Garmin Fishfinder 160C User manual

Fishfinder 160C®
color sonar
owner’s manual

© 2007 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151
st
Street,
Olathe, Kansas 66062, USA
Tel. [phone] or [phone]
Fax [phone]
Garmin (Europe) Ltd.
Liberty House
Hounsdown Business Park,
Southampton, Hampshire, SO40 9RB UK
Tel. [phone] (outside the UK)
0808 2380000 (within the UK)
Fax [phone]
Garmin Corporation
No. 68, Jangshu 2
nd
Road,
Shijr, Taipei County, Taiwan
Tel. [phone]
Fax [phone]
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated,
downloaded or stored in any storage medium, for any purpose without the express prior written consent of Garmin. Garmin hereby grants
permission to download a single copy of this manual onto a hard drive or other electronic storage medium to be viewed and to print one
copy of this manual or of any revision hereto, provided that such electronic or printed copy of this manual must contain the complete text
of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is strictly
prohibited.
Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and to make changes in the content
without obligation to notify any person or organization of such changes or improvements. Visit the Garmin Web site (www.garmin.com) for current updates and
supplemental information concerning the use and operation of this and other Garmin products.
Garmin
®
is a trademark of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Garmin See-Thru
®
, and Ultrascroll
tm
, AutoLocate
®
, TracBack
®
,
BlueChart
®
, and MapSource
®
are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin.
March 2007 Part Number 190-00532-00 Rev. D Printed in Taiwan

Fishnder 160C Owner’s Manual i
IntroductIon > About thIs MAnuAl
IntroductIon
Thank you for choosing the Garmin
®
Fishnder 160C. The
Fishnder 160C is a color sonar that offers many features, including
the following:
• Ultrascroll
™
, which gives you a much faster update rate on
your Sonar Pages.
• Auto Gain, which allows you to see more sh and structures.
• Whiteline, which helps you to interpret bottom hardness.
• 2x and 4x manual zoom.
• Adjustable keel offset.
• Alarms for shallow water, deep water, low battery, and
suspended target detection.
• NMEA sonar data output.
About This Manual
This manual covers the installation and operation of the Fishnder
160C. To get the most out of your new Fishnder, take time to read
this manual and learn the operating procedures for your unit in
detail.
The Introduction contains information about this manual and the
Table of Contents.
The Getting Started section contains general information about
your Fishnder and sonar.
The Installation Instructions contain the information needed to
properly install and care for the Fishnder 160C.
The Operating Instructions contain information about the
operation of the Fishnder 160C.
The Appendix contains information such as specications, license
requirements and warranty information.
The Index helps you nd information quickly.

ii Fishnder 160C Owner’s Manual
IntroductIon > tAble of contents
table of contents
Introduction...........................................................................i
About This Manual ................................................................... i
Product Registration.............................................................. iii
Contact Garmin..............................................................................iii
Caring for the Fishnder 160C.............................................. iii
Caring for the Screen.....................................................................iii
Warnings ................................................................................. iv
Important Information ............................................................ iv
Getting Started.....................................................................1
Understanding the Fishnder and Sonar.............................. 1
Understanding Sonar ...................................................................... 1
Understanding the Fishnder Screen.............................................. 1
Using Dual Beam............................................................................ 2
Whiteline ........................................................................................ 3
Thermoclines .................................................................................. 3
Installing the Fishnder 160C ............................................4
Packing List ............................................................................. 4
Unit Installation ....................................................................... 5
Transducer Installation ........................................................... 6
Selecting a Transom Mount Location............................................. 7
Mounting the Transducer on a Transom ......................................... 8
Mounting the Transducer on a Trolling Motor ............................... 9
Testing the Transom Mount Installation ....................................... 10
Installing the Wiring Harness............................................... 10
Using the Fishnder 160C ................................................12
Simulator Mode ..................................................................... 12
The Keypad ............................................................................ 12
The Fishnder 160C Display ................................................ 13
The Adjustment Bar .............................................................. 14
Range ............................................................................................ 14
Gain .............................................................................................. 14
Scroll............................................................................................. 14
Zoom............................................................................................. 15
View.............................................................................................. 15
The Setup Menu..................................................................... 15
Alarms .......................................................................................... 15
Graph ............................................................................................ 16
Numbers........................................................................................ 18
Units.............................................................................................. 20
System .......................................................................................... 20
Appendix ............................................................................22
Specications ........................................................................ 22
Physical Specications ................................................................. 22
Power ............................................................................................ 22
Sonar............................................................................................. 22
Limited Warranty ................................................................... 23
Software License Agreement ............................................... 24
Declaration of Conformity (DoC) ......................................... 24
Index ...................................................................................25

