en GARDENA ZoneProtect
Translation of the original instructions.
This product may be used under supervision,
orif instruction regarding the safe use of the
product has been provided and the resulting
dangers have been understood, by persons
withphysical, sensory or mental disabilities or
alack of experience and knowledge. Children
must not play with the product.
Intended use:
The GARDENA ZoneProtect is intended for
separating a zone in which the robotic lawn-
mower (SILENO minimo, (smart) SILENO city
and (smart) SILENO life) should not mow, in
domestic gardens and allotments.
The zone must be within the working area
(delimited by the boundary wire) of the robotic
lawnmower.
9
en

It is recommended to use a third party power supply
with the following specifications:
– Frequency: 50 to 60 Hz, single-phase
– Mains voltage: 100 to 240 V AC
– Output voltage/current: 5 V DC/1 A
– Minimum output power: 5 W
– Output connector: USB-C
vBefore using the third-party USB power supply,
check that it complies with national and inter-
national safety standards for safety extra low
voltage (SELV).
DANGER! Cardiac arrest!
This product makes an electromagnetic field
while it operates. This field may under some
conditions interfere with active or passive med-
ical implants. To decrease the risk of conditions
that can possibly injure or kill, we recommend
persons with medical implants to speak with
their physician and the medical implant manu-
facturer before you operate the product.
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There is
also a risk that the polybag can suffocate tod-
dlers. Keep toddlers away when you assemble
the product.
DANGER! Risk of physical injury!
Risk of injury and risk of damage to the product.
vDo not clean the product with water or
with a water jet (in particular high-pressure
water jet).
vDo not clean with chemicals including petrol
or solvents. Some can destroy critical plas-
tic parts.
Disposal:
(in accordance with RL2012/19/EC/S.I. 2013 No. 3113)
The product must not be disposed of to nor-
mal household waste. It must be disposed
of in line with local environmental regulations.
The GARDENA ZoneProtect must not be
used in public places, parks, sport arenas, or
inagriculture or forestry.
1. SAFETY
IMPORTANT!
Read the operator’s manual carefully before
use and keep for future reference.
Battery safety
If used incorrectly or if the batteries are damaged,
flammable liquid may be ejected from the batteries.
Contact with this liquid should be avoided. If contact
accidentally occurs, rinse off with water. If the liquid
comes into contact with your eyes, seek additional
medical attention.
Only charge the battery at ambient temperatures
between +4 °C and + 30 °C. The full charging power
isavailable from 15 °C.
Only charge the product in dry indoor areas.
If the temperature of the battery is outside the per-
missible charging temperature range, the battery
cannot be charged. As soon as the permitted tem-
perature range is reached, the battery is charged.
Do not use the product and its peripherals in bad
weather conditions, especially when there is a risk
oflightning.
Do not detach the battery!
If the product has not been used for a long time,
charge it to more than 60% before use. It should
be charged to 60% at least every 3 months.
Children are not allowed to be unsupervised in the
protected area.
When the battery is empty or if the ZoneProtect has
overheated, the zone is no longer protected.
The same specifications apply to the installation
of the zone wire as for the boundary wire (see the
Operator’s Manual for the robotic lawnmower).
A USB power supply is not included with this
product.
10
en

IMPORTANT!
vDispose of the product through or via your
municipal recycling collection centre.
Disposal of the battery:
Li-ion
The battery contains lithium-ion cells
that should not be disposed of with
normal household waste at the end
of its life.
IMPORTANT!
The battery may only be removed by qualified per-
sonnel.
1. If you have any questions regarding the removal
of the battery, please contact the GARDENA
Service.
2. Dispose of the batteries through or via your
municipal recycling collection centre.
2. INSTALLATION
Preparation:
• Charge the battery (see 3. OPERATION).
• You can use the accessories of your
robotic lawn mower for the zone cable,
ground hooks and connection clamps.
Alternatively, you can also obtain these
from the GARDENA dealer.
• The robotic lawnmower must not be in
ECO Mode during installation
(see ECO Mode in the Operator’s Manual
for the robotic lawnmower).
