Gamatronic PowerPlus RM 100 User manual

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
17 Hartom St., PO Box 45029, Jerusalem 9777517, Israel
Tel: [phone] Fax: [phone]
Email: [e-mail] Website: www.gamatronic.com
2MUM-PP/28
POWER+
M
MO OD DU UL LA AR R U
UP PS S
S SY YS ST TE EM M
R
RM M1 10 00 0
M MO OD DE EL L,
,
3
3X
X2
20 08 8
V
VA
AC C,
,
1
10 0
K KV
VA A
T TO O 1
10 00 0
K KV
VA A
U
Us se er rG Gu ui id de e
Release 1.3, October 2015

ii POWER+RM100, 3X208 V, User Guide, rel. 1.3
GAMATRONIC ELECTRONIC INDUSTRIES LTD.
Har Hotzvim Industrial Park
17 Hartom St., P.O.B. 45029, Jerusalem 9777517, Israel
Tel: [phone] Fax: [phone]
Email: [email protected].il Website: www.gamatronic.com
The equipment described in this document is not intended to be used in connection with any
application requiring fail-safe performance, unless the application design includes appropriate
redundancy. This exclusion includes, but is not limited to, the direct operation of any life support
system or any other system whose failure could lead to serious injury, death, environmental
damage or mass destruction.
Copyright 2015 by Gamatronic Electronic Industries Ltd. All rights reserved worldwide.
Any representations in this document concerning the performance of Gamatronic's product(s) are for informational purposes only
and are not warranties of future performance, either express or implied. Gamatronic's standard limited Warranty, which
accompanies its sales contract or order confirmation form, is the only warranty offered by Gamatronic Electronic
Industries Ltd. in relation thereto.
Gamatronic Electronic Industries Ltd. ("Gamatronic") warrants the products it manufactures to be free from defect for a period of
one calendar year from the date of invoice, including the date of invoice. Gamatronic's liability is limited to repairing or replacing
any defective parts in the equipment under warranty. Gamatronic reserves the right to determine whether the repair work shall be
performed at Gamatronic's factory, at the customer's premises, or at an alternate site. The customer must obtain authorization from
Gamatronic before returning any parts or equipment to Gamatronic for repair or replacement. Any items returned to Gamatronic
must be sent freight prepaid.
Gamatronic’s liability and warranty to the product are according and subject to the fulfillment and implementation by the customer
of all the terms and instructions in connection with “preventive maintenance” and “service and repair” as further detailed in the user
guide which is attached to the product and forms an integral part of it.”
Gamatronic is not responsible for any damage to the product due to unauthorized repair work, misuse or abuse of the product, or
force majeure. If the product is delivered without batteries, Gamatronic is not responsible for any damage or malfunction due to
incorrect wiring of the batteries.
Gamatronic is not liable for and the Purchaser waives any right of action it has or may have against Gamatronic for any
consequential or special damages arising out of any breach of warranty, and for any damages that the Purchaser may claim for
damage to any property or injury or death to any person arising out of its purchase or the use, operation or maintenance of the
subject product.
This warranty includes parts and labor; however, Gamatronic shall not be responsible for any labor subcontracted or performed by
the Purchaser to prepare the warranted item for return to Gamatronic or Gamatronic's agent.
The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws protecting
intellectual property, as well as any specific agreement protecting Gamatronic's rights in the aforesaid information. Neither this
document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part,
without the express, prior, written permission of Gamatronic. In addition, any use of this document or the information contained
herein for any purposes other than those for which it was disclosed is strictly forbidden.
Gamatronic reserves the right, without prior notice or liability, to make changes in equipment design or specifications.
Information supplied by Gamatronic is believed to be accurate and reliable. However, no responsibility is assumed by Gamatronic
for the use thereof nor for the rights of third parties which may be affected in any way by the use thereof.
This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto
unless specifically undertaken in Gamatronic Electronic Industries Ltd. standard limited Warranty. Information contained herein is
periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify
Gamatronic Electronic Industries Ltd. All specifications are subject to change without prior notice.
The product described in this document may cause interference with radio communications if not
installed and used according to the user guide and/or installation guide. Be aware that the
product is intended for use in a commercial or industrial setting. Operation of the product in a
residential area may cause harmful interference, in which case the user will be required to correct
the interference at his own expense.

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER+RM100, 3X208 V, User Guide, rel. 1.3 iii
TABLE OF CONTENTS
1. MOVING THE POWER+RM100 (AND ITS BATTERY CABINET)..............................................................1
2. IMPORTANT SAFETY INSTRUCTIONS..................................................................................................2
2.1 Do’s......................................................................................................................................2
2.2 Don’ts...................................................................................................................................3
3. INTRODUCTION TO THE POWERPLUS RM100 ...................................................................................5
3.1 POWER+features: ..............................................................................................................5
3.2 Ac and dc fuses....................................................................................................................7
3.3 Ac input/output main terminals.............................................................................................7
3.4 System controller .................................................................................................................7
3.5 UPS module (10 kVA / 8 kW)...............................................................................................7
3.6 Static Switch (ST/SW) module.............................................................................................7
4. BATTERY........................................................................................................................................8
4.1 Connecting the battery cabinet to the UPS........................................................................10
4.2 Additional considerations...................................................................................................10
4.3 Battery replacement instructions........................................................................................14
5. OPERATING MODES.......................................................................................................................15
5.1 Normal operation................................................................................................................15
5.2 Battery operation................................................................................................................15
5.3 Bypass operation ...............................................................................................................15
5.4 Maintenance bypass mode................................................................................................16
6. USER INTERFACE ..........................................................................................................................17
6.1 Control Panel .....................................................................................................................17
6.2 UPS Module Panel.............................................................................................................17
6.3 Static Switch Panel ............................................................................................................18
6.4 POWER+control screen....................................................................................................19
6.4.1 Load-level bar graph.............................................................................................19
6.5 Navigation and Operation Keypad.....................................................................................20
6.6 Status Indicators ................................................................................................................21
6.7 Operation Buttons..............................................................................................................22
6.8 Network Access Indicator ..................................................................................................22
6.9 POWER+Operation Modes...............................................................................................23
6.9.1 Normal Operation..................................................................................................23
6.9.2 Battery Operation..................................................................................................23
6.9.3 Bypass Operation (Automatic)..............................................................................24
6.9.4 Bypass Operation (Manual)..................................................................................24
6.9.5 Emergency Power off – EPO (Manual).................................................................24
7. SYSTEM INSTALLATION..................................................................................................................25
7.1 Cabling...............................................................................................................................25
7.2 The Power+ always requires a neutral line........................................................................29
7.2.1 A 4-pole switch might disconnect the neutral line.................................................29
7.3 Ground connections...........................................................................................................34
7.4 Over-Current Protection.....................................................................................................37
7.4.1 Ac wiring................................................................................................................37
7.4.2 Dc wiring ...............................................................................................................38
7.5 Fuses .................................................................................................................................39
AC INPUT FUSES .............................................................................................................39
DC DISTRIBUTION FUSES ..............................................................................................40
7.6 Special terminal connections.............................................................................................41
7.6.1 Load on bypass alarm...........................................................................................41