Fishnder 160C Owner’s Manual iii
IntroductIon > Product regIstrAtIon And cArIng for the fIshfInder 160c
Product Registration
Help us better support you by completing our online registration
today! Connect to our Web site at www.garmin.com/registration/.
Use this area to record the serial number (8-digit number located on
the back of the Fishnder 160C) in case your Fishnder 160C needs
service. Keep the original sales receipt, or a photocopy, in a safe
place.
Serial Number: ___ ___ ___ ___ ___ ___ ___ __
Contact Garmin
Contact Garmin if you have any questions while using your
Fishnder 160C. In the USA contact Garmin Product Support by
phone: [phone] or [phone], Monday–Friday, 8 AM–5
PM Central Time; or go to www.garmin.com/support/, and click
Product Support.
In Europe, contact Garmin (Europe) Ltd. at
+44 (0) 870.8501241 (outside the UK) or
0808 2380000 (within the UK).
Tell Us What You Think
Tell us how you like this manual! Fill out the Product
Documentation Survey. Go to www.garmin.com/contactUs/, and
click Product Documentation Survey.
Caring for the Fishnder 160C
The Fishnder 160C's case is constructed of high-quality materials
and does not require user maintenance except cleaning.
Caring for the Screen
The Fishnder 160C's lens is coated with a special anti-reective coating that
is sensitive to skin oils, waxes and abbrasive cleaners. Cleaners containing
amonia, alcohol, abrasives, or anti-grease detergents will harm the anti-
reective coating. It is important to clean the lens using an eyeglass lens
cleaner (that is specied as safe for anti-reective coatings) and a clean, lint-
free cloth.
Cleaning the Case
Clean the unit’s outer casing (except for the screen) using a cloth dampened
with a mild detergent solution, and then wipe dry. Avoid chemical cleaners and
solvents that may damage plastic components.
Water Immersion
The Fishnder 160C is waterproof to IEC Standard 60529 IPX7. It can
withstand immersion in 1 meter of water for 30 minutes. Prolonged submersion
can cause damage to the unit. After submersion, be certain to wipe and air dry
the unit before reuse.
Storage
Do not store the Fishnder 160C where prolonged exposure to temperature
extremes may occur (such as in the trunk of a car) because permanent damage
may result.

iv Fishnder 160C Owner’s Manual
IntroductIon > WArnIngs And IMPortAnt InforMAtIon
WARNING: This product, its packaging, and its components
contain chemicals known to the State of California to cause cancer,
birth defects, or reproductive harm. This Notice is being provided
in accordance with California’s Proposition 65. If you have any
questions or would like additional information, please refer to our
Web site at http://www.garmin.com/prop65.
Hg - LAMPS INSIDE THIS PRODUCT CONTAIN MERCURY
AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO
LOCAL, STATE, OR FEDERAL LAWS.
For more information go to:
www.garmin.com/aboutGarmin/environment/disposal.jsp.
Important Information
The California Electronic Waste Recycling Act of 2003 requires the recycling
of certain electronics. For more information on the applicability to this product,
see www.erecycle.org.
Warnings