• Update the mower‘s firmware
(via www.gardena.com):
SILENO minimo from 5995762-03
SILENO city from 5908253-11
SILENO life from 5939856-06
• To find out if an update is required, you can
check which firmware is currently installed
on your mower:
SILENO city & SILENO life:
Open the quick info menu (see the
Operator’s Manual of the robotic
lawnmower).
SILENO minimo: You will find the infor-
mation in the GARDENA Bluetooth App.
• Enable the Zone Generator function of your
robotic lawn mower menu/ app. Refer to
the Operator’s Manual of the robotic lawn-
mower.
Conditions for the installation:
• Lay the wire as described in the instructions
for the robotic lawnmower
(chapter: To examine where to put the
boundary wire ).
• The zone must be completely within the
mowing area of the boundary cable 6.
• The distance from the zone wire 2to the
boundary wire 6must be at least 60 cm.
• The zone should not cover the guide
wire7, otherwise the robotic lawnmower
may not find the charging station. If you
donot remember where the guide wire is,
start the robotic lawnmower at the end
ofthe guide cable and let it return to the
charging station (see Operator’s manual
of the robotic lawnmower).
• The distance from zone wire 2to guide
wire 7should be at least 60 cm.
• The ZoneProtect and all objects inside
must be at least 35 cm inside the zone
[Fig. I3].
• Do not lay the cable on slopes >10%.
11
en

robotic lawnmower points forward to the
stay-out zone.
4. Start the robotic lawnmower and make sure
that it stops by the zone boundary wire.
If it enters the stay-out zone, check the con-
ditions for the installation.
3. OPERATION
To charge the battery [Fig. O1/O2]:
The 5 V power supply unit with USB-A socket
is not included.
The battery is delivered partially charged.
To ensure the full performance of the battery,
fully charge the battery before the first use.
The ZoneProtect cannot be used during
charging.
1. Remove the cover 9.
2. Fold open the sealing cap 1.
3. Plug the USB-C plug of the supplied charg-
ing cable into the charging socket X.
4. Plug the USB-A plug of the charging cable
into the power supply unit.
5. Connect the power supply unit into a mains
socket.
The battery is charging and the LED -
blinks orange.
When the battery is fully charged, the LED -
illuminates orange. When the battery is
fully charged, the ZoneProtect works for
approx. 31 days.
LED indicators [Fig. O2]:
By briefly pushing the button 8the status of
ZoneProtect is displayed for 5 seconds.
• When using several ZoneProtects, the
distance from zone wire to zone wire
must be at least 60 cm.
• The zone cable must not cross [Fig. I4].
• The maximum length of the zone wire
is 15 m.
To connect the zone cable
[Fig. I1/I2]:
The zone cable 2, the ground hooks 3and
theconnection clamps 4are not included in
the scope of delivery.
1. Place the zone cable 2around the desired
zone.
2. Cut both ends of the zone cable 2to
length at the point where you want to set
up the ZoneProtect.
3. Attach one connection clamp 4to each
end of the zone cable 2.
4. Attach the connection clamps 4to the
connections 5of the ZoneProtect.
5. Secure the ZoneProtect and the zone cable
with the ground hooks 3.
6. Activate the Zone Generator option in
your robotic lawnmower (see Operator’s
manual of the robotic lawnmower).
To test the installation:
1. Set the product to ON and make sure that
the LED indicator is green.
2. Make sure that ECO mode of the robotic
lawn mower is disabled.
Refer to ECO Mode in the Operator’s
Manual for the robotic lawnmower.
