Garmin Cessna Caravan G1000 User manual

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
SECTION 3 – NAV/COM &
TRANSPONDER
A
G1000
TM
cockpit reference guide
for Cessna Nav III

Garmin G1000 Cockpit Reference Guide for Cessna Nav III

Garmin G1000 Cockpit Reference Guide for Cessna Nav III i
COPYRIGHT
Copyright © 2004, 2005 Garmin Ltd. or its subsidiaries. All rights reserved.
This manual reflects the operation of System Software versions 0394.00 or later for Cessna 172R aircraft, 0395.00 or later for Cessna
172S aircraft, 0371.09 or later for normally aspirated Cessna 182 aircraft, 0372.08 or later for turbocharged Cessna 182 aircraft,
0373.05 or later for normally aspirated Cessna 206 aircraft, and 0374.05 or later for turbocharged Cessna 206 aircraft. Some differ-
ences in operation may be observed when comparing the information in this manual to earlier or later software versions.
NOTE: Cessna Nav III aircraft include the Cessna 172R, the Cessna 172S, the normally aspirated Cessna 182
(182), the turbocharged Cessna 182 (T182), the normally aspirated Cessna 206 (206), and the turbocharged
Cessna 206 (T206). Unless otherwise indicated, information in the G1000 Cockpit Reference Guide pertains
to all Cessna Nav III aircraft.
Garmin International, Inc., 1200 East 151st Street, Olathe, Kansas 66062, U.S.A.
Tel: [phone] Fax: [phone]
Garmin AT, Inc., 2345 Turner Road SE, Salem, OR 97302, U.S.A.
Tel: [phone] Fax [phone]
Garmin (Europe) Ltd., Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, Hampshire S051 9DL, U.K.
Tel: [phone] Fax: [phone]
Garmin Corporation, No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
Tel: [phone] Fax: [phone]
Web Site Address: www.garmin.com
Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or
stored in any storage medium, for any purpose without the express written permission of Garmin. Garmin hereby grants permission
to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to
be viewed for personal use, provided that such electronic or printed copy of this manual or revision must contain the complete text
of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is
strictly prohibited.
Garmin® is a registered trademark of Garmin Ltd. or its subsidiaries, and G1000™ is a trademark of Garmin Ltd. or its subsidiaries.
These trademarks may not be used without the express permission of Garmin.
Honeywell® is a registered trademark of Honeywell International, Inc., Silver Crown Plus™ is a trademark of Honeywell Interna-
tional, Inc.; NavData® is a registered trademark of Jeppesen, Inc.; Stormscope® is a registered trademark of L-3 Communications;
and XM® is a registered trademark of XM Satellite Radio, Inc.
January 2005 190-00384-03 Rev. B Printed in the U.S.A.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
ii
RECORD OF REVISIONS
Part Number Change Summary
190-00384-03
(Rev A)
Added XM Radio and XM Weather
Added DME capability
Added BRG1/BRG2 pointers
Added dual audio panel operation
Added C172 parameters
Changed Airspeed Trend Vector
Changed Altitude Trend Vector
Added Checklist capability
Added Flight ID capability
Revision Date of Revision Affected Pages Description
A
B
12/15/04
01/13/05
i – 158
Back cover, i-ii
Initial release
Corrected system software versions.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III iii
TABLE OF CONTENTS
Copyright i
Record of Revisions ii
Table of Contents iii
List of Figures vi
List of Tables viii
Warranty ix
Warnings and Cautions x
Section 1: Introduction 1
1.1 Purpose and Scope .................................................... 1
1.2 PFD/MFD Controls ...................................................... 4
1.3 Secure Digital Cards ................................................. 6
1.4 System Power-up ....................................................... 7
1.5 Working with Menus ................................................. 9
1.6 System Operation .................................................... 10
Normal Mode 10
Reversionary Mode 11
1.7 AHRS Operation ....................................................... 12
GPS Input Failure 12
Air Data Input Failure 12
Magnetometer Failure 12
Section 2: Primary Flight Display 13
2.1 Introduction .............................................................. 13
2.2 PFD Description ....................................................... 13
2.3 PFD Power-on ........................................................... 13
2.4 Backlighting .............................................................. 13
2.5 PFD Softkeys ............................................................. 14
2.6 Flight Instruments ................................................... 19
Airspeed Indicator 19
Speed Indication 19
Speed Ranges 19
Airspeed Trend Vector 19
Vspeed References 19
True Airspeed Box 20
Attitude Indicator 20
Altimeter 21
Altitude Values 21
Altitude Reference Bug 21
Altitude Trend Vector 21
Altitude Reference Box 21
Barometric Setting Box 21
Vertical Deviation/Glideslope Indicator 22
Marker Beacon Annunciations 22
Vertical Speed Indicator 22
Vertical Speed Pointer 22