Fishnder 160C Owner’s Manual 1
gettIng stArted > understAndIng the fIshfInder And sonAr
GettInG started
Understanding the Fishnder and Sonar
The Fishnder 160C is a fully automatic, color sonar unit that allows
you to go out on the water and nd sh without having to congure a
lot of settings. However, you can customize each setting as you prefer.
If you have used a Fishnder before, you might already know how
to interpret the sonar information on the screen, so you can skip this
section. If you have not used a Fishnder before, you might want to
learn a bit about sonar: what it is, how it works, and what you might
see on the Fishnder 160C screen. This manual provides a general
understanding of those things that you need to know about sonar that
can help you interpret the screen and nd the sh.
Understanding Sonar
During installation, you connect your Fishnder 160C to a
transducer. The transducer uses sound to determine information
about what is in the water beneath your boat. Then the transducer
sends the information to your Fishnder to be shown on the screen
for you to view and interpret.
The transducer sends sound waves down into the water in a cone
shape, similar to a ashlight beam (covering a smaller circular area
at the top and angling out to a larger circular area at the bottom).
These sound waves reect off of any object that they hit, and then
the waves travel back up to the transducer. These objects could
be sh, branches, the bottom, or any other object that has density
that is different from the water. The transducer receives the sound
wave information, and then sends the information to the Fishnder.
The Fishnder shows the information on the screen for you to see
and interpret. The type of transducer and settings that you choose
determine how the information appears on the screen.
Understanding the Fishnder Screen
Experimentation and experience are the keys to successfully
interpreting your Fishnder screen. We recommend that you take
your Fishnder out on familiar water, and spend time learning to
interpret what you see on the Fishnder 160C screen.
Think of the Fishnder screen as if you took a picture from the side
of an aquarium in your home. You can see how deep a sh is in
the water (how close it is to the top or bottom), but you cannot tell
where the sh is located horizontally in the water (whether it is near
the front or the back of the aquarium). Remember this when you are
trying to locate exactly where something is in the water.
The strongest sonar returns appear on your screen as the most
intense solid red. The weaker returns appear as less intense, less
solid colors,with dark blue to black being the weakest.

 Fishnder 160C Owner’s Manual
gettIng stArted > understAndIng the fIshfInder And sonAr
The bottom of the water is always going to be the strongest signal,
and therefore the bottom is the continuous, intense red line running
across the bottom of the screen. The Fishnder 160C includes the
latest technology in interpreting bottom signals; it can see through
sh, structures, and thermoclines (see page 3). Even so, large
schools of sh or dense structures close to the bottom can affect
water depth return readings.
Along the top of the screen, you might see a grouping of intense
colors. This area is surface clutter, which can be caused by waves or
any other sonar interference at the surface of the water. Too much
surface clutter can obscure your view of sh. You can turn down the
Gain setting to reduce this surface clutter.
Between the bottom and the surface clutter, you may see suspended
targets. By default, the targets appear as arches.
NOTE: Suspended target returns might not always appear
as perfect arches, due to the speed, sh orientation, or other
conditions.
You can turn on the Fish Symbols setting if you want to see
suspended targets indicated by sh shapes instead of arches.
Using Dual Beam
A dual beam transducer can transmit a narrow or a wide beam. The
water area covered by the transmitted sound waves is determined by
the transducer beam width and the water depth. The narrow beam
provides crisp detail of what is under your boat, and is very helpful
if you are shing in deeper water where the beam covers more area
(for example, at a depth of 30 feet, the narrow beam covers the area
of about a 7-foot circle).
Wide
Beam
Narrow
Beam
The wide beam is more helpful in shallow water, because it gives
you a much wider view of objects in the water, including areas
beyond the sides of your boat. At a depth of 30 feet, the wide beam
covers the area of approximately a 20-foot circle.

