Gama Sonic 94BM50010 User manual

US patents
# 7172307, 9458970
VICTORIAN BULB MORPH
SOLAR LIGHT – WALL MOUNT
Part # 94BM50010

Thank you for your purchase! GAMA SONIC® solar charged lights are brighter and last
all night with a typical solar charge. Unique design, superior light output and numerous
installation options confirm the outstanding value of our product. GAMA SONIC® has been
recognized as a worldwide leader in the lighting industry for over 20 years.
Please read the instruction manual carefully to obtain the best results from your purchase.
Visit our website or download the latest version of your instruction manual:
www.gamasonic.com or www.gamasonic.com/user-guides
Technical Assistance / Warranty Claims / Replacement Parts
Toll-Free number: [phone] (only within the US) or www.gamasonic.com
For optimum light duration throughout
the night, it is very important to mount
your solar lamp in a spot
where it will receive
the maximum amount
of direct sunlight
throughout the day.
NOTE: For best
results, the solar
light must be
charged in the
“High or Low”
position for at
least 2 days of full
direct sunlight.
Gama Sonic’s NEW
Morph Solar Panel
Technology is a
groundbreaking
process in the way we capture more power
from the sun. Our Morph technology still
uses monocrystalline solar panels. However,
instead of the small sized solar panels, our
new technology allows the solar panels to
MORPH into the light fixture.
Gama Sonic's New Morph
Technology
What’s In The Box
Solar Lamp Location
page 2
A B
C
BULB
SCREWS &
ANCHORS

1. Remove the top (A) from the
fixture (B) by removing the two
phillips head screws.
2. Install the GS Solar LED Bulb into
the top.
3. Move the operation switch to
your desired setting.
4. Attach the top (A) back to the
fixture (B) and secure using
the two phillips head screws
removed earlier.
5. Place the wall bracket (C) in the
desired mounting location.
NOTE: Make sure the long arm of the
bracket is on top
6. Using the bracket (C) as a
template, mark where the two
holes will need to be.
7. Using an electric drill, make two
holes no larger than the size of
the included anchors.
8. Place the anchors in the holes
drilled.
9. Align the wall bracket (C) with
the holes and secure it using
the provided screws.
10. Attach the top (A) to the wall
bracket (C) by screwing it in
clockwise.
1. Insert the GS Solar LED Bulb into the top (A) by twisting clockwise.
2. Move the operation switch to the Low or High position according to
your preferences:
Low = Softer light and longer duration
High = Brighter light output
3. The solar Lamp will automatically operate at dusk
Assembly Instructions Operation Instructions
Replacement Batteries and Bulbs are available at
www.gamasonic.com or via our Toll Free number: [phone]
Your Lamp can use the following bulbs:
C37WW10W – included bulb with Warm White LEDs (2700K)
C37BW10W – bulb with Bright White LEDs (6000K)
F30WW05W – Flame bulb with simulated flame LEDs
T45WW10W – Edison LED Bulb with Warm White
LEDs (2700k)
Your lamp uses two of the following battery:
GS32V30
Replacement Parts
page 3

Replacing the battery
page 4
Maintenance
Batteries are available for purchase at www.gamasonic.com
Troubleshooting
Clean the solar panels regularly with a damp towel to guarantee optimum performance. Do not use any type of
solvent for cleaning and be careful not to put too much pressure on the solar panels while cleaning.
WARNING: Do not dispose of Li-Ion batteries in the regular trash, municipal waste stream or by re as batteries may
leak or explode. Do not open, short circuit, or mutilate batteries as injury may occur. Preserve our environment by
recycling Li-Ion batteries or disposing of them in accordance with local, State, and federal regulations. Do not mix old
and new batteries.
If your solar light does not come on as expected despite observance of all the instructions, please try the
following steps:
1. Make sure that the solar lamp is not being aected by any other light source.
2. Ensure the solar lamp is not positioned in the shade during the day.
3. Check that the batteries are installed correctly.
NOTE: The performance of the solar lamp will vary with the time of year. It will last longer when it has had a full
day in the sun rather than a day in overcast weather.
WARNING: Please keep out of reach of children. Do not dispose of the Li-Ion battery in the regular trash,
municipal waste stream or by fire as batteries may leak or explode. Do not open, short circuit, or mutilate
batteries as injury may occur. Preserve our environment by recycling Li-Ion batteries or disposing of them in
accordance with local, State and federal regulations. Do not mix old and new batteries.
WINTERTIME TIPS: For optimal performance, be sure to remove any snow or debris accumulation from solar
panel(s). A solar panel free of debris will charge the batteries much more eciently.
1. Remove the lamp from the wall bracket (C) by twisting it counterclockwise.
2. Remove the top (A) from the fixture (B) by removing the two phillips head screws.
3. Switch the lamp OFF and remove the bulb.
4. Remove the battery compartment cover screw and the cover.
5. Remove and unclip the battery.
6. Make sure the new battery is a high quality Li-Ion 3.2V/3000mAh battery with a matching connector (item
GS32V30).
7. Clip in the new battery and install it in the compartment.
8. Replace the battery compartment cover and secure with the screw.
9. Repeat steps 4-8 for the other battery compartment.
10. Install the bulb and switch the lamp on to your desired setting.
11. Attach the top (A) to the fixture (B) and secure with the two phillips head screws.
12. Attach the lamp to the wall bracket (C) by twisting clockwise.
