SolarPRO™CURVE
OWNER’S MANUAL
MODEL 4721
IMPORTANT
SAFETY RULES
Read all instructions BEFORE assembling and using
this product. KEEP THIS MANUAL.
ENGLISH
IMPORTANT
DO NOT RETURN PRODUCT TO STORE
For technical assistance and missing parts, call or email Customer Service
1.888.339.2546 (Extension 135)
[e-mail]
Monday through Thursday, 8:00 am to 5:00 pm MST
Friday, 8:00 am to 2:00 pm MST
If replacement parts are needed please visit Amazon.com/GAMELLC

2SAVE THESE INSTRUCTIONS
For further information regarding the installation of multiple SolarPRO units
or for replacements parts, please contact GAME Customer Service, a local
swimming pool specialist, or visit www.Amazon.com/GAMELLC
(replacement parts only).
IMPORTANT
Approved for use with any filter pump up to a maximum of 1.5 HP.
Use of any other type of pump will void the warranty.
A GAME bypass kit is required (sold separately) for filter pumps greater than
1.5 HP or when multiple SolarPRO units are connected to a single filter pump.

3SAVE THESE INSTRUCTIONS
TABLE OF CONTENTS
1. Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Parts List/Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
4. Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
5. Initial Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7. Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8. Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
READ ALL INSTRUCTIONS BEFORE ASSEMBLING AND
USING THIS PRODUCT.
YOUR SOLARPRO CURVE HAS BEEN ENGINEERED AND MANUFACTURED
TO OUR HIGHEST STANDARD FOR DEPENDABILITY, EASE OF OPERATION
AND SAFETY. THANK YOU FOR YOUR PURCHASE.
IMPORTANT
DO NOT RETURN PRODUCT TO STORE
For technical assistance and missing parts, call or email Customer Service
1.888.339.2546 (Extension 135)
[e-mail]
Monday through Thursday, 8:00 am to 5:00 pm MST
Friday, 8:00 am to 2:00 pm MST
If replacement parts are needed please visit Amazon.com/GAMELLC

4SAVE THESE INSTRUCTIONS
1. SAFETY WARNINGS
READ ALL WARNINGS BELOW.
• Carefully read and adhere to all CAUTION and NOTE notices located throughout this manual.
Failure to comply with these instructions can cause serious injury, death, or damage to the unit.
• Do NOT allow children to operate this product.
• Always turn the filter system to a setting that does not allow flow to the pool return when installing
or working on the SolarPRO.
• Install product away from the pool to prevent children from using the SolarPRO as a way to access the pool.
• NEVER service this unit with the pool pump running.
• Do not use any petroleum based lubricant. Only use pool and spa silicon based lubricant on this product.
THESE CAUTION WARNINGS ARE NOT INTENDED TO INCORPORATE ALL POSSIBLE INSTANCES FOR RISK AND/OR SEVERE
INJURY. THE POOL OWNER SHOULD ALWAYS EXERCISE CAUTION WHEN UTILIZING THEIR SWIMMING POOL AND OPERAT
ING EQUIPMENT.
2. GENERAL INFORMATION
This manual provides important information relating to the installation, maintenance, and use of the SolarPRO unit.
The installation instructions assume the SolarPRO unit is for use on an already filled, above ground pool that has the following:
1. A pump-oriented water filtration system.
2. The necessary hoses to feed water from the pool into the water filtration system and from the water filtration system to
the pool.
How It Works
When properly installed, the SolarPRO will be connected to your filter and your pool by two hose connections: One hose will feed cold,
filtered pool water from your pump into one port of the SolarPRO. The other hose will feed sun warmed water from the other port of
the SolarPRO to your pool via the pool return inlet in your pool. As cold water is fed into the SolarPRO, it travels through the solar coils
where it is heated by the sun before it is delivered back into your swimming pool.
Unpacking Your SolarPRO
Carefully remove the product and all component parts from the box. Make certain all parts are present before beginning assembly
(see Section 2, Parts List/Reference).
Tools & Equipment Required
The following items are not included with your new SolarPRO, but will be required for proper installation and operation:
• #2 Phillips screwdriver
• ¼" Flat head screwdriver
• Silicone based lubricant
Know Your Pool
Before you begin installation it is a good idea to know certain specifications about your pool:
The water volume (in gallons) of the pool.
What size hose does it use? (i.e. 32mm, 38mm or 40mm)
What kind of hose connection does your pool use? (i.e. threaded/unthreaded)
What location will position the SolarPRO for maximum sun exposure?