Fishnder 160C Owner’s Manual 
gettIng stArted > understAndIng the fIshfInder And sonAr
Whiteline
The Fishnder 160C can help you to determine if the bottom is hard
or soft. When the sonar sound waves are reected back by the bottom,
a hard bottom returns a stronger signal than a soft bottom. A thin
whiteline indicates a softer bottom while a thick whiteline indicates
a harder bottom. Normally, a red line shows the point where water
meets the bottom. This line follows the bottom contour, along with
any signicant objects lying on the bottom. The unit uses the whiteline
function to make the bottom layer information easier to distinguish.
With the Fishnder 160C, active whiteline helps accentuate where
strong signals are located, which makes bottom type determination
easier. The example below shows the bottom return with and without
the whiteline activated.
Whiteline Turned Off
Hard Bottom
Whiteline Soft Bottom
Thermoclines
Garmin’s See-Thru technology allows the Fishnder 160C to “see”
through thermoclines and helps locate sh where they live; and sh
love thermoclines!
A rough denition of a thermocline is a break in water where the
water temperature changes faster than the water above it.
Thermocline

 Fishnder 160C Owner’s Manual
InstAllIng the fIshfInder 160c > PAckIng lIst
InstallInG the fIshfInder 160c
Read these instructions before attempting installation. Make sure
you completely understand these instructions before you begin.
When in doubt, seek professional assistance.
Be sure the wiring harness reaches the unit and transducer location
before beginning installation. The Garmin Fishnder 160C hardware
allows for installation on either the transom or trolling motor. Check
the packing list below. If you are missing any items, contact your
Garmin dealer.
A–Fishnder 160C Sonar Unit (1)
B–Swivel Mount Bracket (1)
C–Swivel Base (1)
D–Mounting Knobs- Short, Long (1ea)
E–Mounting Knob Spacer (1)
F–Transducer With Power Cable (1)
G–Transducer Mount (1)
H–Trolling Motor Mount Gasket (1)
I–5 mm Flat Washers (2)
J–4 x 12 mm Screws (4)
K–10-32 Lock Nut (1)
L–5 x 30 mm Screws (2)
M–10-32 x 1.75 Screw (1)
N–1/4" Cable Clamps (2)
O–Plastic Spacer (1)
P–1/4" Rubber Washer (1)
Q–Cable Tie, 5.6" (4)
R–Cable Tie, 20" (1)
S–Power/Data Cable
(not shown)
Packing List
ENTER
MENU
A
C
D
I
J
K
L
M
G
F
(Cable not shown)
N
O
P
Q
H
B
R
E

Fishnder 160C Owner’s Manual 
InstAllIng the fIshfInder 160c > unIt InstAllAtIon
Unit Installation
Choose a location that provides optimal viewing and allows easy
access to the unit’s keypad. Select a mounting surface strong enough
to support the weight of the unit and protect it from excessive
vibration or shock. DO NOT mount the bracket in a location where
the unit is exposed to extreme temperature conditions. When
installing the mounting bracket, be sure to allow room for the
connection and routing of the power cable.
Tool List (not included)—drill, screwdriver (Phillips or standard),
three #8 pan-head machine bolts with matching nuts and washers,
and a 5/32" drill bit, OR three #8 pan head self-tapping screws, and
a 1/16" drill bit.
To mount the bracket assembly:
1. Using the swivel base as a template, mark the location of the
three mounting holes.
2. If securing the base with machine bolts, drill three 5/32" holes
at the locations you marked. If securing the base using self-
tapping screws, drill 1/16" starter holes at the locations you
marked. Generally, starter holes should be no deeper than
half the screw length.
3. Secure the swivel base with three bolts or screws. DO NOT
OVERTIGHTEN.
4. Attach the swivel bracket and secure it with the short knob.
Mounting Holes
Swivel Base
Swivel Bracket and Base
Short Knob

6 Fishnder 160C Owner’s Manual
InstAllIng the fIshfInder 160c > trAnsducer InstAllAtIon
To install the unit on the mounting bracket:
1. Align the slot on the back of the unit with the long mounting
knob and slide into place. It may be necessary to adjust the
long knob to spread the bracket arms apart. (Turn counter-
clockwise to widen the bracket arms, clockwise to tighten.)
2. Adjust the unit angle and tighten the long mounting knob until
snug.
3. Tilt the unit by loosening the long knob on the right side of the
bracket assembly.
4. Rotate the entire bracket by twisting it left or right. (NOTE:
You will hear clicks as you turn the bracket.)
5. Tighten all knobs when the viewing angle you want is
obtained.
Transducer Installation
Once you’ve installed the Fishnder 160C unit, you must install the
transducer for it to function. The included transducer can be installed
on the transom (see page 7) or on the trolling motor (see page 9).
To assemble the transducer:
1. Insert the rubber washer and plastic spacer in the transducer
at the same time. DO NOT lubricate the rubber washer.
2. Route the cable toward the back and slide the transducer into
the mounting bracket.
3. Placea5mmatwasheronthe10-32x1.75"screwand
insert the screw through the mounting bracket, spacer, and
rubber washer.
4. Placetheremaining5mmatwasherontheexposedend,
andinstallthe10-32locknutngertight.Thetransduceris
tightened further after installation on the boat.

