another location must be carried out by an experienced.
technician.
!
MANUALLY RESET TEMPERATURE LIMITER
This heater employs a manually reset temperature limiter (see LR in the connection diagram).
This safety device operates when high temperatures are reached at the top of the heater. It requires re-setting
manually: Let the heater cool. The cause of overheating should be investigated.
MANUALLY RESET TEMPERATURE LIMITER
!
WARNING: Re-setting manually must be carried out only by an experienced technician.
Turn off the heater at the circuit breaker.
Take off the front panel by removing the two screws located at the bottom. Find the limiter LR in the connection
diagram and push the small pin until a click is heard.

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 8
3. OPERATING INSTRUCTIONS
On/Off
Once the heater is connected to a mains supply you can turn the heater ON by
switching the main ON/OFF switch positioned on the rear of the right hand side
of the heater as shown above.
Backlight
Press any button and the display will illuminate with a soft white colour.
The display back light will turn off after time if no buttons are pressed.
Programming Buttons will only respond when the back light is on.
Keyboard Lock
During any operation mode, it is possible to lock the keyboard.
You can do this by holding both the and buttons simultaneously
until the padlock indicator is displayed on the screen.
G-Control Hub
connection indicator
Daily Programming:
Temperature level for
each time interval (1h)
of the day
Button “+” Press
the key to increase
different values or
scroll through menus
Button “-” Press the
key to decrease
different values or
scroll through menus
“Config/Prog” Button
Press the button to access
the advanced configuration
and exit menu items
Open Windows
detection indicator
Keyboard lock indicator
Programme mode
indicator
“OK” Button
Press the button to check and set the time. Press
the button to confirm values in the different menus
Current charge level
Current set point in
Programme Mode
To unlock the keyboard, press the and simultaneously until the
padlock indicator disappears from the screen.
3.1 General information
Connection/Disconnection
Power switch. All models are equipped with a switch on the
back side panel. It is used to Turn On and Turn Off the ECOMBI SSH.
Keyboard:
CAUTION: DO NOT USE THIS HEATER TO DRY CLOTHES.
Do not cover this heater at any time.
!

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 9
3.2. Quick Start
Ecombi SSH quick start only requires 2 easy settings:
TIME AND CHARGE SETTING
Charging Hours: By default, Ecombi SSH off-
peak period is set from 00:00 to 07:00. In case
off-peak period of your electricity tariff does
not match with this setting, you can easily
modify it:
- With backlight on, keep pressed button
for 5 seconds until the message “Func.”
is displayed blinking to access the general
configuration menu.
- Press button until the text “PArA” is
displayed blinking.
- Press now button to access general
parameters menu (PArA).
- Parameter UP01 is displayed. Charging
period used by Ecombi SSH goes from
UP02 parameter (Charging period
start. By default 00:00) to UP03 parameter
(Charging period end. By default 07:00).
- Use and buttons to move forward
and backward until the parameter to be
modified is displayed. Press button to
access the parameter value.
- Use and buttons to modify the time
of the start / end of the charging period.
Use button to confirm the desired value.
- Press to exit main menu.
Time setting: Ecombi SSH time setting is set
on factory by default. Check the time setting in
your device. In case time setting is wrong, you
can easily modify it following next steps.
MODIFY HOUR
CONFIRM AND ADVANCE
TO MINUTE SETTINGS
MODIFY HOUR
CONFIRM AND ADVANCE
TO WEEKLY DAY SETTINGS
MODIFY DAY OF THE WEEK
DAY 1 = MONDAY
DAY 7 = SUNDAY
CONFIRM AND EXIT
C

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 10
OPERATION MODE SETTING & TEMPERATURE SET POINT
1. With backlight on, keep pressed button for
5 seconds until the message “Func.” is displayed
blinking to access the general configuration menu.
2. Press button when the message “Func.”
is displayed to access operation mode menu.
3. Press or buttons to select manual
(24hours Set-point Temperature) operation mode.
Press button to confirm.
Current charge level and set-point temperature
are displayed in this mode.
4. Once selected, adjust the desired set-point
temperature using and . Automatically,
Ecombi SSH will manage and adjust daily its
charging level to provide the selected temperature
with minimal cost.
Frost Protection
Mode
Manual
Mode
Programme
Mode

