Gamatronic Power+ User manual

Har Hotzvim Industrial Park,
14 Hartom St., PO Box 45029, Jerusalem 97774, Israel
Tel: [phone] Fax: [phone]
Email: [email protected] Website: www.gamatronic.com
2MUM-PP/4
POWER+
M
MO OD DU UL LA AR R U
UP PS S
S SY YS ST TE EM M
U
Us se er r G Gu ui id de e
Release 3.4
December 2006

Gamatronic Electronic Industries Ltd.
ii POWER+User Guide, Release 3.4
Gamatronic Electronic Industries Ltd.
Har Hotzvim Industrial Park
14 Hartom St.
PO Box 45029
Jerusalem 97774
Israel
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.gamatronic.com
This UPS has been designed for commercial/industrial use only, and is not for use in any life support application.
©Copyright 2006 by Gamatronic Electronic Industries Ltd. . All rights reserved worldwide.
The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws
protecting intellectual property, as well as any specific agreement protecting Gamatronic Electronic Industries Ltd. rights
in the aforesaid information. Neither this document nor the information contained herein may be published, or reproduced,
in whole or in part, without the express, prior, written permission of Gamatronic Electronic Industries Ltd. In addition, any
use of this document or the information contained herein for any purposes other than those for which it was disclosed is
strictly forbidden.
Gamatronic Electronic Industries Ltd. reserves the right, without prior notice or liability, to make changes in equipment
design or specifications.
Information supplied by Gamatronic Electronic Industries Ltd. is believed to be accurate and reliable. However, no
responsibility is assumed by Gamatronic Electronic Industries Ltd. for the use thereof nor for the rights of third parties
which may be affected in any way by the use thereof.
Any representation(s) in this document concerning performance of Gamatronic Electronic Industries Ltd. product(s) are
for informational purposes only and are not warranties of future performance, either express or implied. Gamatronic
Electronic Industries Ltd. standard limited warranty, available upon request, stated in its sales contract or order
confirmation form, is the only warranty offered by Gamatronic Electronic Industries Ltd. in relation thereto.
This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation
thereto unless specifically undertaken in Gamatronic Electronic Industries Ltd. sales contract or order confirmation.
Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you
have encountered an error, please notify Gamatronic Electronic Industries Ltd. All specifications are subject to change
without prior notice.

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 iii
TABLE OF CONTENTS
SAFETY CONSIDERATIONS.............................................................................................................IV
Do’s ..................................................................................................................................iv
Don’ts ...............................................................................................................................iv
1.INTRODUCTION........................................................................................................................... 1
POWER+has many unique features: .............................................................................. 1
System Controller............................................................................................................. 4
UPS Module (10kVA / 8kW)............................................................................................. 4
Static Switch (ST/SW) Module ......................................................................................... 4
Battery .............................................................................................................................. 4
2.OPERATING MODES ................................................................................................................... 5
3.USER INTERFACE....................................................................................................................... 6
Control Panel.................................................................................................................... 6
UPS Module Panel ........................................................................................................... 6
Static Switch Panel........................................................................................................... 7
POWER+Control screen ................................................................................................. 7
Navigation and Operation Keypad ................................................................................... 8
Status Indicators............................................................................................................... 9
POWER+Operation Modes........................................................................................... 11
4.FIRST-TIME SETUP................................................................................................................... 14
Installation and Start-Up Sequence ............................................................................... 14
AC Input/Output Main Terminals.................................................................................... 15
5.POWER+START-UP ............................................................................................................... 16
POWER+Shutdown (Switching to Bypass)................................................................... 18
POWER+Total Shutdown (No AC Output).................................................................... 18
6.POWER+CONTROL PANEL .................................................................................................... 19
Quick-Reference Summary of Power+ Menu Functions ............................................... 20
7.POWER+MENU FUNCTIONS IN DETAIL ...................................................................................... 26
Main Menu...................................................................................................................... 26
System............................................................................................................................ 27
UPS Module ................................................................................................................... 30
Self-Test ......................................................................................................................... 31
History (Logs) ................................................................................................................. 31
Battery ............................................................................................................................ 34
Alarm .............................................................................................................................. 35
Setup Menu .................................................................................................................... 36
Static SW........................................................................................................................ 44
Alarm Dry Contacts ........................................................................................................ 45
Calibration ...................................................................................................................... 45
Communications............................................................................................................. 45
System Controller Setup Verification ............................................................................. 46
8.SNMP AGENT ......................................................................................................................... 48
9.WIRELESS CONTROL (OPTIONAL) ............................................................................................. 49
WING Configurations ..................................................................................................... 50
10.POWER+SPECIFICATIONS.................................................................................................... 52