Fishnder 160C Owner’s Manual 
InstAllIng the fIshfInder 160c > trAnsducer InstAllAtIon
Selecting a Transom Mount Location
For your sonar to operate properly, the transducer has to be located
in clean (non-turbulent) water. The transducer should be mounted as
near the center of the boat as possible.
DO NOT cut the transducer lead, this will void your warranty and
may degrade the sonar’s operation.
DO NOT mount the transducer behind strakes, rivet lines, struts,
ttings, water intake, discharge ports, eroding paint, or anything
that creates air bubbles or causes the water to become turbulent.
It is important that the transducer be as close to the center line as
possible in calm, non-turbulent water for optimal performance.
Avoid mounting the transducer in locations where the boat may be
supported during launching, hauling, trailering, or storage.
Mount the transducer away from the path of the prop on single drive
boats. On twin drive boats, mount the transducer between the drives
if possible. Do not mount the transducer directly in the path of the
prop. The transducer can cause cavitation that may degrade the
boat’s performance and damage the prop.
Make sure the transducer is below
water level when the boat is on plane
at high speed.
Apply marine sealant to all screw threads to
prevent water from seeping into the transom.
Mount the transducer parallel
with the water line.
Do not mount the transducer behind
strakes, rivet lines, struts, ttings, water
intakes or discharge ports.

 Fishnder 160C Owner’s Manual
InstAllIng the fIshfInder 160c > trAnsducer InstAllAtIon
Mounting the Transducer on a Transom
Tool List (not included)—drill, 3/8" wrench or socket, 5/32" and
1/8" drill bits, masking tape, #2 Phillips screwdriver, marine sealant.
To mount the transducer on a transom:
1. Position the transom mount at the selected location, making
sure the transducer is parallel with the water line. Mark the
center locations of each hole on the transom mount (see
gurestotheright).
2. Usingthe5/32"bit,drillthepilotholesapproximately
1" (25 mm) deep at the marked locations. To avoid drilling the
holes too deep wrap a piece of tape around the bit 1" from
the point of the bit.
3. Applymarinesealanttothe5x30mmscrews.Attachthe
transducertothetransomusingthe5x30mmscrews.Adjust
thetransducertoextendbeyondthebottomofthetransom
approximately1/8"(3mm)onberglasshullsor3/8"(10
mm) on aluminum hulls. Adjust the transducer to be aligned
parallel with the water.
4. Tightenthe10-32lockingnutuntilittouchesthemounting
bracket, and then tighten 1/4 turn more (do not overtighten).
NOTE: After you install the transducer on a transom, it is highly
recommended you test the installation (see page 10)
OK
Level
Drill pilot holes here.
Vertical
Bottom of Transom
Align with transom
bottom. Transducer
should extend 1/" below
berglass hulls or /"
below aluminum hulls.
Keep parallel with water line.