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
iv POWER+RM100, 3X208 V, User Guide, rel. 1.3
7.6.2 Battery trip coil ......................................................................................................41
7.6.3 Emergency power-off............................................................................................42
7.7 Dry Contacts ......................................................................................................................43
7.8 Inspections to be performed prior to installation................................................................44
7.9 Installation Procedure........................................................................................................45
7.10 First-time Startup................................................................................................................46
7.11 Checks to be performed following initial startup................................................................49
7.12 Connection diagram...........................................................................................................50
7.13 Configuration......................................................................................................................51
7.13.1 Check Configured Modules ..................................................................................51
7.13.2 Check Total Ampere-Hours ..................................................................................53
7.13.3 Set Date and Time and Serial Number.................................................................54
7.13.4 Define the IP Address of the Power+....................................................................54
7.14 Testing ...............................................................................................................................56
7.14.1 Blackout Test ........................................................................................................56
7.14.2 Cold Start..............................................................................................................56
7.14.3 Test Under Load...................................................................................................56
7.14.4 Check IP Communication with Controller.............................................................57
7.14.5 Test Wing Option ..................................................................................................58
8. POWER+ROUTINE START-UP.......................................................................................................59
8.1 Start-up after Shutdown.....................................................................................................59
8.2 POWER+Shutdown (Switching to Bypass) ......................................................................61
8.3 POWER+Total Shutdown (No Ac Output)........................................................................62
9. POWER+CONTROL PANEL..........................................................................................................63
9.1 Quick-reference summary of Power+ menu functions ......................................................64
10. POWER+MENU FUNCTIONS IN DETAIL.............................................................................................69
10.1 Main Menu .........................................................................................................................69
10.2 “System” Option.................................................................................................................70
10.3 “UPS module” Option.........................................................................................................74
10.4 “Self-test” Option................................................................................................................76
10.5 “History” (logs) Option........................................................................................................77
10.6 “Battery” Option..................................................................................................................81
10.7 “Alarm” Option....................................................................................................................83
10.8 “Setup – Alarm Set” Option................................................................................................85
10.8.1 Setting Ac Voltage Alarms....................................................................................86
10.8.2 Setting Battery Floating Voltage Alarm.................................................................87
10.8.3 Setting Battery Over/Under Temperature Alarms.................................................89
10.8.4 Setting Battery Integration Alarm..........................................................................90
10.9 “Setup – Module Conf.” Option..........................................................................................91
10.9.1 Setting Number of Phases....................................................................................92
10.9.2 Setting Module/s Frequency.................................................................................92
10.9.3 Setting Module/s Voltage......................................................................................93
10.9.4 Update Voltage/Frequency/Phase........................................................................93
10.9.5 Output Adjustment ................................................................................................94
10.9.6 Setting Frequency Limits ......................................................................................95
10.9.7 Calibrating DC Voltage .........................................................................................95
10.9.8 Calibrating AC Voltage..........................................................................................96
10.10 “Setup – Battery” Option............................................................................................97
10.10.1 Setting Battery Test Voltage.................................................................................98
10.10.2 Setting Battery Test Voltage Alarm.......................................................................99
10.10.3 Setting Battery Current Limit...............................................................................100
10.10.4 Enable/Disable Battery Current Limit..................................................................101
10.10.5 Setting Temperature Compensation...................................................................102
10.10.6 Setting Disable Temperature Compensation......................................................103
10.10.7 Setting Absolute Maximum and Minimum Voltages ...........................................103