Gamatronic Electronic Industries Ltd.
iv POWER+User Guide, Release 3.4
SAFETY CONSIDERATIONS
The POWER+UPS system is designed for industrial applications and harsh
environments. Nevertheless the POWER+UPS system is a sophisticated power
system and should be handled with appropriate care, following these guidelines.
Do’s
•Read this manual carefully before starting installation and operation of the
UPS.
•Review the safety precautions described below to avoid injury to users or
damaging equipment.
•All power connections must be completed by a licensed electrician who is
experienced in wiring this type of equipment, and who is knowledgeable
about all federal, state, and local electrical codes and regulations. Improper
wiring may cause damage to the equipment or injury to personnel.
•Pay attention to the warning signs, labels and marks on the unit. A warning
sign signals the presence of a possibly serious, life-threatening condition.
•Keep the surroundings clean, uncluttered and free from excess moisture.
•Allow only qualified technicians to service the UPS. There are no user-
serviceable components. Do not try to repair it yourself!
•Use the UPS only for its intended purpose.
WARNING - RISK OF LETHAL ELECTRIC SHOCK:
The battery drawer contains a series of 12-Volt batteries that provide high voltage
and
energy in the UPS body even when the UPS is not connected to the AC input.
Appropriate precautions should be taken during installation, inspection and
servicing.
Don’ts
•Do not open the cover of the UPS or the battery cabinets under any
circumstances. All UPS panels and doors should be closed.
•Do not insert any objects through the ventilation holes.
•Do not put objects on the UPS.
•Do not move the UPS while it is operating.
•Do not use the UPS outdoors.
•Do not turn the UPS upside down during transportation.
•Do not connect or disconnect the cable to the battery cabinet before the
battery circuit breaker is turned OFF.
•Do not turn ON the battery circuit breaker when the battery cabinet is
disconnected from the UPS.
•Do not install next to any gas or electrical heaters. A restricted location is
recommended in order to prevent access by unauthorized personnel.

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 v
WARNING: RISK OF
SEVERE DAMAGE TO THE UPS!!!
THIS SYSTEM USES THE NEUTRAL LINE FOR
OPERATION.THEREFORE,IT IS STRICTLY
FORBIDDEN TO CONNECT THIS SYSTEM TO
THE AC POWER SOURCE WITHOUT A NEUTRAL
(NULL)CONDUCTOR!!
FAILURE TO USE A NEUTRAL CONDUCTOR MAY
CAUSE PERMANENT DAMAGE TO THE SYSTEM.