Fishnder 160C Owner’s Manual 
InstAllIng the fIshfInder 160c > trAnsducer InstAllAtIon
Mounting the Transducer on a Trolling Motor
To mount the transducer on a trolling motor:
1. Slide the large cable tie through the slot on the transducer
mount with the ridges of the band facing up until equal
lengthsextendonbothsidesofthemount.(NOTE: For cold
water, or heavy timber or debris areas, a metal 4-5" worm
gear clamp is recommended.)
2. Position the mount gasket on the curved top of the transducer
mount.
3. Place the transducer assembly against the motor body of the
trolling motor, with the front of the transducer pointed away
from the trolling motor propeller.
4. Wrap the two ends of the cable tie around the motor body.
Place the pointed end of the cable tie through the fastener
hole on the opposite end and pull it through until it is snug but
not tight. (The cable tie clicks when you pull it.)
5. Position the transducer so that it is parallel with the bottom
when in use, and make sure the gasket is aligned properly.
Pullthecabletieenduntiltight.Trimofftheexcess,if
necessary.Tightenthe10-32lockingnutuntilittouchesthe
mounting bracket and then tighten 1/4 turn more. (Do not
overtighten.)
6. Routethe30'(9m)transducercableusingthesuppliedcable
tiestosecurethecabletothemotorshaft.Youcanllthe
forward-facingportion(exceptthecabletiepocket)ofthe
transducer mount with sealant to avoid accumulating debris.
Cable tie
Mounting
gasket

10 Fishnder 160C Owner’s Manual
InstAllIng the fIshfInder 160c > WIrIng hArness InstAllAtIon
Testing the Transom Mount Installation
Perform this test after you install the Fishnder. Because you need
water to carry the sonar signal, the Fishnder does not function
properly with the transducer out of the water. When you place your
boat in the water, check for leaks around the screw holes that are
below the water line. DO NOT leave your boat in the water for an
extended period of time without checking for leaks.
To test the transom mount installation:
1. Begin testing the installation at a slow speed. If the sonar
appears to be working properly, gradually increase the boat’s
speed observing the sonar’s operation. If the sonar signal
suddenly is lost or the bottom return is severely degraded,
note the speed at which this occurs.
2. Return the boat to the speed at which the signal was lost.
Make moderate turns in both directions and see if the signal
improves.
3. If the signal strength improves while turning, adjust the
transducersothatitextendsanother1/8"belowthetransom
of the boat. It might take several adjustments to eliminate the
degradation.
4. If the signal does not improve it may be necessary to move
the transducer to a different location.
Installing the Wiring Harness
The Fishnder 160C comes with a wiring harness that connects
the unit to power and the transducer with one easy-to-remove
connection. If it is necessary to extend the power wires, use 22
AWG wire. DO NOT cut the transducer cable, because this will void
your warranty. Transducer extension cables are available from your
Garmin Dealer.
If your boat has an electrical system, it may be possible to wire the
unit directly to an unused holder on your current fuse block. If you
are using the boat’s fuse block, remove the in-line fuse supplied with
the unit. You can also wire the unit directly to the battery.
To install the wiring harness:
1. Install the Red (+) wire on the positive battery terminal.
2. Install the Black (-) wire on the negative battery terminal.
3. Install a 2 Amp fuse in the fuse holder (fuse block only).
4. Align the notches on the cable plug and back of the unit.
Insert the cable into the connector and turn the lock ring
counter-clockwise until it stops.
The Fishnder 160C outputs NMEA data for: Water Depth, Water
Speed and Water Temperature.
To connect the NMEA output to a NMEA device:
Connect the Blue wire to the Data Input of the NMEA device.

Fishnder 160C Owner’s Manual 11
InstAllIng the fIshfInder 160c > WIrIng hArness InstAllAtIon
Wiring Diagram
2A
-
+
Red +
Wiring to a Fuse Block
Black -
(red) + 10-18 VDC
(black) - Ground (Power/Data)
(blue) Port 1 Data OUT
(yellow) Alarm Low
GPS/NMEA
Device
10-18 volts
DC
Power
RXD +
TXD +
Alarm Relay
100ma max
coil current
To Transducer
To Unit