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER+RM100, 3X208 V, User Guide, rel. 1.3 v
10.10.8 Activating the Battery Test..................................................................................105
10.10.9 Setting the Automatic Battery Test Period..........................................................105
10.10.10 Setting the Automatic Battery Test Top Time................................................106
10.10.11 Setting the Nth Battery Capacity ....................................................................107
10.10.12 Activating ‘Auto’ Test .....................................................................................108
10.10.13 Enabling/Disabling Options............................................................................108
10.11 Setup – Charge, Time, Site, and Password Options ..............................................110
10.11.1 Setting the Floating Charge................................................................................111
10.11.2 Setting the Time..................................................................................................112
10.11.3 Setting the Site Number......................................................................................112
10.11.4 Changing the Password......................................................................................113
10.12 “Setup – “Service” Option........................................................................................114
10.12.1Setting UPSs.......................................................................................................116
10.12.2 Testing Dry Output Relays..................................................................................116
10.12.3 Configuring the UPS...........................................................................................117
10.12.3.1Number of Redundant UPSs............................................................................................... 117
10.12.3.2Total Number of UPSs.........................................................................................................118
10.12.3.3Total Number of Batteries....................................................................................................118
10.12.3.4Setting up the Static Switch.................................................................................................119
10.12.3.5Setting up the Dry Alarms....................................................................................................120
10.12.3.6Calibrating DC Currents.......................................................................................................121
10.12.3.7Selecting Standalone or Parallel Operation.........................................................................122
10.12.3.8Enabling/Disabling Remote Commands..............................................................................123
10.12.4 Enabling/Disabling Current Sharing....................................................................123
10.12.5 Setting Power Factor Correction.........................................................................124
10.12.6 Setting the SC2012.............................................................................................124
10.13 “Setup – “Silicon” Option.........................................................................................128
10.14 “Static Switch” option...............................................................................................130
10.15 System Controller Setup Verification ......................................................................131
10.15.1 Setup Verification Menu......................................................................................131
10.15.2 Connection Status of UPSs ................................................................................132
10.15.3 On/Off Status of UPSs........................................................................................132
10.15.4 Software and Communication Revision..............................................................132
10.15.5 Network Parameters...........................................................................................133
10.15.6 Dry Input and Output Relay Contact Status........................................................133
10.15.7 Alarms Status......................................................................................................133
10.15.8 Setting the Menu Language................................................................................134
10.15.9 System Parameter Settings................................................................................134
10.15.9.1First General Screen............................................................................................................134
10.15.9.2Second General Screen ......................................................................................................135
10.15.9.3Third General Screen ..........................................................................................................136
10.15.9.4Fourth General Screen........................................................................................................136
11. THE POWER+BUILT-IN WEB INTERFACE.......................................................................................137
11.1 Preliminaries to use of the Web interface........................................................................137
11.2 Main Screen.....................................................................................................................138
11.3 The Main Menu and its options........................................................................................139
11.3.1 “Analysis” main menu option...............................................................................140
11.3.2 “Modules” main menu option..............................................................................140
11.3.3 “STSW” (Static Switch) main menu option .........................................................141
11.3.4 “Log” main menu option......................................................................................142
11.3.5 “Control” main menu option................................................................................144
11.3.6 “SMS” main menu option....................................................................................145
11.3.7 “Configuration” main menu option ......................................................................146
11.3.7.1 Network configuration..........................................................................................................147
11.3.7.2 “Date and time” – setting the calendar and clock ................................................................ 147
11.3.7.3 Set user name and password.............................................................................................. 148
11.3.7.4 SNMP security.....................................................................................................................149
11.3.7.5 SNMP trap targets............................................................................................................... 149
11.3.7.6 Shutdown Targets................................................................................................................150

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
vi POWER+RM100, 3X208 V, User Guide, rel. 1.3
11.3.7.7 Defining email notification targets........................................................................................ 152
11.3.7.8 Defining SMS notifications...................................................................................................153
12. USING THE UPS WITH A GENERATOR ...........................................................................................154
12.1 The Automatic Transfer Switch (ATS).............................................................................154
13. SNMP AGENT.............................................................................................................................156
14. WING:WIRELESS CONTROL (OPTION).........................................................................................157
14.1 Installing the Wing............................................................................................................157
15. RELATED PRODUCTS...................................................................................................................161
15.1 G4.....................................................................................................................................161
15.2 G-Eye...............................................................................................................................162
16. MAINTENANCE BYPASS MODE ......................................................................................................163
16.1 Putting the UPS in maintenance bypass mode ...............................................................163
16.2 Returning the UPS to normal operation...........................................................................164
17. PREVENTIVE MAINTENANCE.........................................................................................................165
18. SERVICE AND REPAIRS ................................................................................................................165
19. TECHNICAL SPECIFICATIONS........................................................................................................166
LIST OF FIGURES
Figure 1: Flanges for securing the RM100 to the ground ....................................................................1
Figure 2: Remove the flanges before moving the RM100 with a forklift..............................................1
Figure 3: Main subassemblies of the RM100.......................................................................................6
Figure 4: Battery cabinet....................................................................................................................11
Figure 5: One battery box....................................................................................................................12
Figure 6: One battery drawer .............................................................................................................12
Figure 7: Battery cabinet wiring..........................................................................................................13
Figure 8: Control panel.......................................................................................................................17
Figure 9: UPS module panel..............................................................................................................17
Figure 10: Static switch panel ............................................................................................................18
Figure 11: POWER+ control screen...................................................................................................19
Figure 12: Navigation and operation keypad .....................................................................................20
Figure 13: Status indicators................................................................................................................21
Figure 14: Network access indicator..................................................................................................22
Figure 15: POWER+ control screen in normal operation...................................................................23
Figure 16: Normal operation indication..............................................................................................23
Figure 17: AC power failure................................................................................................................23
Figure 18: AC power failure indication...............................................................................................24
Figure 19: UPS in Bypass mode........................................................................................................24
Figure 20: Red alarm flashing............................................................................................................24
Figure 21: RM100 3x208 V, rear view................................................................................................26
Figure 22: Cable entry from the top or bottom of UPS cabinet..........................................................27
Figure 23: Connection diagram for 3-3 configuration.........................................................................28
Figure 24: Wrong way to connect UPS with four-pole switch............................................................31
Figure 25: Acceptable connection for grounded generator and 4-pole switch ..................................32