Only used with 40mm
threaded hoses
5SAVE THESE INSTRUCTIONS
SolarPRO Location
Your SolarPRO needs to be located on a hard level surface. You will need to position the SolarPRO lower than the pool’s water level and
at a safe distance away from the pool (see Section 1, Safety Warnings).
• The unit(s) should never be placed on the roof of any structure, or above the water level of the pool.
• The unit(s) should be angled toward the sun using the legs provided. Do not exceed the angle the legs
produces, or 30 degrees from horizontal in any direction.
NOTE: The SolarPRO is to be installed between the filter and the pool water inlet, AFTER the water is filtered. The SolarPRO
must come after the filter to prevent buildup in the tubing.
IMPORTANT: If you are using a chlorine generator OR an in line chlorinator, it must be connected in-line following the SolarPRO
to prevent damage.
CAUTION: BEFORE LOOSENING ANY THREADED CONNECTIONS ON YOUR FILTER, PUMP OR POOL, BE SURE THE SUCTION
AND PRESSURE HOSES ON THE FILTER ARE CLOSED OR BLOCKED TO PREVENT WATER FLOW.
IMPORTANT: To reduce heat loss, use a pool cover on your pool overnight.
3. PARTS LIST/REFERENCE
Main Unit (1) 32mm to 38 mm Hose Reducer (2) Hose Clamp (2)
Flat Gasket (2) Collar and Hose Adapter* Filter Hose (2) with O-Ring (2)
32mm-38mm
40mm Adapter with O-Ring (2)** Teflon Tape (1)
Note: Some parts may be pre-installed at the factory. Parts not shown to scale.
*Compatible with most Bestway pools.
**Compatible with most Intex pools.

1
67 8
43
2
5
6SAVE THESE INSTRUCTIONS
EXPLODED PARTS DIAGRAM
Key Name Qty Item Number
1 SolarPRO Main Unit with Legs 1 4K9010
2 38mm Filter Hose 2 4K9023
3 32mm-38mm Hose Reducer 2 41018
4 Collar and 32mm-38mm Hose Adapter with O-Ring 2 41018
5 38mm Stainless Steel Hose Clamp 2 4K9023
6 Adapter with O-Ring
with Flat Gasket 40mm diameter 2 41018
7 Foot 2 4S1080
8 Teflon Tape (Roll) 1 N/A
Note: Some parts may be pre-installed at the factory.
Parts not shown to scale.

SolarPRO
SolarPRO SolarPRO
NOTE: Not shown to scale
7SAVE THESE INSTRUCTIONS
4. INSTALLATION INSTRUCTIONS
SolarPRO – Filter – Pool Layout
The system layouts below will help you install the SolarPRO to your above ground pool.
BEFORE INSTALLING SolarPRO
AFTER INSTALLING SolarPRO
NOTE: All instructions assume the pool and water filtration system are assembled.
1. SolarPRO Placement
Place the SolarPRO unit at least 10 feet away from the pool and in a location where it will receive the greatest amount of sunlight.
Extend the legs on the underside of the SolarPRO and angle in the direction of the sun’s
natural path. See figure 1.
2. SolarPRO - Filter Pump Connection
a) Turn off filter pump.
b) Block water flow at both the pool return inlet and the filter pump outlet
to prevent water from flowing through the hoses.
c) Detach the pool return hose from your filter system and set aside.
d) Depending on the orientation of your pump setup and desired SolarPRO placement,
choose one side to be the inlet and the other to be the outlet. Disregard the “IN”and
“OUT” markings if present, either port can be used.
e) Locate filter hose and attach between pump (the port where the pool return hose
was previously connected) and the inlet using the included hose clamps .
NOTE: Depending on the size of your hose, the 32mm-38mm reducer may be
needed. Insert the reducer inside of the filter hose and attach using hose clamp.
Apply a small amount of silicon based lubricant to the outside of the reducer to
allow an easy fit.
IMPORTANT: Never move, drag, or relocate the SolarPRO unit when it is filled with
water. Doing so can cause the legs to break. Always empty the unit of all water
prior to moving or relocating.
Leg
Foot
Figure 1