1 Fishnder 160C Owner’s Manual
oPerAtIng InstructIons > the keyPAd And sIMulAtor Mode
usInG the fIshfInder 160c
If you are turning on your Fishnder 160C for the rst time, use the
following procedure. If you have already turned on your Fishnder,
and you are just familiarizing yourself with the basic functions,
please go to “Using the Keypad” on this page.
To start your Fishnder for the rst time:
1. Press and hold the Power/BacklightkeyuntiltheFishnder
powerson.IftheFishnderfailstoturnon,verifythatthe
wiring adapter is properly connected in the back of the
Fishnder,theRedandBlackwiresareconnectedtothe
correct polarity, and that the 2-Amp fuse is installed and
notblown.IftheFishnderdoesnotdetectatransducer,it
automatically enters Simulator mode.
Simulator Mode
You can use Simulator mode to practice and learn the operation
of the Fishnder. If the Fishnder does not detect a transducer, it
automatically starts in Simulator mode.
While in Simulator mode, the Fishnder shows a bottom scene,
and you can control the Fishnder (except the Gain and Auto Gain
options). If no keys are pressed for two minutes, the Fishnder
automatically resets to default settings while in Simulator mode.
To exit Simulator mode, turn off the Fishnder.
The Keypad
ENTER
MENU
The Arrow keys
The up and down Arrow keys are used to
select items on the Adjustment Bar and Setup
menu.
The left and right Arrow keys are used
to quickly cycle through Adjustment Bar
settings .
The ENTER key
The ENTER key opens items in the
Adjustment Bar and Setup Menu.
The MENU key
The MENU key opens and closes the
Adjustment Bar.
The POWER key
The POWER key turns the unit on or off
and activates the backlight. Press and hold
to turn the unit on or off. Press briey and
release to activate the backlight. To change
the backlight level, press the POWER key
repeatedly to cycle between off, user level,
and high.

Fishnder 160C Owner’s Manual 1
oPerAtIng InstructIons > the fIshfInder 160c dIsPlAy
The Fishnder 160C Display
Water Depth
The Depth Scale is shown from top to bottom along the right
side. Messages and Alarm Icons appear along the bottom.
Water Temperature
The unit can show the water temperature at the transducer.
Speed
With a speed capable transducer, speed is shown in miles per
hour, kilometers per hour, and knots.
Distance
With a speed capable transducer, distance is shown in miles,
nautical miles, or kilometers.
Battery Voltage
You can choose to show the current battery voltage (see page 18).
Fish (Suspended Targets)
Suspended targets appear as arches or sh symbols (see page 16),
and you can set an alert for when a target is detected
Thermocline and Structure
Garmin’s See-Thru
®
technology can show more than just the
thermocline and structure, the unit nds targets in and below
the thermocline, trees, brush, and deadfall.
(Simulated display)
Bottom Shape and Type
Garmin’s Auto Gain system provides a clear
graphic representation of the bottom type and
its shape.

1 Fishnder 160C Owner’s Manual
oPerAtIng InstructIons > the AdjustMent bAr
The Adjustment Bar
The Adjustment Bar allows quick access to the settings most
commonly changed while using the unit. The Adjustment Bar
settings are: Range, Gain, Scroll, Zoom, and View.
Press the MENU key to view the current Adjustment Bar settings.
Press MENU again to hide the window. The current adjustment
option always appears in the upper left of the display. Press left or
right on the Arrow keys to scroll through the available options.
To immediately change the current adjustment option, press the up
or down Arrow key. To review the available settings before making
a change, press the ENTER key to activate the adjustment window.
To change a setting on the unit:
1. Press MENU, use the up or down Arrow key.
2. Move the selection arrow to the option you want, and press
ENTER.
3. Choose Setup for the main Setup Menu.
Range
Sets the display depth range. The unit can automatically
track the bottom, or be set to a user-specied range.
Available settings are: Auto (default) or 5-900 ft.
Gain
Controls the sensitivity of the unit’s sonar receiver. This
provides some exibility in what is seen on the display.
To see more detail, increase the receiver sensitivity by
selecting a higher gain (+). If there is too much detail
or if the screen is cluttered, lowering the sensitivity (-)
may increase the clarity of the display. Available settings are: Auto
(default) and 0-100%. The Auto setting level is controlled by the
Auto Gain setting in the Setup menu.
Scroll
Adjusts the rate that the graph scrolls from right to left.
If you are sitting still or the graph is moving too fast,
slowing or pausing the graph can be benecial.