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 1
1. INTRODUCTION
Thank you for purchasing a POWER+UPS system.POWER+ is the most
sophisticated UPS on the market today.
In general, an Uninterruptible Power Supply (UPS) provides backup power for use
when the utility AC electric power mains fail or drop to an unacceptable voltage
level. POWER+is a whole lot more.
POWER+ is designed to protect your data and equipment and minimize downtime
and other adverse effects normally incurred by power irregularities and failures.
POWER+ continually eliminates surges, spikes and sags that are inherent in
commercial utility power. Over time, these irregularities shorten the life of equipment
and components. The efficiency of POWER+thus helps to extend the life of your
equipment, even through normal use when the input power system is constant and
continuous.
POWER+ requires very little attention or intervention during normal operation;
however, you should read and understand the procedures described in this manual
to ensure trouble-free operation.
POWER+is a parallel redundant UPS and is flexible in structure, allowing it to be
easily extended by adding modules as required. The UPS modules are designed for
hot swapping, making many different configurations possible.
POWER+has many unique features:
•POWER+ is reliable thanks to its N+ 1 parallel redundancy.
•POWER+
is both flexible and modular; it may include from one to ten
modules.
•POWER+
is a true on-line battery design according to IEC62040-3.
•POWER+
is a "green" power solution thanks to THD of 5% at the input,
and provides “clean” power to your loads.
•POWER+
employs active current sharing at the input / output.
•POWER+
has an overall efficiency of up to 96% and backup efficiency of
98%.
•POWER+
is light and small, a 10kVA module weighs only 9Kg.

Gamatronic Electronic Industries Ltd.
2 POWER+User Guide, Release 3.4
40kVA configuration
100kVA – Small enough to fit in a 4-passenger elevator

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 3
The POWER+is comprised of the following sub-assemblies.
System Controller
1-10 UPS modules × 10kVA
Static Switch Module
System Controller
10kVA UPS modules
Static Switch
POWER+System - full complement

Gamatronic Electronic Industries Ltd.
4 POWER+User Guide, Release 3.4
System Controller
The POWER+system controller has three purposes:
•to allow the user to manage and control the UPS as well as monitor the
parameters of all sections of the POWER+via the control panel
•to collect and summarize data from all sections of the UPS
•communication with external computers for data transfer and operation
The POWER+can work without the system controller but with reduced functionality.
UPS Module (10kVA / 8kW)
The UPS module is the core of the POWER+, which consists of from one to ten
identical modules in parallel depending on capacity requirements.
Each module includes a 3-phase charger with PFC1and a 3-phase PWM inverter
connected to batteries by a classic DC link. Each module is plug-in and weighs a
mere 9kg.
Static Switch (ST/SW) Module
The centralized hybrid Static Switch enables an automatic transfer of the load from
the output of the inverters to an alternate source whenever the inverter can no
longer supply power to the load. The static switch can transfer high currents at high
speed.
Battery
The POWER+battery bank is used as a backup in the event that the utility AC input
fails.
For systems from 10kVA through 30kVA, the batteries may be housed internally,
however for systems from 40kVA through 100kVA, or for sites where a long backup
duration is required, the batteries are housed in external cabinets next to the
POWER+cabinet.
Batteries are charged by the rectifier which supplies both the inverter and the battery
charger.
1PFC is a feature included that reduces the amount of generated reactive power. Reactive
power operates at right angles to true power and energizes the magnetic field. Reactive
power has no real value for an electronic device, but electric companies charge for both true
and reactive power resulting in unnecessary charges.
In power factor correction, the power factor (represented as "k") is the ratio of true power
(kWatts) divided by apparent power (kVA). The power factor value is between 0.0 and 1.00. If
the power factor is above 0.8, the device is using power efficiently. A standard power supply
has a power factor of 0.70-0.75, and a power supply with PFC has a power factor of 0.95-
0.99.

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 5
2. OPERATING MODES
The POWER+UPS functions to supply AC electrical power to your load.
While using the POWER+, three modes of operation are possible:
•Normal operation
•Battery operation
•Bypass operation
Normal Operation
The UPS is almost always in normal operation mode. The load receives its power
from the inverters that supply stabilized voltage, protected from spikes and
irregularities in the AC input. The AC input system feeds the charger which supplies
DC power to the inverter, while concurrently charging the batteries.
Battery Operation
During battery operation, the load continues to receive power from the inverters, but
the DC input to the inverter is taken from the batteries, instead of from the rectifier.
The batteries are galvanically connected by DC link to the inverter and the charger.
The DC inherently remains constant when the AC input supply drops out, without
any switching devices.
The duration of the battery operation is determined by the load demand and the
battery capacity.
Bypass Operation
During bypass operation, the load receives power directly from the AC input via the
static switch.
Whenever the inverters cannot provide power to the load, either due to an overload
or a short-circuit in the load, transfer to the AC input is automatic. As soon as the
problem is corrected, the load is transferred back to the inverter.