8SAVE THESE INSTRUCTIONS
3. SolarPRO – Pool Connections
NOTE: If your pool is plumbed with heavy-duty, reinforced flex hose, contact your local pool retailer or
visit www.amazon.com/GAMELLC for an available GAME adapter kit (item 4553).
A) Pools with 32mm-38mm Diameter Unthreaded Hoses
Connect the hose adapter into the SolarPRO port. Secure with the collar. Attach the filter hose and secure with a hose clamp. Repeat on
the other side of the SolarPRO, connecting the return hose to the pool. Use Teflon Tape on all threaded connections. See figure 2.
OR
B) Pools with 40mm Diameter Threaded Hoses
Connect the hose adapter into the SolarPRO port. Secure with the collar. Attach the 40mm adapter (use flat gasket as shown if needed)
to the SolarPRO port. Be sure the O-ring is in the adapter before attaching. Attach the filter hose and secure with a hose clamp. Repeat
on the other side of the SolarPRO, connecting the return hose to the pool. Use Teflon Tape on all threaded connections. See figure 3.
NOTE: If the location of the SolarPRO unit is further away from the pool than the current hose(s) length will allow, longer
hose(s) are required.
CAUTION: ENSURE ALL HOSE CONNECTIONS ARE TIGHT AND THE HOSES ARE NOT KINKED OR BENT AT SEVERE ANGLES. IF
THE HOSES ARE LEAKING, CHECK TO MAKE SURE ALL OF THE PARTS THAT HAVE ORINGS HAVE THEM ATTACHED AND ARE
SCREWED ON TIGHTLY, AND HAVE TEFLON TAPE APPLIED TO THE THE THREADS.
Reducer
(if needed)
Reducer
(if needed)
Hose ClampHose Adapter Hose AdapterHose Clamp
CollarCollar O-Ring O-Ring
Hose to
Pool
Hose from
Filter/Pump
Figure 2
Pools with 32mm-38mm Unthreaded Hoses
40mm 40mm
Hose Adapter Hose Adapter O-Ring O-Ring
Collar
Flat Gasket
2.125” (5.4 cm) dia
Flat Gasket
2.125” (5.4 cm) dia
O-Ring O-Ring
Collar
Hose to
Pool
Hose from
Filter/Pump
Figure 3
Pools with 40mm Threaded Hoses

9SAVE THESE INSTRUCTIONS
4. INITIAL OPERATION
Once the SolarPRO has been assembled and the hoses are connected to the filter pump and pool return, unblock the flow of water into
the pool return hose and turn on the pump and filter system. Bubbles will shoot out of the return nozzle into the pool initially while air
is pushed out of the SolarPRO. If this persists for longer than 2 or 3 minutes, check for and repair any leaks in the hoses
or connections.
FOR BEST RESULTS: To reduce heat loss, use a pool cover on your pool overnight, run your filter system during 12:00pm-
6:00pm and cover the pool at night.
5. MAINTENANCE
The SolarPRO should not require servicing or maintenance other than winterizing. Prior to the first frost, or at the end of your swim
season, the SolarPRO should be removed from its connections to the pool and stored in a frost free location.
Winterizing
Drain all the water from the SolarPRO by disconnecting the tubes. Store in a location protected from frost. Reconnect the pool return
hose to the pool return.
CAUTION: DO NOT ALLOW STANDING WATER INSIDE THE SOLARPRO TO FREEZE. WATER EXPANDS AS IT FREEZES AND CAN
RUPTURE THE SOLAR COILS ON THE SOLARPRO.
6. TROUBLESHOOTING
Problem Possibilities/Solutions
Does not appear to be heating the
pool.
• Check to make sure that water is flowing through the hoses. Check the flow strength at
the pool inlet.
• Has it been sunny?
• Put your pool cover on at night to prevent heat loss.
• If pool water volume is greater than 10,000 gallons, additional SolarPRO units are required.
• If using a bypass kit, check and adjust flow restrictions if necessary.
No initial bubbling after SolarPRO is
connected and pump is on.
• Check the setting of the filter to make sure it is returning water to the pool through the
pool water inlet.
• Check that water is flowing through the system.
Bubbles continue to flow out of the
pool water inlet well after the pump
has been turned on.
• Check the connections for a suction leak.
• Check to make sure the flow rate is normal.
• There could be a rupture or break in one or more of the hoses.
• There could be a blockage in one or more of the hoses. If possible, remove the blockage.
Leaking SolarPRO • Check the connector seals and replace or repair if defective.
High filter pressure • Flow through SolarPRO may be too high. A bypass kit may be needed.
• Filter may need backwashing or filter medium change.
• Pool system valves may need adjusting.
• Water return outlet may be blocked.

