Gaggenau VP 230 620 User manual

*DJJHQDX
Installation instructions2
Notice de montage10
Instrucciones de instalación18
VP 230 620
Teppan Yaki

2
en-us
Table of Contents
Installation instructions
9Safety Definitions 2
IMPORTANT SAFETY INSTRUCTIONS 3
Appliance Handling Safety 3
Safety Codes and Standards 3
Electric Safety 3
Related Equipment Safety 4
Proposition 65 Warning 5
Before you begin 6
Tools and parts needed 6
Parts included 6
Installation accessories 6
Cabinet Requirements 6
Countertop Requirements 6
Installation Procedure 7
Prepare Installation Space 7
Install Appliance 7
Connect Electrical Supply 8
Check the Installation 8
Removing appliance 9
Customer Service 9
9Safety Definitions
SafetyDefinitions 9WARNING
This indicates that death or serious injuries may
occur as a result of non-observance of this
warning.
9CAUTION
This indicates that minor or moderate injuries may
occur as a result of non-observance of this
warning.
NOTICE
This indicates that damage to the appliance or property
may occur as a result of non-compliance with this
advisory.
Note: This alerts you to important information and/or
tips.

3
9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READANDSAVETHESEINSTRUCTIONS INSTALLER: LEAVE THESE
INSTRUCTIONS WITH THE APPLIANCE
AFTER INSTALLATION IS COMPLETE.
IMPORTANT: SAVE THESE
INSTRUCTIONS FOR THE LOCAL
ELECTRICAL INSPECTOR'S USE.
9WARNING
If the information in this manual is
not followed exactly, fire or shock
may result causing property damage
or personal injury.
9WARNING
Do not repair, replace or remove any
part of the appliance unless
specifically recommended in the
manuals. Improper installation,
service or maintenance can cause
injury or property damage. Refer to
this manual for guidance. All other
servicing should be done by an
authorized servicer.
Appliance Handling Safety
Safety Codes and Standards
This appliance complies with one or more
of the following Standards:
▯UL 858, The Standard for the Safety of
Household Electric Ranges
▯UL 923, The Standard for the Safety of
Microwave Cooking Appliances
▯UL 507, The Standard for the Safety of
Electric Fans
▯ANSI Z21.1, The American National
Standard for Household Cooking Gas
Appliances
▯CAN/CSA-C22.2 No. 113 Fans and
Ventilators
▯CAN/CSA-C22.2 No. 61 Household
Cooking Ranges
▯CAN/CSA-E60335-1
▯CAN/CSA-E60335-2-6 Household and
similar electrical appliances - Safety
It is the responsibility of the owner and
the installer to determine if additional
requirements and/or standards apply to
specific installations.
Electric Safety
9WARNING
Before you plug in an electrical cord
or turn on power supply, make sure
all controls are in the OFF position.
If required by the National Electrical
Code (or Canadian Electrical Code), this
appliance must be installed on a separate
branch circuit.
Hidden surfaces may have sharp
edges. Use caution when
reaching behind or under
appliance.

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
4
9WARNING
Risk of electrical shock or fire!
Frame grounded to neutral through a
ground strap. Grounding through the
neutral conductor is prohibited for
new branch-circuit installations
(1996 NEC), mobile homes, and
recreational vehicles, or in an area
where local codes prohibit
grounding through the neutral
conductor.
For installations where grounding
through the neutral conductor is
prohibited,
1. disconnect the link from the
neutral,
2. use grounding terminal or lead to
ground unit,
3. connect neutral terminal to lead
branch circuit neutral in usual
manner (when the appliance is to
be connected by means of a cord
kit, use a UL listed 4-conductor
cord for this purpose).
Be sure your appliance is properly
installed and grounded by a qualified
technician. Installation, electrical
connections and grounding must comply
with all applicable codes.
Before installing, turn power OFF at the
service panel. Lock service panel to
prevent power from being turned ON
accidentally.
Installer – show the owner the location of
the circuit breaker or fuse. Mark it for
easy reference.
Related Equipment Safety
The appliance should only be used if
installed by a qualified technician in
accordance with these installation
instructions. The manufacturer is not
responsible for any damage resulting
from incorrect installation.
Remove all tape and packaging before
using the appliance. Destroy the
packaging after unpacking the appliance.
Never allow children to play with
packaging material.
Never modify or alter the construction of
the appliance. For example, do not
remove leveling legs, panels, wire covers
or anti-tip brackets/screws.
To eliminate the risk of burns or fire by
reaching over heated surface units,
cabinet storage space located above the
surface units should be avoided. If
cabinet storage is to be provided, the risk
can be reduced by installing a hood that
projects horizontally a minimum of 5
inches (127 mm) beyond the bottom of
the cabinet.
Verify that cabinets above the cooktop are
a maximum of 13" (330 mm) deep.
When installing a cooktop over a single
oven, be sure to follow both the oven’s
and cooktop’s installation manuals.

5
9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
Ventilation Recommendations
We strongly recommend the installation
of a ventilation hood above this
appliance. The hood must be installed
according to instructions furnished with
the hood.
9CAUTION
The appliance should not be
installed with a ventilation system
that blows air downward toward the
burners. This type of ventilation
system may cause ignition and
combustion problems with the gas
cooking appliance resulting in
personal injury or unintended
operation.
Proposition 65 Warning:
This product may contain a chemical
known to the State of California, which
can cause cancer or reproductive harm.
Therefore, the packaging of your product
may bear the following label as required
by California:

&DQFHUDQG5HSURGXFWLYH+DUPZZZ3:DUQLQJVFDJRY
67$7(2)&$/,)251,$352326,7,21:$51,1*
:$51,1*