Horizontal Situation Indicator (HSI) 23
ARC HSI 23
Heading Indication 23
Turn Rate Indicator 24
Course Deviation Indicator 24
Bearing Pointers and Information Windows 26
DME Radio (optional) 27
DME Tuning Window (optional) 27
Navigation Source 28
True Airspeed (TAS) Box 29
Outside Air Temperature Box 29
Barometric Setting Box 29
System Time Box 29
2.7 Auxiliary Windows ................................................. 30
References Window 30
Flight ID 30
Nearest Airports Window 31
Direct-to Window 31
Direct-to Window Operations 32
Flight Plan Window 32
Flight Plan Window Operations 33
Procedures Window 33
Inset Map 34
2.8 Additional PFD Functionality ................................ 35
PFD Navigation Status Bar 35
2.9 Display Backup ......................................................... 36
Section 3: NAV/COM and Transponder 37
3.1 Windows and Fields ................................................ 38
3.2 Radio Selection ........................................................ 38
3.3 Color Code ................................................................ 39
3.4 Tuning Box ................................................................. 39
3.5 Frequency Toggle Arrow ........................................ 39
3.6 Radio Status Indications ........................................ 39
3.7 Controls ..................................................................... 40

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
iv
TABLE OF CONTENTS
3.8 COM Frequency Window ........................................ 41
Volume 41
Automatic Squelch 41
Switching the Tuning Box Between COM Radios 42
Manually Tuning a COM Frequency 42
Toggling COM Frequencies 42
Selecting a COM Radio 42
Radio Status 43
Emergency Frequency (121.500 MHz) 43
Quickly Tuning and Activating 121.500 MHz 43
Stuck Microphone 43
3.9 NAV Frequency Window ......................................... 44
Volume 44
Morse Code Identifier 44
Switching the Tuning Box Between NAV Radios 45
Manually Tuning a NAV Frequency 45
Toggling NAV Frequencies 45
Selecting a NAV Radio 46
3.10 Optional NAV Radios .............................................. 47
DME Tuning Window 47
Selecting the DME Transceiver Tuning Mode 47
3.11 Frequency Auto-tuning .......................................... 48
Auto-tuning on the PFD 48
Auto-tuning on the MFD 49
WPT – Airport Information Page 49
WPT – VOR Information Page 51
NRST – Nearest Airports Page 52
NRST – Nearest VOR Page 53
NRST – Nearest Frequencies Page 53
Auto-Tuning Upon Approach Activation
(NAV Frequencies) 54
3.12 Transponder .............................................................. 56
Transponder Softkeys 56
Transponder Status Bar 56
Mode Selection 57
Ground Mode (Automatic) 57
Standby Mode (Manual) 57
ON Mode (Manual) 57
Altitude Mode (Automatic or Manual) 57
Reply Status 58
Code Selection 58
VFR Code 58
Important Codes 58
IDENT Function 58
Mode-S Transponder Functionality 59
Traffic Information Service (TIS) 59
Section 4: Audio Panel 61
4.1 Introduction .............................................................. 61
4.2 Description ................................................................ 61
4.3 Audio Panel Controls .............................................. 61
4.4 Unit Operation ......................................................... 63
Microphones 63
Mono/Stereo Headsets 63
Unmuted/Unswitched Inputs 63
Power-up Settings 63
Fail-safe Mode 63
Selecting and Deselecting Keys 63
Lighting 63
Transceiver Keys 63
Transmitting 64
Optional COM Muting 64
PA Function 64
Cabin Speaker 64
Marker Beacon Receiver 65
Marker Beacon Signal Sensitivity 65
Navigation Radios 67
Intercom System (ICS) Isolation 67
PILOT Mode 67
COPILOT Mode 67
CREW Mode 68
ALL Mode 68
Entertainment Inputs 68
MUSIC 1 68
MUSIC 1 Muting 68
MUSIC 2 68
Volume/Squelch Control 70
Intercom VOL/SQ State 70
Intercom Volume Control 70
Intercom Squelch Threshold Control 71
Master Avionics Squelch (MASQ) 71
Digital Clearance Recorder with Playback Capability 72
Reversionary Mode 72
Interface to Cockpit Voice Recorder 72
Dual Panel Operation 73
Simultaneous COM Transmission 73

Garmin G1000 Cockpit Reference Guide for Cessna Nav III v
TABLE OF CONTENTS
Section 5: Multi Function Display 75
5.1 Introduction .............................................................. 75
5.2 MFD Description ...................................................... 75
5.3 MFD Power-on .......................................................... 75
5.4 Backlighting .............................................................. 75
5.5 MFD Softkeys ........................................................... 75
5.6 Electronic Checklists ............................................... 77
Displaying the Checklist Page .................................................. 77
Selecting a Procedure Group ................................................... 77
Selecting a Checklist within the Procedure Group 77
Selecting a Checklist Item 77
Removing the Check Mark from a Checklist Item 78
Advancing to the Next Checklist 78
One-Button Access to Emergency Procedures 78