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 11
3.3. DEFAULT SETTINGS & UNIT RESET
To reset the unit to factory default settings, hold and simultaneously until the message “SrES” is displayed.
Confirm the reset with
Default Values
Sun: Comfort temperature 21ºC
Moon: Economic temperature 18ºC
Frost: protection temperature 3ºC
UP01: Initial % of storage charge 100%
UP02: Starting time off peak period 1 00:00
UP03: Ending time off peak period 1 07:00
UP04: Starting time off peak period 2 00:00
UP05: Ending time off peak period 2 00:00
UP06: Charging days of the week Default -> Charging 7 days of the week.
UP07: Ambient sensor Offset 0ºC
UP08: Max. Balancing element – working period 16 hours
UP09: Overtemperature protection 2ºC
UP10: Temperature Unit ºC
UP11: Open Window Detection Function Off
UP12: Adaptive Start Control Off
UP13: Kind of temperature control PID
Default Programming Comfort: 07:00 to 22:00.
Eco: 00:00 to 07:00 & 22:00 to 00:00.
Incorrect time settings, erroneous programming of the reduced rate time and too high
temperature settings may result in a high cost of your electricity bill.
!
5s

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 12
4. REMOTE OPERATION USING THE WIFI G-CONTROL HUB
It is possible to control the full operation of the Ecombi
SSH remotely with the Elnur-Gabarron app or web-app.
The unit must be connected to a G-Control Hub
connected to the Internet to use this feature.
(Wifi is needed for this feature)
4.1 To associate the unit to the G-Control Hub, the
discovery mode must be activated. Press the
associate button at the back of the hub for 3
seconds. An orange flashing light every second
indicates association mode.
4.2 With the hub in association mode, press on the
storage heater for 3 seconds until is shown.
You can control and adjust the programming and
temperatures on the Ecombi SSH via the
Gabarron-Elnur app.
4.3 To disassociate the unit, a reset of the unit must
be realized. See “Default settings and unit reset”.
When the storage heater is reset, it will remove
the programming and revert back to the default
settings and also disassociate from the RF network
and G-Control Hub.

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 13
5. TROUBLESHOOTING
ECOMBI SSH does not heat. Please check it is connected and switched on.
ECOMBI SSH does not reach set up
temperature
Make sure that adequate temperature is selected.
Make sure the storage heater is sized correctly
for heat loss.
“Err” Message in display Please contact technician.
Keyboard does not respond If the symbol is displayed, the keyboard is
locked. Hold “+” and “-” buttons simultaneously
for 3 seconds to unlock the keyboard.
(See Keyboard Lock Section).
ECOMBI SSH does not communicate
with the G Control Hub.
Check the unit is associated, the symbol
must be shown on the display LCD.
For distances greater than 30 metros and 2-3
walls, associate first the closest units. Each unit
can work as signal extender.
If symbol is flashing, check the G Control
Hub connexion to the network, and if any other
device in the RF Net that could be working as
signal extender has been removed.

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 14
6. CLEANING MAINTENANCE
INSTRUCTIONS
7. MAIN COMPONENTS LIST
Before cleaning, make sure the power has been
turned off at the circuit breaker panel and that
the heating element of the heater is cool.
Occasionally, clean dust with a dry, soft cloth.
Do not use any solvent or abrasive product
for cleaning.
When the Heating season is finished, please
disconnect the device by turning off the power
switch located at the right side on the back
of the unit or at the circuit breaker.
Any other servicing should be performed by
an authorised technician.
ECOMBI SSH has been manufactured
under a fully assured quality system
and using environmentally friendly
processes. Once its useful life is
finished please take the device
to a recycling depot so that its
components can be recycled in
an appropriate way.
Storage Heating Element
(All except ECOSSH158) Ref. 15190091
Storage Heating Element (ECOSSH158) Ref. 15190875
450W Balancing Heating Element
(ECOSSHI58) Ref. 15190105
600W Balancing Heating Element
(ECOSSH208) Ref. 15190110
900W Balancing Heating Element
(ECOSSH308) Ref. 15190120
1200W Balancing Heating Element
(ECOSSH408) Ref. 15190130
Switch Ref. 46100530
Power PCB & Fixing Bracket Ref. 15191890
Keyboard PCB ECO SSH Ref. 15191873
Core Sensor Ref. 15192140
Room Sensor Ref. 46102195
110ºC Balancing Element Limiter Ref. 15190725
135ºC Cut Out Manually Limiter Ref. 10190460
i
LE BALANCING ELEMENT LIMITER
LR CUT OUT MANUALLY LIMITER
8. CONNECTION DIAGRAMS