Gamatronic Electronic Industries Ltd.
6 POWER+User Guide, Release 3.4
3. USER INTERFACE
This section describes the buttons and indicators used to operate the POWER+.
Control Panel
The POWER+Control Panel, located on the front of the controller, provides the user
with an interface to the POWER+system. It includes an LCD display, a keypad,
buttons and indicators for monitoring and controlling the UPS configuration and
functions. The control panel is aimed both at the end-user as well as the service
engineer. All of the POWER+parameters can be viewed on the control panel.
Use of the POWER+Control Panel is described in detail in Chapter 6 beginning on
page 19
Network Access Indicator
Navigation and
Operation keypad Status indicators
Operation buttons
LCD Panel
UPS Module Panel
The UPS module panel, located on the front of each UPS module, provides the user
with the status of that module

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 7
Static Switch Panel
The static switch panel, located on the front of static switch module, provides the
user with the status of the static switch module. All the functions and indications are
available on the POWER+Control Panel.
POWER+Control screen
The POWER+control screen is illustrated below. It is part of the control panel
described on page 6.
How to read and understand the POWER+control screen is described in detail in
Chapter control screen is described in Chapter 6 beginning on page 19
The control screen provides menus and displays all aspects of the POWER+
systems input, output and static switch as well as operational details.
The figure on page 8 shows the POWER+3-phase display.
Output Output
Load level bar graph Current Voltage Current time Battery Voltage

Gamatronic Electronic Industries Ltd.
8 POWER+User Guide, Release 3.4
LO A D L EVE L
G A MATRONIC ---11:20:25 - - -
R :
_ ___ _ 01 5A, 2 34V BATTERY: 86 8 V
S :
_ _ ___ _ 01 2A, 236V UPS OK (O N )
T :
_ _ _ ___ _ 01
1A, 234V STSW OK (I N V )
This is how the control screen appears while the UPS is running normally.
Navigation and Operation Keypad
The navigation and operation keypad works in conjunction with the control screen. It
allows you to navigate through the available menus using the direction
arrow buttons and the Enter and Escape buttons to select or quit, respectively.
Status
Indication

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 9
Status Indicators
The status indicators show precisely what is running and how the UPS is providing
power to the load.
The diagram below shows the power source and destination routes in use for each
of the 3 automated operation modes.
Normal
operation
route
Bypass
operation
route
Battery
operation
route
AC Line Green – Shows that the AC input is present and within range
Alarm Red – Flashes to indicate general alarm condition
Battery Green – Shows that the battery is in discharge mode
Bypass Green – Shows that the load is supplied from the AC input
Inverter Green - Shows that the inverter is supplying power to the load
Bat. Test Blinking Red – Shows that a battery test is in progress
Steady Red – Battery test failure
UPS On Green – Indicates that the UPS is running
Load Green – Indicates that AC voltage is available at the output

Gamatronic Electronic Industries Ltd.
10 POWER+User Guide, Release 3.4
Operation Buttons
The operation buttons illustrated below are “soft” switches.
•On/Off resets the entire UPS
•Alarm silence shuts the alarm sounder
•Inv/Byp allows the maintenance engineer to manually change the
operation mode
UPS ON/OFF switch
Alarm silence
Inverter/Bypass manual switch over
Network Access Indicator
The network access indicator shows whether the network connection is available
and whether it is active.
Link Red – Indicates the presence of a network connection link
Act Green – Indicates that the network is active

