Garden Gear D2939 User manual

For correct usage, read these instructions carefully and keep in
a safe place for future reference
After Sales Support
Call 0871 911 7031
Email Customerser[email protected]
Product Code: D2939
Thank you for purchasing this
product, which has been made to
demanding high quality standards
and is guaranteed for domestic use
against manufacturing faults for a
period of 12 months from date
of purchase
3.6V Trimming Shears
Instruction Manual

2
INTRODUCTION
Congratulations
You have made an excellent choice with the purchase of this quality Garden
Gear product.
By doing so you now have the assurance and peace of mind which comes
from purchasing a product that has been manufactured to the highest
standards, performance and safety.
We want you to be completely satisfied with your purchase, so this Garden
Gear product is backed by our full 12 month manufacturers guarantee
and an outstanding after sales service through our dedicated Helpline.
Register your product for an extended 2-year warranty by visiting our website
www.gardengearonline.co.uk. The product must be registered, along with
your contact information, within 30 days of purchase. For full terms and
conditions please visit our website.
We hope you enjoy using your purchase for many years to come.

3
Safety information and general warnings
•Remove all packaging and make sure that the product is intact. Do
not leave packaging materials like bags and staples within the reach
of children and pets.
•This appliance is approved solely for use in accordance with the
description and safety instructions specified in this user manual.
•Read through these instructions fully before using the product.
•Wear appropriate personal protective clothing during use, including
ear defenders, safety glasses and gloves.
•Wear solid, closed in shoes with a good grip when using the trimming
shears.
•Do not use if any parts are damaged, always consult a qualified repair
person.
•Do not use in wet weather, wet areas or in areas where gases or other
flammable materials are stored.
•Not suitable for use in frozen or snowy conditions.
•Keep children and pets well away from the working area.
•Tie long hair back and remove any loose jewellery before use.
•Only use the shears in a well-lit area.
•When not in use store in a cool dry area and out of reach of children.
•Keep the shears in good clean condition.
•Do not use the shears if you are tired or under the influence of drugs or
alcohol.
•If the shears strike a foreign object, turn it off immediately and check
for damage.
•If the shears start to vibrate abnormally, turn it off immediately and
check for the cause.
•Wear gloves and use caution when cleaning or performing
maintenance on the shears.
•Do not put hands, feet or any body part or clothing near the blades
•The product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the product by a person responsible for their safety.
•Do not attempt to modify the product or use accessories. Any such
modification or misuse could result in a hazardous condition leading to
serious injury.
•If any parts are damaged or missing, do not operate until the parts are
replaced.
•Always carry the shears by the handle.

4
•Do not over reach. Always keep a firm footing and maintain balance
during operation, always distribute the weight evenly on your body
and reduce the possibility of strain.
•Do not use the tool if the switch fails to turn it on and off. Any machine
that cannot be controlled with its switch is potentially dangerous and
must be checked by a qualified electrician and repaired if necessary.
•Recharge the battery only with the charger provided. A charger that is
suitable for one type of battery may create risk of fire when used with
another battery.
•The supplied battery charger is only suitable for charging the shears,
and to prevent the risk of fire and explosion must not be used for
charging any other product.
•Before each use, check the battery charger, cable and plug for signs
of damage. If the battery charger is damaged, do not use it or try to
repair it, instead take it to your local qualified specialist.
•Make sure the power rating on the charger plug matches the outlet.
•Never modify the charger plug in any way.
•Do not use any adaptor plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce the risk of electric
shock.
•Never use the power cable for carrying, pulling or unplugging the
charger.
•Never expose the battery charger or plug to damp or wet
environments.
•When you are not using the shears charger store in a safe dry place.
•Never leave a battery unattended when charging.
•Not suitable for commercial purposes.
Safety symbols and explanations
Read the instruction manual completely before using the power
tool.
The product should not be disposed of with other household
waste. Follow the disposal instructions within this manual.
Warning! This symbol is displayed on the appliance to remind you
of the safety precautions you should take when operating the
machine.
Warning! Keep all persons, especially children and animals, at a
safe distance of at least 15 metres when operating.
The manufacturer confirms that this power tool is in accordance
with applicable European directives.