5.7 Engine Indication System Window ...................... 79
Engine Indication System Pages 80
LEAN Page 80
SYSTEM Page 81
Engine Indication System Operation 81
5.8 Multi Function Window .......................................... 82
Multi Function Window Page Groups 82
Navigation Map Page 84
Navigation Map Page Operations 85
Traffic Map Page 88
Terrain Proximity Page 89
Terrain Proximity Page Operations 89
5.9 MFD Auxiliary Pages ............................................... 90
Flight Plan Page Group 90
Active Flight Plan Page 90
Active Flight Plan Page Operations 91
Direct-to Navigation 93
Direct-to Page 93
Direct-to Page Operations 93
5.10 Introduction to Instrument Approach
Procedures .......................................................................... 96
Arrivals and Departures 96
Approaches 97
G1000 Navigational Guidance for Approaches 97
Selecting Approaches 98
GPS Approach Examples 100
No Procedure Turn 100
Flying the Missed Approach 102
Flying the Procedure Turn 104
Flying the DME ARC 106
Flying the Holding Pattern 108
5.11 MFD Navigation Status Window ........................ 110
MFD Waypoint Status Window Operations 110
Section 6: Multi Function Display Optional
Interfaces 111
6.1 Introduction ............................................................ 111
6.2 STORMSCOPE® Interface .................................... 111
Displaying Stormscope Lightning Data on the
Navigation Map Page 111
Stormscope Lightning Data Display Range 112
Customized Display 113
Removing Stormscope Lightning Data 114
Stormscope Page 114
Stormscope Page Operations 116
6.3 Weather and Digital Audio Entertainment
Interface ........................................................................... 117
GDL 69 Weather Interface 118
Displaying Weather Data on the Navigation Map
Page 119
Navigation Map Page Weather Control Softkeys 119
Navigation Map Setup Options 120
Displaying Weather Data on the Nearest Pages 121
Displaying METAR and TAF information on the
Airport Information Page 122
Displaying Weather Data on the AUX – Trip
Planning Page Map 123
Displaying Weather Data on the Flight Plan Page
Maps 123
Displaying Weather on the Weather Data Link
Page 124
Weather Data Link Page Softkeys 125
NEXRAD Abnormalities 125
NEXRAD Limitations 125
NEXRAD Intensity 125
Weather Data Link Page Setup 130
Map Panning Information - Weather Data Link
Page 131
Weather Product Symbols 132
Weather Product Age 132

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
vi
TABLE OF CONTENTS
GDL 69A Digital Audio Entertainment Interface 133
XM Information Page 133
Data and Audio Radio ID 134
Service Class 134
Weather Products 134
XM Radio Page 135
XM Radio Interface Softkeys 135
Active Channel 135
Channels 135
Category 136
Volume 136
Presets 136
GDL 69 Troubleshooting 137
Appendix A 139
Annunciations and Alerts 139
A.1 Introduction ............................................................ 139
A.2 Alert Level Definitions ......................................... 140
A.3 Cessna Nav III Aircraft Alerts .............................. 141
Voice Alerts 141
WARNING Alerts 141
CAUTION Alerts 141
CAUTION Alerts (T182, T206, and 206 with Prop
De-Ice Only) 141
Safe Operating Annunciation (T182, T206, and 206
with Prop De-Ice Only) 141
A.4 G1000 System Annunciations ............................. 142
A.5 G1000 System Message Advisories ................... 145
MFD & PFD Message Advisories 145
Database Message Advisories 146
GMA 1347 Message Advisories 146
GIA 63 Message Advisories 147
GEA 71 Message Advisories 149
GTX 33 Message Advisories 149
GRS 77 Message Advisories 150
GMU 44 Message Advisories 150
GDL 69 Message Advisories 150
GDC 74A Message Advisories 151
Miscellaneous Message Advisories 151
Index 155

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
LIST OF FIGURES
vii
Figure 1-1 Basic G1000 System ..................................................2
Figure 1-2 G1000 Optional Interfaces ........................................3
Figure 1-3 PFD/MFD Controls .....................................................4
Figure 1-4 PFD Initialization ........................................................7
Figure 1-5 MFD Power-up Page ..................................................8
Figure 1-6 PFD Menu – No Options With NRST Window
Displayed ....................................................................9
Figure 1-7 PFD Menu – Options With FPL Window Displayed ..9
Figure 1-8 Normal Mode ...........................................................10
Figure 1-9 Reversionary Mode (Failed PFD) .............................11
Figure 2-1 PFD Setup Menu Window ......................................13
Figure 2-2a PFD Softkeys (1 of 2) ...............................................15
Figure 2-2b PFD Softkeys (2 of 2) ...............................................16
Figure 2-3 Default PFD Information ..........................................17
Figure 2-4 Additional PFD Information .....................................18
Figure 2-5 Airspeed Indicator ....................................................19