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER+RM100, 3X208 V, User Guide, rel. 1.3 vii
Figure 26: Preferred generator (neutralized) and connection (3-pole) ..............................................33
Figure 27: Ground connections on theUPS cabinet roof ...................................................................34
Figure 28: Crimp -type cable shoes recommended for all ground cables .........................................35
Figure 29: Ground studs on UPS cabinet roof, view from below.......................................................35
Figure 30: Ground studs on inside of batt. cabinet roof.....................................................................36
Figure 31: Ground bus bar at base of UPS rear ................................................................................36
Figure 32: Ac input fuses (100 kVA model)........................................................................................39
Figure 33: Dc distribution fuse assignment (100 kVA).......................................................................40
Figure 34: Special purpose terminal connections..............................................................................41
Figure 35: Dry contacts on rear of controller......................................................................................43
Figure 36: Start-up screen 1...............................................................................................................46
Figure 37: Start-up screen 2...............................................................................................................46
Figure 38: Start-up screen 3...............................................................................................................46
Figure 39: Start-up screen 4...............................................................................................................47
Figure 40: Default screen, with no load, for 3-phase output..............................................................47
Figure 41: Default screen, with no load, for 2-phase output..............................................................47
Figure 42: Normal display, system under load (3-phase output).......................................................47
Figure 43: Normal display, system under load (2-phase output).......................................................47
Figure 44: Connection diagram (for completion by the customer).....................................................50
Figure 45: Main Menu ........................................................................................................................51
Figure 46: Password access..............................................................................................................51
Figure 47: Setup menu.......................................................................................................................51
Figure 48: Service menu....................................................................................................................52
Figure 49: Configure menu.................................................................................................................52
Figure 50: # of UPSs (Total)...............................................................................................................52
Figure 51: # of UPSs (Redundancy)..................................................................................................52
Figure 52: Battery status ....................................................................................................................53
Figure 53: Battery capacity.................................................................................................................53
Figure 54: Set battery capacity...........................................................................................................53
Figure 55: Date and time....................................................................................................................54
Figure 56: Site number.......................................................................................................................54
Figure 57: Network menu...................................................................................................................54
Figure 58: IP Address.........................................................................................................................55
Figure 59: Gateway............................................................................................................................55
Figure 60:Network menu...................................................................................................................55
Figure 61: Main Screen of the Power+ Web interface.......................................................................57
Figure 62: Login screen of built-in web server...................................................................................58
Figure 63: SMS screen.......................................................................................................................58
Figure 64: Main screen after a power shutdown................................................................................59
Figure 65: Main screen after a power shutdown indication................................................................59
Figure 66: Main screen at power-up ..................................................................................................59
Figure 67: Normal operation indication..............................................................................................60
Figure 68: Main screen results...........................................................................................................60
Figure 69: Main screen – switching to bypass...................................................................................61
Figure 70: Bypass indication..............................................................................................................61
Figure 71: Main screen – total shutdown...........................................................................................62
Figure 72: UPS off indication..............................................................................................................62
Figure 73: Control panel.....................................................................................................................63
Figure 74: Main menu ........................................................................................................................64
Figure 75: System menu ....................................................................................................................65
Figure 76: Battery menu.....................................................................................................................65
Figure 77: Setup menu.......................................................................................................................65

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
viii POWER+RM100, 3X208 V, User Guide, rel. 1.3
Figure 78: Static switch menu............................................................................................................65
Figure 79: Alarm set sub-menu..........................................................................................................66
Figure 80: Module configuration sub-menu........................................................................................66
Figure 81: Battery menu.....................................................................................................................66
Figure 82: Service sub-menu.............................................................................................................67
Figure 83: Configure sub-sub-menu ..................................................................................................68
Figure 84: Silicon sub-menu...............................................................................................................68
Figure 85: Main menu ........................................................................................................................69
Figure 86: Main menu option 1 ("System") ........................................................................................70
Figure 87: System dc voltages...........................................................................................................70
Figure 88: Output power factor 1........................................................................................................71
Figure 89: Input power factor 1 ..........................................................................................................71
Figure 90: Overall phase voltages/currents .......................................................................................71
Figure 91: Elapsed time .....................................................................................................................71
Figure 92: Jumper settings WITHOUT remote panel.........................................................................72
Figure 93: Jumper settings WITH remote panel................................................................................72
Figure 94: Internal controller voltages................................................................................................72
Figure 95: Battery parameters............................................................................................................72
Figure 96: Fuse status........................................................................................................................73
Figure 97: Communication with inverter – transmit............................................................................73
Figure 98: Communication with inverter – receive.............................................................................73
Figure 99: Main Menu option 2 (“UPS Module”) ................................................................................74
Figure 100: LCD Panel – select a UPS..............................................................................................74
Figure 101: Module phase voltages/currents.....................................................................................75
Figure 102: Battery voltages & technician parameters......................................................................75
Figure 103: Main Menu option 3 (“Self Test”) ....................................................................................76
Figure 104: Result screen from self-test............................................................................................76
Figure 105: Main Menu option 4 (“History”) .......................................................................................77
Figure 106: History logs .....................................................................................................................77
Figure 107:History log scroll..............................................................................................................78
Figure 108: Main Menu option 5 (“Battery”).......................................................................................81
Figure 109: Battery status ..................................................................................................................81
Figure 110: Battery equalizing............................................................................................................82
Figure 111: Time left...........................................................................................................................82
Figure 112: Last test...........................................................................................................................82
Figure 113: Battery current.................................................................................................................82
Figure 114: Battery capacity...............................................................................................................83
Figure 115: Battery current limit.........................................................................................................83
Figure 116: Main Menu option 6 (“Alarm”).........................................................................................84
Figure 117: Alarms 01-12...................................................................................................................84
Figure 118: Alarms 13-24...................................................................................................................84
Figure 119: Alarms 25-32...................................................................................................................84
Figure 120: Main Menu option 7 (“Setup – Alarm Set”) .....................................................................85
Figure 121: Level 1 password access................................................................................................85
Figure 122: Setup menu.....................................................................................................................86
Figure 123: Alarm setup menu...........................................................................................................86
Figure 124: Ac alarms menu..............................................................................................................86
Figure 125: Set ac alarm voltage levels.............................................................................................86
Figure 126: Ac alarms menu..............................................................................................................87
Figure 127: Set ac voltage hysteresis................................................................................................87
Figure 128: Alarm set menu...............................................................................................................87
Figure 129: Battery floating charge alarm setup menu......................................................................87