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 15
LE BALANCING ELEMENT LIMITER
LR CUT OUT MANUALLY LIMITER
LE BALANCING ELEMENT LIMITER
LR CUT OUT MANUALLY LIMITER

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 16
LE BALANCING ELEMENT LIMITER
LR CUT OUT MANUALLY LIMITER
9. TECHNICAL FEATURES
Model ECOSSH158 ECOSSH208 ECOSSH308 ECOSSH408
Connection 220 - 240V ~ 220 - 240V ~ 220 - 240V ~ 220 - 240V ~
Balancing Element Output 450/490W 600/653W 900/980W 1200/1307W
Storage Heater Output 975/1062W 1300/1415W 1950/2123W 2600/2831W
Charge Period 7.6 – 7h 7.6 – 7h 7.6 – 7h 7.6 – 7h
Charging 7.4 kWh 9.9 kWh 14.9 kWh 19.8 kWh
Insulation Class I Class I Class I Class I
Length 55cm 66cm 89cm 111cm
Height 73cm 73cm 73cm 73cm
Depth 18cm 18cm 18cm 18cm
Weight 59kg 77kg 112kg 147kg
Num. Of Bricks 7,5kg - 8 12 16
Num. Of Bricks 11,5kg 4 - - -
Brick Type Package 11072 11016 11016 11016
Storage heater elements and balancing heating element will never operate at the same time.
!

Elnur powered by Gabarrón | ECOMBI SSH | Installation Guide 17
PRODUCT FICHE
Value
Item Symbol ECOSSH 158 ECOSSH 208 ECOSSH 308 ECOSSH 408 Unit
Heat Output
Nominal heat output Pnom 0.55 0.75 1.125 1.5 kW
Minimum heat output Pmin N.A. N.A. N.A. N.A. kW
Maximum continuous heat output Pmax, c 0.55 0.75 1.125 1.5 kW
Auxiliary electricity consumption
At nominal heat output el max 0.000 0.000 0.000 0.000 kW
At minimum heat output el min 0.000 0.000 0.000 0.000 kW
In standby mode el sb <0.0005 <0.0005 <0.0005 <0.0005 kW
MODEL(S): GABARRON ECOSSH158, ECOSSH208, ECOSSH308, ECOSSH408
ErP
Item Value. All models
Type of heat input
Electronic heat charge control with room and/or outdoor temperature feedback Yes
Type of heat output / room temperature control
Electronic room temperature control plus week timer Yes
Other control options
Room temperature control, with open window detection Yes
With distance control option Yes
With adaptive start control Yes
Contact details ELNUR, UK
Unit 1, Brown Street North, Leigh, Wigan, WN7 1BU
Commission Regulation (UE) 2015/1188 of 28 April 2015.
Ecodesign requirements for electric storage local
space heaters.

Supplier:
ELNUR UK Ltd.
Unit 1, Brown Street North
Leigh, Lancashire, WN7 1BU.
[phone]
[e-mail]
15190020 R2 | EN
Manufactured by:
ELNUR S.A.
Travesía de Villa Esther, 11 28110, Algete
Madrid Telephone: [phone]
© All rights reserved. As part of the continuous improvement
policy, ELNUR, S.A. reserves the right to alter or modify any
specifications without notice.
The symbol on the product or in its packaging indicates that this
product may not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this
product, please contact your local council office, your household
waste disposal service or the shop where you purchased the
product. These instructions are only valid in the EU member states.
www.elnur.co.uk