Figure 2-6 Red Pointer at Vne ...................................................19
Figure 2-7 Attitude Indicator .....................................................20
Figure 2-8 Altimeter ...................................................................21
Figure 2-9 Marker Beacon and Vertical Deviation ....................22
Figure 2-10 Vertical Speed Indicator ...........................................22
Figure 2-11 ARC HSI ....................................................................23
Figure 2-12 Current Heading .......................................................23
Figure 2-13 Selected Heading Box ..............................................23
Figure 2-14 Selected Course Box ................................................23
Figure 2-15 Turn Rate Indicator and Trend Vector ......................24
Figure 2-16 Arc CDI and Compass Rose CDI .............................24
Figure 2-17 Horizontal Situation Indicator .................................25
Figure 2-18 HSI with Bearing Information ..................................26
Figure 2-19 BRG1 Information Window .....................................26
Figure 2-20 BRG2 Information Window .....................................26
Figure 2-21 DME Information Window .......................................27
Figure 2-22 Radio Tuning Window ..............................................27
Figure 2-23 DME Selection Window ...........................................27
Figure 2-24 GPS INTEG, GPS SUSP, LOC1 and VOR2 .................28
Figure 2-25 True Airspeed Box ...................................................29
Figure 2-26 Outside Air Temperature Box ..................................29
Figure 2-27 Barometric Setting Box ............................................29
Figure 2-28 System Time Box ......................................................29
Figure 2-29 References Window .................................................30
Figure 2-30 Nearest Airports Window ........................................31
Figure 2-31 Direct-to Window .....................................................31
Figure 2-32 PFD Flight Plan Window .........................................32
Figure 2-33 Procedures Window .................................................33
Figure 2-34 Inset Map .................................................................34
Figure 2-35 PFD Navigation Status Bar .....................................35
Figure 2-36 PFD Backup Mode Display ......................................36
Figure 3-1 G1000 VHF NAV/COM Interface (PFD) ...................37
Figure 3-2 Frequency Fields .......................................................38
Figure 3-3 Frequency Toggle Arrow and Tuning Box ................39
Figure 3-4 NAV/COM Controls ..................................................40
Figure 3-5 COM Volume Level ...................................................41
Figure 3-6 Switching COM Radios ............................................42
Figure 3-7 Toggling COM Frequencies .....................................42
Figure 3-8 Selecting a COM Radio ............................................42
Figure 3-9 Radio Status Indications ..........................................43
Figure 3-10 COM Tuning Failure .................................................43
Figure 3-11 Quickly Tuning 121.500 MHz ..................................43
Figure 3-12 Stuck COM Microphone Alert .................................43
Figure 3-13 NAV Volume Level ....................................................44
Figure 3-14 ID Indication .............................................................44
Figure 3-15 Morse Code Identifier Audio ...................................44
Figure 3-16 Switching NAV Radios .............................................45
Figure 3-17 Toggling NAV Frequencies .......................................45
Figure 3-18 Selecting a NAV Radio .............................................46
Figure 3-19 DME Tuning Window ...............................................47
Figure 3-20 Loading Frequencies ................................................48
Figure 3-21 Nearest Airports Window (PFD) ..............................48
Figure 3-22 MFD Page Group Icon .............................................49
Figure 3-23 WPT – Airport Information Page (INFO) .................49
Figure 3-24 WPT – Airport Information Page (APR) ..................50
Figure 3-25 WPT – VOR Information Page .................................51
Figure 3-26 NRST – Nearest Airport Page ..................................52
Figure 3-27 NRST – Nearest VOR Page ......................................53
Figure 3-28 NRST – Nearest Frequencies Page ..........................54
Figure 3-29 Selecting an Approach .............................................54
Figure 3-30 Loading an Approach ...............................................55
Figure 3-31 Activating an Approach ...........................................55

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
LIST OF FIGURES
viii
Figure 3-32 Top-level Softkeys ....................................................56