3. Put the robotic lawn mower 1 – 2 m in front
of the stay-out zone. Make sure that the
12
en

illuminates green Activated and battery capacity
>30 %
blinks green Activated and battery capacity
<30 %
flashes green Activated and battery capacity
<10 %
illuminates orange Battery is fully charged
blinks orange Battery is charging
illuminates blue Zone cable is not connected or
cut and battery capacity >30%
blinks blue Zone cable is not connected or
cut and battery capacity <30%
flashes blue Zone cable is not connected or
cut and battery capacity <10%
illuminates purple Mower is in ECO Mode, boundary
cable is not detected or invalid
zone range and battery capacity
>30 %
blinks purple Mower is in ECO Mode, boundary
cable is not detected or invalid
zone range and battery capacity
<30 %
flashes purple Mower is in ECO Mode, boundary
cable is not detected or invalid
zone range and battery capacity
<10 %
illuminates red Error and battery capacity >30%
(see 6. TROUBLESHOOTING)
blinks red Error and battery capacity <30%
(see 6. TROUBLESHOOTING)
flashes red Error and battery capacity <10%
(see 6. TROUBLESHOOTING)
flashes white
5 times every
10 sec
Push the button 8so that the
status is displayed
blinks white ZoneProtect switches off
In order to achieve the maximum runtime of
the ZoneProtect, the mower must be operated
in Eco mode (see Operator’s manual of the
robotic lawnmower).
To switch on the ZoneProtect
[Fig. O2]:
vPush the button 8for 2 seconds.
The ZoneProtect is switched on and
the LED -illuminiates / blinks green
(depending on the battery capacity).
To switch off the ZoneProtect
[Fig.O2]:
vPush the button 8for 2 seconds.
The ZoneProtect is switched off and
the LED -blinks white.
4. MAINTENANCE
vClean the ZoneProtect with a damp cloth.
5. STORAGE
To put into storage:
The product must be stored away from
children.
1. Charge the battery.
2. Clean the ZoneProtect
(see 4. MAINTENANCE).
3. Store the ZoneProtect in a dry, enclosed
and frost-free place.
13
en

7. TECHNICAL DATA
ZoneProtect Unit Value
Battery operation time (approx.) d 31
Battery charging voltage V 5
Battery charging current A 1
Battery charging time h 6
IP Protection class IPx4
Operating temperature range °C 0 – 40
Operating Frequency Band Hz 100 –
80000
Max. radio-frequency power1) mW <25
1) Maximum active output power to antennas in the fre-
quency band in which the radio equipment operates.
8. ACCESSORIES
GARDENA
Boundary wire 50 m / 150 m Art 4058-60 / Art 4088-60
GARDENA
Ground hooks 100 pieces Art 4090-20
GARDENA
Connectors
+ Connection
clamps
6 connectors
+ 3 connection
clamps
Art. 4089-20
9. SERVICE
Please contact the address on the back page.
6. TROUBLESHOOTING
Problem Possible Cause Remedy
-illuminates/
blinks/flashes
blue
Zone cable is
not connected
or cut.
v Connect the
zone cable.
-illuminates/
blinks/flashes
purple and the
mower is not in
ECO mode
Boundary cable
isnot detected
orcut.
v Check the
boundary
cable.
-illuminates/
blinks/flashes
red
ZoneProtect
overtemperature.
Permanent error.
v Put the Zone-
Protect in the
shade and let
it cool down.
Contact the
GARDENA
Service.
-flashes
white 5 times
every 10 sec
Battery is empty
or there is an
error or the zone
cable is broken/
unplugged.
v Charge the
battery or
check the
zone cable.
Robotic lawn-
mower crosses
the zone cable
Software transfer
error.
v Press and hold
the button 8
for 15 seconds.
Zone Generator
function is not
enabled in the
mower menu/
app.
v Enable the
Zone Generator
function in the
mower menu/
app.
Robotic lawn-
mower stops
(Zone
Generator
Problem)
Battery is empty. v Charge the
battery.
ZoneProtect
overtemperature.
v Put the Zone-
Protect in the
shade and let it
cool down.