5
Do not expose to rain.
Wear protective equipment such as safety glasses and gloves.
Keep hands and feet away from all blades.
Wear solid, closed shoes with a good grip.
Sound level indicated by LwA in dB.
Beware of feet near blades.
Beware of flying objects
Remove the charger plug from the mains immediately if the
cable is damaged.
3.6 Volt Lithium-Ion battery
Only use the battery charger indoors
Beware of moving blades

6
1
5
6
2
4
3
7
Description of parts
1. Handle grip 5. Safety lock-off
2. Grass shear blades 6. On/off switch
3. Trimming blades 7. Charging inlet
4. Blade cover

7
Before first use
Carefully remove the tool from its packaging and check that the below
contents are included:
•Shear with grass blades (assembled)
•Trimming blade
•Blade guard (for both blades)
•Battery charger
The battery charger should be fully charged before using for the first time. The
charging time is about 3-5 hours.
Charging the battery
Check that your mains voltage is the same as that marked on the rating
plate of the battery charger.
1. Connect the charger to the charging socket (7) at the rear of the
handle grip (1).
2. Plug the battery charger in a power socket. The red LED will come on
to indicate that charging is underway.
3. The temperature of the battery may rise slightly during the charging
operation. This is normal.
4. As soon as battery is fully charged, the red LED will turn off.
If the LED light does not come on or the battery fails to charge, check
whether there is voltage at the socket.
Regular recharging of the battery is advised to maintain full power of the
shears. Recharging is necessary when you notice a drop in the tool’s
performance.
Never allow the battery to become fully discharged. This may cause a fault
to develop.
Instructions for use
This product is intended for light trimming of garden hedges, shrubs and lawn
edges.
1. Push the safety lock-off (5) then depress the on/off switch (6). This will
start the trimming shears.
Please note: when you release the on/off switch it will re-engage the
safety lock-off switch, this is to prevent accidental start-up.
2. Practice with the shears first on small areas until you are more
comfortable.
3. Work in straight rows, keeping the head of the trimmer at the correct
height and not pointing down to the earth.

8
Changing the blade
1. Slide the blade cover (4) away from the main housing.
2. Lift the blade out.
3. Fit the new blade by aligning the holes in the blade onto the drive pins.
4. When re-fitting the blade cover, ensure all 4 legs are inside the housing
before sliding the cover into place.
5. Slide the blade cover on towards the blade.
Care and maintenance
Before each use check the trimming shears for any obvious defects such as
loose, worn or damaged parts.
Do not use the trimming shears if there is any sign of damage.
Check the outer sections of the body for any damage and if present get a
qualified person to replace.
Carry out the following maintenance and cleaning work regularly:
•Every time you use the trimming shears clean all parts especially the
blades. Remove any moisture, debris or dust and store in a clean dry
environment.
•Do not use or submerge the trimming shears in water or use cleaning
agents or solvents, these may damage the trimming shears.
•Do not try to service the trimming shears yourself, always take it to a
qualified repair person.
•We recommend using a small amount of lubricating oil, periodically, to
keep your blades in a good condition.
To purchase lubricating oil please contact our dedicated customer service
team on 0871 911 7031 and quote the code D8211. Alternatively, you can
visit our website www.gardengearonline.co.uk
Li-Ion battery care & maintenance
Lithium-Ion rechargeable batteries require routine maintenance and care in
their use and handling. Read and follow the guidelines to safely use Lithium-
Ion batteries and achieve the maximum battery life span.
•Do not leave batteries unused for extended periods of time, either in
the machine or in storage. When a battery has been unused for 3
months or more, check the charge status and charge or dispose of the
battery as appropriate.

9
•The typical estimated life of a Lithium-Ion battery is about two years or
300 charge cycles, whichever occurs first. One charge cycle is a period
of use from fully charged, to fully discharged, and fully recharged
again.
•Rechargeable Lithium-Ion batteries have a limited life and will
gradually lose their capacity to hold a charge. This loss of capacity
(aging) is irreversible. As the battery loses capacity, the length of time it
will power the product (run time) decreases.
•Lithium-Ion batteries continue to slowly discharge (self-discharge) when
not in use or while in storage. Routinely check the battery’s charge
status.
•Carefully monitor batteries that are approaching the end of their
estimated life.
•Consider replacing the battery with a new one if you note either of the
following conditions:
The battery run time drops below about 60% of the original run
time.
The battery charge time increases significantly.
•If a battery is stored or otherwise unused for an extended period, follow
the storage instructions. If damaged, do not attempt to recharge it or
to use it. Replace it with a new battery.
Storage
•Charge or discharge the battery to approximately 50% of capacity
before storage.
•Charge the battery to approximately 50% of capacity at least once
every six months.
•Remove the battery and store it separately from the product.
•Store the battery at temperatures between 5°C and 20°C (41°F and
68°F).
Please note: Higher temperatures (above 20°C or 68°F) reduce the battery
storage life.