Figure 3-33 Mode Selection Softkeys ..........................................56
Figure 3-34 Standby Mode ..........................................................56
Figure 3-35 Ground Mode ...........................................................57
Figure 3-36 Standby Mode ..........................................................57
Figure 3-37 ON Mode ..................................................................57
Figure 3-38 Altitude Mode ..........................................................57
Figure 3-39 Reply Indication .......................................................58
Figure 3-40 Entering a Code .......................................................58
Figure 3-41 IDENT Indication ......................................................59
Figure 4-1 Front Panel Controls ................................................62
Figure 4-2 Transceivers ..............................................................64
Figure 4-3 Marker Beacon .........................................................65
Figure 4-4 Marker Beacon Signal Indicator Lights on the
PFD ...........................................................................66
Figure 4-5 Navigation Radios ....................................................67
Figure 4-6 ICS Isolation .............................................................67
Figure 4-7 Volume/Squelch Control ..........................................70
Figure 4-8 Playback ...................................................................72
Figure 4-9 Reversionary Mode key ............................................72
Figure 4-10 Dual G1000 Audio Panels (GMA 1347) .................74
Figure 5-1 MFD Softkeys ...........................................................76
Figure 5-2 Checklist Page ..........................................................78
Figure 5-3 Engine Indication Window (T182 Shown) ..............79
Figure 5-4 LEAN Page (182 Shown) .........................................80
Figure 5-5 Engine System Window (206 Shown) .....................81
Figure 5-6 Page Group Icon .....................................................83
Figure 5-7 Navigation Map Page .............................................84
Figure 5-8 Traffic Map Page ......................................................88
Figure 5-9 Terrain Proximity Page ............................................89
Figure 5-10 Active Flight Plan Page ...........................................91
Figure 5-11 Direct-to Page ..........................................................93
Figure 5-12 Procedures Page .......................................................96
Figure 5-13 Selecting an Approach Procedure ...........................98
Figure 5-14 Selecting an Approach Transition ............................98
Figure 5-15 Activating an Approach Procedure .........................99
Figure 5-16 Approach with No Procedure Turn .......................101
Figure 5-17 Flying the Missed Approach ..................................103
Figure 5-18 Flying the Procedure Turn ......................................105
Figure 5-19 Flying the DME Arc ................................................107
Figure 5-20 Flying the Holding Pattern .....................................109
Figure 5-21 Waypoint Status Window .....................................110
Figure 6-1 In-Flight Navigation Map Page Displaying
Stormscope Lightning Data ...................................112
Figure 6-2 Lightning Display Range Annunciation .................113
Figure 6-3 Weather Group Options Menu ..............................113
Figure 6-4 Stormscope Page ....................................................115
Figure 6-5 Stormscope Page Options Menu ...........................116
Figure 6-6 XM Information Page .............................................117
Figure 6-7 Navigation Map Page Displaying NEXRAD
Weather ..................................................................119
Figure 6-8 Map Setup Options ................................................120
Figure 6-9 Weather Display on the Nearest NDB Page .........121
Figure 6-10 METAR and TAF Text Displayed on the Airport
(Weather) Information Page ..................................122
Figure 6-11 AUX – Trip Planning Page Map Displaying
NEXRAD Weather .................................................123
Figure 6-12 Stored Flight Plan Page Map Displaying
Weather Data ........................................................123
Figure 6-13 Weather Data Link Page ........................................124
Figure 6-14 Weather Legends Window ....................................128
Figure 6-15 Weather Data Link Page Menu .............................130
Figure 6-16 Panning on the Weather Data Link Page ..............131
Figure 6-17 Weather Product Symbols .....................................132
Figure 6-18 XM Information Page .............................................133
Figure 6-19 XM Radio Page ......................................................134
Figure 6-20 Channels Page .......................................................135