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER+RM100, 3X208 V, User Guide, rel. 1.3 ix
Figure 130: Set BATEND ...................................................................................................................88
Figure 131: Battery floating charge alarm setup menu......................................................................88
Figure 132: Set BATLOW...................................................................................................................88
Figure 133: Battery floating charge alarm setup menu......................................................................88
Figure 134: Set BAT-HI......................................................................................................................88
Figure 135: Alarm set menu...............................................................................................................89
Figure 136: Over/Under temperature menu.......................................................................................89
Figure 137: Set battery maximum temperature alarm .......................................................................89
Figure 138: Over/Under temperature menu.......................................................................................89
Figure 139: Set battery minimum temperature alarm ........................................................................90
Figure 140: Alarm set menu...............................................................................................................90
Figure 141: Set the integration factor alarm.......................................................................................90
Figure 142: Main Menu option 7 (“Setup – Module Conf.”)................................................................91
Figure 143: Level 1 password access................................................................................................91
Figure 144: Setup menu.....................................................................................................................92
Figure 145: Module Config. setup menu............................................................................................92
Figure 146: Module Config. setup menu............................................................................................92
Figure 147: Setting the Module/s frequency ......................................................................................92
Figure 148: Module Config. setup menu............................................................................................93
Figure 149: Setting the Module/s voltage...........................................................................................93
Figure 150: Module Config. setup menu............................................................................................93
Figure 151: Updating the Module/s voltage/frequency/phase............................................................93
Figure 152: Module Config. setup menu............................................................................................94
Figure 153: Select a phase to adjust..................................................................................................94
Figure 154: Select a module to adjust................................................................................................94
Figure 155: Select a value to adjust...................................................................................................94
Figure 156: Module Config. setup menu............................................................................................95
Figure 157: Select the frequency limits..............................................................................................95
Figure 158: Module Config. setup menu............................................................................................95
Figure 159: Calibrate Positive or Negative Voltage ...........................................................................95
Figure 160: Enter measured value.....................................................................................................96
Figure 161: Module Config. setup menu............................................................................................96
Figure 162: Calibrate INPUT or OUTPUT Voltage ............................................................................96
Figure 163: Enter measured value.....................................................................................................96
Figure 164: Main Menu option 7 (“Setup – Battery”)..........................................................................97
Figure 165: Level 1 password access................................................................................................98
Figure 166: Setup menu.....................................................................................................................98
Figure 167: Battery setup menu.........................................................................................................98
Figure 168: Set battery test voltage ...................................................................................................98
Figure 169: Battery setup menu.........................................................................................................99
Figure 170: Set battery test voltage alarm.........................................................................................99
Figure 171: Battery setup menu.......................................................................................................100
Figure 172: Current Limit setup menu..............................................................................................100
Figure 173: Current limit indication for (each) battery......................................................................100
Figure 174: Set Current limit for (each) battery................................................................................100
Figure 175:Battery setup menu.......................................................................................................101
Figure 176: Current Limit setup menu..............................................................................................101
Figure 177: Enable/Disable current limit..........................................................................................101
Figure 178: Battery setup menu.......................................................................................................102
Figure 179: Temperature compensation setup menu......................................................................102
Figure 180: Set temperature compensation.....................................................................................102
Figure 181: Battery setup menu.......................................................................................................103

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
x POWER+RM100, 3X208 V, User Guide, rel. 1.3
Figure 182: Enable/Disable temperature compensation..................................................................103
Figure 183: Select Set ABSOLUTE Max & Min Voltages ................................................................103
Figure 184: Select Set absolute minimum output voltage................................................................104
Figure 185: Set absolute minimum output voltage when compensating .........................................104
Figure 186: Select Set absolute maximum output voltage...............................................................104
Figure 187: Set absolute maximum output voltage when compensating ........................................104
Figure 188: Battery setup menu.......................................................................................................105
Figure 189: Select Activate Battery Test… ......................................................................................105
Figure 190: Activate battery test.......................................................................................................105
Figure 191: Battery setup menu.......................................................................................................105
Figure 192: Select Set auto battery test period................................................................................106
Figure 193: Set battery test period...................................................................................................106
Figure 194: Battery setup menu.......................................................................................................106
Figure 195: Select Set auto battery test top time.............................................................................106
Figure 196: Set battery test top time................................................................................................107
Figure 197: Battery setup menu.......................................................................................................107
Figure 198: Select Set capacity of battery #1 ..................................................................................107
Figure 199: Set battery capacity.......................................................................................................107
Figure 200: Battery setup menu.......................................................................................................108
Figure 201: Activated ‘Auto’ test.......................................................................................................108
Figure 202: Battery setup menu.......................................................................................................108
Figure 203: Enable/Disable shutdown by long AC failure................................................................109
Figure 204: Main Menu option 7 (“Setup – Charge, Time, Site, & Password”)................................110
Figure 205: Level 1 password access..............................................................................................110
Figure 206: Setup menu...................................................................................................................111
Figure 207: Charge setup menu ......................................................................................................111
Figure 208: Set floating charge........................................................................................................111
Figure 209: Setup menu...................................................................................................................112
Figure 210:Set date and time..........................................................................................................112
Figure 211: Setup menu...................................................................................................................112
Figure 212: Set site number.............................................................................................................112
Figure 213: Setup menu...................................................................................................................113
Figure 214: Change password.........................................................................................................113
Figure 215: Main Menu option 7 (“Setup – Service”) 1/2.................................................................114
Figure 216: Main Menu option 7 (“Setup – Service”) 2/2.................................................................115
Figure 217: Level 1 password access..............................................................................................115
Figure 218: Setup menu...................................................................................................................116
Figure 219: Service menu................................................................................................................116
Figure 220: Set UPSs.......................................................................................................................116
Figure 221: Service menu................................................................................................................116
Figure 222: Set UPSs.......................................................................................................................117
Figure 223: Service menu................................................................................................................117
Figure 224: Service > Configure menu ............................................................................................117
Figure 225: Set number of redundant UPSs....................................................................................117
Figure 226: Service > Configure menu ............................................................................................118
Figure 227: Set total number of UPSs .............................................................................................118
Figure 228: Service > Configure menu ............................................................................................118
Figure 229: Set total number of batteries.........................................................................................118
Figure 230: Service > Configure menu ............................................................................................119
Figure 231: Static Switch setup menu..............................................................................................119
Figure 232: Set the mask .................................................................................................................119
Figure 233: Static Switch setup menu..............................................................................................119