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 11
POWER+Operation Modes
Normal Operation
LO A D L EVE L G A MATRONIC ---11:20:25 - - -
R :
_ ___ _ 01 5A, 2 34V BATTERY: 86 8 V
S :
_ _ ___ _ 01 2A, 236V UPS OK (O N )
T :
_ _ _ ___ _ 01
1A, 234V STSW OK (I N V )
Battery Operation
Lo ad l e v e l no ac 005m ---11:2 0 : 2 5 - - -
r : _ _ _ _ _ 015A, 234V battery : 86 8 V
s : _ _ _ _ _ _ 012A, 236V ups oK (o n )
T : _ _ _ _ _ _ _ 011A, 234V stsW oK (i n v )
During normal operation, the UPS
draws power from the AC line, feeds
DC to the inverter which provides
AC to the load.
During Battery Operation, the battery
supplies DC to the inverter which then
provides AC to the load.
The red alarm flashes to indicate the
abnormal status.
Status
Indication
AC failed for the past
5 minutes

Gamatronic Electronic Industries Ltd.
12 POWER+User Guide, Release 3.4
Bypass Operation (Automatic)
LO A D L EVE L
G A MATRONIC ---11:20:25 - - -
R :
_ ___ _ 01 5A, 2 34V BATTERY: 86 8 V
S :
_ _ ___ _ 01 2A, 236V UPS OK (O F f )
T :
_ _ _ ___ _ 01
1A, 234V STSW warnin g
Bypass Operation (Manual)
LO A D L EVE L
G A MATRONIC ---11:20:25 - - -
R :
_ ___ _ 01 5A, 2 34V BATTERY: 86 8 V
S :
_ _ ___ _ 01 2A, 236V UPS OK (O n )
T :
_ _ _ ___ _ 01
1A, 234V STSW OK (B Y P )
Status
Indication
During Bypass operation, the AC
feeds the load via the bypass static
switch. The red alarm flashes to
indicate the abnormal status.
If the Power+ is manually switched to
bypass operation by pressing the
Inv/Byp button, the load is transferred
to the mains AC input line. Transfer
back to normal operation must be
performed manually. The red alarm
indicator will be lit but will not flash.
Status
Indication

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 13
Emergency Power Off - EPO (Manual)
An external Emergency Power Off (EPO) switch may be installed by the customer.
The EPO switch cuts power to the load in emergency situations. Once switched
OFF by the EPO, the POWER+must be restarted manually.
The EPO switch must be an N.C.-type, rated for at least 230VAC.

Gamatronic Electronic Industries Ltd.
POWER+User Guide, Release 3.4 14
4. FIRST-TIME SETUP
Installation and Start-Up Sequence
Preparation
1. Prepare the proper infrastructure for the POWER+with adequate cables and
connections.
2. Prepare the POWER+for installation. Ensure all components and modules are
complete and securely fastened to their shelves.
3. Verify that utility AC power is disconnected and that all switches are OFF.
4. Connect the POWER+to the electricity mains according to the correct phase
sequence.
5. Connect the battery set(s) to the POWER+.
6. Re-check your connections.
7. Ensure that the maintenance bypass switch is set to NORMAL (OFF).
Operation
Note: Before first setting up the UPS, make sure that the load is not connected.
When applying power to the POWER+, the system automatically runs the startup
process without a need to press the On/Off button.
1. Turn the AC input and AC bypass switch ON and wait (for about 2
minutes) for the POWER+to initialize.
2. The start-up sequence will begin and the control panel will show the
following sequence. (The details will vary, depending on your
application.)
G A MAT R O N I C - ELECTRONIC INDUSTR I E S LTD.
UPS POWER+
SC25270105
Power up
Start-up 1
W E L C O M E ! ! !
Figure 1: Start-up screen 1
WARNING !!!
SYSTEM RUNNING IN:
S I L I C O N M O D E (JP2 - I N )
Power up
Start-up 2
- - --- - - - P L EASE NOTIFY SUPERVISO R - - - - - ---
Figure 2: Start-up screen 2