Figure 6-21 Direct Channel Selection .......................................136
Figure 6-22 Categories List .......................................................136
Figure 6-23 Volume Control ......................................................136
Figure 6-24 LRU Information Window ......................................137
Figure A-1 G1000 Alerting System ..........................................139
Figure A-2 WARNING Softkey Annunciation ..........................140
Figure A-3 CAUTION Softkey Annunciation ............................140
Figure A-4 ADVISORY Softkey Annunciation ..........................140
Figure A-5 G1000 System Failure Annunciations ...................144

Garmin G1000 Cockpit Reference Guide for Cessna Nav III ix
LIST OF TABLES
LIST OF TABLES
Table 4-1 Marker Beacon Signal Characteristics ......................66
Table 4-2 ICS Isolation Mode Transitions ..................................67
Table 4-3 ICS Isolation Modes & Telephone Distribution ........69
Table 4-4 Transitioning from Auto to Manual Squelch Mode ..70
Table 6-1 GDL 69 Advisory Messages .....................................138

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
x
WARRANTY
LIMITED WARRANTY
This Garmin product is warranted to be free from defects in materials or workmanship for two years from the date of purchase. Within this
period, Garmin will, at its sole option, repair or replace any components that fail in normal use. Such repairs or replacement will be made at no
charge to the customer for parts and labor, provided that the customer shall be responsible for any transportation cost. This warranty does not
cover failures due to abuse, misuse, accident, or unauthorized alterations or repairs.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED OR
STATUTORY, INCLUDING ANY LIABILITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
STATUTORY OR OTHERWISE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM STATE TO STATE.
IN NO EVENT SHALL GARMIN BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, WHETHER RESULTING
FROM THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT OR FROM DEFECTS IN THE PRODUCT. Some states do not allow the exclusion of
incidental or consequential damages, so the above limitations may not apply to you.
Garmin retains the exclusive right to repair or replace the unit or software, or to offer a full refund of the purchase price, at its sole discretion.
SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.
To obtain warranty service, contact your local Garmin Authorized Service Center. For assistance in locating a Service Center near you, visit the
Garmin Web site at “http://www.garmin.com” or contact Garmin Customer Service at 800-800-1020.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III xi
WARNINGS & CAUTIONS
WARNING: Navigation and terrain separation must NOT be predicated upon the use of the terrain function.
The G1000 Terrain Proximity feature is NOT intended to be used as a primary reference for terrain avoidance
and does not relieve the pilot from the responsibility of being aware of surroundings during flight. The Terrain
Proximity feature is only to be used as an aid for terrain avoidance and is not certified for use in applications
requiring a certified terrain awareness system. Terrain data is obtained from third party sources. Garmin is
not able to independently verify the accuracy of the terrain data.
WARNING: The displayed minimum safe altitudes (MSAs) are only advisory in nature and should not be relied
upon as the sole source of obstacle and terrain avoidance information. Always refer to current aeronautical
charts for appropriate minimum clearance altitudes.
WARNING: The Garmin G1000, as installed in Cessna Nav III aircraft, has a very high degree of functional integ-
rity. However, the pilot must recognize that providing monitoring and/or self-test capability for all conceivable
system failures is not practical. Although unlikely, it may be possible for erroneous operation to occur without
a fault indication shown by the G1000. It is thus the responsibility of the pilot to detect such an occurrence
by means of cross-checking with all redundant or correlated information available in the cockpit.
WARNING: For safety reasons, G1000 operational procedures must be learned on the ground.
WARNING: The altitude calculated by G1000 GPS receivers is geometric height above Mean Sea Level and could
vary significantly from the altitude displayed by pressure altimeters, such as the GDC 74A Air Data Computer,
or other altimeters in aircraft. GPS altitude should never be used for vertical navigation. Always use pressure
altitude displayed by the G1000 PFD or other pressure altimeters in aircraft.
WARNING: The Jeppesen database used in the G1000 system must be updated regularly in order to ensure
that its information remains current. Updates are released every 28 days. A database information packet is
included in the G1000 package. Pilots using an outdated database do so entirely at their own risk.