10SAVE THESE INSTRUCTIONS
7. LIMITED WARRANTY STATEMENT
The manufacturer warranties safe operation and reliability only under the following conditions:
• The SolarPRO is installed and operated according to the assembly and operating instructions.
• Only original replacement parts are used.
• Consumable parts do NOT fall under the warranty.
General Terms
This Limited Warranty applies to the enclosed product (the “Product”) distributed by Great American Duck Races, Inc., an Arizona corporation (doing
business as Great American Merchandise and Events) (“GAME”).
GAME warrants that the Product will be free from defects in materials and workmanship under normal use for a period of ninety (90) days from the
date of purchase. (Your dated sales or delivery receipt, showing the date of your Product purchase, is your proof of the purchase date.) During the
warranty period, GAME will repair or replace any defective parts at no charge.
All defective parts that are replaced by GAME will be replaced, at GAME’s discretion, with either new parts or used parts that meet or exceed
performance specifications for new parts. All parts removed from the Product under this warranty will become the property of GAME. Repair
or replacement of any parts will not serve to extend the ninety (90) day warranty period.
This Limited Warranty does not apply to expendable parts. This Limited Warranty does not extend to any product (a) from which the serial number has
been removed or (b) that has been damaged or rendered defective (i) as a result of accident, misuse, abuse or other external causes; (ii) by
operation outside the usage parameters stated in the Instruction Sheet that shipped with the Product; (iii) by the use of parts not manufactured
or sold by GAME; or (iv) by modification or service by anyone other than GAME or an authorized GAME distributor.
If a defect is identified within the warranty period, please contact GAME.
EXCEPT FOR THE LIMITED WARRANTY SET FORTH ABOVE, GAME EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES, WHETHER EXPRESS OR
IMPLIED, ORAL OR STATUTORY (INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE). ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THE ABOVE LIMITED WARRANTY.
Limitation of Liability
EXCEPT FOR THE LIMITED WARRANTY DESCRIBED ABOVE, IN NO EVENT WILL GAME HAVE ANY LIABILITY OF ANY KIND WHATSOEVER
(WHETHER UNDER CONTRACT, TORT, OR ANY OTHER THEORY OF LEGAL LIABILITY) TO ANY PERSON WITH RESPECT TO THE PRODUCT
(INCLUDING, WITHOUT LIMITATION, (A) ANY USE OR MISUSE OF THE PRODUCT, (B) ANY FAILURE OR MALFUNCTION OF THE PRODUCT, (C) ANY
BODILY INJURY, DEATH, LOSS OF OR DAMAGE TO ANY PROPERTY, OR ANY OTHER DAMAGES RELATED TO OR RESULTING FROM THE PRODUCT
OR ITS USE (INCLUDING, WITHOUT LIMITATION, ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, LOST PROFITS, LOSS
OF USE), EVEN IF GAME OR GAME’S AUTHORIZED REPRESENTATIVES HAVE BEEN ADVISED OF THE POSSIBILITY OF ANY SUCH DAMAGES.
TO OBTAIN WARRANTY SERVICE, PLEASE CALL, WRITE, OR EMAIL US DIRECTLY AT THE ADDRESS SHOWN BELOW.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Severability
Any provision of this Limited Warranty which is prohibited or unenforceable in any jurisdiction will, as to such jurisdiction, be ineffective to the extent
of such prohibition or unenforceability without invalidating the remaining portions hereof or affecting the validity or enforceability of such provision
in any other jurisdiction.
Venue and Choice of Law
This Limited Warranty is applicable in all countries. This Limited Warranty will be governed by the laws of the State of Arizona (regardless of any
conflict of laws rules), and any disputes arising from this Limited Warranty will be resolved in Phoenix, Arizona.
Entire Agreement
This Limited Warranty is understood to be the complete and exclusive agreement between GAME and the purchaser of the Product, superseding all
prior agreements, oral or written, and all other communications between such parties relating to the Product. No employee or representative of GAME
or any other party is authorized to make any warranty in addition to the limited warranty set forth above.
To obtain warranty service, please call, write, or email us directly at the address shown below.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
IMPORTANT
DO NOT RETURN PRODUCT TO STORE
For technical assistance and missing parts, call or email Customer Service
1.888.339.2546 (Extension 135)
[e-mail]
Monday through Thursday, 8:00 am to 5:00 pm MST
Friday, 8:00 am to 2:00 pm MST
If replacement parts are needed please visit Amazon.com/GAMELLC

11 SAVE THESE INSTRUCTIONS

Intex® is a registered trademark of Intex Recreation Corp. Bestway® is a
registered trademark.
GAME is not affiliated with, sponsored by, or otherwise associated with Intex
Recreation Corp. or t®.
Look for other GAME products at your favorite store
or visit our website, www.game-group.com.
4721_R12A_IM_EN_110420
GAME ®, LLC
16444 N. 91st Street
Scottsdale, AZ 85260-1567 U.S.A.
tel: [phone] ext: 139
email: [e-mail]
www.game-group.com/retailers
/GAME.DerbyDuck
IMPORTANT
DO NOT RETURN PRODUCT TO STORE
For technical assistance and missing parts, call or email Customer Service
1.888.339.2546 (Extension 135)
[e-mail]
Monday through Thursday, 8:00 am to 5:00 pm MST
Friday, 8:00 am to 2:00 pm MST
If replacement parts are needed please visit Amazon.com/GAMELLC
© 2020 GAME®, LLC. All rights reserved. Information subject to change.