10
Technical specifications
Batter pack voltage
DC 3.6V
Battery pack capacity
1300m AH
Battery type
Lithium-ion
No load speed
950rpm
Grass shear blade cutting width
80mm
Trimming blade cutting length
115mm
Toothspacing
8mm
Noise power level LWA
84Db (A)
Noise power level LPA
64 dB (A)
Vibration
<2.5 M/S2
Charger (adaptor) input
AC240V 50Hz
Battery charging time
3-5 hour
•The vibration emission level has been measured in accordance with a
set of standardized criteria and can be used to compare one power
tool with another.
•The specified emission level can also be used to make an initial
assessment of the exposure to vibrations.
•The vibration emission level may vary from the level specified during
actual use, depending on the way in which the power tool is used.

11
Declaration of Conformity
In accordance with EN ISO 17050-1:2010
We Branded Garden Products Ltd
of Poplar Lane, Ipswich, Suffolk, IP8 3BU, UK
in accordance to the following Directives:
2014/35/EU Low Voltage Directive
2014/30/EU The Electromagnetic Compatibility Directive
2006/42/EC The Machinery Directive
2000/14/EC The Noise Emission in the Environment by Equipment for Use Outdoors
Directive
2015/863/EU & Amending Annex II 2011/65/EU Restriction of Hazardous Substances Directive
2012/19 Waste Electrical and Electronic Equipment Directive
94/62/EC Packaging and Waste
850/2004/EC Amended by EU No. 757/2010 & EU 756/2010 Persistent Organic Pollutants
hereby declare that:
Equipment 3.6V POWER TRIMMING SHEARS
Model number D2939 / M1E-LD-115M / SH-3.6V300
is in conformity with the applicable requirements of the following documents
Ref. No.
Trimmer - EN 55014-1:2017, EN 55014-2:2015, EN 60335-1:2012/A11:2014, EN 60745-1:2009/A11:2010, EN
60745-2-15:2009/A1:2010, EN 62233:2008, EN 50636-2-94:2014.
Adaptor –EN 55014-1: 2006/A1: 2009/+A2: 2011, EN 55014-2: 1997/+A1: 2001/+A2: 2008, EN61000-3-2:2014,
EN61000-3-3:2013, EN 60335-2-29:2004+A2:2010, EN 62233:2008, EK1 557-13:013, EN 60335-
1:2012+A11:2014, AfS GS 2014:01 PAK.
Noise measurements have been made in accordance with EN ISO11680-1 with internal control of production
(Schedule 8 / Annex V). The declared noise values are as follows:
Measured sound power level
Guaranteed sound pressure level
92.4 dB LwA
81.4 dB LpA
I hereby declare that the equipment named above has been designed to comply with the relevant sections of
the above referenced specifications and is in accordance with the requirements of the Directives.
Signed by:
Mr Dan Price
Managing Director
Branded Garden Products Ltd
December 2020
The technical documentation for the machinery is available from:
Poplar Lane, Ipswich, Suffolk, IP8 3BU, UK

12
GUARANTEE
IMPORTANT
Please do not return this product without first calling the Customer Service number
below:
0871 911 7031*
Thank you for purchasing this product, which has been made to demanding
high quality standards and is guaranteed for domestic use against
manufacturing faults for a period of 12 months from the date of purchase.
Register your product for an extended 2-year warranty by visiting our website
www.gardengearonline.co.uk. The product must be registered, along with your
contact information, within 30 days of purchase. For full terms and conditions please
visit our website.
This guarantee does not affect your statutory rights. If your product fails due to a
defect in material or workmanship during this period, please return it to the place of
purchase. Normal wear and tear is not covered under the guarantee.
Any guarantee is invalid if the product has been misused or subject to neglect or an
attempted repair other than by our own service centre.
Due to continuous product improvement, we reserve the right to change the
product specification without prior notice.
After Sales Customer Service:
Customer Service Department, Branded Garden Product Ltd, Premier House,
Hortonwood 7, Telford, TF1 7GP, UK
Telephone: [phone]*
E-mail [e-mail]
Please retain for future reference.
Colours and contents may vary.
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
Please note that all products with the symbol below must be recycled.
*Calls cost 13p per minute, plus your phone company’s access charge