WARNING: The basemap (land and water data) must not be used for navigation, but rather only for non-navi-
gational situational awareness. Any basemap indication should be compared with other navigation sources.
CAUTION: The United States government operates the Global Positioning System and is solely responsible
for its accuracy and maintenance. The GPS system is subject to changes which could affect the accuracy and
performance of all GPS equipment. Portions of the Garmin G1000 utilize GPS as a precision electronic NAVi-
gation AID (NAVAID). Therefore, as with all NAVAIDs, information presented by the G1000 can be misused or
misinterpreted and, therefore, become unsafe.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
xii
WARNINGS & CAUTIONS
CAUTION: To reduce the risk of unsafe operation, carefully review and understand all aspects of the G1000
Pilot’s Guide documentation and the G1000 Flight Manual Supplement. Thoroughly practice basic operation
prior to actual use. During flight operations, carefully compare indications from the G1000 to all available
navigation sources, including the information from other NAVAIDs, visual sightings, charts, etc. For safety
purposes, always resolve any discrepancies before continuing navigation.
CAUTION: The Garmin G1000 does not contain any user-serviceable parts. Repairs should only be made by
an authorized Garmin service center. Unauthorized repairs or modifications could void both the warranty and
the pilot’s authority to operate this device under FAA/FCC regulations.
CAUTION: The GDU 1040 PFD and MFD displays use a lens coated with a special anti-reflective coating that is
very sensitive to skin oils, waxes, and abrasive cleaners. CLEANERS CONTAINING AMMONIA WILL HARM THE
ANTI-REFLECTIVE COATING. It is very important to clean the lens using a clean, lint-free cloth and an eyeglass
lens cleaner that is specified as safe for anti-reflective coatings.
CAUTION: All visual depictions contained within this document, including screen images of the G1000 panel
and displays, are subject to change and may not reflect the most current G1000 system. Depictions of equip-
ment may differ slightly from the actual equipment.
CAUTION: The illustrations in this guide are only examples. Never use the G1000 to attempt to penetrate
a thunderstorm. Both the FAA Advisory Circular, Subject: Thunderstorms, and the Aeronautical Information
Manual (AIM) recommend avoiding “by at least 20 miles any thunderstorm identified as severe or giving an
intense radar echo.”
CAUTION: There are several atmospheric phenomena in addition to nearby thunderstorms that can cause
isolated discharge points in the strike display mode. However, clusters of two or more discharge points in
the strike display mode do indicate thunderstorm activity if these points reappear after the screen has been
cleared. Avoid the clusters to avoid the thunderstorms. In the cell display mode, even a single discharge point
may represent thunderstorm activity and should therefore be avoided.
WARNING: This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
WARNING: Use of the Stormscope interface for hazardous weather penetration (thunderstorm penetration)
is prohibited. Weather information on the G1000 MFD is approved only for weather avoidance, not penetra-
tion.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III xiii
WARNINGS & CAUTIONS
WARNING: Traffic information shown on the G1000 Multi Function Display is provided as an aid in visually
acquiring traffic. Pilots must maneuver the aircraft based only upon ATC guidance or positive visual acquisition
of conflicting traffic.
WARNING: Use of the GDL 69 Weather Interface for hazardous weather penetration (thunderstorm penetra-
tion) is prohibited. Weather information provided by the GDL 69 is approved only for weather avoidance, not
penetration.
CAUTION: NEXRAD weather data is to be used for long-range planning purposes only. Due to inherent delays
in data transmission and the relative age of the data, NEXRAD weather data should not be used for short-range
weather avoidance.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
xiv
WARNINGS & CAUTIONS
This page intentionally left blank.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III 1
SECTION 1 – INTRODUCTION
1
SECTION 1: INTRODUCTION
This document is designed to provide an overview
of the G1000 Integrated Cockpit System as installed in
Cessna Nav III aircraft.
The G1000 system includes the following Line Re-
placeable Units (LRUs):
• GDU 1040 Primary Flight Display (PFD)
• GDU 1040 Multi Function Display (MFD)
• GIA 63 Integrated Avionics Units (2)
• GEA 71 Engine/Airframe Unit
• GDC 74A Air Data Computer (ADC)
• GRS 77 Attitude and Heading Reference System
(AHRS)
• GMU 44 Magnetometer
• GMA 1347 Audio System with integrated Marker
Beacon Receiver
• GTX 33 Mode-S Transponder
• GDL 69/69A Data Link
The LRUs are further described in the following sec-
tion. All LRUs have a modular design, which greatly eases
troubleshooting and maintenance of the G1000 system.