14
en

158
de Produkthaftung
Wir weisen ausdrücklich darauf hin, dass wir in Übereinstimmung mit dem Produkthaftungsgesetz nicht für Schäden haften, die durch unsere
Produkte entstehen, wenn diese unsachgemäß und nicht durch einen von uns autorisierten Servicepartner repariert wurden oder wenn keine
Original GARDENA Teile oder von uns zugelassene Teile verwendet wurden.
en Product liability
In accordance with the German Product Liability Act, we hereby expressly declare that we accept no liability for damage incurred from our products
where said products have not been properly repaired by a GARDENA-approved service partner orwhere original GARDENA parts or parts authorised
by GARDENA were not used.
fr Responsabilité
Conformément à la loi relative à la responsabilité du fait des produits défectueux, nous déclarons expressément par la présente que nous déclinons
toute responsabilité pour les dommages résultant de nos produits, si lesdits produits n’ont pas été correctement réparés par un partenaire d’entre-
tien agréé GARDENA ou si des pièces d’origine GARDENA ou des pièces agréées GARDENA n‘ont pas été utilisées.
nl Productaansprakelijkheid
Conform de Duitse wet inzake productaansprakelijkheid verklaren wij hierbij uitdrukkelijk dat wij geen aansprakelijkheid aanvaarden voor schade
ontstaan uit onze producten waarbij deze producten niet zijn gerepareerd door een GARDENA-erkende servicepartner of waarbij geen originele
GARDENA-onderdelen of onderdelen die door GARDENA zijn goedgekeurd zijn gebruikt.
sv Produktansvar
I enlighet med tyska produktansvarslagar förklarar vi härmed uttryckligen att vi inte åtar oss något ansvar för skador som orsakas av våra produkter
där produkterna inte har genomgått korrekt reparation från en GARDENA-godkänd servicepartner eller där originaldelar från GARDENA eller delar
godkända av GARDENA inte använts.
da Produktansvar
I overensstemmelse med den tyske produktansvarslov erklærer vi hermed udtrykkeligt, at vi ikke påtager os noget ansvar for skader på vores pro-
dukter, hvis de pågældende produkter ikke er blevet repareret korrekt af en GARDENA-godkendt servicepartner, eller hvor der ikke er brugt originale
GARDENA-reservedele eller godkendte reservedele fra GARDENA.
fi Tuotevastuu
Saksan tuotevastuulain mukaisesti emme ole vastuussa laitteiden vaurioista, jos korjauksia ei ole tehnyt GARDENAn hyväksymä huoltoliike tai jos
niiden syynä on muiden kuin alkuperäisten GARDENA-varaosien tai GARDENAn hyväksymien varaosien käyttö.
it Responsabilità del prodotto
In conformità con la Legge tedesca sulla responsabilità del prodotto, con la presente dichiariamo espressamente che decliniamo qualsiasi responsa-
bilità per danni causati dai nostri prodotti qualora non siano stati correttamente riparati presso un partner di assistenza approvato GARDENA o lad-
dove non siano stati utilizzati ricambi originali o autorizzati GARDENA.
es Responsabilidad sobre el producto
De acuerdo con la Ley de responsabilidad sobre productos alemana, por la presente declaramos expresamente que no aceptamos ningún tipo de
responsabilidad por los daños ocasionados por nuestros productos si dichos productos no han sido reparados por un socio de mantenimiento apro-
bado por GARDENA o si no se han utilizado piezas originales GARDENA o piezas autorizadas por GARDENA.
pt Responsabilidade pelo produto
De acordo com a lei alemã de responsabilidade pelo produto, declaramos que não nos responsabilizamos por danos causadospelos nossos pro-
dutos, caso os tais produtos não tenham sido devidamente reparados por um parceiro de assistência GARDENA aprovado ou se não tiverem sido
utilizadas peças GARDENA originais ou peças autorizadas pela GARDENA.
pl Odpowiedzialność za produkt
Zgodnie z niemiecką ustawą o odpowiedzialności za produkt, niniejszym wyraźnie oświadczamy, że nie ponosimy żadnej odpowiedzialności za szko-
dy poniesione na skutek użytkowania naszych produktów, w przypadku gdy naprawa tych produktów nie była odpowiednio przeprowadzana przez
zatwierdzonego przez firmę GARDENA partnera serwisowego lub nie stosowano oryginalnych części GARDENA albo części autoryzowanych przez tę
firmę.