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER+RM100, 3X208 V, User Guide, rel. 1.3 xi
Figure 234: Service > Configure menu ............................................................................................120
Figure 235: Dry relay menu..............................................................................................................120
Figure 236: Set dry contact N alarm associations ...........................................................................120
Figure 237: Enable / disable alarms.................................................................................................120
Figure 238: Service > Configure menu ............................................................................................121
Figure 239: DC-I menu.....................................................................................................................121
Figure 240: Remove current offsets.................................................................................................121
Figure 241: DC-I menu.....................................................................................................................121
Figure 242: Calibrating DC current ..................................................................................................122
Figure 243: Entering actual current..................................................................................................122
Figure 244: Service > Configure menu ............................................................................................122
Figure 245: Setting standalone or parallel operation .......................................................................122
Figure 246: Service > Configure menu ............................................................................................123
Figure 247: Enabling/disabling remote commands..........................................................................123
Figure 248: Service menu................................................................................................................123
Figure 249: Enabling/disabling current sharing................................................................................123
Figure 250: Service menu................................................................................................................124
Figure 251: Enabling/disabling power factor correction...................................................................124
Figure 252: Service menu................................................................................................................124
Figure 253: SC2012 menu...............................................................................................................124
Figure 254: SC2012 menu...............................................................................................................125
Figure 255: SC2012 menu...............................................................................................................125
Figure 256: Network menu...............................................................................................................125
Figure 257: Setting an IP address....................................................................................................125
Figure 258: Network menu...............................................................................................................126
Figure 259: Setting the gateway.......................................................................................................126
Figure 260: Network menu...............................................................................................................126
Figure 261: Setting the mask ...........................................................................................................126
Figure 262: Network menu...............................................................................................................127
Figure 263: Network menu...............................................................................................................127
Figure 264 : Setting the SNMP NO COMM factor.............................................................................127
Figure 265: SC2012 menu...............................................................................................................127
Figure 266 :Main Menu option 7 (“Setup – Static Switch”) ..............................................................128
Figure 267: Level 1 password access..............................................................................................128
Figure 268: Setup menu...................................................................................................................128
Figure 269: Silicon menu..................................................................................................................129
Figure 270: Silicon menu..................................................................................................................129
Figure 271: Silicon defaults..............................................................................................................129
Figure 272: Confirmation screen......................................................................................................129
Figure 273: Silicon menu..................................................................................................................129
Figure 274: Static switch option .......................................................................................................130
Figure 275: Static switch voltage and frequency..............................................................................130
Figure 276: Static switch messaging status.....................................................................................130
Figure 277: Setup verification screens.............................................................................................131
Figure 278: Setup verification menu ................................................................................................131
Figure 279: Connection status of UPSs...........................................................................................132
Figure 280: On/Off status of UPSs...................................................................................................132
Figure 281: Software and communication revision..........................................................................132
Figure 282: Network parameters......................................................................................................133
Figure 283: Dry input and output relay contact status .....................................................................133
Figure 284: Alarms status ................................................................................................................133
Figure 285: Set menu language.......................................................................................................134

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
xii POWER+RM100, 3X208 V, User Guide, rel. 1.3
Figure 286: Select General ..............................................................................................................134
Figure 287: General (Screen 1) .......................................................................................................134
Figure 288: General (Screen 2) .......................................................................................................135
Figure 289: General (Screen 3) .......................................................................................................136
Figure 290: General (Screen 4) .......................................................................................................136
Figure 291: Power+ controller rear panel.........................................................................................137
Figure 292: Main Screen of the Power+ Web interface...................................................................138
Figure 293: Analysis of system input and output voltages and power.............................................140
Figure 294: Modules measurements and status display..................................................................140
Figure 295: Static Switch data and status display............................................................................141
Figure 296: Listing the log entries....................................................................................................142
Figure 297: The "Control" main menu option screen.......................................................................144
Figure 298: “SMS” screen................................................................................................................145
Figure 299: Configuration menu.......................................................................................................146
Figure 300: Configuring network communication parameters.........................................................147
Figure 301: Setting the Power+ internal date and time....................................................................147
Figure 302: Changing username and password of the Web interface.............................................148
Figure 303: Define SNMP permissions............................................................................................149
Figure 304: Defining SNMP trap targets..........................................................................................149
Figure 305: Define computers for auto-shutdown............................................................................150
Figure 306: Defining email notification targets.................................................................................152
Figure 307: Defining SMS recipients................................................................................................153
Figure 308: Timing variables when using a generator and an ATS.................................................154
Figure 309: Example of an ATS control panel .................................................................................155
Figure 310: POWER+PSM-AC lets you monitor and control your POWER+UPS.........................156
Figure 311: A Wing unit connected to the PowerPlus......................................................................157
Figure 312: Connections between the Power+ controller and the Wing..........................................158
Figure 313: Home screen of the Power+ web interface...................................................................158
Figure 314: The SMS screen on the Power+ web interface............................................................159
Figure 315: GMACi G4.....................................................................................................................161
Figure 316: G-Eye............................................................................................................................162
LIST OF TABLES
Table 1: Status indicators...................................................................................................................21
Table 2: Operation buttons.................................................................................................................22
Table 3: Network access indication....................................................................................................22
Table 4: Key to Figure 29...................................................................................................................35
Table 5: Key to Figure 30 and Figure 31 above.................................................................................36
Table 6: Required over-current protection ..........................................................................................37
Table 7: Pre-installation inspections ...................................................................................................44
Table 8: Installation procedure............................................................................................................45
Table 9: Checks after initial startup.....................................................................................................49
Table 10: Main Menu Options............................................................................................................69
Table 11: Log Messages....................................................................................................................79
Table 12: Interpreting the Static Switch transfer code (LOADBP).....................................................80
Table 13: Main Screen features.......................................................................................................138
Table 14: Main Menu options...........................................................................................................139
Table 15: Data items on the event log screen..................................................................................142
Table 16: Alarm message text in Web interface log display............................................................143