A top-level G1000 block diagram is given in Figure 1-1.
Additional or optional interfaces are depicted in Figure
1-2.
1.1 PURPOSE AND SCOPE
The purpose of this Cockpit Reference Guide is
to introduce the Cessna pilot to the major features
of the G1000 System. It is not intended to be a
comprehensive operating guide. Complete operating
procedures for all of the system features are found in the
documents listed below:
• G1000 Multi Function Display Pilot’s Guide
• G1000 Multi Function Display Optional Interface
Addendum
• G1000 Primary Flight Display Pilot’s Guide
• G1000 Engine Indication System Pilot’s Guide
• G1000 Audio Panel Pilot’s Guide
• G1000 VHF NAV/COM Pilot’s Guide
• G1000 Mode S Transponder Pilot’s Guide
This guide gives the pilot a basic overview of the
Primary Flight Display (PFD), Multi Function Display
(MFD), and the GMA 1347 Audio System.
NOTE: The pilot should read and thoroughly
understand the Cessna Aircraft Flight Manual for
limitations, procedures and performance infor-
mation not contained in this Cockpit Reference
Guide, The Cessna Aircraft Flight Manual always
takes precedence over the information found in
this guide.
NOTE: Throughout this document references
made to Cessna Nav III shall apply equally to
the 172, 182, T182, 206, and T206 except where
specifically noted.
NOTE: All visual depictions contained within this
Cockpit Reference Guide, including screen images
of the G1000 panel and displays, are subject to
change and may not reflect the most current
G1000 system software. Depictions of equipment
may differ slightly from the actual equipment.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
2
SECTION 1 – INTRODUCTION
Figure 1-1 Basic G1000 System
No. 1 GIA 63
Integrated Avionics Unit
System Inegration Processors
I/O Processors
VHF COM
VHF NAV/LOC
GPS
Glideslope
No. 2 GIA 63
Integrated Avionics Unit
System Integration Processors
I/O Processors
VHF COM
VHF NAV/LOC
GPS
Glideslope
GTX 33
Transponder
High-Speed Data Bus (Ethernet)
Reversionary
Control
GEA 71
Engine/Airframe
Unit
GDC 74A
Air Data
Computer
OAT
Airspeed
Altitude
Vertical Speed
GRS 77
AHRS
Attitude
Rate of Turn
Slip/Skid
GMU 44
Magnetometer
Heading
GPSOutputGPSOutput
Reversionary
Control
GMA 1347
Audio Panel
GDU 1040 (PFD) GDU 1040 (MFD)
Honeywell
KAP 140
Autopilot
(If equipped)

Garmin G1000 Cockpit Reference Guide for Cessna Nav III 3
SECTION 1 – INTRODUCTION
High-Speed Data Bus (Ethernet)
No. 2 GIA 63
Integrated Avionics Unit
System Integration Processors
I/O Processors
VHF COM
VHF NAV/LOC
GPS
Glideslope
L3
Stormscope
Lightning Strike and
Thunderstorm Detection
Honeywell
KR 87
ADF Receiver
Honeywell
KN 63
DME
GDL 69/69A
Data Link
Real-time Weather
Digital Audio Entertainment
Figure 1-2 G1000 Optional Interfaces
NOTE: For information on all optional equipment shown in Figure 1-2, please refer the Garmin G1000 MFD
Optional Interface Addendum as well as the Multi Function Display Optional Interfaces section of this document.
This document assumes that the reader is already familiar with the operation of this additional equipment.

Garmin G1000 Cockpit Reference Guide for Cessna Nav III
4
SECTION 1 – INTRODUCTION
1.2 PFD/MFD CONTROLS
Figure 1-3 PFD/MFD Controls
421 6
579
8
3
17
12
13
11
10
16
15
14
NAV Knob
NAV VOL/ID Knob
NAV Frequency Toggle Key
Heading Knob
Course/Baro Knob
COM VOL/SQ Knob
COM Frequency Toggle Key
COM Knob
Range Joystick
8
9
5
6
7
4
3
2
1
Flight Plan Key
Altitude Knob
Enter Key
Procedure Key
Direct-to Key
Clear Key
Menu Key
Flight Management System Knob
11
12
13
14
15
16
17
10
