Gama Sonic GS-105B-FPW User manual

BAYTOWN II BULB
SOLAR LAMP
Model: GS-105B-FPW
Version 1.2
US Patent #9458970 #7172307
Instruction Manual
Post/3"Fitter Mount
Pier Mount
Wall Mount
Note: If you're
not going to use
the 3” fitter base,
disassemble the
nut and part (H)
from part (E).
H
E
Step 1
Step 2
For optimum light duration throughout the night, it is very important to place your solar lamp in a spot
where it will receive the maximum amount of direct sunlight throughout the day.
page 2
Thank you for your purchase. GAMA SONIC® solar charged lights are brighter and last all night with a full day solar charge.
Unique designs, superior light output, and numerous installation options confirm the outstanding value of our product.
For technical assistance and more information call our Toll-Free number:
800-835-4113 (only within the US)
Or
visit our website or download the latest version of your instruction manual:
www.gamasonic.com Or www.gamasonic.com/user-guides
Please read the instruction manual carefully to obtain the best results from your purchase.
What's inside
A. Finial
B. Top
D. Fixture
E. 3" Fitter
F. Wall bracket
G. Pier Mount
I. GS LED Bulb
H. Base
C. Window
Frame
Open your package and remove the contents. Check to
make sure all pieces are present and accounted for.
• You will need to follow these two steps to
disassemble the unit completely
Note: For best results, the solar lamp post must be charged
for two sunny days on the “ON” position.
WARNING: GAMA SONIC® Light bulbs are built and
designed for Gama Sonic products only. They are not
designed to be used in other electrical sockets.
For the same reason, regular AC and/or Low Voltage
bulbs cannot be used in Gama Sonic products.
page 3
1. Attach the fixture (D) to the base (H) with the
four supplied screws, as shown on the right.
2. Install the lamp onto your existing 3” post, using
the screws provided
After assembling your specific bracket
here are the steps to finish assembling
your unit, this step applies to all three
brackets:
1. Use a drill to make two holes in the desired
surface.
2. Place the screw anchors into the holes, place
the lamp in line with the holes and secure
with the provided screws.
3. Attach the base (H) to the Pier Mount (G)
with the nut (Fig.1).
4. Attach the fixture (D) to the base (H) with
the four supplied screws, as shown (Fig.2).
1. Use a drill to make two holes in the desired
surface.
2. Place the screw anchors into the holes, place
the lamp in line with the holes and secure
with the provided screws.
3. Attach the base (H) to the Wall bracket (F)
with the nut (Fig.3).
4. Attach the fixture (D) to the base (H) with
the four supplied screws, as shown (Fig.4).
Note: If you are replacing an existing gas/electric
post light, you must consult a certified technician
to disconnect them before installation. 1.Place the
lens and cone (C)
in the body (D).
2.Screw the GS
LED lightbulb into
the socket. Turn on
switch to desired
setting.
3.Attach top
(B) to the body
(D) with the two
supplied screw
caps.
4.Screw the finial
(A) on top
1. Remove the Top (B) by unscrewing the 2 screw caps.
Screw the GS LED lightbulb into the socket. Turn on switch
to desired setting high or low (for longer duration). The
Solar Lamp will automatically operate at dusk.
2. Reattach the Top (B) and
secure with the 2 screw caps.
Note:There are specific types of screws for
specific surfaces. If unsure of the appropriate
type of screw to use on your desired surface,
please consult a professional.
Assembly Instructions:
Post/3"Fitter Mount
Pier/ Flat base
Wall Mount
Fig. 2
Operation
Instructions
Operation Switch
Fig. 3
Fig. 4
Fig. 1
page 4
Replacing the Batteries
Replacement batteries are available
at www.gamasonic.com or via our Toll free number: +1-800-835-4113
After several years of use, the battery may need replacing.
1. Unscrew the two screw caps and detach the top (B). Make sure the ON/OFF switch is in the
OFF(O) position.
2. Unscrew the battery compartment (Fig.5) screw located on the silver reflector and remove the
compartment cover.
3. Unclip the connector and remove the old battery. Make sure the new battery is a Gama Sonic -
3.2V/1,500mAh, Li-ion Rechargeable battery with connector.
4. Clip on new battery and install into the battery compartment.
Reinstall battery compartment cover.
5. Reattach the top and secure with the 2 screw caps.
WARNING: Do not dispose of Li-Ion batteries in the regular trash,
municipal waste stream or by fire as batteries may leak or explode.
Do not open, short circuit, or mutilate batteries as injury may occur.
Preserve our environment by recycling Li-Ion batteries or disposing
of them in accordance with local, State and federal regulations. Do
not mix old and new batteries.
Maintenance
Clean the solar module regularly with a damp towel to guarantee optimum performance
of the solar panel. Do not use any type of solvent for cleaning and be careful not to put too
much pressure on the module while cleaning.
Trouble Shooting
If your solar charged light does not come on at dusk despite
observance of all the instructions, please try the following steps:
1. Make sure that the solar light is not being affected by any other light source.
2. Ensure the solar light is not positioned in the shade during the day.
3. Make sure the switch in the lamp head is in the” ON” position.
4. Check that the batteries are installed correctly.
NOTE: The performance of the solar light will vary with the time of year. It will deliver
longer duration when it has had a full day in the sun rather than a day in overcast
weather.
WINTERTIME TIPS: For optimal performance, be sure to remove any snow or debris
accumulation from solar panel(s). A solar panel free of debris will charge the batteries
much more efficiently.
WARNING: Please keep out of reach of children.
Fig. 5