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER+RM100, 3X208 V, User Guide, rel. 1.3 xiii
Table 17: Commands available on the “Control” screen..................................................................144
Table 18: Defining computers for auto-shutdown............................................................................150
Table 19: Fields in the email notifications screen ............................................................................152
Table 20: Fields in the SMS notification target definition screen.....................................................153
Table 21: List of SMS commands ....................................................................................................160
Table 22: Normal operating position of the ac circuit breakers........................................................163
Table 23: Position of the ac CBs in maint. bypass mode.................................................................163
Table 24: Technical specifications for the RM100 3x208 Vac..........................................................166

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
xiv POWER+RM100, 3X208 V, User Guide, rel. 1.3
IN THE EVENT THAT SYSTEM OUTPUT CAPACITY IS INCREASED ABOVE THE
ORIGINAL FACTORY CONFIGURATION, THE SYSTEM NAMEPLATE MUST BE
UPDATED TO INDICATE THE NEW POWER AND CURRENT CAPACITY.
This condition applies when new, non-redundant power modules are added to the
system or when formerly redundant modules are designated as non-redundant.
SI LA CAPACITE DE SORTIE EST AUGMENTEE AU DELA DE LA CONFIGURATION
D'ORIGINE, LA PLAQUE INDICATIVE DU PRODUIT DOIT ETRE MISE A JOUR AVEC
LES NOUVELLES CAPACITES.
Cette condition s'applique si de nouvelles modules onduleurs non redondantes sont
ajoutées ou si des modules onduleurs redondantes sont désignées comme non
redondantes.
STANDARDS AND CONVENTIONS
This manual contains diagrams that include images of the LCD display screen of the UPS. Unless
otherwise indicated, the readings shown in the screen images are representational only, and are
not intended to match the readings on a specific system in a particular environment.

Gamatronic Electronic Industries Ltd.
POWER+RM100, 3X208 V, User Guide, 1.3
1
1. MOVING THE POWER+RM100 (AND ITS BATTERY
CABINET)
The Power+RM100 is usually shipped in its cabinet. After unpacking the RM100, you will notice two metal
flanges at the base of the cabinet – one on the left side and one on the right side of the cabinet. These
flanges can be used to secure the RM100 to the ground if desired.
To move the RM100 cabinet with a forklift, these flanges must be temporarily removed. The same applies
to the RM100 battery cabinet, if you have ordered it. See Figure 1 and Figure 2 below.
After the cabinet has been positioned, the flanges can be reattached if desired.
Figure 1: Flanges for securing the RM100 to the ground
Figure 2: Remove the flanges before moving the RM100 with a forklift.

Gamatronic Electronic Industries Ltd.
POWER+RM100, 3X208 V, User Guide, 1.3
2
2. IMPORTANT SAFETY INSTRUCTIONS
(SAVE THESE INSTRUCTIONS)
This manual contains important instructions for the Power+ RM100 3x208 Vac model.
The PowerPlus UPS system is designed for industrial applications and harsh environments.
Nevertheless the PowerPlus system should be handled with appropriate care, according to the
following guidelines.
WARNING! HIGH TOUCH CURRENT!
EARTH CONNECTION ESSENTIAL BEFORE CONNECTING SUPPLY.
2.1 Do’s
•Read this manual carefully before starting installation and operation of the UPS.
•Review the safety precautions described below to avoid injury to users and damage to the
equipment.
•This UPS is intended for installation in a temperature-controlled, indoor area that is free from
conductive contaminants.
•All power connections must be completed by a licensed electrician who is experienced in wiring
this type of equipment, and who is familiar with the local electrical codes and regulations. Improper
wiring may cause injury or death to personnel, or damage to the equipment.
•Pay attention to the warning signs, labels, and markings on the unit. A warning sign signals the
presence of a possibly serious, life-threatening condition.
•Ensure all power is disconnected before performing installation or maintenance.
•Leave at least 20 cm of clearance space between the ventilation openings of the UPS and other
objects or walls.
•The UPS must be well grounded to the building’s grounding system with a conductor that has a
current carrying capacity that matches the rating of the UPS.
•Battery installation, battery maintenance, and battery replacement shall be performed only by
authorized service personnel.
•Pay attention to all DANGER, CAUTION, and WARNING notices affixed to the inside and outside
of the UPS.
•Keep the surroundings clean, uncluttered and free from excess moisture.
•Keep the operating environment within the parameters stated in this document.
•Allow only qualified technicians to service the UPS. There are no user-serviceable components.
Do not try to repair it yourself!
•Use the UPS only for its intended purpose.
•The battery cabinet should preferably be installed next to the UPS, or as close to it as is practically
possible.
•Fast-acting fuses (semiconductor fuses) must be used between the battery and the UPS.For
example, the Bussmann “FWH” fuse.
•If you remove a UPS module from the PowerPlus while the module is operating, wait five minutes
before reinserting the module. This allows the module’s capacitors time to discharge.

