Gama Sonic ASPEN GS-8 User manual

ASPEN SOLAR
POST LAMP
Model: GS-8
Version 1.2
US Patent #9458970
Instruction Manual

For optimum light duration throughout
the night, it is very important to mount
your solar lamp post in a spot where it
will receive the maximum amount of
direct sunlight throughout the day.
page 2
Thank you for your purchase. GAMA SONIC® solar charged lights are brighter and last all night with a full day solar charge.
Unique designs, superior light output, and numerous installation options confirm the outstanding value of our product.
For technical assistance and more information call our Toll-Free number:
800-835-4113 (only within the US)
Or
visit our website or download the latest version of your instruction manual:
www.gamasonic.com Or www.gamasonic.com/user-guides
Please read the instruction manual carefully to obtain the best results from your purchase.
What's inside
Top
GS LED Bulb
Fixture
Note: The solar light
must be charged for
two sunny days in
the “ON” position for
best results.
WARNING: GAMA SONIC® Light
bulbs are built and designed for
Gama Sonic products only. They
are not designed to be used in
other electrical sockets.
For the same reason, regular AC
and/or Low Voltage bulbs cannot
be used in Gama Sonic products.
For optimum light duration throughout
the night, it is very important to mount
your solar lamp post in a spot where it
will receive the maximum amount of
direct sunlight throughout the day.
Note: The solar light
must be charged for
two sunny days in
the “ON” position for
WARNING: GAMA SONIC® Light
bulbs are built and designed for
Gama Sonic products only. They
are not designed to be used in
other electrical sockets.
For the same reason, regular AC
and/or Low Voltage bulbs cannot
be used in Gama Sonic products.
Top
GS LED Bulb
Fixture

page 3
Assembly Instructions
NOTE: The following steps are for reference only. Consult your local
hardware store for the best installation method for your surface.
1. Using a screwdriver remove
the four screws attaching
the top and remove the top
(Fig. 1).
2. Screw in provided A-60
Gama Sonic bulb while
gripping the base only
(Fig. 2).
3. Reverse Step 1 and re-attach
top and screws accordingly.
NOTE: When installing the GS
Solar LED Bulb, hold it from its
silver base not by the glass .
Fig. 1
Fig. 2
1. Place the assembled light fixture
on top of your existing 3” post and
hand tighten the 3 provided screws
to secure the lamp (Fig. 3).
Note: Installing the light on or near a
wall may limit the functionality of the
solar panel for sun exposure. Make
sure the lamp is mounted so direct sun
exposure is available.
Installation Instructions
Fig. 3
Operation Instructions
1. Turn the external operation
switch to the Low or High
position (Fig. 4).
2. according to your preferences:
Low: For softer light and
longer duration.
High: For brighter light
output.
3. The solar lamp will
automatically operate at dusk.
NOTE:
The solar light must be
charged for two sunny days in the
“ON” position for best results.
Fig. 4
: For brighter light
automatically operate at dusk.
The solar light must be
charged for two sunny days in the
“ON” position for best results.

page 4
Replacing the Batteries and Bulbs
Replacement batteries are available at
www.gamasonic.com or via our Toll free number: [phone]
Replacing the Batteries
After several years of use, the battery may need replacing.
1. Make sure the ON/OFF switch is in the “OFF” position (0).
2. Unscrew the four screws on the underside of the lamp top
to detach it from the lamp.
3. Unscrew the battery compartment’s screws located on the
silver reflector and remove the compartment doors.
4. Unclip the battery connectors and remove the old
batteries. Make sure the new batteries are high quality –
Li-Ion Battery packs (3.2 Volt / 1500 mAh) with matching
connector (Fig. 5).
5. Install the new batteries into the battery compartment.
6. Reassemble the unit by reversing the above procedure.
Replacing the GS Solar LED Light Bulb
The GS Solar LED Light Bulb is designed to last up to 10
years, however if it is not working, or if you want to use a
different color temperature bulb, you can replace it with
a new GAMA SONIC Solar LED Bulb.
1. Make sure the operation switch is in the OFF (“O”)
position.
2. Detach the upper part of the lamp as shown in (Fig. 1).
3. Remove the existing A-60 GS Solar LED Light Bulb by
turning it counterclockwise while gripping the base
only see (Fig. 2).
4. Install the new GS Solar LED Light Bulb by turning into
the bulb socket clockwise while gripping the base only
see (Fig. 2).
5. Reassemble the unit by reversing the above procedure
Maintenance
Clean the solar module regularly with a damp towel to guarantee optimum
performance of the solar panel. Do not use any type of solvent for cleaning and
be careful not to put too much pressure on the module while cleaning.
Trouble Shooting
If your solar charged light does not come on at dusk despite
observance of all the instructions, please try the following steps:
1. Make sure that the solar light is not being affected by any other light source.
2. Ensure the solar light is not positioned in the shade during the day.
3. Make sure the switch in the lamp head is in the” ON” position.
4. Check that the batteries are installed correctly.
NOTE: The performance of the solar light will vary with the time of year. It will
deliver longer duration when it has had a full day in the sun rather than a day in
overcast weather.
WINTERTIME TIPS: For optimal performance, be sure
to remove any snow or debris accumulation from solar
panel(s). A solar panel free of debris will charge the
batteries much more efficiently.
WARNING: Please keep out of reach of children.
WARNING: Do not dispose of Li-Ion battery
in the regular trash, municipal waste stream
or by fire as batteries may leak or explode.
Do not open, short circuit, or mutilate
batteries as injury may occur. Preserve our
environment by recycling Li-Ion batteries or
disposing of them in accordance with local,
State and federal regulations. Do not mix old
and new batteries.
connector (Fig. 5).
5. Install the new batteries into the battery compartment.
6. Reassemble the unit by reversing the above procedure.
Fig. 5