Gamatronic Electronic Industries Ltd.
POWER+RM100, 3X208 V, User Guide, 1.3
3
2.2 Don’ts
•Do not open the cover of the UPS or the battery cabinets under any circumstances. All UPS panels
and doors should be closed.
•Do not insert any objects through the ventilation holes.
•Do not put objects on the UPS.
•Do not move the UPS while it is operating.
•Do not use the UPS outdoors.
•Do not turn the UPS upside down during transportation.
•Do not connect or disconnect the cable to the battery cabinet before the battery circuit breaker is
turned OFF.
•Do not turn ON the battery circuit breaker when the battery cabinet is disconnected from the UPS.
•Do not install the UPS next to gas or electrical heaters. A restricted location is recommended in
order to prevent access by unauthorized personnel.
•If you remove a UPS module from the Centric while the module is operating, do not reinsert the
module immediately. Wait five minutes.
CAUTION - WARNING - RISK OF LETHAL ELECTRIC SHOCK:
The battery drawer contains a series of 12-Volt batteries that provide high voltage
and energy in the UPS body even when the UPS is not connected to the ac input.
Appropriate precautions should be taken during installation, inspection and
servicing.
CAUTION - WARNING - RISK OF LETHAL ELECTRIC SHOCK:
The UPS receives power from more than one source. Disconnection of all of the
ac sources and the dc source is required to de-energize this unit before servicing.
ATTENTION - AVERTISSEMENT -RISQUE DE DÉCHARGE ÉLECTRIQUE
MORTELLE :
Le module de batterie contient une série de batteries 12-Volt qui fournissent une
haute tension et l'énergie dans le corps de l'onduleur même lorsque l'onduleur
n'est pas relié à l'entrée à A.C. Des précautions appropriées devraient être prises
pendant l'installation, l'inspection et l'entretien.
ATTENTION - AVERTISSEMENT -RISQUE DE DÉCHARGE ÉLECTRIQUE
MORTELLE :
L'onduleur reçoit la puissance de plus d'une source. Le débranchement de toutes les
sources à A.C.et source de D.C est exigé pour désactiver cette unité avant l'entretien.

Gamatronic Electronic Industries Ltd.
POWER+RM100, 3X208 V, User Guide, 1.3
4
WARNING: RISK OF SEVERE DAMAGE TO THE UPS!!!
This system uses the neutral line for operation. Therefore, it is strictly
forbidden to connect this system to the ac power source without a
neutral (null) conductor!!
Failure to use a neutral conductor may cause permanent damage to the
system.
AVERTISSEMENT : RISQUE DE DOMMAGES GRAVES
À L'ONDULEUR!
Ce système emploie la ligne neuter pour l'opération. Par
conséquent, il est strictement interdit de relier ce système a
la source (ac) de courant alternative sans conducteur
neuter (nul)!
L'échec à l'utilisation d'un conducteur neuter peut
endommager en le système de façon permanente.
CAUTION –GROUND CONNECTION ESSENTIAL BEFORE CONNECTING SUPPLY
Connect the UPS to ground before connecting it to the ac supply.
ATTENTION – LA PRISE DE TERRE AU SOL EST ESSENTIELLE AVANT DE RELIER
L'APPROVISIONNEMENT
Mettre l'onduleur à la terre avant de le relier à l'approvisionnement à A.C.
WARNING -RISK OF ELECTRIC SHOCK! DO NOT OPEN THE REAR DOOR!
Do not open the rear door of the UPS cabinet. Keep the rear door locked.
The rear door should be opened only by an authorized technician.
ATTENTION - RISQUE DE CHOC ÉLECTRIQUE!
NE PAS OUVRIR PORTE ARRIERE!
Ne pas ouvrir la porte arrière de l'armoire de l'ondeuleur. Gardez la porte arrière
verrouillée. Seul un technicien qualifié peut ouvrir la porte arrière de l'armoire de
l'onduleur.

Gamatronic Electronic Industries Ltd.
POWER+RM100, 3X208 V, User Guide, 1.3
5
3. INTRODUCTION TO THE POWERPLUS RM100
In general, an Uninterruptible Power Supply (UPS) provides backup power for use when the utility ac
electric power mains fail or drop to an unacceptable voltage level. POWER+is a whole lot more.
POWER+ is designed to protect your data and equipment and minimize downtime and other adverse
effects normally incurred by power irregularities and failures.
POWER+ continually eliminates surges, spikes and sags that are inherent in commercial utility power.
Over time, these irregularities shorten the life of equipment and components. The efficiency of POWER+
thus helps to extend the life of your equipment, even through normal use when the input power system is
constant and continuous.
POWER+ requires very little attention or intervention during normal operation; however, you should read
and understand the procedures described in this manual to ensure trouble-free operation.
POWER+is a parallel redundant UPS and is flexible in structure, allowing it to be easily extended by
adding modules as required. The UPS modules are designed for hot swapping, making many different
configurations possible.
The POWER+ RM100 model fits into a standard 19” wide enclosure and is configurable for a capacity of
10 to 100 kVA.
3.1 POWER+ features:
POWER+ is:
•Reliable, thanks to its N+ 1 parallel redundancy.
•Both flexible and modular; it may include from one to ten modules.
•A true on-line battery design according to IEC62040-3.
•A "green" power solution thanks to a THD of 5 % at the input, and provides “clean” power to your
loads.
•A UPS that employs active current sharing at the input / output.
•A UPS that has an overall efficiency of up to 96 % and a backup efficiency of 98 %.
•Light and small, a 10 kVA module weighs approximately 22 lb. (10 Kg).

Gamatronic Electronic Industries Ltd.
POWER+RM100, 3X208 V, User Guide, 1.3
6
ITEM DESCRIPTION
1 19-inch cabinet
2 System controller module
3
From 1 to 10 UPS power modules,
10 kVA each
4 Static switch assembly
Figure 3: Main subassemblies of the RM100
